- Page 1 Double oven MB557G5.0B User manual and installation instructions Register your product on My Siemens and discover exclusive services and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
en Safety 1.2 Intended use Table of contents This appliance is designed only to be built into kitchen units. Read the special installation instructions. USER MANUAL Only a licensed professional may connect ap- Safety .............. 2 pliances without plugs. Damage caused by in- correct connection is not covered under the Preventing material damage ....... -
Page 3: Safety
Safety en ▶ Keep your hands away from the hinges. Opening the appliance door creates a Components inside the appliance door may draught. Greaseproof paper may come into have sharp edges. contact with the heating element and catch ▶ Wear protective gloves. fire. -
Page 4: Preventing Material Damage
en Preventing material damage ▶ Do not let children play with packaging ma- ▶ Also unplug the appliance from the mains terial. or switch off the circuit breaker in the fuse box. Children may breathe in or swallow small parts, causing them to suffocate. 1.6 Meat probe ▶... -
Page 5: Environmental Protection And Saving En- Ergy
Environmental protection and saving energy en 3 Environmental protection and saving energy Help protect the environment by using your appliance in a way that conserves resources and by disposing of reusable materials properly. 3.1 Disposing of packaging The packaging materials are environmentally compat- ible and can be recycled. - Page 6 en Familiarising yourself with your appliance 4 Familiarising yourself with your appliance 4.1 Controls You can use the control panel to configure all functions of your appliance and to obtain information about the operat- ing status. Note: On certain models, specific details such as col- our and shape may differ from those pictured.
-
Page 7: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en Temperature selector Use the temperature selector to set the temper- ature for the type of heating and select settings for other functions. You can only turn the temperature selector clockwise from the zero setting until it offers resistance. - Page 8 en Familiarising yourself with your appliance Symbol Type of heating What it's used for/how it works Top/bottom heating Traditionally bake or roast on one level. This type of heating is ideal for cakes with moist toppings. The heat is emitted evenly from above and below. This type of heating is used to measure the energy consumption in the conven- tional mode.
- Page 9 Familiarising yourself with your appliance en Symbol Function 1, 2, 3 Grill settings Set the grill settings for Full-surface grill and Grill, small area (depending on the appliance model). I, II, III 1 = low 2 = medium 3 = high Programme Set the programme function.
-
Page 10: Meat Thermometer
en Accessories Ensure that the ventilation slots are unobstructed. The Oven light setting on the function selector can be ▶ used to switch on the light without heating. To ensure that the appliance cools down more quickly after operation, the cooling fan continues to run for a Cooling fan certain period afterwards. - Page 11 Note: Take any accessories that you will not be using your appliance in our brochures and online: out of the cooking compartment while the appliance is www.siemens-home.bsh-group.com in operation. Accessories vary from one appliance to another. When purchasing accessories, always quote the exact Combining accessories product number (E no.) of your appliance.
- Page 12 en Basic operation 7 Basic operation When your food is ready, switch off the appliance. 7.1 Switching on the appliance Tips Turn the function selector to any position other than ▶ ¡ The most suitable type of heating for your food can the "Off"...
- Page 13 Time-setting options en The timer duration can be set in 30-second incre- Reset the cooking time to zero using the button. ▶ ments up to 10 minutes. Above 10 minutes, the a After a few seconds, the appliance applies the time increments become longer the higher the change and continues to heat without a cooking value.
- Page 14 en Meat thermometer Tip: You can go to the basic settings → Page 17 to 9.5 Setting the time on the clock specify whether or not the time should be shown on Once the appliance has been connected to the mains the display. or following a power failure, the time flashes on the dis- play.
- Page 15 Programme en WARNING ‒ Risk of burns! The cooking compartment, accessories and meat probe become very hot. Always use oven gloves to remove hot accessor- ▶ ies and the meat probe from the cooking com- partment. When the core temperature is reached: Switch off the appliance. ‒...
- Page 16 en Programme No. Food Cookware Weight setting Add liquid Shelf Information posi- tions Roasting dish with Weight of meat Almost cover Do not sear the meat 06 Pot-roasted beef E.g. prime rib, the meat with beforehand shoulder, rump or mar- liquid inated beef roast Roasting dish with Total weight of all...
-
Page 17: Childproof Lock
Childproof lock en 12 Childproof lock Secure your appliance to prevent children from acci- 12.1 Activating and deactivating the dentally switching on the main oven or changing the childproof lock settings. Requirement: The function selector must be set to the Notes "Off" position . ¡... - Page 18 en Cleaning and servicing 14 Cleaning and servicing Do not use harsh or abrasive cleaning products. To keep your appliance working efficiently for a long ▶ Do not use cleaning products with a high alcohol time, it is important to clean and maintain it carefully. ▶...
-
Page 19: Cleaning And Servicing
Cleaning and servicing en Cooking compartment Area Suitable cleaning agents Notes Enamel surfaces ¡ Hot soapy water Soak any heavily soiled areas and use a brush or steel wool. Leave the appliance door open to dry the cooking compartment ¡ Vinegar water after cleaning it. -
Page 20: Cleaning Function
en Cleaning function If dark stains are visible on the self-cleaning sur- Use the cleaning function. ▶ ▶ faces, use the cleaning function to clean the cook- → "Cleaning function ", Page 20 ing compartment. If a prompt to clean appears in the display, use the ▶... -
Page 21: Cleaning Assistance Humidclean
cleaning assistance humidClean en Requirement: Prepare the appliance for the cleaning Requirement: Prepare the appliance for the cleaning function. → Page 20 function. → Page 20 Use the function selector to set Cleaning Use the function selector to set Cleaning function . function . Use the temperature selector to set the cleaning a The display shows the duration. - Page 22 en Shelf supports 17 Shelf supports To clean the rails and the cooking compartment, or to ATTENTION! replace the rails, you can remove these. The self-cleaning surfaces in the cooking compartment may be damaged by detaching and attaching the pull- 17.1 Detach the rails in the main cooking out rails.
-
Page 23: Shelf Supports
Shelf supports en Remove the pull-out rail. Keep the PUSH tab pushed in and swing the pull- out rail inwards until the front retainer is located between the two bars . Release the PUSH tab. ‒ Clean the pull-out rail. → "Cleaning products", Page 18 17.4 Attaching the pull-out rail a The retainer... -
Page 24: Appliance Door
en Appliance door ¡ For both shelf supports, ensure that the hooks that Push the rail into the front socket until the rail are attached at the rear are pointing upwards. also rests against the cooking compartment wall, and then press this downwards ... - Page 25 Appliance door en Close the appliance door fully . Grab hold of the Open the appliance door fully. appliance door with both hands (on the left and Open the locking levers on the left- and right-hand right) and pull it upwards and out . hinges ...
- Page 26 en Appliance door If necessary, you can remove the condensate Slide the intermediate pane into the left- and right- trough for cleaning. hand retainers . Open the appliance door. ‒ Tilt the condensate trough upwards and remove ‒ Push the intermediate pane upwards until it is in the left- and right-hand retainers ...
- Page 27 Appliance door en Close the locking levers on the left- and right-hand Close the appliance door fully . Grab hold of the hinges . appliance door with both hands (on the left and right) and pull it upwards and out . a The locking levers are closed.
- Page 28 en Appliance door Close the appliance door. Lift out the inner pane and set it down carefully on a flat surface. 18.7 Removing the door panes from the upper the appliance door WARNING ‒ Risk of injury! The hinges on the appliance door move when the door is opened and closed, which could trap your fingers.
-
Page 29: Troubleshooting
Troubleshooting en Push the inner pane upwards until it is in the left- Slide the appliance door straight onto the two and right-hand retainers . hinges. Slide the appliance door on as far as it will go. When doing so, ensure that the hinges are in- serted into the correct opening. - Page 30 en Troubleshooting Fault Cause and troubleshooting The appliance does not switch off At the end of a cooking time, the appliance stops heating up. The oven light and fully at the end of a cooking time. cooling fan do not switch off. For types of heating with recirculation, the fan con- tinues to run in the back wall of the cooking compartment.
-
Page 31: Disposal
Disposal en 20 Disposal Find out here how to dispose of old appliances cor- This appliance is labelled in accord- rectly. ance with European Directive 2012/19/EU concerning used elec- 20.1 Disposing of old appliance trical and electronic appliances (waste electrical and electronic equip- Valuable raw materials can be reused by recycling. - Page 32 en How it works ¡ Keep the appliance door closed when using the Notes ¡ When baking on several layers, always use hot air. grill. Baked goods that are placed in the oven at the Never grill with the appliance door open. same time will not necessarily be ready at the same ¡...
- Page 33 How it works en Food Accessories/cookware Shelf pos- Type of Temperature Cooking ition heating in °C/grill set- time in mins ting Rich fruit cake Deep 23 cm diameter 140-150 180-210 Fruit pie 20 cm diameter plate or 160-170 60-70 pie tin Quiche Quiche tin (dark-coated) 3 180-200...
- Page 34 en How it works 22.5 Food selection Selection for the top oven Food Accessories/cook- Shelf pos- Type of Temperature in Cooking time in ware ition heating °C mins Scones Baking sheet 200-210 10-12 Small cakes 12-cup-tin 150-160 25-35 Lamb chops, height 2-3 cm Wire rack 1.
- Page 35 Installation instructions en Baking Selection for the main oven Food Accessories/cookware Shelf pos- Type of Temperature in Cook- ition heating °C ing time in mins Viennese whirls Baking tray 140-150 25-35 Viennese whirls Baking tray 140-150 20-30 Viennese whirls, 2 levels Universal pan 3 + 1 140-150 25-35...
-
Page 36: 23.1 General Installation Instructions
en Installation instructions 23.1 General installation instructions Follow these instructions before you start with the installation of the appliance. ¡ The safe operation of this appliance can only be guaranteed if it has been installed to a professional standard in accordance ¡ Wear protective gloves so that you do not with these installation instructions. - Page 37 Installation instructions en 23.3 Installation in a tall unit 23.5 Electrical connection Observe the installation dimensions and the installation In order to safely connect the appliance to the elec- instructions when installing in a tall unit. trical system, follow these instructions. ¡ The appliance corresponds to protection class I and must only be operated with a protective earth con- nection.
- Page 38 en Installation instructions The appliance must be transported by two people Screw the appliance into place. using the carry handles on the right and left, while securing the front of the appliance with one hand. 23.7 Removing the appliance Place the appliance in the unit and fold the carry Disconnect the appliance from the power supply.
- Page 40 BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München GERMANY www.siemens-home.bsh-group.com Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom 由博西家用电器（江苏）有限公司根据西门子股份公司的商标许可制造 *9001580325* 9001580325 (010121)
