Summary of Contents for Samsung HW-JM25
- Page 1 HW-JM25 User manual Wireless Audio - Soundbar Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register 'This Nanum Gothic Eco font is provided by NAVER'...
-
Page 2: Features
You can connect a Bluetooth device to the Soundbar and enjoy music with high quality stereo sound, all without wires! Using the Samsung Audio Remote App To control the product with your Smart Device via the Samsung Audio Remote app, download the Samsung Audio Remote App by accessing the app through the Google Play store. LICENSES Manufactured under license from Dolby Laboratories. -
Page 3: Safety Information
SAFETY INFORMATION SAFETY INFORMATION SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION The lighting flash and arrowhead within the triangle indicates that there is dangerous RISK OF ELECTRIC SHOCK. -
Page 4: Precautions
SAFETY INFORMATION PRECAUTIONS 2.7 inch 3.9 inch 3.9 inch 3.9 inch Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches). -
Page 5: Table Of Contents
CONTENTS CONTENTS FEATURES 15 FUNCTIONS Licenses Input Mode Bluetooth SAFETY INFORMATION Using the Samsung Audio Remote APP TV SoundConnect Safety Warnings Precautions Software update GETTING STARTED 22 TROUBLESHOOTING Before reading the User’s Manual What’s Included 23 APPENDIX DESCRIPTIONS Specifications Top/Front Panel... -
Page 6: Getting Started
▶ Copyright ©2015 Samsung Electronics Co.,Ltd. All rights reserved; no part of this user’s manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd. WHAT’S INCLUDED Check for the supplied accessories shown below. (Wall Mount L: 1EA) -
Page 7: Descriptions
DESCRIPTIONS DESCRIPTIONS TOP/FRONT PANEL (Source) Button Selects the D.IN, AUX, TV, BT, USB input. VOL -/+ While the unit is powered on, Controls the volume level. pressing the ( ) button for more than 3 seconds sets the button to act as the MUTE button. To cancel MUTE button setup, press the ( ) button for more... -
Page 8: Rear Panel
DESCRIPTIONS REAR PANEL (USB Port) Connect USB devices such as MP3 players here to play files on the devices. DC 14V (Power Supply In) Connect the DC power adaptor to the power supply jack, and then connect the AC power adaptor plug to a wall outlet. -
Page 9: Remote Control
REMOTE CONTROL REMOTE CONTROL REMOTE CONTROL BUTTONS AND FUNCTIONS POWER Turns the Soundbar on and off. D.IN Press the D.IN button to select Digital In mode. VOLUME Adjusts the volume level of the unit. D.IN If you set the volume to Max or Min, the LEDs turn on. - Page 10 -3, -2, -1, 0, +1, +2, +3, +4, +5, +6). When you select the SW -12 or SW +6, the function LED lights. D.IN • To adjust woofer level using mobile APP (Samsung Audio Remote), use [, ] buttons to decrease or increase woofer level within 3 seconds since WOOFER button is pressed.
-
Page 11: Connections
CONNECTIONS CONNECTIONS INSTALLING THE WALL MOUNT You can use the wall mount bracket to mount this unit on a wall. ▶ Installation Precautions Install on a vertical wall only. ● For the installation, avoid a location with high temperature or ●... -
Page 12: Detaching The Wall Mount
CONNECTIONS DETACHING THE WALL MOUNT 1. Pull the Soundbar upwards as shown in the figure to separate it from the wall mounts. Detaching the Soundbar from the Wall Mounts Do not hang onto the installed unit and avoid striking or dropping the unit. ●... -
Page 13: Installing The Bracket Without Referring To The Wall-Mount Installation Guide
CONNECTIONS INSTALLING THE BRACKET WITHOUT REFERRING TO THE WALL-MOUNT INSTALLATION GUIDE 2 inches 2 inches (5 cm) or more (5 cm) or more 6.3 inches 6.9 inches (16 cm) (17.5 cm) Minimum 12.9 ~ 13.2 inches (32.8 ~ 33.5cm) 1. Place Wall Mount L on the desired wall surface parallel to the floor as shown above. Mark the location of the screw holes on the wall. -
Page 14: Connecting An External Device Using Audio (Analog) Cable Or Optical (Digital) Cable
CONNECTIONS CONNECTING AN EXTERNAL DEVICE USING AUDIO (ANALOG) CABLE OR OPTICAL (DIGITAL) CABLE This unit comes equipped with one digital optical in jack and one analog audio in jack (Aux In), giving you two ways to connect it to a TV. Audio Cable (supplied) BD/ DVD player/... -
Page 15: Functions
FUNCTIONS FUNCTIONS INPUT MODE Press each mode button on the remote control or the ( ) button on the main unit’s top panel to select the mode you want. The unit turns off automatically in the following Input mode Display situations: D.IN (Optical Digital (White) -
Page 16: Bluetooth
Soundbar. You will see a list of scanned devices. ● - If several Bluetooth devices are 4. Select "[Samsung] Soundbar J-Series" from the simultaneously paired with the Soundbar. list. - If the Bluetooth device is turned off, If the Bluetooth device is successfully not in place, or malfunctions. - Page 17 FUNCTIONS ▶ Bluetooth POWER on (Bluetooth POWER) When the Bluetooth Power On function is on and the Soundbar is turned off, if a previously paired Bluetooth device tries to pair with the Soundbar, the Soundbar turns on automatically. 1. To turn Bluetooth Power ON, press the Bluetooth POWER button on the remote while the Soundbar is turned on.
-
Page 18: Using The Samsung Audio Remote App
USING THE SAMSUNG AUDIO REMOTE APP Installing the Samsung Audio Remote App To control the product with your Smart Device via the Samsung Audio Remote app, download the Samsung Audio Remote App from the Google Play store. Starting the Samsung Audio Remote App After you install the Samsung Audio Remote app, follow the instructions in the app. -
Page 19: Tv Soundconnect
FUNCTIONS TV SOUNDCONNECT You can enjoy TV sound through your Soundbar when it is connected to a Samsung TV that supports the TV SoundConnect function. ▶ Connecting a TV to the Soundbar Connect 1. Turn on the TV and Soundbar. -
Page 20: Usb
FUNCTIONS You can play music files located on USB storage devices through the Soundbar. Display USB port 1. Connect the USB device to the USB port on the Do not connect multiple storage devices to the ● product. product via a multi-card reader. It may not operate properly. -
Page 21: Software Update
FUNCTIONS SOFTWARE UPDATE Samsung may offer updates for the Soundbar's system firmware in the future. Insert a USB device containing the ● firmware update into the USB port on the If an update is offered, you can update the firmware main unit. -
Page 22: Troubleshooting
Does your TV support TV SoundConnect? ¼ TV SoundConnect is supported by some ● Samsung TVs released from 2012 on. Check your TV to see if it supports TV SoundConnect. ¼ Update your TV with the latest firmware. Is your TV firmware the latest version? ●... -
Page 23: Appendix
Engineering Society) guidelines. * Nominal specification - Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. - Weight and dimensions are approximate. - For information about the power supply and power consumption, refer to the label attached to the product. - Page 24 Transportation of the product to and from the service center is the responsibility of the purchaser. SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.
- Page 25 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT WRITE Samsung Electronics America, Inc. 1-800-SAMSUNG www.samsung.com/us/ 85 Challenger Road U.S.A (726-7864) support Ridgefield Park, NJ 07660 AH68-02839Z-00...
