Specifications
Features
CPU
On-die L2 cache
Single-Channel DDR2 RAM, PC2 6400
Hard Drive
Ethernet
GPIB (IEEE 488 Controller)
Serial Ports (RS-232)
Parallel Port
Hi-Speed USB (2.0) Ports
ExpressCard/34 Slot
PS/2 Keyboard/Mouse Connector
PXI Trigger Bus Input/Output
Installed Operating System
© National Instruments Corporation
This appendix lists the electrical, mechanical, and environmental
specifications of the NI PXI-8110 embedded computer.
NI PXI-8110
® ™
Intel Core 2 Quad processor Q9100
(2.26 GHz quad core processor), 1066 MHz FSB
12 MB;
6 MB shared between cores 0 and 1
6 MB shared between cores 2 and 3
2 GB Standard
4 GB Maximum
120 GB 7200 RPM Serial ATA, minimum;
80 GB (or greater) SATA Ext Temp, 24/7,
optional
10/100/1000 BaseTX
Yes
Yes (1)
Yes (1)
Yes (4)
Yes
No
Yes
Windows 7 Professional,
Windows Vista Business;
Windows Vista Business downgraded to
Windows XP Professional
A-1
