SIP Phone
<KX-UT136>
KX-UT113/KX-UT123
KX-UT133/KX-UT136/KX-UT248
Model No.
Thank you for purchasing this Panasonic product.
Please read this manual carefully before using this product and save this manual for future use.
KX-UT113/KX-UT123/KX-UT133/KX-UT136/KX-UT248: Software File Version 01.000 or later
In this manual, the suffix of each model number is omitted unless necessary.
Document Version: 2011-10
