PJD5211/PJD5221/
PJD5231/PJD5122
DLP Projector
IMPORTANT: Please read this User Guide to obtain important information on install-
ing and using your product in a safe manner, as well as registering your product for
future service. Warranty information contained in this User Guide will describe your
limited coverage from ViewSonic Corporation, which is also found on our web site
at http://www.viewsonic.com in English, or in specific languages using the Regional
selection box in the upper right corner of our website.
"Antes de operar su equipo lea cuidadosamente las instrucciones en este manual"
®
- User Guide
- Guide de l'utilisateur
- Bedienungsanleitung
- Guía del usuario
- Guida dell'utente
- Guia do usuário
- Användarhandbok
- Käyttöopas
- Руководство пользователя
- 使用手冊 (繁體)
- 使用手冊 (簡體)
- 사용자 안내서
- Podręcznik użytkownika
- Kullanιcι kιlavuzu
Model No. : VS13304/VS13305
VS13306/VS13308

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PJD5122 and is the answer not in the manual?

Questions and answers

Related Manuals for ViewSonic PJD5122

Summary of Contents for ViewSonic PJD5122

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.

  • Page 2: Compliance Information

    Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Declaration Of Rohs Compliance

    Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance Lead (Pb)

  • Page 4: Product Registration

    PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.

  • Page 5: Table Of Contents

    Table of contents Important safety instructions ...3 Introduction...5 Projector features ... 5 Shipping contents... 6 Projector exterior view... 7 Controls and functions ... 8 Positioning your projector...11 Choosing a location... 11 Projection dimensions ... 12 Connection ...13 Connecting a computer or monitor ... 13 Connecting Video source devices ...

  • Page 6: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before you operate your projector.
  • Page 7 Do not block the ventilation holes. If the ventilation holes are seriously obstructed, overheating inside the projector may result in a fire. - Do not place this projector on a blanket, bedding or any other soft surface. - Do not cover this projector with a cloth or any other item. - Do not place inflammables near the projector.

  • Page 8: Introduction

    Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features. • Screen Color correction allowing projection on surfaces of several predefined colors •...

  • Page 9: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated.

  • Page 10: Projector Exterior View

    Projector exterior view Front/upper side Rear/lower side Warning • THIS APPARATUS MUST BE EARTHED. • When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring, or connect the power plug to an easily accessible socket-outlet near the unit. If a fault should occur during operation of the unit, operate the disconnect device to switch the power supply off, or disconnect the power plug.

  • Page 11: Controls And Functions

    Controls and functions Projector and remote control Focus ring Adjusts the focus of the projected image. "Fine-tuning the image size and clarity" on page 26 for details. Zoom ring Adjusts the size of the image. See tuning the image size and clarity" on page for details.
  • Page 12 LAMP indicator light Indicates the status of the lamp. Lights up or flashes when the lamp has developed a problem. See "Indicators" on page 49 details. AUTO Automatically determines the best picture timings for the displayed image. See "Auto-adjusting the image" on page 25 details.

  • Page 13: Remote Control Effective Range

    Remote control effective range Infra-Red (IR) remote control sensor is located on the front of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor to function correctly. The distance between the remote control and the sensor should not exceed 8 meters (~ 26 feet).

  • Page 14: Positioning Your Projector

    Positioning your projector Choosing a location Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment.

  • Page 15: Projection Dimensions

    Projection dimensions Refer to "Dimensions" on page 52 calculating the appropriate position. • 4:3 image on a 4:3 screen • 16:9 image on a 4:3 screen (e): Screen (f): Center of lens (a) Screen (b) Projection distance Size [m (inch)] [inch (m)] min.

  • Page 16: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...

  • Page 17: Connecting A Monitor

    Many notebooks do not turn on their external video ports when connected to a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a function key labeled CRT/LCD or a function key with a monitor symbol on the notebook. Press FN and the labeled function key simultaneously.

  • Page 18: Connecting Video Source Devices

    Connecting Video source devices You can connect your projector to various Video source devices that provide any one of the following output sockets: • Component Video • S-Video • Video (composite) You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality.

  • Page 19: Connecting A Component Video Source Device

    Video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly. VGA-Component adapter • (ViewSonic P/N: CB-00008906) Connection Component Video to VGA (D-Sub) adaptor cable Audio cable for details.

  • Page 20: Connecting An S-Video Source Device

    Connecting an S-Video source device Examine your Video source device to determine if it has an unused S-Video output socket available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to an S-Video source device: Take an S-Video cable and connect one end to the S-Video output socket of the Video source device.

  • Page 21: Connecting A Composite Video Source Device

    Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a composite Video source device: Take a Video cable and connect one end to the composite Video output socket of the Video source device.

  • Page 22: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Check that the POWER indicator light on the projector flashes blue after power has been applied. Remove the lens cap.
  • Page 23 The projector will start to search for input signals. The current input signal being scanned appears in the upper left corner of the screen. If the projector doesn't detect a valid signal, the message 'No Signal' will continue to be displayed until an input signal is found.

  • Page 24: Using The Menus

    3D Sync Invert Color Management Analog RGB Auto Disable MENU Exit English Front Table Disable Disable Disable ViewSonic MENU Exit : SYSTEM SETUP: Basic : SYSTEM SETUP: Advanced : INFORMATION Auto Status ENTER Go to the previous page Disable or to exit.

  • Page 25: Utilizing The Password Function

    Utilizing the password function For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the On-Screen Display (OSD) menu. For details of the OSD menu operation, please refer to page You will be inconvenienced if you activate the password functionality and subsequently forget the password.

  • Page 26: Entering The Password Recall Procedure

    If the password is incorrect, the password error message is displayed lasting for three seconds, and the message 'INPUT PASSWORD' is displayed for your RECALL PASSWORD Please write down the recall code, and contact ViewSonic Customer Center. Recall code: 0 2 1 2...

  • Page 27: Switching Input Signal

    retry. You can press MENU/EXIT on the projector or Exit on the remote control to cancel the change or try another password. Though the password function is disabled, you need to keep the old password in hand should you ever need to re-activate the password function by entering the old password. Switching input signal The projector can be connected to multiple devices at the same time.

  • Page 28: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with 1 quick-release adjuster foot and 1 rear adjuster foot. These adjusters change the image height and projection angle. To adjust the projector: Press the quick-release button and lift the front of the projector.

  • Page 29: Correcting Keystone

    Fine-tuning the image size and clarity Adjust the projected image to the size that you need using the zoom ring. Then sharpen the image by rotating the focus ring. Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom.

  • Page 30: Magnifying And Searching For Details

    Magnifying and searching for details If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture. • Using the remote control Press Magnify +/- to display the Zoom bar. Press Magnify + to magnify the center of the picture.
  • Page 31 Press to highlight Aspect Ratio. Press to select an aspect ratio to suit the format of the video signal and your display requirements. About the aspect ratio In the pictures below, the black portions are inactive areas and the white portions are active areas.

  • Page 32: Optimizing The Image

    Optimizing the image Selecting a picture mode The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type. To select an operation mode that suits your need, you can follow one of the following steps.

  • Page 33: Adjusting Brightness

    Setting the User 1/User 2 mode There are two user-definable modes if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the User 1/User 2) as a starting point and customize the settings. Press MENU/EXIT on the projector or MENU on the remote control to open the On- Screen Display (OSD) menu.

  • Page 34: Adjusting Color

    Adjusting Color Highlight the PICTURE > Color menu and press Lower setting produces less saturated colors. If the setting is too high, colors on the image will be overpowering, which makes the image unrealistic. Adjusting Tint Highlight the PICTURE > Tint menu and press The higher the value, the more reddish the picture becomes.

  • Page 35: Color Management

    Color Management Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered. Color management provides fine color control adjustment to allow for more accurate color reproduction, should you require it. If you have purchased a test disc which contains various color test patterns and can be used to test the color presentation on monitors, TVs, projectors, etc., you can project any image from the disc on the screen and enter the Color Management menu to make adjustments.

  • Page 36: Hiding The Image

    Hiding the image In order to draw the audience's full attention to the presenter, you can use on the remote control to hide the screen image. Press any key on the projector or remote control to restore the image. The word 'BLANK' appears at the lower right corner of the screen while the image is hidden.

  • Page 37: Freezing The Image

    Freezing the image Press Freeze on the remote control to freeze the image. The word 'FREEZE' will be displayed in the upper left corner of the screen. To release the function, press any key on the projector or remote control. Even if an image is frozen on the screen, the pictures are running on the video or other device.

  • Page 38: Personalizing The Projector Menu Display

    Personalizing the projector menu display The On-Screen Display (OSD) menus can be set according to your preferences. The following settings do not affect the projection settings, operation, or performance. • Menu Display Time in the SYSTEM SETUP: Advanced > Menu Settings menu sets the length of time the OSD will remain active after your last key press.

  • Page 39: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. The menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.
  • Page 40 Front Table/Rear Table/Rear Ceiling/Front Ceiling Disable/5 min/10 min/20 min/30 min/40 min/50 min/60 min Disable/5 min/10 min/15 min/20 min/25 min/30 min On/Off Disable/30 min/1 hr/2 hr/3 hr/4 hr/8 hr/12 hr Black/Blue/ViewSonic On/Off On/Off On/Off On/Off On/Off Mute On/Off Volume Active Audio Out On/Off...

  • Page 41: Description Of Each Menu

    Description of each menu Function Screen Color Aspect Ratio Keystone Position Phase H. Size Zoom 3D Sync 3D Sync Invert Color Management Operation Description Corrects the projected picture’s color when the projection surface is not white. See "Using Screen Color" on page 30 There are three options to set the image's aspect ratio depending on your input signal source.

  • Page 42: Function Description

    Function Pre-defined picture modes are provided so you can optimize Color Mode your projector image set-up to suit your program type. See "Selecting a picture mode" on page 29 Selects a picture mode that most suits your need for the image Reference quality and further fine-tune the image based on the selections Mode...
  • Page 43 Sets the auto-shutdown timer. The timer can be set to a value between 30 minutes and 12 hours. Allows you to select which logo screen will be displayed during projector start-up. Three options are available: ViewSonic logo, Black screen, or Blue screen. Selecting On displays the current information on the screen when the projector is detecting or searching for a signal.
  • Page 44 Function Selecting On outputs a VGA signal when the COMPUTER IN Active VGA 1/COMPUTER IN 2 and COMPUTER OUT sockets are correctly connected to devices. See page 14 The sound adjustments made as below will have an effect on the projector speaker.
  • Page 45 Function Lamp Settings Security Settings Reset All Settings Current System Status Operation Description Lamp Mode "Setting Lamp mode as Economic" on page 44 Reset Lamp Timer "Resetting the lamp timer" on page 48 Equivalent Lamp Hour "Getting to know the lamp hour" on page 44 on how the total lamp hour is calculated.

  • Page 46: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

  • Page 47: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. To obtain the lamp hour information: Press MENU/EXIT on the projector or MENU on the remote control and then press until the SYSTEM SETUP: Advanced menu is highlighted.

  • Page 48: Timing Of Replacing The Lamp

    Timing of replacing the lamp When the Lamp indicator lights up red or a message appears suggesting it is time to replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. CAUTION The Lamp indicator light and Temperature warning light will light up if the lamp becomes too hot.

  • Page 49: Replacing The Lamp

    Be careful of sharp edges in the lamp compartment. Wash hands after lamp replacement. • Only ViewSonic certified lamps are tested with this projector. Use of other lamps may cause electrical shock and fire. Turn the power off and disconnect the projector from the wall socket.
  • Page 50 Pull out the lamp connector from a slot in the lamp compartment. Disconnect it from the projector as illustrated. Lift the handle so that it stands up. Use the handle to slowly pull the lamp out of the projector. CAUTION •...

  • Page 51: Resetting The Lamp Timer

    Tighten the screw that secures the lamp. CAUTION • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screw. Ensure the handle is fully laid flat and locked in place. Replace the lamp cover on the projector.
  • Page 52 Indicators Light Power Temp Lamp Blue Flashing Blue Blue Blue Flashing Purple Flashing Green Green Blue Blue Green Purple Purple Green Green Status & Description Power events Stand-by mode Powering up Normal operation The projector needs 90 seconds to cool down as it was abnormally shut down without the normal cooling down process.

  • Page 53: Troubleshooting

    Troubleshooting The projector does not turn on. Cause There is no power from the power cord. Attempting to turn the projector on again during the cooling process. No picture Cause The video source is not turned on or connected correctly. The projector is not correctly connected to the input signal device.

  • Page 54: Specifications

    Environmental Requirements Operating temperature Operating relative humidity Operating altitude Digital Projector • PJD5122: 800 x 600 SVGA • PJD5211/PJD5221/PJD5231: 1024 x 768 XGA 1-CHIP DMD F = 2.57 to 2.65, f = 21 to 23.1 mm PJD5122/PJD5211/PJD5221: 220 W lamp (RLC-055) •...

  • Page 55: Dimensions

    Dimensions 264 mm (W) x 96.4 mm (H) x 225 mm (D) Ceiling mount installation Timing chart Supported timing for PC input Horizontal Resolution Frequency 720 x 400 640 x 480 800 x 600 Specifications 96.4 Vertical Frequency (kHz) (Hz) 31.469 70.087 31.469...
  • Page 56 65.317 1600 x 1200 640 x 480@67Hz 832 x 624@75Hz 49.722 1024 x 768@75Hz 60.241 1152 x 870@75Hz 68.68 1024 x 768@120Hz is not supported for the PJD5122. Supported timing for Component-YP Signal Format 480i(525i)@60Hz 480p(525p)@60Hz 576i(625i)@50Hz 576p(625p)@50Hz 720p(750p)@60Hz 720p(750p)@50Hz...

  • Page 57: Copyright Information

    Copyright 2010. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of ViewSonic Corporation. Disclaimer...

  • Page 58: Appendix

    Appendix IR control table Format Power Freeze Down Left Right Color Mode Volume+ Volume- Auto Source Blank Menu Magnify + Magnify - Enter Exit Mute VGA1 VGA2 Video Keystone + Keystone - RS232 command table <Pin assignment for this two end> Byte1 Byte2 Byte3 Byte4 Description Description...
  • Page 59 <Interface> Baud Rate Data Length Parity Check Stop Bit Flow Control Function Status Write Power Read Reset Execute Write High Altitude Mode Read Mode status Lamp Mode Write Lamp Mode Lamp Mode Lamp Mode Read Front Table Write Rear Ceiling Projector Position Read...
  • Page 60 Contrast decrease Write Contrast Contrast increase Contrast Read ratio Brightness decrease Write Brightness Brightness increase Read Brightness Aspect ratio Auto Aspect ratio Write Aspect Aspect ratio Ratio Aspect ratio 16:9 Read Aspect ratio Auto Adjust Execute Horizontal position shift right Write Horizontal Horizontal...
  • Page 61 Write Blank Read Blank status Write Keystone- Vertical Read Write Color Mode Color Mode Read Write Primary Color Read color status Write Read Write Saturation Read Write Gain Read Write Freeze Read Appendix Blank on 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x09 0x01 0x68 Blank off 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x09 0x00 0x67 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x12 0x09 0x68...
  • Page 62 Input source Input source VGA2 Write Input source Source Composite input Input source S-VIDEO Read Source Quick Auto Search on Write Quick Auto Quick Auto Search off Search Quick Auto Read Search status Mute on Write Mute Mute off Read Mute status Increase Volume...
  • Page 63 Reset Lamp Write 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x01 0x00 0x62 usage hour Lamp Time Lamp usage Read 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x15 0x01 0x63 hour Read error Error status Read 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x0C 0x0D 0x66 status Appendix...

  • Page 64: Customer Support

    Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Merida, Yucatan. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America (Peru) www.viewsonic.com/la/ Macau www.hk.viewsonic.com...

  • Page 65: Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
  • Page 66 2. To obtain warranted service, you will be required to provide (a) the original dated sales slip, (b) your name, (c) your address, (d) a description of the problem, and (e) the serial number of the product. 3. Take or ship the product freight prepaid in the original container to an authorized ViewSonic service center or ViewSonic.

  • Page 67: Viewsonic Projector

    Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.
  • Page 68 E-Mail: rrrb@sureste.com Tijuana: Av Ferrocarril Sonora #3780 L-C Col 20 de Noviembre Tijuana, Mexico 4.3: ViewSonic Mexico Limited Warranty Villahermosa: Compumantenimietnos Garantizados, S.A. de C.V. AV. GREGORIO MENDEZ #1504 COL, FLORIDA C.P. 86040 Tel: 01 (993) 3 52 00 47 / 3522074 / 3 52 20 09 E-Mail: compumantenimientos@prodigy.net.mx...
