Exclusive Control Unit for Safety Light Curtain
SF-C10
SERIES
Category 4 PLe SIL3
The control category differs depending on the configuration and wiring of the external circuit.
* The contents of this catalog are as of October 2017.
2022.5
For the latest information, please visit our company website.
Advertisement
Related Manuals for Panasonic SF-C10 Series
Summary of Contents for Panasonic SF-C10 Series
- Page 1 Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES Category 4 PLe SIL3 The control category differs depending on the configuration and wiring of the external circuit. * The contents of this catalog are as of October 2017. 2022.5 For the latest information, please visit our company website.
- Page 2 Exclusive Control Unit for Safety Light Curtain SF-C10 SERIES Listing Certified Certified (SF-C11/C13 only) Category 4 PLe SIL3 The control category differs depending on the configuration and wiring of the external circuit. Less setup time for safety circuits Plug-in type control unit SF-C11 / SF-C14EX(-01) Quick-connection Easy setup requiring no torque control...
- Page 3 SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain Building of muting control circuits is easy SF-C14EX(-01) The method used to build the safety circuit is selectable It is possible to build muting control circuits using a stand-alone safety light curtain from the SF4B / SF4B-G series. The SF-C14EX(-01) application expansion unit allows the safety light curtain, muting sensors and muting lamps to be connected together directly, so that muting control circuits can be built very easily.
- Page 4 SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain Three safety circuit systems can be controlled independently so that equipment can be stopped all together or partially SF-C14EX(-01) Motors that use muting control and those that do not use it can be controlled independently! Controls the motors that use muting control (robots) and the motors that do not use muting control (turntables) with a single unit.
-
Page 5: Order Guide
SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain ORDER GUIDE Designation Appearance Model No. Applicable cable (Note) Description Safety light curtain connection cable: Use 8-core cable with connector to connect to the safety SFB-CB□ Connector light curtain. (For SF4B series) SF-C11 connection type Compatible with up to Control Category 4. -
Page 6: Specifications
SF4D / SF4B / SF4B-G / SF2B series SF4B / SF4B-G series Safety light curtain manufactured by Panasonic Industrial Devices SUNX EN 61496-1 (Type 4), EN 55011, EN ISO 13849-1 (Category 4, PLe), IEC 61496-1 (Type 4), ISO 13849-1 (Category 4, PLe),... - Page 7 SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain SPECIFICATIONS Model No. SF-C14EX(-01) (Note 2) Item Connectable safety light curtains SF4B / SF4B-G series IEC 61496-1 (Type 4), EN 55011, EN ISO 13849-1 (Category 4, PLe), IEC 61496 (Type 4), ISO 13849-1 (Category 4, PLe), Applicable standards JIS B 9704-1 (Type 4), JIS B 9705-1 (Category 4, PLe), ANSI/UL 61496-1 (Type 4), UL 1998 (Class 2) CE marking directive compliance...
- Page 8 SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain SAFETY LIGHT CURTAIN WIRING DIAGRAMS Wiring diagram of SF-C11 and SF4B / SF4B-G series or SF2B series (Control Category 4 or 2) For PNP output (minus ground) When connecting the SF-C11 to the safety light curtains, make •...
- Page 9 SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain SAFETY LIGHT CURTAIN WIRING DIAGRAMS Wiring diagram of SF-C13 and SF4B / SF4B-G series or SF2B series (Control Category 4 or 2) For PNP output (minus ground) For NPN output (plus ground) •...
- Page 10 SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain SAFETY LIGHT CURTAIN WIRING DIAGRAMS Wiring diagram of SF-C14EX(-01) and SF4B / SF4B-G series (Control Category 4) • When connecting the SF-C14EX to For PNP output (minus ground) the safety light curtains, make sure to use the following connecting cable.
-
Page 11: Precautions For Proper Use
SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain PRECAUTIONS FOR PROPER USE Part description and function [SF-C14EX(-01)] Output waveform (Safety output ON) [SF-C14EX(-01)] • When safety output is ON, self-diagnosis of the output Receiver side connector circuit is carried out, so that the output transistor will Emitter side connector periodically turn OFF. - Page 12 If the seal is peeled off canceled immediately. or broken, SF-C10 series will not be certified as “Safety equipment” and will not be covered by our guarantee. Others Do not open! •...
- Page 13 SF-C10 SERIES Exclusive Control Unit for Safety Light Curtain DIMENSIONS (Unit: mm in) The CAD data can be downloaded from our website. SF-C11 SF-C12 Control unit Control unit 2-ø6 ø0.236 5.000 67.5 2-ø10 ø0.394 3.150 2.657 0.276 0.236 1.181 54.1 0.126 1.811 2.130...
- Page 14 Disclaimer The applications described in the catalog are all intended for examples only. The purchase of our products described in the catalog shall not be regarded as granting of a license to use our products in the described applications. We do NOT warrant that we have obtained some intellectual properties, such as patent rights, with respect to such applications, or that the described applications may not infringe any intellectual property rights, such as patent rights, of a third party. Panasonic Industry Co., Ltd. Industrial Device Business Division 7-1-1, Morofuku, Daito-shi, Osaka 574-0044, Japan industrial.panasonic.com/ac/e/ Specifications are subject to change without notice. ⓒ Panasonic Industry Co., Ltd. 2022.5 Printed in Japan...
