BN68-03317A
BN68-03317A-00
LCD TV

user manual

imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model
Serial No.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LN22D450G1F and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung LN22D450G1F

Summary of Contents for Samsung LN22D450G1F

  • Page 1: User Manual

    If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Comuníquese con SAMSUNG WORLDWIDE Si desea formular alguna pregunta o comentario en relación con los productos de Samsung, comuníquese con el centro de atención al cliente de SAMSUNG.

  • Page 2: Securing The Installation Space

    United States, for the warranty period originally specified, and to the Original Purchaser only. The above described warranty repairs must be performed by a SAMSUNG Authorized Service Center. Along with this Statement, the Original Limited Warranty Statement and a dated Bill of Sale as Proof of Purchase must be presented to the Service Center. Transportation to and from the Service Center is the responsibility of the purchaser.

  • Page 3: Table Of Contents

    Contents Getting Started y List of Features ... 4 y Accessories ... 4 y Installing the LCD TV Stand ... 4 y Viewing the Control Panel ... 5 y Viewing the Remote Control ... 6 y Connecting to an Antenna ... 7 y Plug &...

  • Page 4: Getting Started

    ■ Excellent Digital Interface & Networking : With a built-in HD digital tuner, nonsubscription HD broadcasts can be viewed without a cable box / STB (Set-Top-Box) satellite receiver. ■ Media Play: Allows you to play music files, and pictures saved on a USB device. (P. 22) ■...

  • Page 5: Viewing The Control Panel

    B 3EA ✎ Make sure to distinguish between the front and back of each component when assembling them. ✎ Make sure that at least two people lift and move the TV. ✎ Stand the product up and fasten the screws. If you fasten the screws with the TV placed down, it may lean to one side. ✎...

  • Page 6: Viewing The Remote Control

    Turns the TV on and off. Press to directly access to channels. Press to select additional channels (digital) being broadcast by the same station. For example, to select channel ‘54-3’, press ‘54’, then press ‘-’ and ‘3’. Adjusts the volume. Displays the channel list on the screen.

  • Page 7: Connecting To An Antenna

    When the TV is initially powered on, basic settings proceed automatically. ✎ Connecting the power cord and antenna. Power Input When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWERP button.

  • Page 8: Connections

    Using an HDMI cable or HDMI to DVI Cable: HD connection (up to 1080p) We recommend using the HDMI connection for the best quality HD picture. Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver ✎ HDMI/DVI IN PC/DVI AUDIO IN When using an HDMI/DVI cable connection, you must use the...

  • Page 9: Connecting To An Audio Device

    Using an Optical (Digital) or Audio (Analog) Cable Connection Available devices: Digital Audio System, Amplifier, Home Theater ✎ DIGITAL AUDIO OUT (OPTICAL) When a Digital Audio System is connected to the of both the TV and the system. 5.1 CH (channel) audio is available when the TV is connected to an external device supporting 5.1 CH. When the receiver (home theater) is set to on, you can hear sound output from the TV’s optical jack.
  • Page 10 <LN19D450> Display Modes (D-Sub and HDMI/DVI Input) Optimal resolution is 1360x768@60Hz. Mode Resolution Horizontal Frequency (KHz) 640 x 350 720 x 400 640 x 480 832 x 624 640 x 480 800 x 600 VESA DMT 1024 x 768 1360 x 768 <LN22D450>...

  • Page 11: Changing The Input Source

    Basic Features ✎ ✎ NOTE POWER For HDMI/DVI cable connection, you must use the The interlace mode is not supported. The set might operate abnormally if a non-standard video format is selected. Separate and Composite modes are supported. SOG(Sync On Green) is not supported. EX-LINK Connector for service only.

  • Page 12: How To Navigate Menus

    How to Navigate Menus Before using the TV, follow the steps below to learn how to navigate the menu and select and adjust different functions. MEDIA.P MENU button: Displays the main on-screen menu. 2 ENTERE / Direction button: Move the cursor and select an item.

  • Page 13: Using Favorite Channels

    Using Favorite Channels ¦ MENUm → Channel → Channel List → ENTERE Add to Favorite / Delete from Favorite Set channels you watch frequently as Favorites. 1. Select a channel and press the TOOLS 2. Add or delete a channel using the Add to Favorite or Delete from Favorite menu respectively.

  • Page 14: Picture Menu

    ■ Add / Delete: Delete or add a channel to display the channels you want. ✎ NOTE All deleted channels will be shown on the All Channels menu. A gray-colored channel indicates the channel has been deleted. The Add menu only appears for deleted channels.

  • Page 15: Setting Up The Tv With Your Pc

    Advanced Settings MENUm → Picture → Advanced Settings → ENTERE (available in Standard / Movie mode) Compared to previous models, new Samsung TVs have a more precise picture. ✎ In PC mode, you can only make changes to Gamma and White Balance.

  • Page 16: Picture Options

    Picture Options MENUm → Picture → Picture Options → ENTERE ✎ In PC mode, you can only make changes to the Color Tone and Size. Picture Options Color Tone : Normal Size : 16:9 Digital Noise Filter : Auto HDMI Black Level : Normal Film Mode : Off...

  • Page 17: Sound Menu

    Sound Menu Changing the Preset Sound Mode ¦ MENUm → Sound → Mode → ENTERE Mode ■ Standard: Selects the normal sound mode. ■ Music: Emphasizes music over voices. ■ Movie: Provides the best sound for movies. ■ Clear Voice: Emphasizes voices over other sounds. ■...

  • Page 18: Setup Menu

    Sound Reset (Reset All / Reset Sound Mode / Cancel) ■ Reset All: Resets all sound settings to the factory defaults. ■ Reset Sound Mode: Returns all sound values in the currently selected mode to the default settings Setup Menu Setting the Time ¦...

  • Page 19: Locking Programs

    Locking Programs ¦ MENUm → Setup → V-Chip → ENTERE V-Chip The V-Chip feature automatically locks out programs that are deemed inappropriate for children. The user must enter a PIN (personal identification number) before any of the V-Chip restrictions are set up or changed. ✎...

  • Page 20: Other Features

    ■ Change PIN: The Change PIN screen will appear. Choose any 4 digits for your PIN and enter them. As soon as the 4 digits are entered, the Confirm New PIN screen appears. Re-enter the same 4 digits. When the Confirm screen disappears, your PIN has been memorized.

  • Page 21: Support Menu

    Yes: If the test pattern does not appear or there is noise in the test pattern, select Yes. There may be a problem with the TV. Contact Samsung’s Call Center for assistance (1-800-SAMSUNG). No: If the test pattern is properly displayed, select No.

  • Page 22: Advanced Features

    TV’s USB port. USB (HDD) is not supported. Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss. Please connect directly to the Compatibility problem.
  • Page 23 MSC supports MP3 and JPEG files, and the PTP device supports JPEG files only. MTP (Media Transfer Protocol) is not supported. The playing duration of an mp3 file may be displayed as “00:00:00” if its playing time information is not found at the start of the file.
  • Page 24 Music Using the MP3 List Folder icon Photo Music list icon 307.2MB/973.7MB Move to the previous folder stage icon ✎ The selected file is displayed on the top with its playing time. Photo 1. To select all files or a file, press the menus.
  • Page 25 Setup Using the Setup Menu ■ Slide Show Speed: Select to control the slide show speed. You can select Fast, Normal or Slow. ■ Background Music: Select to determine whether to play an MP3 file during a slide show. You can select Music On or Music Off. ■...

  • Page 26: Anynet

    Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.

  • Page 27: Setting Up Anynet

    Make sure to switch to an Anynet+ device by using the Device List. Recording ¦ You can make a recording of a TV Program using a Samsung recorder. 1. Select Recording. ✎ When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed.

  • Page 28: Listening Through A Receiver

    Listening through a Receiver ¦ You can listen to sound through a receiver (i.e Home Theater) instead of the TV speaker. 1. Select Receiver and set to On. 2. Press the EXIT button to exit. ✎ If your receiver supports audio only, it may not appear in the device list. ✎...

  • Page 29: Other Information

    Do not fasten the screws too strongly; this may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.

  • Page 30: Securing The Tv To The Wall

    TV. The Kensington Lock is not supplied by Samsung. It a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for additional information on proper use.

  • Page 31: Troubleshooting

    If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, visit samsung.com, then click on Support, or call Samsung customer service at 1-800-SAMSUNG. Issues Solutions and Explanations...
  • Page 32 Issues No Picture, No Video The TV will not turn on. The TV turns off automatically. There is no picture/video. RF(Cable/Antenna) Connection The TV is not receiving all channels. No Caption on digital channels. The picture is distorted: macroblock, error, small block, dots, pixelization. PC Connection A “Mode Not Supported”...

  • Page 33: Storage And Maintenance

    Program the Cable/Sat remote control to operate the TV. Refer to the Cable/Sat user manual for SAMSUNG TV code. Check the supported resolution of the TV and adjust the external device’s output resolution accordingly. Refer to resolution settings in this manual.

  • Page 34: Specifications

    Environmental Considerations Operating Temperature Operating Humidity Storage Temperature Storage Humidity Model Name Display Resolution Screen Size (Diagonal) Sound Output Dimensions (WxDxH) Body With stand Weight Without Stand With Stand ✎ Design and specifications are subject to change without prior notice. ✎...

  • Page 35: Dimensions

    NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. © 2011 Samsung Electronics America, Inc Dimensions 12.0...

  • Page 36: Index

    Antenna Anynet Auto Adjustment Auto Program Balance Cables Caption button 6, 20 Clear Scrambled Channel Clear Voice Component Composite Device List DIGITAL AUDIO OUT 9, 26 DST (Daylight Saving Time) D-sub Dynamic Contrast Energy Saving Equalizer External Speaker English Index Favorite Channel HDMI Home theater...
