COLOR TELEVISION
USER'S GUIDE
IMPORTANT NOTE TO THE CUSTOMER
In the sp a c es b elow, enter the mod el and serial numb er of your television (loc ate d
at the re ar of the television c a binet). Sta ple your sales re c eipt or invoic e to the
insid e cover of this guid e. K e e p this user's guid e in a convenient pla c e for
future referenc e. K e e p the c arton and original p a cka ging for future use.
Serial Numb er
Page 1
Illustration of AV-27D302 and RM-C 303 G
For models:
AV-27D302
AV-27D202
AV-20D202
AV-27230
Mod el Numb er
LC T 0924-001A-A
0101-T N -JII-JIM
