- Page 1 USER MANUAL SONICBOOM ® PLUS SMOKEJET V2.0 2021/04/23 Showven Technologies Co., Ltd.
-
Page 2: Technical Specifications
SHOWVEN or your local SHOWVEN partner for advise. \ Suggest use SHOWVEN original FX-S fog fluid, other fluid may lead to clog or malfunction. Please do not adding any other material such as pigment, water etc to the fuel bottle. -
Page 3: Operation Panel
\ MAX CONTINUOUS OUTPUT DURATION: 10s \ OUTPUT: 80000cuft/min \ FLUID CONSUMPTION RATE: 3min/L \ TANK CAPACITY: 5L \ DMX CHANNEL: 1/11/14 \ CONSUMABLES: FX-S ▲Operation Panel 1. Control button area MENU: switch through setup menu +: Parameter up; multiplex “TIMER” (smoke output time) -: Parameters down;... - Page 4 3. Setting Menu: Press “MENU” switch through setup menu. Options Range Explanation 1~499 DMX 512 Address Set DMX address Power Regulation Standard/Half Power Setting working power for the machine Color Optional 0~10 LED color set when manual firing Channel Mode 1/11/14 DMX channel mode switch Fog Volume...
- Page 5 DMX Channel 1, start a firing. ▲ Maintenance 1. Use SHOWVEN original fog fluid for the best effect of SONICBOOM. Warranty will be void if any other type fluid is used. 2. Don’t disassemble the machine by unauthorized person, modifications to the machine are not allowed.
- Page 6 A. Fluid spill: heat can’t effectively transmit to fog fluid, leads to insufficient atomization of the fog fluid in the heating pipe. Possible Reason 1: Use other type of low quality fog fluid instead of SHOWVEN original fog fluid. Possible reason 2: Use inappropriate fog fluid. For different types of fog fluid, the atomization temperature is different.
-
Page 7: Warranty Instructions
4. Damage caused by improper installation or use; For product damage not included in warranty range, we can provide paid service. Invoice and warranty card are necessary when applying for maintenance service from SHOWVEN. Warranty Card Product Name: Serial No. - Page 8 Showven Technologies Co., Ltd. Tel: +86-731-83833068 Web: www.showven.cn E-mail: info@showven.cn Add: Liuyang Economic Development Zone, Changsha, 410300, Hunan Province, P.R.China...
