Audio Pro Avanti Series SW-200 Specifications

English
CONTROLS AND INDICATORS
1
2
3
4
5
1) Low level input (MONO)
from amplifier
(Enclosed Y-adaptor)
2) Standby switch
(Auto or ON)
WARNING !
To reduce the risk of electric shock, do not open or remove cover or back. Do not expose this appliance to rain or moisture. In case
of malfunction consult qualified service personel.
The lightning flash with arrowhead, within an equilateral
triangle, is intended to alert the user of the presence of
uninsulated "dangerous voltage" within the product´s
enclosure; that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
3) Phase switch
4) Volume control
5) Low pass crossover control
(variable 50Hz - 100Hz)
6) ON/OFF indicator (Red)
7) Speaker Level input
(from amplifier)
The exclamation point, within an equilateral triangle, is intended to alert
the user of the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
6
10
11
8) Speaker Level output
(to satellite speakers)
9) Mains switch
10) Fuse ( T1AL )
11) Mains cord (230V)
