Mitsubishi Electric PUHZ-P100VHA2 Service Manual

Split-type, heat pump air conditioners
Hide thumbs
Table of Contents

Advertisement

Quick Links

SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SERVICE MANUAL
R410A
Outdoor unit
[model names]
PUHZ-P100VHA2
PUHZ-P125VHA2
PUHZ-P140VHA2
PUHZ-P100VHA2.UK
[Service Ref.]
PUHZ-P100VHA2.UK
PUHZ-P125VHA2.UK
PUHZ-P125VHA2
PUHZ-P140VHA2.UK
PUHZ-P140VHA2
REVISED EDITION-A
Revision:
• PUHZ-P125/140VHA2
• Some descriptions have
•
.UK
1
Note:
• This manual describes only
.UK
1
• RoHS compliant products
CONTENTS
1. TECHNICAL CHANGES·································2
2. REFERENCE MANUAL··································2
3. SAFETY PRECAUTION··································3
4. FEATURES ·····················································6
5. SPECIFICATIONS···········································7
6. DATA ·······························································8
7. OUTLINES AND DIMENSIONS ····················11
8. WIRING DIAGRAM ·······································13
9. WIRING SPECIFICATIONS ··························14
10. REFRIGERANT SYSTEM DIAGRAM··············19
11. TROUBLESHOOTING···································21
12. FUNCTION SETTING····································70
13. EASY MAINTENANCE FUNCTION ··············77
15. DISASSEMBLY PROCEDURE ·····················90
PARTS CATALOG (OCB415)
February 2008
No.OCH415
.UK
1
are added in REVISED
EDITION-A.
been modified.
Please void OCH415.
service data of the outdoor
units.
have <G> mark on the
spec name plate.
