QUICK START GUIDE
For a full explanation of all features and instructions, please refer to the User's Guide
(available for download from www.motorolastore.com).
1. Setting up your Digital Video Baby Monitor
MODELS:
MBP35XL,
A. Connecting power supply for the Baby Unit.
MBP35XL-2,
MBP35XL-3,
MBP35XL-4
B. Installing the battery pack for the Parent Unit.
WARNING:
Strangulation Hazard:
Children have
STRANGLED in cords.
Keep this cord out of the
reach of children (more
than 1m away).
Never use extension
cords with AC Adapters.
Only use the AC Adapters
provided.
Black
Red
• Connect the small plug of the power adapter to the
Baby Unit and the other end to a suitable mains power
socket.
• Only use the enclosed adapter (6V DC/800mA).
• Ensure the ON/OFF switch is at "ON" position.
• Insert the wire tab of the rechargeable battery pack
into the contact slot as shown above and fit the battery
pack into the compartment.
UK EN
Advertisement
Table of Contents
Related Manuals for Motorola MBP35XL
Summary of Contents for Motorola MBP35XL
- Page 1 For a full explanation of all features and instructions, please refer to the User’s Guide (available for download from www.motorolastore.com). 1. Setting up your Digital Video Baby Monitor MODELS: MBP35XL, A. Connecting power supply for the Baby Unit. MBP35XL-2, MBP35XL-3, MBP35XL-4 •...
- Page 2 C. Fastening the cover for the Parent Unit. • Small cross head or Flat end screw driver. D. Connecting power supply for the Parent Unit. • Connect the small plug of the power adapter to the parent unit and the other end to a suitable mains power socket.
-
Page 3: Basic Operation Of The Keys
2. Basic operation of the keys Parent Unit ON/OFF button Press and hold to switch on/off the Unit. Press to tilt the camera upward or downward. Press to UP/DOWN buttons adjust menu settings. <> Press to pan the camera left or right. Press to access LEFT/RIGHT buttons different menu options. -
Page 4: General Information
+44 (0) 8187 62092 (ROI) Email: support@motorolastore.com Consumer Products and Accessories Limited Warranty ("Warranty") Thank you for purchasing this Motorola branded product manufactured under license by Binatone Electronics International LTD ("BINATONE"). What Does this Warranty Cover? Subject to the exclusions contained below, BINATONE warrants that this Motorola branded product ("Product") or certified accessory ("Accessory") sold for use with this product that it manufactured to... - Page 5 PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MOTOROLA OR BINATONE BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE...
- Page 6 Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of MOTOROLA or BINATONE, are excluded from coverage. Use of Non-Motorola branded Products and Accessories. Defects or damage that result from the use of Non-Motorola branded or certified Products or Accessories or other peripheral equipment are excluded from coverage.
- Page 7 Altered Products. Products or Accessories with (a) serial numbers or date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola branded housings, or parts, are excluded from coverage.
-
Page 8: Disposal Of The Device (Environment)
Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee for this product. MOTOROLA and the Stylized M Logo, are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other Printed in China trademarks are the property of their respective owners.
