AV Receiver
Owner's Manual
• This unit is a product for enjoying video and music at home.
• This manual explains preparations and operations for everyday users of the unit.
EN
• Read the supplied booklet "Quick Start Guide" before using the unit.

Advertisement

Table of Contents
loading

Related Manuals for Yamaha HTR-2071

Summary of Contents for Yamaha HTR-2071

  • Page 1 AV Receiver Owner's Manual • This unit is a product for enjoying video and music at home. • This manual explains preparations and operations for everyday users of the unit. • Read the supplied booklet “Quick Start Guide” before using the unit.

  • Page 2: Table Of Contents

    CONTENTS BEFORE USING THE UNIT 7 Configure the speaker settings............23 PLAYBACK Accessories....................4 How to use this manual................4 Basic playback procedure..............25 Remote control..................4 Enjoying playback................................. 25 Insert the batteries................................... 4 Switching information on the front display......................... 25 Operating range of the remote control...........................
  • Page 3 Video......................................62 FM radio....................................62 Error indications on the front display........... 63 Glossary....................64 Audio information................................. 64 HDMI and video information............................. 64 Yamaha technologies................................65 Information on HDMI................66 HDMI Control..................................66 Audio Return Channel (ARC)............................. 68 HDMI signal compatibility..............................68...

  • Page 4: Before Using The Unit

    BEFORE USING THE UNIT Accessories Remote control Check that the following accessories are supplied with the product. The supplied remote control is used as follows. £ FM antenna £ Remote control Insert the batteries £ Batteries (AAA, R03, UM-4) (x2) £...

  • Page 5: Features

    FEATURES What you can do with the unit The unit is equipped with full of useful functions. The ECO mode (power saving function) allows you to create an eco-friendly home theater system Supports 2- to 5.1-channel speaker system When the ECO mode is enabled, you can reduce the unit's power consumption. You can enjoy your favorite acoustic spaces in various styles.
  • Page 6 Surround playback with 5 speakers placed in front Useful applications You can enjoy the surround sound even when the surround speakers are placed in The useful application for connections and operations of the unit is as follows. front. Application for tablets “AV SETUP GUIDE” •...

  • Page 7: Part Names And Functions

    Part names and functions The part names and functions of the unit and the supplied remote control are as follows. Front panel INFO MEMORY PRESET TUNING FM MODE MUTE VOLUME SCENE RADIO PHONES INPUT TONE CONTROL PROGRAM STRAIGHT SILENT CINEMA z (power) key Front display VOLUME knob...

  • Page 8: Front Display (Indicators)

    Front display (indicators) LINK MASTER STEREO TUNED ZONE SLEEP PARTY A - DRC ENHANCER YPAO VOL. VOL. MUTE VIRTUAL SB SBR HDMI ENHANCER Lights up when HDMI signals are being input or output. Lights up when Compressed Music Enhancer (p.31) is working.

  • Page 9: Rear Panel

    Rear panel WOOFER SPEAKERS terminals ▪ The area around the video/audio output jacks is marked in white For connecting to speakers (p.15). on the actual product to prevent improper connections. VOLTAGE SELECTOR (Brazil and General models only) Selects the switch position according to your local voltage HDMI OUT jack (p.21).

  • Page 10: Remote Control

    Remote control Remote control signal transmitter MUTE key Transmits infrared signals. Mutes the audio output. z (receiver power) key OPTION key Turns on/off (standby) the unit. Displays the option menu (p.37). SLEEP DISPLAY key SLEEP key S C E N E RADIO Pressing this key repeatedly will specify the time (120 min, Turns on/off the browse screen, playback screen, etc.

  • Page 11: Preparations

    PREPARATIONS General setup procedure Placing speakers..........................(p.12) Connecting speakers........................(p.15) Connecting a TV/playback devices....................(p.17) Connecting the FM antenna......................(p.20) Connecting the power cable......................(p.21) Selecting an on-screen menu language..................(p.22) Configure the speaker settings......................(p.23) This completes all the preparations. Enjoy playing movies, music, radio and other content with the unit!

  • Page 12: Placing Speakers

    Placing speakers Select the speaker layout for the number of speakers that you are using and place the speakers and subwoofer in your room. This section describes the representative speaker layout examples. Notice ▪ Use speakers with an impedance of at least 6 W. ▪...

  • Page 13: Typical Speaker Layouts

    Typical speaker layouts 5.1-channel system 5.1-channel system (Virtual CINEMA FRONT) We recommend this speaker layout which can maximize the performance of the unit. We recommend this speaker layout when the speakers can't be placed in back of the room. 10° to 30° 10°...

  • Page 14: Other Speaker Layouts

    Other speaker layouts The following speaker layouts are also available. 3.1-channel system 2.1-channel system...

  • Page 15: Connecting Speakers

    Connecting speakers Connect the speakers placed in your room to the unit. The following diagrams provide connections for a 5.1-channel system as an example. For other systems, connect speakers while referring to the connection diagram for the 5.1-channel system. Notice ▪...

  • Page 16: Connecting Speaker Cables

    Connecting speaker cables Connecting center/surround speakers and a subwoofer Speaker cables have two wires. One is for connecting the negative (-) terminals of the Remove approximately 10 mm (3/8”) of insulation from the ends of unit and the speaker to each other, and the other is for the positive (+) terminals. If the the speaker cable, and twist the bare wires of the cable firmly wires are colored to prevent confusion, connect the black wire to the negative and the together.

  • Page 17: Connecting A Tv/Playback Devices

    Connecting a TV/playback devices The unit is equipped with a variety of input jacks AUDIO jacks Audio jacks including HDMI input jacks to allow you to connect different types of playback devices. (Stereo L/R jacks) OPTICAL jack Input/output jacks and cables Transmit analog stereo audio signals.

  • Page 18: Connecting A Tv

    Connecting a TV Connecting video devices (such as BD/DVD players) Connect the TV to the unit with an HDMI cable and a digital optical cable. Connect video devices such as BD/DVD players, set-top boxes (STBs) and game consoles to the unit. Depending on the video/audio output jacks available on your video device, choose one of the following connections.
  • Page 19 Changing the combination of video/audio input jacks Press OPTION. If the combination of video/audio input jacks available on the unit does not match your video device, change its combination according to the output jacks of your device. SLEEP S C E N E MUTE MUTE You can connect a video device that has the following video/audio output jacks.

  • Page 20: Connecting Audio Devices (Such As Cd Players)

    Connecting audio devices (such as CD players) Connecting the FM antenna Connect audio devices such as CD players and MD players to the unit. Depending on Connect the supplied FM antenna to the unit. the audio output jacks available on your audio device, choose one of the following Fix the end of the FM antenna to a wall.

  • Page 21: Connecting The Power Cable

    Connecting the power cable Warning (Brazil and General models only) Make sure you set VOLTAGE SELECTOR of the unit BEFORE plugging the power cable into an AC wall outlet. Improper setting of VOLTAGE SELECTOR may cause damage to the unit and create a potential fire hazard.

  • Page 22: Selecting An On-Screen Menu Language

    Selecting an on-screen menu language Select the desired on-screen menu language. To exit from the menu, press SETUP. Press z (receiver power) to turn on the unit. Note The information on the front display is provided in English only. Turn on the TV and switch the TV input to display video from the unit (HDMI OUT jack).

  • Page 23: Configure The Speaker Settings

    Configure the speaker settings Press RECEIVER z to turn on the unit. Configure the output characteristics of the speakers. Use the cursor keys to select “Configuration” and press ENTER. Turn on the TV and switch the TV input to display video from the unit (HDMI OUT jack).
  • Page 24 Set the distance between each speaker and listening position. Adjust the volume of each speaker. Use the cursor keys to select “Distance” and press ENTER. Use the cursor keys to select “Test Tone” and press ENTER. Use the cursor keys (q/w) to select speaker and cursor keys (e/r) to Use the cursor keys (e/r) to select “On”...

  • Page 25: Playback

    PLAYBACK Basic playback procedure Enjoying playback Switching information on the front display Turn on the external devices (such as a TV or BD/DVD player) Press INFO repeatedly to select between the various display connected to the unit. items. LINK MASTER STEREO TUNED ZONE...

  • Page 26: Selecting The Input Source And Favorite Settings With One Touch (Scene)

    Selecting the input source and favorite settings with one touch (SCENE) The SCENE function allows you to select the assigned input source, sound program, Registering a scene and Compressed Music Enhancer on/off with just one touch. Selecting a registered scene Perform the following operations to prepare the settings you want to assign to a scene.

  • Page 27: Selecting The Sound Mode

    Selecting the sound mode The unit is equipped with a variety of sound programs and surround decoders that I want to enjoy listening to compressed music. allow you to enjoy playback sources with your favorite sound mode (such as sound •...

  • Page 28: Enjoying Sound Field Effects (Cinema Dsp)

    You’ll never get tired listening The unit is equipped with a variety of sound programs that utilize Yamaha’s original for long periods.
  • Page 29 Sound programs suitable for music (MUSIC) Sound programs suitable for stereo playback (STEREO) The following sound programs are optimized for listening to music sources. You can select stereo playback. This program simulates a Munich concert hall with approximately 2,500 Use this program to mix down multichannel sources to 2 channels. When seats that uses stylish wood for the interior finishing.

  • Page 30: Enjoying Unprocessed Playback

    Enjoying unprocessed playback Playing back 2-channel sources in multichannel (surround decoder) You can play back input sources without any sound field effect processing. The surround decoder enables unprocessed multichannel playback from 2-channel sources. When a multichannel source is input, it works the same way as the straight Playing back in original channels (straight decode) decode mode.

  • Page 31: Enhancing The Bass (Extra Bass)

    Enhancing the bass (Extra Bass) Playing back digitally compressed formats (such as MP3, etc.) with enriched sound (Compressed Music Extra Bass allows you to enjoy enhanced bass sounds, regardless of the size of the Enhancer) front speakers and the presence or absence of the subwoofer. Press BASS.

  • Page 32: Listening To Fm Radio

    Listening to FM radio You can tune into a radio station by specifying its frequency or selecting from Press STRAIGHT to select “FM100”. registered radio stations. Note Press z (power) to set the unit to standby mode and turn it on ▪...

  • Page 33: Registering Favorite Radio Stations (Presets)

    Registering favorite radio stations (presets) Press TUNING repeatedly to set a frequency. You can register up to 40 radio stations as presets. Once you have registered stations, Hold down the key for about a second to search stations automatically. you can easily tune into them by selecting their preset numbers. SLEEP S C E N E RADIO...
  • Page 34 Registering a radio station manually To start the Auto Preset process, press ENTER. Select a radio station manually and register it to a preset number. “SEARCH” appears during Auto Preset Follow “Selecting a frequency for reception” (p.32) to tune into LINK MASTER STEREO TUNED...
  • Page 35 Selecting a preset station Clearing preset stations Tune into a registered radio station by selecting its preset number. Clear radio stations registered to the preset numbers. Press FM to select “TUNER” as the input source. Press FM to select “TUNER” as the input source. Press PRESET repeatedly to select the desired radio station.

  • Page 36: Radio Data System Tuning

    Radio Data System tuning Receiving traffic information automatically When “TUNER” is selected as the input source, the unit automatically receives traffic (U.K. and Europe models only) information. To enable this function, follow the procedure below to set the traffic Radio Data System is a data transmission system used by FM stations in many information station.

  • Page 37: Configuring Playback Settings For Different Playback Sources (Option Menu)

    Configuring playback settings for different playback sources (Option menu) You can configure separate playback settings for different playback sources. This Option menu items menu is available on the front panel (or on the TV screen), allowing you to easily configure settings during playback. Note ▪...
  • Page 38 Input Select (Input Select) DSP/Surround (DSP/Surround) Switches the input source. Press ENTER to switch to the selected input source. Configures the sound field program and surround settings. DSP Level (DSP Level) Tone Control (Tone Control) Adjusts the sound field effect level. Adjusts the level of high-frequency range (Treble) and low-frequency range (Bass) individually.
  • Page 39 Volume Trim (Volume Trim) Signal Info. (Signal Info.) Fine-adjusts volume difference between input sources or subwoofer volume. Displays information about the video/audio signal. Choices Input Trim (In.Trim) Format (FORMAT) Audio format of the input signal Corrects volume differences between input sources. If you are bothered by volume The number of source channels in the input signal (front/surround/LFE) differences when switching between input sources, use this function to correct it.
  • Page 40 Video Out (Video Out) Selects a video to be output with the selected audio source. For example, you can watch the video while listening to the radio. Input sources AUDIO 1-5, TUNER Settings Off(Off) Does not output video. HDMI 1-4 Outputs video input through the corresponding video input jacks.

  • Page 41: Configurations

    CONFIGURATIONS Configuring various functions (Setup Menu) You can configure the unit’s various function with the menu displayed on the TV screen. Note Operations with TV screen are available only when your TV is connected to the unit via HDMI. If not, carry out operations while viewing the front display.

  • Page 42: Setup Menu Items

    Setup menu items Menu Item Function Page Subwoofer Selects whether or not a subwoofer is connected. p.44 Front Selects the size of the front speakers. p.44 Selects whether or not a center speaker is connected and its size. p.44 Center Surround Selects whether or not surround speakers are connected and their size.
  • Page 43 Menu Item Function Page Auto Power Standby Set the amount of time for the auto-standby function. p.51 ECO Mode Enables/disables the eco mode (power saving mode). p.51 Input Rename Changes the input source name displayed on the front display. p.52 Set which input source is skipped when operating the INPUT key.

  • Page 44: Speaker

    Speaker Configures the speaker settings manually. Front Note Selects the size of the front speakers. Default settings are underlined. Settings Configuration Select this option for small speakers. Small The subwoofer will produce front channel low-frequency components Configures the output characteristics of the speakers. (configurable in “Crossover”).
  • Page 45 Surround Extra Bass Selects whether or not surround speakers are connected and their sizes. Enables/disables Extra Bass. When Extra Bass is enabled, you can enjoy enhanced bass sounds, regardless of the size of the front speakers and the Settings presence or absence of the subwoofer. Select this option for small speakers.
  • Page 46 Distance Equalizer Sets the distance between each speaker and listening position so that sounds from the Adjusts the tone with an equalizer. speakers reach the listening position at the same time. First, select the unit of distance EQ Select from “Meter” or “Feet”. Choices Selects the type of equalizer to be used.

  • Page 47: Hdmi

    HDMI Configures the HDMI settings. 4K Upscaling Note Enables/disables the upscaling function. When it is enabled, 1080p content is Default settings are underlined. displayed at 4K resolution. Settings HDMI Control Disables the upscaling function. Enables/disables HDMI Control (p.66). Enables the upscaling function. Settings TV Audio Input Disables HDMI Control.
  • Page 48 Standby Sync SCENE Select whether to use HDMI control to link the unit's standby mode to the TV's power Enables/disable SCENE link playback when “HDMI Control” is set to “On”. when “HDMI Control” is set to “On”. When SCENE link playback is enabled, HDMI Control-compatible devices connected to the unit via HDMI automatically works as follows, with a scene selection.

  • Page 49: Sound

    Sound Configures the audio output settings. Lipsync Note Adjusts the delay between video and audio output. Default settings are underlined. Note You can enable/disable the Lipsync function by input sources in “Lipsync (Lipsync)” (p.39) in the “Option” DSP Parameter menu. Configures the surround decoder settings.
  • Page 50 Dialogue Max Volume Adjusts the volume of dialogue sounds. Sets the limit value of the volume. Setting range Dialogue Level -30.0 dB to +15.0 dB (5.0 dB increments), +16.5 dB [50.0 to 95.0 (5.0 increments), 97.0] Adjusts the volume of the center orientation sounds such as dialogue. Setting range Initial Volume 0 to 3 (higher to strengthen)

  • Page 51: Eco

    Configures the power supply settings. Note Default settings are underlined. Auto Power Standby Set the amount of time for the auto-standby function. Settings Does not set the unit to standby mode automatically. Sets the unit to standby mode when you have not operated the unit and 20 minutes the unit has not detected any input signal for the specified time.

  • Page 52: Function

    Function Configures the functions that make the unit easier to use. Procedure to rename manually Note Default settings are underlined. Use the cursor keys (q/w) to select an input source to be renamed. Input Rename Use the cursor keys (e/r) to select “Manual” and press Changes the input source name displayed on the front display.
  • Page 53 Input Skip Remote Color Key Set which input source is skipped when operating the INPUT key. Set the unit's functions for the RED/GREEN/YELLOW/BLUE key of the remote control. You can select the desired input source quickly by using this function. Settings Input sources Assigns the functions of playback devices connected to the unit with an...

  • Page 54: Language

    Language Select an on-screen menu language. Note Default settings are underlined. Settings English English Japanese 日本語 Français French Deutsch German Español Spanish Russian Русский Italiano Italian Chinese 中文 Note The information on the front display is provided in English only.

  • Page 55: Configuring The System Settings (Advanced Setup Menu)

    Change the unit’s remote control ID so that it matches the remote control’s ID (default: again. ID1). When using multiple Yamaha AV receivers, you can set each remote control with a unique remote control ID for its corresponding receiver. The new settings take effect.

  • Page 56: Changing The Fm Tuning Frequency Setting (Tu)

    Changing the FM tuning frequency setting (TU) Selecting the HDMI 4K signal format (4K MODE) (Asia and General models only) LINK MASTER STEREO TUNED ZONE SLEEP PARTY ENHANCER YPAO VOL. A- DRC VOL. MUTE VIRTUAL 4K MODE•MODE 1 LINK MASTER STEREO TUNED ZONE...

  • Page 57: Restoring The Default Settings (Init)

    Restoring the default settings (INIT) LINK MASTER STEREO TUNED ZONE SLEEP PARTY ENHANCER YPAO VOL. A- DRC VOL. MUTE VIRTUAL INIT••••CANCEL SB SBR Restores the default settings for the unit. Choices Restores the default settings for the unit. CANCEL Does not perform an initialization. Checking the firmware version (VERSION) LINK MASTER...

  • Page 58: Appendix

    When using multiple Yamaha products, the remote control may work on another If you have changed speakers or have a new speaker system, reconfigure the speaker Yamaha product or another remote control may work on the unit. If this happens, settings in “Speaker” in the “Setup” menu.

  • Page 59: Troubleshooting

    The power does not turn on. consecutively. nearest Yamaha dealer or service center to request repair. The internal microcomputer has frozen, due to an external electric Hold down z (power) on the front panel for more than 15 seconds to reboot the The power does not turn off.

  • Page 60: Audio

    Problem Cause Remedy The unit is out of the operating range. Use the remote control within the operating range (p.4). The batteries are weak. Replace with new batteries. The unit cannot be controlled using the remote The unit’s remote control sensor is exposed to direct sunlight or Adjust the lighting angle, or reposition the unit.
  • Page 61 Problem Cause Remedy The playback source does not contain Low Frequency Effect (LFE) To check it, set “Extra Bass” in the “Setup” menu to “On”, in order to output the or low-frequency signals. front channel low-frequency components from the subwoofer (p.45). Subwoofer output is disabled.

  • Page 62: Video

    Video Problem Cause Remedy Another input source is selected on the unit. Select an appropriate input source with the input selection keys. Another input source is selected on the TV. Switch the TV input to display the video from the unit. Check the video output setting of the playback device.

  • Page 63: Error Indications On The Front Display

    Check SP Wires Internal Error An internal error has occurred. Contact the nearest authorized Yamaha dealer or service center. The remote control IDs of the unit and the remote control are not RemID Mismatch Change the remote control ID of the unit or the remote control (p.55).

  • Page 64: Glossary

    Glossary This is a glossary of the technical terms used in this manual. HDMI and video information Audio information Deep Color Deep Color is a technology that HDMI specification supports. Deep Color increases the number of available colors within the boundaries defined by the RGB or YCbCr color space. Conventional Audio decoding format color systems process the color using 8 bits.

  • Page 65: Yamaha Technologies

    SILENT CINEMA Yamaha has developed a natural, realistic sound effect DSP algorithm for headphones. Parameters for headphones have been set for each sound program, so that accurate representations of all the sound programs can be enjoyed on headphones.

  • Page 66: Information On Hdmi

    Information on HDMI The additional information on HDMI is as follows. (Example) HDMI Control HDMI Control HDMI Control HDMI Control allows you to operate external devices via HDMI. If you connect a TV that supports HDMI Control to the unit with an HDMI cable, you can control the unit Playback starts Turns on and displays (such as power and volume) with TV remote control operations.
  • Page 67 Use the cursor keys to select “HDMI” and press ENTER. Check that the unit is properly synchronized with the TV by turning off the TV or adjusting the TV volume with the TV remote control. Note ▪ If HDMI Control does not work properly, the problem may be solved by turning the playback device off and on again, or by unplugging the power plug and plugging it in again.

  • Page 68: Audio Return Channel (Arc)

    Audio Return Channel (ARC) HDMI signal compatibility ARC allows you to input TV audio to the unit with the HDMI cable which transmits video • When CPPM copy-protected DVD-Audio is played back, video/audio signals may signal to the TV. not be output, depending on the type of the DVD player. Check the following after the HDMI Control settings.

  • Page 69: Trademarks

    HDMI Licensing LLC in the United States and other countries. x.v.Color™ “x.v.Color” is a trademark of Sony Corporation. App Store is a service mark of Apple Inc. Android™ is a trademark of Google Inc. “SILENT CINEMA” is a trademark of Yamaha Corporation.

  • Page 70: Specifications

    Specifications The specifications of this unit are as follows. HDMI Input jacks HDMI Features: • 4K UltraHD Video (include 4K/60, 50Hz 10/12bit), 3D Video, ARC (Audio Return Channel), HDMI Analog Audio Control (CEC), Auto Lip Sync, Deep Color, “x.v.Color”, 21:9 Aspect Ratio, BT.2020 Colorimetry, HDR Compatible •...
  • Page 71 Compatible Decoding Formats Dynamic Power (IHF) • [Canada model] Decoding Format – Front L/R (8/6/4/2 Ω) 110/130/160/180 W • Dolby Digital Plus • [Other models] • Dolby Digital • DTS – Front L/R (6/4/2 Ω) 110/130/150 W Post Decoding Format Damping Factor •...
  • Page 72 * The contents of this manual apply to the latest specifications as of the publishing date. To obtain Tuning Range the latest manual, access the Yamaha website then download the manual file. • [Canada model] 87.5 MHz to 107.9 MHz •...
  • Page 73 Yamaha Global Site http://www.yamaha.com/ Yamaha Downloads http://download.yamaha.com/ Manual Development Group © 2017 Yamaha Corporation Published 01/2017 NV-A0 YJ184A0/EN...
