Summary of Contents for Condeco Connect
- Page 1 Screen Mounting Instructions Condeco Group Ltd 2 Harbour Exchange Square London E14 9GE www.condecosoftware.com...
-
Page 2: Table Of Contents
Contents Introduction ................................... 3 Cable routing ..................................4 Recommended screen height ............................4 Wall mount ..................................... 5 Glass mount ................................... 6 Cabling ....................................7 Contact ....................................9... -
Page 3: Introduction
Introduction Congratulations to your purchase of you Condeco Connect meeting room screens. This document contains mounting instructions for your screens. The screens can be mounted to solid or partition walls using the mounting plate supplied in the box and suitable fixings. -
Page 4: Cable Routing
Cable routing When deciding where to mount the Condeco room screen please consider the locations of the cable entry points on the back plate on the top left and right, and the bottom center, highlighted below. Typically, the power or network cable is running aside, or inside the doorframe, entering the mounting plate from the side. -
Page 5: Wall Mount
Wall mount Once desired screen height is finalised, the back needs to be fixed to the wall using screws to secure the back plate in position. Fixing Point Fixing Point... -
Page 6: Glass Mount
Glass mount The following illustration shows a screen mounted to Glass. Double- Screen Back Plate sided sticky pad To fix the screen to a glass wall, attach the double-sided sticky pad* to the back plate, and then firmly press the back plate against the glass. If you mount on glass, you may decide that you want to fit a manifestation behind the device to hide cabling and fixings. -
Page 7: Cabling
Cabling Once the back plate has been fixed to the wall connect the LAN cable or the power cable to the rear of the Condeco screen. Power Çable Network Cable Input Network Port Feed the LAN cable through the appropriate cable input hole in the back plate. - Page 8 Clip the screen on to the back plate and screw the unit in place using the screws provided so it can’t be removed. Fixing screws to fix the unit to the back plate.
-
Page 9: Contact
Contact Condeco Group 8th Floor Exchange Tower 2 Harbour Exchange Square London E14 9GE United Kingdom...
