HHB BurnIT CDR-830 Service Manual page 10

CDR-830
2.5 CD-R CORE ASSY (2/2)
• Bottom View
24
14
6
13
16
10
20
25
15
7
24
22
To
CD-CORE
CN452
2
17
5
C
1
4
26
(Gray)
1
22
12
19
10
11
9
24
16
3
4
21
27
(Black)
8
How to Install the Disc Table
1 Use nippers or other tool to cut the two sections marked A in figure 1 .
2
While supporting the spindle motor shaft with the stopper, put spacer on
top of the carriage base, and stick the disc table on top (takes about 9kg
pressure). Take off the spacer.
A
1
A
Spacer
Spacer
Servo Base
18
2
(Pressure of about 9kg)
Disc table Assy
Spacer setting
Position
Spacer
Spindle
motor
OK NG
Stopper
11mm
2.8mm
Carriage
Base
PCB
