Congratulations on your purchase of the Canyon, an extremely powerful yet easy-
to-use Delay and Looper pedal. Within the compact Canyon chassis there's a vast
array of awe-inspiring tones including 10 different types of delays: from pristine
digital to warm tape and more. We've even included an exquisite Deluxe Memory
Man emulation plus otherworldly octave delay and shimmer effects. Add in a full-
featured looper, built-in or external tap tempo with tap divide, a selection of
secondary controls and you're in for a truly grand delay experience.
- GETTING STARTED WITH THE CANYON -
1. Plug the supplied EHX9.6DC AC Adapter into the jack at the top of the
CANYON.
2. Plug your guitar into the INPUT jack and plug the OUTPUT jack into
your amplifier.
3. Turn the 11-position mode knob to the ECHO setting for a standard
digital delay.
4. Set the number of repeats with the FEEDBACK knob, the delay time
with the DELAY knob, and the delay volume with the FX LVL knob.
Getting started with the CANYON
Secondary Controls Chart
Warranty Information and FCC Compliance
CANYON
Multifunction Delay & Looper
- TABLE OF CONTENTS -
1
1
2
3
4
5
7
9
12
13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Electro-Harmonix Canyon
Summary of Contents for Electro-Harmonix Canyon
-
Page 1: Table Of Contents
Multifunction Delay & Looper Congratulations on your purchase of the Canyon, an extremely powerful yet easy- to-use Delay and Looper pedal. Within the compact Canyon chassis there’s a vast array of awe-inspiring tones including 10 different types of delays: from pristine digital to warm tape and more. -
Page 2: Controls
S/H and LOOP modes, the dry signal remains at unity volume even as FX LVL is turned to maximum DELAY Knob – Controls the delay time of the CANYON, from a minimum position of 5 milliseconds to a maximum of 3 seconds. -
Page 3: Connections
When Tails are set to OFF, all repeats will stop as soon as the bypass switch is pressed, regardless of the FEEDBACK knob setting. - CONNECTIONS - INPUT Jack – This ¼” jack is the audio input of the CANYON. The input impedance is 1M. - Page 4 Tip: Use the reversed echoes that best suit your delay time setting. CANYON’s Secondary Knob Mode to adjust the sensitivity of the intelligent pluck detection algorithm. DMM – Deluxe Memory Man – This is a faithful emulation of the tone of the EHX Deluxe Memory Man bucket brigade analog delay pedal.
-
Page 5: Using The Canyon's Loop Mode
S/H mode. As FEEDBACK is turned up, the sensitivity of this mode increases. LOOP – Looper mode – When the CANYON is in LOOP mode, it becomes a looper pedal with a maximum loop length of 62 seconds. A recorded loop is stored permanently, even when the CANYON is removed from power. - Page 6 4. Note: once Undo/Redo is enabled, this function is available until the loop is erased. This is true even after power cycling the CANYON. ERASING A LOOP 1. To erase a loop, playback must be stopped. If a loop is playing, press the footswitch two times quickly to stop it.
-
Page 7: Tap Tempo With The Canyon
MODE knob is moved while recording the loop. 4. If the CANYON has a loop saved in its memory and is turned on in LOOP mode, or if the MODE knob is turned to LOOP mode, the LED will light bright green for half a second, then turn dim green to indicate that there is previously recorded loop memory. -
Page 8: Secondary Knob Functionality
Tip: If you set the Tails switch to ON and disable removed from power. internal tap tempo, you can quickly switch the CANYON in and out of effect mode to “grab” individual notes or phrases to repeat, or to keep high FEEDBACK settings from becoming too busy. - Page 9 CANYON from power. Press and hold both the TAP/DIVIDE switch and the footswitch. Then, while holding both switches, plug power back in to the CANYON. The LED will cycle through red, orange and green to indicate that the CANYON has been restored to factory default...
- Page 10 ECHO mode. REVRS – The DELAY knob controls pluck sensitivity. Turn the knob up to make the CANYON more sensitive to your pluck attack, turn it down to reduce sensitivity. Factory default is maximum sensitivity with the knob fully clockwise.
- Page 11 As the knob is turned down, the amount of time it takes to reach silence decreases. LOOP – No secondary knob functions. SECONDARY KNOBS CHART Tip: cut out this chart as a handy go-to reference for the Canyon’s Secondary Knob Controls. MODE DELAY...
- Page 12 WARRANTY INFORMATION Please register online at http://www.ehx.com/product-registration or complete and return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will repair or replace, at its discretion, a product that fails to operate due to defects in materials or workmanship for a period of one year from date of purchase.
