Sealey STR600 Quick Start Manual

INcorPoratING two level tyre rack eXteNSIoN 200kG Per level
thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
refer to Wear gloves
instructions
1. Safety
 warNING! Ensure Health & Safety, and local authority regulations are adhered to when assembling and using this racking system.
 locate the racking in a suitable area where it will not be an obstruction.
 Keep the general area clean, uncluttered and ensure there is adequate lighting.
 warNING! erect the racking on a level and solid surface such as concrete.
 Keep children and unauthorised persons away from the storage area.
Do Not use the racking for any purpose other than that for which they are designed.

Do Not site the racking out of doors.

Do Not get the racking wet or use in damp or wet locations or areas where there is condensation.

Do Not clean the cross beams with any solvents which may damage the coated surface.

 ensure that the racking is properly assembled before loading with heavy tyres.
 maximum load for each shelf is 200kg. load must be evenly distributed.
 Where possible the unit should be fixed to the wall with suitable fixings.
 Place heavier items on the lower racks.
 Where possible heavier items should be evenly distributed across the racks.
2. INtroDuctIoN
racking unit with cross beams. 200kg capacity per level. designed for direct loading of small storage pallets.
3. SPecIfIcatIoN
Model No: . . . . . . . . . . . . . . . . . . . . . . . . . . . . Str600
overall size: . . . . . . . . . . . . . . . . 1950 x 455 x 2000mm
maximum capacity:. . . . . . . . . . . . . 400kg (200kg/level)
Beam width: . . . . . . . . . . . . . . . . . . . . . . . . . . . 1840mm
4. coNteNtS
Carefully unpack the product and check the contents (fig.1)
against the list below. Should any items be missing or
damaged, immediately contact your Sealey stockist.
Part Description: . . . . . . . . . . . . . . . . . . . . . . . Qty
a Upright:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
B Horizontal Brace: . . . . . . . . . . . . . . . . . . . . . . . . . . 4
c diagonal Brace: . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
D Spacer:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
e rubber Foot: . . . . . . . .not supplied with this model
f Bolt m6 x 45mm: . . . . . . . . . . . . . . . . . . . . . . . . . 12
G nut m6: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
H locking Pin: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
I Cross Beam: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. aSSeMBly
warNING! Before assembly and use, ensure you have

read, understood and apply Section 1 safety instructions.
5.1. It is recommended that this tyre racking system be
assembled by two people. When installing the cross beams
it is advisable to use a rubber mallet. Do Not use a hard faced hammer as this will damage the surface finish of the cross beams. make
sure that all the clips lock in place securely and safety bolts are fitted before using the unit. Do Not use any parts that are damaged and/
or distorted as these may assemble incorrectly and result in an installation that is unsafe and which may cause injury or damage when the
shelves are loaded.
© Jack Sealey limited
two level tyre rack 200kG Per level
Str600
model no:
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE
SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL
INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS
Wear safety SAFE FOR FUTURE USE.
footwear
Original Language Version
Str600e
model no:
STr600, STr600e | Issue 5 (H,F) 03/12/19
