Page 1 Operation Manual A165-L35 XAC22125 English Original Operation Manual Chapter Document-ID Introduction HZTL4005_EN_G Safety HZTL4024_EN_D Safety data sheet XAC22125 Product description HZTL4034_EN_P ABB Turbocharging...
Page 2 Operating limits and replacement intervals The recommended replacement intervals and the corresponding operating limits in chapter 3 are jointly defined with the enginebuilder. This information is specific to the product. Non-observance of the recommended replacement intervals and the operating limits increases the risk of unpre- dictable component failures.
Page 3: Table Of Contents
Operation Manual / 1 Introduction Table of contents Introduction Introduction......................2 Purpose of the manual....................2 Symbols, definitions...................... 3 Storage of new turbochargers and spare parts ............5 Contact information...................... 7 © Copyright 2020 ABB. All rights reserved. HZTL4005_EN Rev.G March 2020...
Page 4: Introduction
Availability of the Operation Manual The Operation Manual must be available where the turbocharger is used. All persons operating or working on the turbocharger must have read and fully understood the Operation Manual. © Copyright 2020 ABB. All rights reserved. HZTL4005_EN Rev.G March 2020...
Page 5: Symbols, Definitions
Definition of Caution / Warning Caution and warning signs are described in chapter Safety. ABB Turbocharging ABB Switzerland Ltd, Turbocharging is identified as ABB Turbocharging or as ABB Turbo Sys- tems in this document. Official service stations of ABB Turbocharging Official service stations are regularly audited and certified by ABB Turbocharging.
Page 6 Visually inspect Please note text for numbered work step. See document Dispose of in an environmentally compatible, professional way and in compliance with locally applicable regulations. Table 1: Definition of pictograms © Copyright 2020 ABB. All rights reserved. HZTL4005_EN Rev.G March 2020...
Page 7: Storage Of New Turbochargers And Spare Parts
Dispose of the old VCI corrosion protection emitter in an environmentally compatible manner, professionally and in accordance with local regulations. Seal the package. The better the external seal is designed, the more permanent the pro- tection. © Copyright 2020 ABB. All rights reserved. HZTL4005_EN Rev.G March 2020...
Page 8 Inspect the package for damage. If the package is damaged, the turbocharger must be in- spected by an ABB Turbocharging Service Station and repacked. After every 3 years the following work steps must be performed by an ABB Turbocharging Service Station: ¡...
Page 9: Contact Information
Operation Manual / 1 Introduction 1 Introduction / 1.4 Contact information Contact information Contact information for the ABB Turbocharging Service Stations is available online. Scan the QR code to access our website. ABB Switzerland Ltd, Turbocharging Bruggerstrasse 71a CH-5401 Baden Switzerland www.abb.com/turbocharging...
Page 11 Lifting of loads ......................8 1.10 Prerequisites for operation and maintenance............9 1.11 Hazards during operation and maintenance ............10 1.12 Safe operation ......................12 1.13 Safe maintenance ......................13 © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 12: Safety
Safety Introduction Turbochargers manufactured by ABB reflect the state of the art. The respective safety and health protection requirements are met. This ensures safe operation of the turbocharger. Nevertheless, there may be some residual risks during operation of and work on the tur- bocharger which: ¡...
Page 13: Definition Of Mandatory Signs
CAUTION can lead to seri- ous damage to engine or property with grave consequences. Caution signs must always be observed. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 14: Intended Use
The specific operating limits of the turbocharger were determined on the basis of informa- tion from the enginebuilder about the intended use. These data are given on the rating plate. ABB accepts no liability and rejects all warranty claims for any non-intended uses. WARNING Unapproved operation Any operation of the turbocharger outside of its operating limits can be haz- ardous to personnel.
Page 15: Warning Plates On The Turbocharger
Manual, Chapter 4 Product description. Turbochargers supplied to the enginebuilder without insulation must be equipped later with warning plates on the insulation. This is the responsibility of the enginebuilder. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 16: Turbocharger Rating Plate
06 Customer part number 07 Designation for special design 08 Weight of turbocharger in kg 09 Turbocharger type 10 Serial number Year of construction of turbocharger Manufacturing plant © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 17: Periodic Check Of The Pressure Vessels
The locations of the rating plates are defined in the Operation Manual, Chapter 4 Product description. Periodic check of the pressure vessels The pressure vessels used by ABB Turbocharging, such as those for wet or dry cleaning, are so-called "simple pressure vessels". ¡...
Page 18: Lifting Of Loads
The assembly devices must be completely screwed in and must not unscrew during use. Use assembly devices only for the described applications. Put down dismantled components of the turbocharger in such a way that they cannot tip over. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 19: Prerequisites For Operation And Maintenance
Original parts and accessories are specially designed by ABB Turbo Systems for the ABB tur- bochargers. ABB accepts no liability for any damage resulting from the use of non-original parts and cor- responding accessories. © Copyright 2017 ABB. All rights reserved.
Page 20: Hazards During Operation And Maintenance
Wear heat-resistant safety gloves and protective clothing. Wait for the turbocharger to cool down before carrying out any work. Wear safety gloves to protect against thermal hazards. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 21 At the same time, electrical or electronic components and parts can also be damaged or destroyed. Only specially trained personnel should perform work on, or with, elec- trical components. Observe national regulations. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 22: Safe Operation
When switching on operating energy supplies (hydraulics, pneumatics, electricity), pay at- tention to the risks that may occur as a consequence of this energy input. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 23: Safe Maintenance
Keep the floor, equipment, and turbocharger clean. Have oil binding agents ready and provide or keep oil pans at hand. Clean up any spills. Have fire protection means and extinguishing agents available. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 24 Secure rotor against turning. The rotor can rotate due to the stack draught alone. Observe the material safety data sheet for the cleaning and mothballing agents. Wear personal protective equipment (PPE) according to the material safety data sheet. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D...
Page 25 Wear personal protective equipment (PPE) according to the material safety data sheet. Comply with local legislation. Wear safety goggles. Wear safety gloves to protect against chemical hazards. Wear a respiratory mask to protect against gases. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 26 Dispose of insulation materials properly and in an environmentally com- patible manner in compliance with the legal regulations. Wear safety goggles. Wear a respiratory mask to protect against dusts. Wear safety gloves to protect against chemical hazards. © Copyright 2017 ABB. All rights reserved. HZTL4024_EN Revision D June 2017...
Page 27 Operation Manual / A165-L35 / Safety data sheet Page 1 / 1 Safety data sheet A165-L35 XAC22125 A165-L35 XAC22125 AV65MZ00811 2020 2300 © Copyright 2020 ABB. All rights reserved. XAC22125 May 2020...
Page 29 Cleaning the compressor during operation ............36 Cleaning the turbine during operation..............40 Draining the gas outlet casing ................. 44 Troubleshooting....................45 Malfunctions when starting..................45 Malfunctions during operation ................46 © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 30 Ordering spare parts....................104 12.2 View of turbocharger with part numbers ............106 12.3 View of cartridge group with part numbers............108 Figures......................... 110 Tables ........................112 © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 31: Introduction
This document is valid for different design variants of turbochargers. There may be sections and descriptions of components that are not relevant for a specific turbocharger variant. Please contact an ABB Turbocharging Service Station if you have any questions regarding a design variant (see Contact information at www.abb.com/turbocharging).
Page 32: Layout And Function Of The Turbocharger
03 Radial plain bearing 10 Diffuser 04 Radial plain bearing 11 Compressor wheel 05 Gas outlet casing 12 Compressor casing 06 Turbine wheel 13 Air-outlet silencer (option) 07 Nozzle ring © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 33 This oil tank supplies the bearings of the rotor with oil until standstill in the event that a mal- function of the lubrication oil system causes an emergency stop of the engine. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 34: Warning Plates On The Turbocharger
If warning plates are not present in the designated locations or not readable, proceed as fol- lows: Order new warning plates from ABB Turbocharging Service Stations. Remove any warning plates that have become unreadable. Clean and degrease the areas designated for the warning plates.
Page 35: Locations Of The Rating Plates
Locations of the rating plates Fig. 3: Locations of the rating plates One rating plate (01) each is attached on the left and the right side of the turbocharger bear- ing casing. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 36: Removal And Installation
Loosen cable to speed sensor. Disconnect all pipes according to the instructions of the enginebuilder. Check lifting gear. Fasten lifting gear on suspension eyes of the bearing casing and tauten. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 37: Fig. 4: Fit The Lifting Gear
2 Removal and installation / 2.2 Removing the turbocharger Fig. 4: Fit the lifting gear Loosen fixing screws on compressor-end and turbine-end foot. Lift turbocharger from engine and put down in a suitable location. Cover oil connections. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 38: Installing The Turbocharger
→11) while only slightly loosening the lifting gear. Remove lifting gear from suspension eyes of the bearing casing. Connect cable to speed sensor. Connect all gas, air and oil pipes. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 39: Fig. 6: Compressor-End Foot
Tighten the foot fixing screws or nuts diagonally according to the selected tightening method. Turbine-end foot Fig. 7: Turbine-end foot Tighten the foot fixing screws or nuts according to the selected tightening method. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 40: Table 4: Tightening Torques (Foot Screws)
A190-L Table 5: Tightening angle (foot screws) Pinning of turbocharger feet with positioning pins If the turbocharger is pinned at its feet, one pin hole per foot must be used. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 41: Commissioning
Inspection procedures include preventative visual controls, monitoring and measuring work before and during commissioning. Inspection procedures enable changes to the turbochar- ger to be detected. Machine damage can be prevented. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 42 Check oil inlet temperature. The admissible values are specified in section Oil supply. Gas, air and oil pipes After starting the engine, check all gas, air and oil pipes for leaks. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 43: Commissioning After Taking Out Of Operation
Lubricants and pastes used during assembly can liquefy or vaporise and escape as oily fluids during the initial hours of operation. Continual escape of an oily fluid indicates an oil leak. If there is a leak, contact an ABB Turbocharging Service Station. Commissioning after taking out of operation...
Page 44: Monitoring During Operation
Oil temperature at the inlet [°C] oil,inlet Admissible (see Table 6: Lubricating oil pressure, oil inlet 30 … 80 →16) Temporarily admissible (< 1 h) → alarm > 80 Not admissible → stop engine > 85 © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 45: Fig. 8: Oil Temperature At The Outlet
Temporarily admissible → alarm > 110 Temporarily admissible → alarm > 125 Not admissible → stop engine > 120 Not admissible → stop engine > 135 Table 8: Lubricating oil temperature at the outlet © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 46 4 Monitoring during operation / 4.1 Oil pressure, oil temperature If the turbocharger was operated for a longer period of time outside of the admissible range, ABB Turbo Systems recommends to have the turbocharger inspected by an ABB Tur- bocharging Service Station.
Page 47: Admissible Air Inlet Temperature
Tachometer 86506 O-ring 42047 Screw plug 86515 Cable connector 32109 Sealing disc with cams 86526 F/I converter Alternative mounting position for speed sensor or for the second speed sensor © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 48 Check the pressure loss of the alternative air inlet and compare it with normal values. If the engine can be stopped temporarily: Inspect air lines, gas piping and the turbochargers and remedy any malfunctions. In any case, contacting the nearest ABB Turbocharging Service Station is recommended. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 49: Fig. 10: Replacing The Speed Sensor
Unscrew the defective speed sensor. Screw in new speed sensor to the stop. Connect cable connector (86515) with the speed sensor (86505) Switch on lubricating oil supply to the turbocharger. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 50: Low Pressure Measurement At The Filter Silencer
Better readability of the U-tube manometer can be achieved by filling with slightly coloured water. Colour the water with food colouring or ink. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 51: Operation And Service
Directive 2006/42/EC, 1.7.4.2 / u / Paragraphs 5 + 7 : A-weighted emission sound pressure level The enginebuilder must provide acoustically equivalent measures in case of deviating in- sulation versions © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 53 5.2.3 Service work on turbocharger every 18000 hours It is recommended to have this service work and these checks carried out by an ABB Tur- bocharging Service Station. Damaged and worn out parts must be replaced with original ABB parts.
Page 54 Service work according to instructions of enginebuilder Clean or replace the oil filter located in the supply pipe to the turbocharger while the en- gine is stopped, in accordance with the instructions of the enginebuilder. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 55 Lubricating oil pressure and lubricating oil temperature ¡ Pressure loss in the filter silencer ¡ Air temperature after the charge air cooler If present: ¡ Air temperature after the compressor © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 56: Expected Replacement Intervals
See information on rating plate Bearings See information on rating plate Table 11: Recommended replacement intervals for turbocharger parts The specified values are guideline values and not guaranteed values, see Influencing para- meters. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 57: Flexible Turbocharger Cut-Out
Close the compressor outlet flap just before the gas inlet flap. Contamination with closed flaps To limit the contamination deposits when operating with closed flaps, we recommend you open them at least every 500 hours of operation. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 58: Stopping The Engine
Operation Manual / 4 Product description / A100-L 5 Operation and service / 5.5 Stopping the engine Stopping the engine Observe the instructions regarding post-lubrication (Pre-lubrication and post-lubrication →18) Stop the engine. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 59: Periodic Maintenance
Maintenance work includes regular visual controls and cleaning operations which are inten- ded to ensure the trouble-free functioning of the turbocharger. Described maintenance points: ¡ Filter silencer ¡ Compressor ¡ Turbine and nozzle ring © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 60: Cleaning The Filter Silencer
Connecting strip 81136 Absorption segment 81270 Tension band 81137 Sheet-metal covering 81271 Lock 81265 Filter ring (if present) 81400 Water connection Insert unit (absorption segment / sheet-metal covering fitted) © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 61 Guide the tension bands (81270) through the eyelets of the connecting strips (81268). Tighten the tension bands (81270) at the locks (81271). Any damaged tension bands must be replaced. Fit filter ring (81265), if present. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 62: Changing The Filter Strip On The Filter Silencer Casing
Fig. 14: Dismantling filter ring circumferential part Dismantle circumferential part (9). Fig. 15: Opening filter ring lock Open the lock of the filter ring (81265). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 63: Fig. 16: Attaching New Filter Ring
Pull on the old filter ring until the new filter ring is completely wrapped around the filter silencer. Undo the connection between the new and the old filter ring. Fasten the newly installed filter ring (81265), then fit circumferential part (9). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 64: Cleaning The Compressor During Operation
ABB Turbo Systems. Cleaning method and operating state The compressor is cleaned during operation using the wet cleaning method. The cleaning method is tested and approved by ABB Turbo Systems. When undertaking wet cleaning, the following operating state must be ensured: ¡...
Page 65 CAUTION Volume of water for cleaning the compressor Uncontrolled volumes of water can damage the turbocharger and the en- gine. Do not guide water pipes to the filler openings. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 66: Fig. 18: Overview Of Wet Cleaning Of Compressor
Screw in lock and hand-tighten. Fit insulation to flange of filter silencer (if present). After cleaning, allow the engine to continue to run for at least 5 minutes under normal load. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 67: Fig. 19: Filter Plug View
Repeating the cleaning If the cleaning is still unsuccessful after three processes, it is recommended to have the tur- bocharger checked and cleaned by an ABB Turbocharging Service Station if the engine val- ues are unsatisfactory. Volume of water per cleaning process...
Page 68: Cleaning The Turbine During Operation
The dry cleaning of the turbine end components is carried out at an engine load of 5 … 85%. Cleaning several turbochargers If several turbochargers are installed on an engine, ABB Turbo Systems recommends clean- ing one turbine after the other. © Copyright 2020 ABB. All rights reserved.
Page 69: Fig. 20: Overview Of Dry Cleaning Device
Plate Piping Cleaning instructions (51717) On-Off valve [closed] (51705) Gas inlet casing, insulated CAUTION Protecting the pressurised air system Protect the pressurised air system against overpressure (> 7 bar). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 70 Repeating the cleaning If the cleaning is still unsuccessful after three processes, it is recommended to have the tur- bocharger checked and cleaned by an ABB Turbocharging Service Station if the engine val- ues are unsatisfactory. Optimum cleaning effect It is important that the specified amount of granulate is blown in for each cleaning process in order to achieve an optimum cleaning effect.
Page 71: Table 14: Amount Of Granulate
Table 14: Amount of granulate NOTICE Storage of dry cleaning materials The cleaning material must be stored in a dry and clean location to prevent blockage of the pipes when cleaning. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 72: Draining The Gas Outlet Casing
Set the drain cock (02) to position 2 (B) and clean the drain pipe (01) with air from the compressor casing (04). If cleaning with air is not sufficient, the drain pipe (01) must be cleaned mechanically. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 73: Troubleshooting
To prevent significant loss of efficiency, specific tolerances must be fulfilled. ¡ If there is any doubt about the extent of the rubbing, contact an ABB Tur- bocharging Service Station. ¡...
Page 74: Malfunctions During Operation
Drop in speed Possible causes Remedy Turbochar- Heavy contamination of the turbine Clean Damaged rotor components or bearing Contact ABB Turbocharging Service Station Pipes Defects, such as leaks, in the exhaust Repair gas pipes or charge air ducts Table 19: Malfunctions during operation – Drop in speed ©...
Page 75: Table 20: Malfunctions During Operation - Exhaust Gas Temperature Too High
Injection mistimed Set correctly Valve control misadjusted Pipes Pipes downstream to the compressor Repair. outlet not sealed. Table 21: Malfunctions during operation – Charge air pressure too low © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 76: Surging Of The Turbocharger
Gradually reduce the engine load. Have the cause clarified and remedied immediately by an ABB Turbochar- ging Service Station. Have parts assessed for damage and, if necessary, replaced by an ABB Turbocharging Service Station. © Copyright 2020 ABB. All rights reserved.
Page 77: Malfunctions When Stopping
Possible causes Remedy Turbochar- Turbocharger contaminated Clean Bearing damaged Contact an ABB Turbocharging Service Station Rotor rubbing Foreign object in the turbocharger Table 25: Malfunctions when stopping – Shortened runout time © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 78: Speed Measurement System
If none of the measures described above remedy the malfunc- causes of tion, it is recommended to have the speed measurement sys- malfunc- tem checked by an ABB Turbocharging Service Station. tion Table 26: Malfunctions of the speed measurement system © Copyright 2020 ABB. All rights reserved.
Page 79: Disassembly And Assembly
(Table of tightening torques →92). Tightening torques for assembly devices Unless described otherwise, the screws and nuts of the assembly devices supplied by ABB must be tightened so they are tight-fitting. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 80 Use assembly devices only for the described applica- tions. ¡ Lifting gear Equipment for the lifting and transporting of loads (ropes, chain block, crane). Lifting gear is not supplied by ABB. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 81: Weights Of Assemblies
The total weight of the complete wall insert is made up of the wall insert and diffuser as- semblies. A165-L A170-L A175-L A180-L A185-L A190-L 1290 1770 Table 28: Weight of wall insert [kg] © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 82: Disassembly And Assembly Of The Filter Silencer Casing
Fig. 23: Dismantling the filter silencer casing 01, 02 Bottom part 03, 04, 07, 08 Side part 05, 06, 09 Circumferential part 10, 11 Flange The complete filter silencer casing has the part number 81500. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 83: Fig. 24: Fitting The Filter Silencer Casing
The location of screw (A) serves as a reference for the correct assembly of the filter silencer casing. Before disassembling the bottom part (01), mark the location of screw (A). Fit all remaining screws on the bottom part (01). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 84: Fig. 25: Fitting The Filter Silencer Casing
Fit the side parts (03) and (04) with the screws on the filter silencer and on the bottom part. Fit the side parts (07) and (08) with the screws on the filter silencer, on the bottom part, and on the side parts (03, 04). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 85: Fig. 27: Fitting The Filter Silencer Casing
Fig. 27: Fitting the filter silencer casing Insert the flanges (10) and (11) laterally between the side parts and fit the screws. Fig. 28: Fitting the filter silencer casing Fit the circumferential part (05) with the screws. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 86: Fig. 29: Fitting The Bellows
Tighten all screws of the side parts (03, 04, 07, 08) and the flanges (10, 11). Tighten all screws of the circumferential parts (05, 06, 09). Bellows Fig. 29: Fitting the bellows Fit bellows (C) with frame (F), screws (S) and nuts (N) on the filter silencer casing. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 87: Dismantling The Filter Silencer
Fig. 30: Dismantling the filter silencer 1. Attach lifting gear to the eyelets of the filter silencer (81000). 2. Loosen nuts (72004) and remove with washers (72003). 3. Remove and put down filter silencer. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 88: Fig. 31: Dismantling The Filter Silencer
1. Attach the lifting gear to the front lug and rear eyelet of the filter silencer (81000). 2. Loosen nuts (72004) and remove with washers (72003). 3. Remove and put down filter silencer. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 89: Dismantling The Filter Silencer With Noise Package
3. Loosen nuts (72004) and remove with washers (72003) and insulating discs (81302). 4. Remove and put down filter silencer. 5. Remove the gasket (81301). 6. Loosen counter-sunk screws (74043), remove with air outlet silencer (74040) and gasket (74042). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 90: Dismantling Wall Insert And Diffuser
4. Fit shackle (90195) with lifting gear on P1 of lifting device (90190). 5. Fit lifting device (90190) with crane on upper area of wall insert (77000). 6. Change the position of the shackle with the lifting gear to P2 of the lifting device (90190). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 91: Fig. 34: Moving Out Wall Insert
Fig. 35: Putting down wall insert Put down wall insert (77000) with diffuser (79000) in horizontal position and use appro- priate supports to prevent it from falling over and rolling away. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 92: Fig. 36: Putting Down Wall Insert
1. Put wall insert (77000) down on suitable supports. 2. Tilt wall insert (77000) with diffuser (79000) against lifting device (90190). 3. Place wall insert with the flange (F) on the underlay. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 93: Fig. 37: Dismantling The Diffuser
8 Disassembly and assembly / 8.6 Dismantling wall insert and diffuser Fig. 37: Dismantling the diffuser 4. Loosen and remove screws (77015). 5. Remove O-rings (79020, 79021). 6. Attach lifting gear (L) to the diffuser (79000). 7. Remove and put down diffuser. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 94: Axial Clearance A Prior To Disassembly
Clearances outside the tolerance Serious damage to engines or property can be caused by clearances outside the tolerance and excessively worn parts. Have the components assessed and, if necessary, replaced by an ABB Tur- bocharging Service Station. Fig. 38: Measuring axial clearance A The axial clearance (A) of the rotor should always be measured before and after service work.
Page 95: Dismantling The Insulation (≤ A175-L)
1. Loosen and remove screws of insulation jackets (51200) from gas outlet casing (61001). 2. Loosen and remove all connecting plates of insulation jackets. 3. Remove insulation jackets. 4. Detach flange connection between gas inlet casing (51001) and bellows. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 96: Dismantling The Gas Inlet Casing (≤ A175-L)
Dismantling the gas inlet casing (A175-L and smaller) – screwed variant Fig. 40: Dismantling the gas inlet casing (A175-L and smaller) – screwed variant If one of the screws (61009) shears off when loosening, an ABB Turbocharging Service Station should be contacted.
Page 97: Fig. 41: Dismantling The Gas Inlet Casing (A175-L And Smaller) - Threaded Stud Variant
A175-L Table 31: Maximum admissible loosening torque (51087) If a threaded stud (51086) shears off when loosening, an ABB Turbo Systems Service Sta- tion should be contacted. If a threaded stud (51086) works loose when removing the nut (51087), it should be refit- ted, after disassembling the gas outlet casing, up to the stop in the gas inlet casing until hand-tight.
Page 98: Dismantling The Nozzle Ring (≤ A175-L)
8.10 Dismantling the nozzle ring (≤ A175-L) Fig. 42: Dismantling the nozzle ring (A175-L and smaller) 1. Loosen screws (56014) and remove with washers (56011). 2. Remove and put down nozzle ring (56001). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 99: Dismantling The Gas Inlet Casing (≥ A180-L)
Variant with screw Fig. 43: Dismantling the gas inlet casing (A180-L and larger) – screwed variant If one of the screws (61009) shears off when loosening, an ABB Turbocharging Service Station should be contacted. 1. Dismantle both halves of the insulation segment (51215) and remove with all fixing ele- ments.
Page 100: Fig. 44: Dismantling The Gas Inlet Casing (180-L And Larger) - Threaded Stud Variant
1610 Table 32: Maximum admissible loosening torque (51087) If a threaded stud (51086) shears off when loosening, an ABB Turbo Systems Service Sta- tion should be contacted. If a threaded stud (51086) works loose when removing the nut (51087), it should be refit- ted, after disassembling the gas outlet casing, up to the stop in the gas inlet casing until hand-tight.
Page 101: Dismantling The Nozzle Ring (≥ A180-L)
Fig. 45: Fitting the nozzle ring holder 1. Remove screws (B 2. Fit the nozzle ring holder (90477) with screws (B ) at the top of the flange of the gas inlet casing (51001). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 102: Fig. 46: Dismantling The Nozzle Ring
4. Screw the screws (B ) into the nozzle ring holder. 5. Remove screws (B Fig. 47: Put down the nozzle ring Use the crane to remove and put down the nozzle ring (56001). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 103: Fitting The Nozzle Ring (≤ A175-L)
) with the flange connection (A ) and slide the nozzle ring (56001) into the gas inlet casing (51001). 2. Fit screws (56014) with high-temperature grease and with washers (56011). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 104: Fitting The Gas Inlet Casing (≤ A175-L)
2. Loop around the gas inlet casing (51001) with the lifting gear and secure it to the crane. 3. Push gas inlet casing over the guide studs up to the gas outlet casing. 4. Coat two opposite screws (61009) with high-temperature grease and screw in. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 105: Fig. 50: Fitting The Gas Inlet Casing (A175-L And Smaller) - Threaded Stud Variant
1) Pre-tightening torque of the nuts 1. Coat threaded stud (51086) with high-temperature grease, screw in up to the stop in the gas outlet casing (61001) and tighten hand-tight. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 106: Fitting The Insulation (≤ A175-L)
2. Fit the insulation jackets (51200) on the gas inlet casing (51001) with the screws. 3. Fit connecting plates of insulation jackets with screws. 4. Fit insulation jackets with screws on gas outlet casing (61001). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P...
Page 107: Fitting The Nozzle Ring (≥ A180-L)
Fig. 52: Looping around the nozzle ring (A180-L and larger) Loop around the nozzle ring (56001) with lifting gear on the nozzle ring holder (90477) and fix on the crane. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 108: Fig. 53: Fitting The Nozzle Ring (A180-L And Larger)
4. Coat screws (56014) with high-temperature grease and fit with washers (56011). 5. Remove screws (B ) along with the nozzle ring holder (90477). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 109: Fitting The Gas Inlet Casing (≥ A180-L)
8. Remove the lifting gear. 9. Connect the flanges of the gas inlet casing and the bellows. 10. Fit the insulation segments (51215). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 110: Fig. 55: Fitting The Gas Inlet Casing (A180-L And Larger) - Threaded Stud Variant
7. Remove the lifting gear. 8. Connect the flange of the gas inlet casing and the bellows. 9. Fit the insulation segments (51215). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 111: Axial Clearance A After Assembly
Clearances outside the tolerance Serious damage to engines or property can be caused by clearances outside the tolerance and excessively worn parts. Have the components assessed and, if necessary, replaced by an ABB Tur- bocharging Service Station. Fig. 56: Measuring axial clearance A The axial clearance (A) of the rotor should always be measured before and after service work.
Page 112: Fitting The Diffuser
3. Fit new O-rings (79020, 79021) on the diffuser. 4. Degrease screws (77015) and threaded holes in wall insert. 5. Coat threads of the screws with Loctite® 542. 6. Fit screws. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 113: Fitting Wall Insert
8 Disassembly and assembly / 8.20 Fitting wall insert 8.20 Fitting wall insert Fig. 58: Positioning wall insert Carefully bring wall insert (77000) into vertical position with the lifting device (90190). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 114: Fig. 59: Fitting Wall Insert
7. Move the wall insert fully in, then remove the guide studs (90320). Check the correct position of both casings (arrow markings are aligned to one another). 8. Fit screws (72011). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 115: Fitting The Filter Silencer
Fig. 60: Fitting the filter silencer Product Size Tightening torque [Nm] A165-L A170-L A175-L A180-L A185-L A190-L Table 42: Tightening torque (72004) 1. Attach lifting gear to the eyelets of the filter silencer (81000). © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 116: Fig. 61: Fitting The Filter Silencer
1. Attach the lifting gear to the front lug and rear eyelet of the filter silencer (81000). 2. Position filter silencer on compressor casing. 3. Fit nuts (72004) with washers (72003) and tighten. Fit insulation as far as necessary. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 117: Fitting The Filter Silencer With Noise Package
Fig. 62: Fitting the filter silencer with noise package Product 72004 [Nm] 72043 [Nm] A165-L 130 Nm 45 Nm A170-L 200 Nm 45 Nm A175-L 300 Nm 45 Nm A180-L 420 Nm 45 Nm A185-L 570 Nm 45 Nm A190-L 710 Nm 45 Nm Table 44: Tightening torque (51087) © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 118 4. Fit nuts (72004) with washers (72003) and insulating discs (81302) and tighten. 5. Fit insulation ring (81300). 6. Fit air outlet silencer (74040) with gasket (74042) and secure with counter-sunk screws (74043). Fit insulation as far as necessary. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 119 Operation Manual / 4 Product description / A100-L 8 Disassembly and assembly / 8.22 Fitting the filter silencer with noise package © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 120: Table Of Tightening Torques
8 Disassembly and assembly / 8.23 Table of tightening torques 8.23 Table of tightening torques Tightening torques [Nm] Fig. 63: Overview of tightening torques Fig. 64: Tightening torques of speed sensor © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 121: Table 45: Overview Of Tightening Torques
1) Tighten crosswise 2) Pre-tightening torque of the screws Use hydraulic tool for tightening torques exceeding 500 Nm. Thread size Tightening torque [Nm] M12 (compressor casing insulation) Table 46: Tightening torque, insulation © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 122: Taking A Turbocharger Out Of Operation
Impermissible vibrations and unbalance values can cause serious damage to the engine or property during operation. It is imperative that the following work is carried out after emergency operation with a locked rotor by an ABB Turbocharging Service Station: Remove rotor and check for unbalance...
Page 123: Taking Defective Turbochargers Out Of Operation
If necessary, remove the nozzle ring (see chapter Engines without bypass around the turbocharger →98) Table 47: Bypass procedure Continue to operate engine in accordance with enginebuilder's instructions. Observe the prescribed power reduction. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 124: Fig. 65: Locking The Rotor
Continue to operate engine in accordance with enginebuilder's instructions. Observe the prescribed power reduction. 9.2.3 Locking the rotor Fig. 65: Locking the rotor Product Thread Tightening torques of screws B [Nm] A165-L A170-L A175-L A180-L © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 125: Table 48: Tightening Torque
Close the lubricating oil supply to the turbocharger. Open the bypass around the turbocharger. Observe specifications from enginebuilder. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 126: Fig. 66: Ensuring Clamping Of The Cover Ring
If the nozzle ring is removed for emergency operation, the clamping of the cover ring (57001) to the gas outlet casing must be ensured. In this case, additional washers (01) must be provided in accordance with the following table. These washers (01) are not supplied by ABB. Fig. 66: Ensuring clamping of the cover ring...
Page 127: Fig. 67: Position Of Cover Plates
The chapter is only applicable for engines with several turbochargers and joint air and ex- haust gas receivers. The cover plates for the compressor casing outlet, gas inlet and gas outlet are not included in the ABB scope of delivery. The following figure shows the positions where to fit the cover plates.
Page 128 Operation Manual / 4 Product description / A100-L 9 Taking a turbocharger out of operation / 9.2 Taking defective tur- bochargers out of operation © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 129: Mothballing The Turbocharger
If the acid number (TAN) is greater than 2 mg KOH/g, the following mothballing measures are necessary after taking the engine out of operation: Dismantle the turbocharger. The rotor and bearing parts must be dismantled and subsequently refitted by an ABB Tur- bocharging Service Station. Clean all parts.
Page 130: Taking The Engine Out Of Operation For More Than 12 Months
¡ The casings of the turbocharger remain attached to the engine, the rotor and bearing parts are dismantled by an ABB Turbocharging Service Station and stored separately ¡ The turbocharger is completely removed, either as a whole unit or in individual parts For the measures always necessary for preparing the turbocharger parts for mothballing, see section Taking the engine out of operation for up to 12 months, subsection Preparations...
Page 131: Disposing Of Turbocharger Components
Dispose of metals as scrap metal for recycling. Dispose of non-metallic materials as waste. Dispose of residues of lubricants as waste oil. Dispose of electronic components as electronic waste. Dispose of thermal insulation as hazardous waste. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 132: Spare Parts
Designation and part number. Spare parts can be ordered from any ABB Turbocharging Service Station. If different model variants are not taken into account in this document, contact an ABB Turbocharging Service Station. The customer spare part sets (97070 / 97071) are available for the work described in the op- eration manual.
Page 133: Table 52: Customer Spare Part Set (97071)
77040 O-ring 79020 O-ring 79021 Table 52: Customer spare part set (97071) Dispose of replaced parts and parts that are not reusable in a professional and environ- mentally compatible manner. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 134: View Of Turbocharger With Part Numbers
Operation Manual / 4 Product description / A100-L 12 Spare parts / 12.2 View of turbocharger with part numbers 12.2 View of turbocharger with part numbers Fig. 68: View of turbocharger with part numbers © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 135: Table 53: Turbocharger With Part Numbers
79021 (in the customer spare part set) O-ring 81000 Filter silencer 81300* Insulation ring (option) 81301* Gasket (option) 81302* Insulating disc (option) Table 53: Turbocharger with part numbers * Depending on the specification of the turbocharger © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 136: View Of Cartridge Group With Part Numbers
View of cartridge group with part numbers Fig. 69: View of cartridge group with part numbers NOTICE Cartridge group The cartridge group is not delivered as a fitted assembly. Spare parts must be ordered individually. © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 137: Table 54: Cartridge Group With Part Numbers
Socket screw 42458 Blind flange 86505 Speed sensor 86506 (in the customer spare part set) O-ring Table 54: Cartridge group with part numbers * Depending on the specification of the turbocharger © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Rev.P January 2020...
Page 138: Figures
Fig. 30: Dismantling the filter silencer ..... 59 ger) – threaded stud variant........82 Fig. 31: Dismantling the filter silencer...... 60 Fig. 56: Measuring axial clearance A ......83 Fig. 57: Fitting the diffuser .......... 84 © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Revision P January 2020...
Page 139 Fig. 66: Ensuring clamping of the cover ring ..98 Fig. 67: Position of cover plates ........ 99 Fig. 68: View of turbocharger with part numbers 106 Fig. 69: View of cartridge group with part numbers... © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Revision P January 2020...
Page 140 Table 24: Malfunctions when stopping – Runout Table 54: Cartridge group with part numbers..109 noises................49 Table 25: Malfunctions when stopping – Shortened runout time..............49 Table 26: Malfunctions of the speed measurement system ................50 © Copyright 2020 ABB. All rights reserved. HZTL4034_EN Revision P January 2020...

This manual is also suitable for:

Xac22125

ABB A165-L35 Operation Manual

Introduction

Safety

Product Description

Figures

Quick Links

Chapters

Related Manuals for ABB A165-L35

Summary of Contents for ABB A165-L35

This manual is also suitable for:

Table of Contents
