Summary of Contents for EVERCROSS Pro EV10K
- Page 1 EV10K Pro V2022.0.1 User Manual...
- Page 2 Step 3: Click the "Ask a Question" button. Choose your topic from list displayed. Step 4: Select Contact seller. *If you purchased EVERCROSS products by other platforms or channels, please also find the corresponding seller contact support. Thanks for your support and patience!
-
Page 3: Table Of Contents
CONTENTS Package Contents···························································03 Product Overview························································04-06 Assembly and Set-Up·······················································07 Charge Your Scooter························································08 How To Ride······························································09~10 Smart Phone App·····························································11 Safety Reminder························································12~15 Safety Instructions······················································16~17 Folding your scooter·························································18 Daily Care and Maintenance·········································19~21 Specifications····························································21~22 Product Warranty·····························································23... - Page 4 Thanks for choosing the EVERCROSS Electric Scooter EV10K Pro (hereinafter referred to as EV10K Pro)! The EV10K Pro is not only a short-distance transportation product that is easy to fold and carry, also a stylish sport entertainment equipment. Enjoy your ride and connect with riders worldwide!
-
Page 5: Package Contents
PACKAGE CONTENTS Accessories L-shape Allen Key Assembled electric scooter Charging Adapter Screw × 4 *When unpacking your EV10K Pro, please verify that the above items are included in the package. If any components are missing, please contact us. After verifying that all components are present and in good condition, you can assemble your new EV10K Pro. -
Page 6: Product Overview
PRODUCT OVERVIEW 1. Product Diagram Turn Signal Button Handlebar Accelerator Headlight Control Panel & Power Button Brake Lever Bell Turn left signal on/off Stem Turn right signal on/off Buckle Quick Release Lever Brake Light Folding Mechanism Disc Brake Kickstand Front Shock Absorption Wheel Motor Battery Compartment Solid Front Wheel... - Page 7 2. Dashboard & Power Switch Speedometer: Display the current speed of the scooter, as well as to display error codes. Bluetooth: The icon indicates that the scooter has been successfully connected to the mobile device. Modes: for pedestrian mode (the maximum speed is 6 km/h, it is easier to push the scooter along as you walk).
- Page 8 4. Troubleshooting Error Code Failure Description Solution Check if the brake wire is connected properly or “E1/F1” Brake Failure replace the brake lever. Check if the accelerator wire is connected “E2/F2” Accelerator Failure properly or replace the accelerator. Check if the communication wire between the “E3”...
-
Page 9: Charge Your Scooter
CHARGE YOUR SCOOTER Charging step Open the charge Insert the Close the charge port port cover. charge plug. cover when finished. WARNING Do not charge if the charge port or charge cable is wet. Do not charge or use your battery if it is damaged or see trace of water. Close the charge port cover when not charging. - Page 10 4. Release the accelerator and the speed will slowly 5. Tilt your body to the steering direction as you turn, drop to a stop; If you need to decelerate quickly, slowly and slowly turn the handlebar. squeeze the brake lever while releasing the accelerator. WARNING When sudden braking, you may risk serious injury due to loss of traction and falls.
-
Page 11: Smart Phone App
SMART PHONE APP Your EV10K Pro is an App-enabled electric scooter that works with most mobile devices. You must download the app in order to change certain features of your electric scooter. You could download the APP in the following two ways: Method 1: Search for the APP from either the App Store or Google Play Store to download. -
Page 12: Safety Instructions
SAFETY INSTRUCTIONS 1. This electric scooter is a leisure device. But once they're in a public area, they'll be seen as vehicles, subjecting to any risks faced by vehicles. For your safety, please follow instructions in the manual and traffic laws and regulations set forth by government and regulatory agencies. We will not be liable for any property damage, personal injury, accident or legal dispute caused by the rider's inexperience or failure to use the product. - Page 13 5. Check the scooter before every use. When you note loosen parts, low battery alerts, flat tires, excessive wear, strange sounds, malfunctions and other abnormal conditions, stop riding immediately and call for professional support. 6. Please pay attention to the road surface when riding, avoid obstacles (including but not limited to wet and slippery ground, loose sand, gravel ground and ice surface).
-
Page 14: Daily Care And Maintenance
DAILY CARE AND MAINTENANCE Cleaning If you see stains on the scooter’s body, wipe them off with a damp cloth. If the stains won’t scrub off, put on some toothpaste, and brush them with a toothbrush, then wipe them off with a damp cloth. If you see scratches on plastic parts, use sandpaper or other abrasive materials to polish them. - Page 15 If the scooter is expected to be left idle for more than 30 days, please fully charge the battery and place it in a dry and cool place. Keep in mind to recharge it every 60 days to protect the battery from potential damage which is beyond limited warranty.
-
Page 16: Specifications
SPECIFICATIONS Electric Scooter Name Product EV10K Pro Model Scooter: L × W × H(cm) 110*51*118 cm Dimensions After Folding: L × W × H(cm) 110*51*54 cm Net Weight (kg) 16 kg (35.3 LBS) Weight Gross Weight (kg) 19.3 kg (42.5 LBS) Load Weight (kg) 150 kg (330 LBS) Riding... - Page 17 Unusual temperature/short circuit/under voltage/ Intelligent Battery Battery Pack overcurrent/dual overcharge/ Management System dual overdischarge protections Rated Power (W) 350 W Wheel Motor Peak Power (W) 500 W 100–240 ~ Input Voltage (V) Charging Adapter Output Voltage (V) 42 V Output Current (A) Tire Tires 10 inch honeycomb solid tire...
-
Page 18: Product Warranty
2)The warranty will be performed in such a way that we shall decide whether to repair the defective parts or to replace them with working parts free of charge. EVERCROSS reserves the right to exchange the product for a replacement product of equal value if the product sent in cannot be repaired within a reasonable time or at a reasonable cost. - Page 19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
