Summary of Contents for Lunar Artefacts Pointer Instruments Classic
- Page 1 THE POINTER INSTRUMENT -- USER GUIDE -- LUNAR ARTEFACTS LONDON...
-
Page 2: Table Of Contents
CONTENTS: Specifications BoxContents ProductFeatures Overview Connections DPISettings ChargingBattery HelpandSupport... -
Page 3: Specifications
SPECIFICATIONS 72mm 40mm Model : Pointer Instruments Classic (LAPI-C-MK1) Interface : Bluetooth 5.0 | Wireless 2.4G dongle | USB-C Sensor : Pixart PAW 3805 Optical Sensor -Glass thickness minimum 5mm- DPI : 800 | 1200 | 2000 | 3000 Hand Orientation :... -
Page 4: BoxContents
BOXCONTENTS -1- The Pointer Instrument. -4- USB to USB-C cable. -2- Reusable frame. -5- User guide booklet. -3- USB dongle. -6- Soft Pouch. -
Page 5: ProductFeatures
PRODUCTFEATURES - Full-Grain French Leather Top - Lightly treated calf leather maximises tactile comfort and ages well. - Solid Brass or Aluminium Base - Polished brass and aluminium allow easy maintenance and age well. - Replaceable Top Cover - Allows customisation of materials and colour combinations. - Triple Modes: Bluetooth 5.0 | 2.4G | Cable - Multi-modes maximise flexibility and allow easy connection. -
Page 6: Overview
OVERVIEW -1- Leather top latch point -2- Left mouse button -3- Right mouse button -4- Scroll wheel -5- Charge indicator -6- Battery compartment -7- Magnetic latch -8- USB-C Socket -9- Battery gauge -10- Power switch -11- USB Dongle -12- DPI (Sensitivity) button -13- Tracking sensor -14- Connection button -15- Wireless charging point... -
Page 7: Connections
CONNECTIONS - Bluetooth Connection - Power on the mouse. Turn the ON/OFF switch to the ON position. Click and hold the connection button until the Bluetooth indicator is ON. Press the connection button to switch to the Bluetooth mode with the Bluetooth indicator ON. 3 sec Press and hold down the connection button for 3 seconds and then release. - Page 8 - 2.4G Dongle Connection - Retrieve the Dongle from the base of the mouse. Insert the Dongle into the device. Switch the power button to the ON position. Press the connect button to Dongle (2.4G) mode with the Dongle indicator ON. The mouse is now ready for use.
-
Page 9: DpiSettings
DPISETTINGS DPI settings: Press to change DPI settings. 3000 DPI 2000 DPI 1200 DPI 800 DPI CHARGING|BATTERY - Charging - The wireless charging point is located towards the rear of the device. USB cable (approx. 2 hrs) Top battery indicator light: Fast double flashes - Low battery Slow breathing light - Charging Continuously on - Fully charged... -
Page 10: HelpAndSupport
Here you will find multi-language guides, FAQ and other useful information regarding the Pointer Instrument, as well as the contact form to contact Customer Support. Lunar Artefacts Ltd. 38 Spital Square, London, E1 6DY, United Kingdom support@lunarartefacts.com www.lunarartefacts.com ©2022... - Page 11 © MMXXII Lunar Artefacts...
