- Page 1 Fitting Instructions for YewdaleDefiant roller blinds ® (R42) Fitting Instructions YewdaleDefiant roller blinds ® (R42) Part no: 949 yewdale.co.uk...
- Page 2 Fitting Instructions YewdaleDefiant roller blinds(R42) ® Safety Instructions: Loops in pull cords, chains, tapes and inner cords that operate the product can cause strangulation To avoid strangulation and entanglement, keep cords out of the reach of young children. Cords may become wrapped around a child’s neck Move beds, cots and furniture away from window covering cords Do not tie cords together.
- Page 3 Call: +44 (0)1268 570900 Fax: +44 (0)1268 732509 Email: enquiries@yewdale.co.uk Visit: www.yewdale.co.uk...
- Page 4 Fitting Instructions YewdaleDefiant roller blinds(R42) ® R42 Spring assisted sidewinder control: N.B. This blind should be installed by a person competent in DIY. If in doubt please consult a professional. The standard plastic brackets are suitable for face or top-fixing.
- Page 5 R42 Spring assisted sidewinder control: 926325W Back Bar Top Fix Bracket 938031W Aluminium Back Bar 926325W Back Bar Top Fix Bracket OPTIONAL 911940 Retactable pin end 933010W Back Bar Screw 911864 911938W Barrel 36mm Bracket set 941002W Braked Spring Bracket Set...
- Page 6 Fitting Instructions YewdaleDefiant roller blinds(R42) ® R42 Spring assisted sidewinder control: Remove the blind and fix the pin-end bracket using appropriate screws/ plugs. Insert the spring sidewinder end of the blind into its bracket. Turn the clear plastic wheel at the pin-end of the blind to retract pin. Locate the blind into the pin-end bracket and turn the wheel in the opposite direction to extend the pin into the bracket.
- Page 7 Ensure the relevant child safety device is used to comply with BS EN13120:2009+A1:2014, BS EN16433:2014 and BS EN16434:2014 as follows: Chain Tidy The chain tidy will be attached to the chain when the blind arrives. The chain tidy should be at a maximum distance from the control mechanism, keeping the chain taut (not under excessive tension however as this could negatively affect the longevity and...
- Page 8 Yewdale, Enterprise Way, Wickford, Essex SS11 8DH Call +44 (0)1268 570900 +44 (0)1268 732509 Email enquiries@yewdale.co.uk Visit yewdale.co.uk For more information on all Yewdale products, please call the sales department.
