ProSolar RoofTrac Installation Manual

UL2703
WARNING:
All Professional Solar Products (ProSolar
and tested to withstand stated specifications (as stated on
published specification sheets) when installed properly.
Failure to install properly may decrease the performance of
installation.
SAFETY:
All regional safety requirements should be followed
when installing Professional Solar Products. All tools and
equipment located on the roof should be secured to avoid
falling object hazards. All equipment/tools should be properly
maintained and inspected prior to use. Any exposed studs
should be protectively capped to avoid injury. This racking
system may be used to ground and/or mount a PV module
complying with UL 1703 only when the specific module
frame has been evaluated for grounding and/or mounting
compliance with the included instructions. This installation
manual is intended for use by professional installers with a
working knowledge of construction principles.
Tool List
• Cordless impact wrench
• Cordless drill
• 1/2" Irwin #10 Unibit
• 1/2" deep socket
COPYRIGHT PROFESSIONAL SOLAR PRODUCTS (ProSolar
manual is property of ProSolar
trademarks for ProSolar
Class A
Fire Rated
® ) are engineered
• Torque wrench
• RoofTrac ® rail spreader (optional)
• Reciprocating saw
• Flashing
Page 1 of
® . ProSolar ® , TileTrac ® , RoofTrac
® .(v 2 )
Installation Manual
APPLICATION:
The RoofTrac ® mounting system consists of support rails and
top-down clamping hardware which is integrated with either
a TileTrac ® or FastJack ® attachment device. The RoofTrac
mounting system can be utilized on virtually all standard
construction residential roof tops, to install UL1703 approved
framed solar modules.
Symbol Legend
Explanation or Install Tip
Performance Information
• 3/8" Nut driver
• 3/16" Carbide drill
• 5/52" Hex L key
® ) 2021: All information contained in this
® , and FastJack ® are registered
RoofTrac
®
Important Product
Critical for Safety
®
