  • Page 1 Dryer User manual DVE(G)52M8650* DV8650M-03170X-00_EN.indd 1 2017-01-06 4:36:49...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions Warnings Cautions Installation requirements Key installation requirements Location considerations Ducting requirements Exhausting requirements Gas requirements Electrical requirements Installation What’s included Step-by-step installation Vent blockage test Exhaust ducting guide Switching the door position...
  • Page 3 Maintenance Cleaning Troubleshooting Checkpoints Information codes Specifications Fabric care chart Protecting the environment Specification sheet Cycle chart English 3 DV8650M-03170X-00_EN.indd 3 2017-01-06 4:36:49...

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung dryer. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your dryer’s many benefits and features.

  • Page 5: Important Safety Precautions

    WARNING - Gas Appliances: • State of California Proposition 65 Warning (US only) This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. • Gas appliances can cause low-level exposure to Proposition 65 listed substances, including but not limited to, benzene, carbon monoxide, formaldehyde and soot, substances resulting from the incomplete combustion of natural gas or LP fuels.
  • Page 6 Safety information 5. Do not allow children to play on or in the appliance. Close supervision of children is necessary when the appliance is used near children. 6. Before the appliance is removed from service or discarded, remove the door to the drying compartment.

  • Page 7: Warnings

    WARNING - To reduce the risk of fire or explosion: • Do not dry items that have been previously cleaned, washed, soaked, or spotted with gasoline, dry cleaning solvents, or other flammable or explosive substances. They emit vapors that could ignite or explode. Any material that has been in contact with a cleaning solvent or flammable liquids or solids should not be placed in the dryer until all traces of these flammable liquids or solids and their fumes have been removed.

  • Page 8: Cautions

    Safety information Cautions CAUTION • Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is necessary when the appliance is used near children and pets. • Before discarding or removing your dryer from service, remove the door to the drying compartment to prevent children or animals from becoming trapped inside.
  • Page 9 • Residual oil on clothing can ignite spontaneoulsy. The potential for spontaneous combustion increases when items containing vegetable oil or cooking oil are exposed to heat. Heat sources such as your dryer can warm these items, allowing an oxidation reaction in the oil to occur. Oxidation creates heat. If this heat cannot escape, the items can become hot enough to catch fire.

  • Page 10: Installation Requirements

    Installation requirements Read through the following instructions before installing the dryer, and keep this manual for future reference. WARNING The control board and inlet valve are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel - Do not contact these parts while the appliance is energized.

  • Page 11: Ducting Requirements

    Ducting requirements Recommended Use only for short-run installation Weather hood type 4” (10.2 cm) 2.5” (6.4 cm) No. of 90° Metallic Metallic Rigid Rigid elbows flexible* flexible* 80 ft. (24.4 m) 41 ft. (12.4 m) 74 ft. (22.6 m) 33 ft. (10.1 m) 68 ft.

  • Page 12: Exhausting Requirements

    Installation requirements Exhausting requirements The dryer must not be exhausted into a • If your existing ductwork is plastic, non- chimney, a wall, a ceiling, an attic, a crawl metal, or combustible, replace it with space, or a concealed space of a building. metal.

  • Page 13: Gas Requirements

    Gas requirements WARNING • Do not reuse old flexible metal gas lines. Flexible gas lines must be • Use only natural or LP (liquid propane) design certified by the American Gas gases. Association (CGA in Canada). • THE INSTALLATION MUST CONFORM WITH LOCAL CODES, OR IN THE NOTE ABSENCE OF LOCAL CODES, WITH...

  • Page 14: Electrical Requirements

    Installation requirements Electrical requirements Grounding The wiring diagram is located on the plate under the control panel or rear frame. This dryer must be grounded. In the event of a malfunction or breakdown, the ground WARNING will reduce the risk of electrical shock by •...
  • Page 15 • If a power cord is not used and the WARNING electric dryer is to be permanently Risk of Electric Shock wired, the dryer must be connected to When local codes allow, you can connect a permanently grounded metal wiring the dryer’s electrical supply with a new system, or an equipment grounding power supply cord kit, marked for use with...

  • Page 16: Installation

    What’s included Make sure all the parts are included in the product package. If you have a problem with the dryer or the accessories, contact a local Samsung service center or the retailer. Dryer at a glance 01 Control panel...
  • Page 17 Accessories & tools (applicable models only) Accessories Y connector Water hose Short water hose (Canadian models only) Required tools Pliers Cutting knife Pipe wrench Nut screwdriver (gas models only) Level Philips screwdriver Duct tape Wrench WARNING Packing materials can be dangerous to children. Keep all packing materials (plastic bags, polystyrene, etc.) out of children’s reach.

  • Page 18: Step-By-Step Installation

    Installation Step-by-step installation Make sure you have a qualified technician install the dryer. Step by step installation instructions start below. STEP 1 Install the exhaust system 1. Select a location and move the dryer to the site. For easy access, we recommend you install the dryer in the same location as your washer.
  • Page 19 STEP 3 Connect the electrical wiring First, read through the “Electrical requirements” section, and then follow these steps. 3-wire system 1. Loosen or remove the center terminal block. 2. Connect the neutral wire (white or center wire) of the power cable to the center, silver-colored terminal screw of the terminal block.
  • Page 20 Installation 4-wire system 1. Remove the external ground connector’s screw, and connect the ground wire (green or unwrapped) of the power cable to the screw. CAUTION • To connect the ground wire to the neutral position without through contact A (cabinet ground), contact a technician.
  • Page 21 STEP 4 Connect the water hose (applicable models only) The dryer must be connected to a cold water tap using the provided water hoses. 1. Close the cold water tap. If you have a washer cold water hose attached to the cold water faucet, unscrew and remove the hose.
  • Page 22 Installation Using the short hose as an extension 1. Close the cold water tap. If you have a washer cold water hose attached to the cold water faucet, unscrew and remove the hose. Then, connect the short hose (B) to the cold water tap. Turn the coupling manually until it is tight.
  • Page 23 STEP 5 Level the dryer To ensure optimal performance, the dryer must be level. 1. Using a level (A), check if the dryer is level side to side and then front to back. If the dryer is not level, adjust the leveling feet (B) at the bottom of the dryer.

  • Page 24: Vent Blockage Test

    Installation STEP 6 Power on (Gas models) Make sure all gas connections, the exhaust line, and all wiring is connected correctly. Then, plug the power cord into a power source and check the dryer’s installation and operation using the final checklist in Step 7 below. STEP 7 Final Check When installation is complete, confirm that: •...
  • Page 25 3. The Vent Blockage Test starts immediately after pressing the START/PAUSE button. During the test, the number indicator makes a circle in 6 steps clockwise. The test takes about 2 minutes. Do not open the door during the test. 4. After 2 minutes, if the test has completed, the result is displayed and a tone is given. If status of the duct system is normal, “0”...

  • Page 26: Exhaust Ducting Guide

    Installation Exhaust ducting guide Ducting 1. Make sure the dryer is installed properly so the air exhausts freely. 2. Use 4-inch rigid metal ducts. Tape all joints including the dryer connection. Never use lint-trapping screws. 3. To facilitate the exhaust, keep the ducts as straight as possible. Cleaning Clean all old ducts before installing the dryer, and make sure the vent flap opens and closes freely.
  • Page 27 3. Remove the two screws from the lever holder, and then remove the holder cover. 4. Put the lever holder on the other side as shown, and then tighten the screws. Install the holder cover on the opposite side as shown. 5.
  • Page 28 Installation 7. Remove the glass holder, and switch the positions of: a. the hinge cover and the door handle. b. the hinge holder and the glass-guide holder 8. Remove the door lever, and then move it to the other side as shown. 9.

  • Page 29: Before You Start

    Before you start Here are a few things you should know before starting your dryer. Sort and load • Put one wash load in the dryer at a • Overloading reduces the tumbling time. action, resulting in uneven drying and •...

  • Page 30: Operations

    Operations WARNING To reduce the risk of fire, electric shock, or injury to persons, read the “Safety information“ before operating this appliance. Feature panel The dryer lets you select a cycle from the left-most panel. This cycle panel consists of 3 sections and corresponding section buttons: Cycle 1, Cycle 2, and Cycle 3.
  • Page 31 Press Dry Level to select a dry level from the options available. The corresponding indicator turns on. • Larger or bulkier loads may require Very Dry or More Dry for complete dryness. • Damp Dry is designed to partially dry items. Use for items 03 Dry Level that lay flat or hang to dry.
  • Page 32 Operations You can change the set time for the selected cycle. This is available only with TIME DRY, QUICK DRY, AIR FLUFF, and 09 Adjust Time WRINKLE AWAY. To change the cycle time, press Adjust Time or Adjust Time until the desired time is displayed. The Mixed Load Bell notifies you when the average dry level in a load is damp dry (80 % dried).

  • Page 33: Simple Steps To Start

    Simple steps to start 1. Press POWER to turn on the dryer. 2. Press to select a cycle in the left-most panel. 3. Change the cycle settings (Dry Level, Temp. and Time) as necessary. 4. Optionally, you can activate options available by pressing the relevant button (Anti Static, Eco Dry, Mixed Load Bell, and/or Wrinkle Prevent).

  • Page 34: Cycle Overview

    Operations Cycle overview Sensor Dry Cycle Description For most fabrics including cottons and linens. If NORMAL is NORMAL selected, the Eco Dry function is enabled by default. For more information, see Eco Dry in the “Feature panel“ section. For drying items made out of heavy fabrics, such as jeans, HEAVY DUTY corduroys, or work clothes, with high temperature heat.
  • Page 35 Manual Dry Cycle Description You can specify a cycle time in minutes. If TIME DRY is selected, TIME DRY the Eco Dry function is enabled by default. For more information, see Eco Dry in the “Feature panel“ section. QUICK DRY A quick drying cycle running for 30 minutes AIR FLUFF Tumbles the load in room temperature air.

  • Page 36: Drying Guide

    Operations Drying guide The best way to dry items is to follow the instructions on the care label. If no drying instructions are provided, see the following table for reference. Cycle Description Follow the care label instructions or dry using BEDDING. Bedspreads &...

  • Page 37: Special Features

    Special features Sound On/Off Child Lock To turn off the dryer’s notification beeps Child Lock prevents children from and melodies, press and hold l Mixed Load playing with the dryer. When Child Lock Bell for 3 seconds. is activated, all buttons except for the POWER button are disabled.
  • Page 38 To use Smart Care, you must have the • If you hold the smartphone at an angle Samsung Smart Care app installed on your to the dryer’s display, the smartphone smartphone. may not recognize the information NOTE code.

  • Page 39: Maintenance

    Maintenance Keep the dryer clean to prevent decreased performance and to lengthen its life. WARNING The control board and inlet valve are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel - Do not contact these parts while the dryer is energized. Cleaning Feature panel Dryer exterior...

  • Page 40: Troubleshooting

    Troubleshooting Checkpoints If the dryer operates abnormally, first check the list of problems in the table below and try the suggested actions. Problem Action • Make sure the door is latched shut. • Make sure the power cord is plugged into a live electrical outlet.
  • Page 41 Problem Action • Check the load for objects such as coins, loose buttons, nails, etc. Remove promptly. • It is normal to hear the dryer gas valve or heating element cycle on and off during the drying cycle. Is noisy. •...
  • Page 42 Extended time. reached. The drying time can change according to the type and amount of laundry. See the cycle chart for reference. If a problem persists, contact a local Samsung service center. English DV8650M-03170X-00_EN.indd 42 2017-01-06 4:37:03...

  • Page 43: Information Codes

    • If this information code remains, contact a Samsung service center. Incorrect door switch. • Contact a Samsung service center. If any information code keeps appearing on the screen, contact a Samsung service center. English 43 DV8650M-03170X-00_EN.indd 43 2017-01-06 4:37:03...

  • Page 44: Specifications

    Specifications Fabric care chart Bleach The following symbols provide garment care direction. The clothing care labels Any bleach (when needed) include symbols for drying, bleaching, Only non-chlorine (color-safe) ironing, and dry cleaning. The use of bleach (when needed) symbols ensures consistency among garment manufacturers of domestic Tumble dry and imported items.

  • Page 45: Protecting The Environment

    Iron dry or steam temperatures Dry-clean High Dry-clean Medium Do not dry-clean Line dry / Hang to dry Drip dry Warning symbols for laundering Dry flat Do not wash Do not wring Do not bleach Do not tumble dry No steam (added to iron) Do not iron Protecting the environment This appliance is manufactured from...

  • Page 46: Specification Sheet

    Specifications Specification sheet Type Front loading dryer Model DVE(G)52M8650* Product - inches (cm) 42.4 (107.7) A. Height Required for Installation - inches 44.4 Product - inches (cm) 27.0 (68.6) B. Width Required for Installation - inches 29.0 Product - inches (cm) 30.2 (76.8) C.

  • Page 47: Cycle Chart

    Cycle chart NOTE For best results, follow the load size recommendations for each dry cycle. • Large load: Fill the drum to about ¾ full. Do not add items over this level as they need to tumble freely. • Medium load : Fill the drum to about ½ full. •...
  • Page 48 Specifications NOTE • : factory setting, : can be selected Functions Temp. Control Cycle Time High Medium Extra Low NORMAL  HEAVY DUTY  PERM PRESS  BEDDING  DELICATES  REFRESH  WRINKLE AWAY   STEAM SANITIZE  ACTIVE WEAR ...
  • Page 49 If service is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized service center. SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above.
  • Page 50 God; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG that damage this product or result in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions, maintenance and environmental instructions that are covered and prescribed in the instruction book;...
  • Page 51 Ridgefield Park, NJ 07660 1-800-SAMSUNG (726-7864) www.samsung.com/us/support Visits by a Service Engineer to explain functions, maintenance or installation is not covered by warranty. Please contact your Samsung call agent for help with any of these issues. English 51 DV8650M-03170X-00_EN.indd 51 2017-01-06 4:37:13...
  • Page 52 If service is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized service center. SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above.
  • Page 53 God; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG that damage this product or result in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions, maintenance and environmental instructions that are covered and prescribed in the instruction book;...
  • Page 54 1-800-SAMSUNG (726-7864) www.samsung.com/ca/support (English) www.samsung.com/ca_fr/support (French) Visits by a Service Engineer to explain functions, maintenance or installation is not covered by warranty. Please contact your Samsung call agent for help with any of these issues. English DV8650M-03170X-00_EN.indd 54 2017-01-06 4:37:13...
  • Page 55 Memo DV8650M-03170X-00_EN.indd 55 2017-01-06 4:37:13...
  • Page 56 Scan this with your smartphone QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 1-800-SAMSUNG (726-7864) U.S.A www.samsung.com/us/support 1-844-SAM-PAYS (726-7297) www.samsung.com/ca/support (English) CANADA 1-800-SAMSUNG(726-7864) www.samsung.com/ca_fr/support (French) DC68-03170X-00 DV8650M-03170X-00_EN.indd 56 2017-01-06 4:37:14...
