Container Refrigeration
OPERATIONS AND SERVICE
MANUAL
For
PrimeLINE
69NT40-561-200 to 299
69NT40-561-500 to 599
PrimeLINE ONE
TM
69NT40-565-200 to 299
69NT40-565-500 to 599
Container Refrigeration Units
T-362 Rev J

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PrimeLINE and is the answer not in the manual?

Questions and answers

Related Manuals for Carrier PrimeLINE

Summary of Contents for Carrier PrimeLINE

  • Page 1 Container Refrigeration OPERATIONS AND SERVICE MANUAL PrimeLINE 69NT40-561-200 to 299 69NT40-561-500 to 599 PrimeLINE ONE 69NT40-565-200 to 299 69NT40-565-500 to 599 Container Refrigeration Units T-362 Rev J...
  • Page 2 OPERATIONS AND SERVICE MANUAL PrimeLINE 69NT40-561-200 to 299 69NT40-561-500 to 599 PrimeLINE ONE 69NT40-565-200 to 299 69NT40-565-500 to 599 Container Refrigeration Units © 2022 Carrier Corporation Printed in USA February 2022 ●...
  • Page 3 TABLE OF CONTENTS PARAGRAPH NUMBER PAGE SAFETY SUMMARY ..............1–1 GENERAL SAFETY NOTICES .

  • Page 4: Table Of Contents

    DESCRIPTION ............... . 3–1 GENERAL DESCRIPTION .
  • Page 5 4.3.24 QUEST Mode ............4–28 CONTROLLER ALARMS .
  • Page 6 5.10.8 Pharma Mode ............5–14 TROUBLESHOOTING .
  • Page 7 7.11.4 Condenser Coil Installation ..........7–12 7.11.5 Micro Channel Heat Exchanger (MCHE) Repair Instructions .
  • Page 8 7.28.1 Downloading Unit Data ........... . 7–37 7.28.2 Loading Operational Software .
  • Page 9 Figure 3.9 Evaporator Section - PrimeLINE ONE ........
  • Page 10 Figure 7.11 Evaporator Fan Assembly ........... . . 7–24 Figure 7.12 Access Panel Torque Pattern .
  • Page 11 7–42 Table 7–4 Sensor Resistance - PrimeLINE CPDS ..........
  • Page 13 SECTION 1 SAFETY SUMMARY 1.1 General Safety Notices Installation and servicing of refrigeration equipment can be hazardous due to system pressures and electrical com- ponents. Only trained and qualified service personnel should install, repair, or service refrigeration equipment. When working on refrigeration equipment, observe all potential Danger, Warning and Caution hazards, including those shown below and on hazard labels attached to the unit.
  • Page 14 WARNING EXPLOSION HAZARD: Failure to follow this WARNING can result in death, serious personal injury and / or property damage. Never use air or gas mixtures containing oxygen (O ) for leak testing or operating the product. Charge only with refrigerants R-134a or R-513A as specified for the unit model number: Refrigerant must conform to AHRI Standard 700 specification.
  • Page 15 WARNING Always turn OFF the unit circuit breakers (CB-1 & CB-2) and disconnect main power supply before working on moving parts. WARNING Installation requires wiring to the main unit circuit breaker, CB-1. Make sure the power to the unit is off and power plug disconnected before beginning installation. WARNING Before powering on the unit, it is important to ensure that all dismantling work is done and tools are away and service personnel are not working on the unit at the time of power on.
  • Page 16 CAUTION Pre-trip inspection should not be performed with critical temperature cargoes in the container. CAUTION When PRE-TRIP key is pressed, economy, dehumidification and bulb mode will be deactivated. At the completion of pre-trip activity, economy, dehumidification and bulb mode must be reacti- vated.
  • Page 17 CAUTION Do not remove wire harnesses from module unless you are grounded to the unit frame with a static safe wrist strap. CAUTION Unplug all module connectors before performing arc welding on any part of the container. CAUTION The unit must be OFF whenever a programming device is inserted or removed from the control- ler programming port.
  • Page 19 PrimeLINE units are self-contained, all electric units, which include cooling and heating systems to provide precise temperature control. The units are supplied with a complete charge of refrigerant and compressor lubricating oil, and are ready for operation upon installation.
  • Page 20 2.4.4 Compressor The unit is fitted with either an R-134a or an R-513A scroll compressor equipped with suction and discharge service connections. To identify an R-513A-ready compressor in the field, a green dot is located on the top of the compressor on the DUV fitting.
  • Page 21 If the unit is equipped with an autotransformer and communications module, the autotransformer will be fitted with a transformer bridge unit (TBU) to assist in communications. 2.5.8 Gutters Rain gutters may be fitted over the control box and recorder section to divert rain away from the controls. 2.5.9 Handles The unit may be equipped with handles to facilitate access to stacked containers.
  • Page 22 Literature section, click on Options > XtendFRESH. 2.5.23 TripWise TripWise™ is a new premium option available for PrimeLINE units. TripWise is software logic that runs in the background during every voyage and will let you know whenever a standard pre-trip inspection (PTI) is needed. Section 5.10.2 Refer to for more detail on the TripWise option.

  • Page 23: Description

    SECTION 3 DESCRIPTION 3.1 General Description 3.1.1 Refrigeration Unit - Front Section The unit is designed so that the majority of the components are accessible from the front (see Figure 3.1). The unit model number, serial number and parts identification number can be found on the unit nameplate on the back wall under the condenser fan.

  • Page 24: Compressor Section

    3.1.2 Compressor Section The compressor section (see Figure 3.2) includes the compressor, digital unloader valve (DUV), high pressure switch, discharge pressure transducer (DPT), evaporator pressure transducer (EPT) and the suction pressure transducer (SPT). The supply temperature sensor (STS) and supply recorder sensor (SRS) are located to the left of the compressor.

  • Page 25: Figure 3.3 Condenser Section With "C" Shape Coil (Pids < Nt3000)

    Figure 3.3 Condenser Section with “C” Shape Coil (PIDs < NT3000) 1) Condenser Coil 8) Receiver Moisture & Liquid Indicator 2) Grille and Venturi Assembly 9) Fusible Plug 3) Condenser Fan 10) Filter Drier 4) Condenser Coil Cover 11) Economizer 5) Condenser Fan Motor 12) Economizer Solenoid Valve (ESV) 6) Receiver, Steel...

  • Page 26: Figure 3.4 Condenser Section, With Mche And Steel Receiver (Pids Nt3000 To Nt3099)

    Figure 3.4 Condenser Section, with MCHE and Steel Receiver (PIDs NT3000 to NT3099) 1) MCHE Coil 8) Receiver Moisture & Liquid Indicator 2) Grille and Venturi Assembly 9) Fusible Plug 3) Condenser Fan 10) Service Access Valve 4) Condenser Coil Cover 11) Filter Drier 5) Condenser Fan Motor 12) Economizer...

  • Page 27: Figure 3.5 Condenser Section, With Mche And Aluminum Receiver (Pids > Nt3100)

    Figure 3.5 Condenser Section, with MCHE and Aluminum Receiver (PIDs > NT3100) 1) MCHE Coil 8) Receiver Moisture & Liquid Indicator 2) Grille and Venturi Assembly 9) Fusible Plug 3) Condenser Fan 10) Service Access Valve 4) Condenser Coil Cover 11) Filter Drier 5) Condenser Fan Motor 12) Economizer...

  • Page 28: Water-Cooled Condenser Section

    3.1.4 Water-Cooled Condenser Section The unit may contain a water-cooled condenser (WCC) installed as an option. When operating on the water-cooled condenser, the condenser fan is deactivated by a water pressure switch or condenser fan switch. There are two types of water-cooled condensers available and both are described below. Tube in Shell Water-Cooled Condenser Figure 3.6) consists of a water-cooled condenser, sight...

  • Page 29: Fresh Air Makeup Vent

    Brazed Plate Water-Cooled Condenser The brazed plate water-cooled condenser section (see Figure 3.7) consists of the brazed plate water-cooled condenser (WCC), water couplings, a water pressure switch and a fusible plug. The receiver is retained in this configuration and the brazed plate heat exchanger is placed between the air-cooled condenser and the receiver. Figure 3.7 Brazed Plate Water-Cooled Condenser 1) Water-Cooled Condenser (WCC) 3) Self Draining Coupling - Water Out...

  • Page 30: Figure 3.8 Evaporator Section

    Figure 3.8 Evaporator Section Evap Coil, 4 row Evap Coil, 6 row Side View 6, 7 1) Evaporator Fan and Motor (EM1) 8) Heat Termination Thermostat (HTT)** 2) Evaporator Fan and Motor (EM2) 9) Defrost Temperature Sensor (DTS)** 3) Return Temperature Sensor (RTS) / Return 10) Electronic Expansion Valve (EEV) Recorder Sensor (RRS) 11) Evaporator Temperature Sensors (ETS1 / ETS2)

  • Page 31: Figure 3.9 Evaporator Section - Primeline One

    Figure 3.9 Evaporator Section - PrimeLINE ONE Side View 1) Evaporator Fan and Motor (EM1) 7) Heat Termination Thermostat (HTT)** 2) Evaporator Fan and Motor (EM2) 8) Defrost Temperature Sensor (DTS)** 3) Return Temperature Sensor (RTS) / Return 9) Electronic Expansion Valve (EEV)

  • Page 32: Control Box Section

    3.1.7 Control Box Section The control box (see Figure 3.10) includes: the manual operation switches, circuit breaker (CB-1), compressor, fan and heater contactors, control power transformer, fuses, keypad, display module, current sensor module, controller module and the communications interface module. Figure 3.10 Control Box Section 1) Compressor Contactor (CH) 8) Controller Battery Pack (standard location)

  • Page 33: 3.2 Refrigeration System Data

    3.2 Refrigeration System Data Table 3–1 Refrigeration System Data Model Number ZMD26KVE-TFD-272 Weight (With Oil) 42.9 kg (95 lb) Compressor / Motor Assembly Approved Oil Uniqema Emkarate RL-32-3MAF Oil Charge 1774 ml (60 ounces) Electronic Expansion Valve Verify at - 18°C (0°F) 4.4 to 6.7°C (8 to 12°F) (EEV) Superheat Evaporator container box temperature...

  • Page 34: 3.3 Electrical Data

    3.3 Electrical Data Table 3–2 Electrical Data CB-1 (25 amp) Trips at 29 amps Circuit Breaker CB-2 (50 amp) Trips at 62.5 amps CB-2 (70 amp) Trips at 87.5 amps Compressor Motor (CP) Full Load Amps (FLA) 13 amps @ 460 VAC Nominal Supply 380 VAC / 3 Phase / 50 Hz 460 VAC / 3 Phase / 60 Hz Full Load Amps...

  • Page 35: 3.4 Safety And Protective Devices

    Table 3–2 Electrical Data (Continued) Coil Feed to Ground Electronic Expansion 47 ohms (Gray Wire) Valve (EEV) Nominal Resistance Coil Feed to Coil Feed 95 ohms Orange wire Power Red wire Output Brown wire Ground Input voltage 5 VDC Output voltage 0 to 3.3 VDC Humidity Sensor (HS) Output voltage readings verses relative humidity (RH) percentage:...
  • Page 36 3.5 Refrigeration Circuit 3.5.1 Standard Operation Starting at the compressor, (see Figure 3.11) the suction gas is compressed to a higher pressure and temperature. The refrigerant gas flows through the discharge line and continues into the air-cooled condenser. When operating with the air-cooled condenser active, air flowing across the coil fins and tubes cools the gas to saturation temperature.

  • Page 37: Figure 3.11 Refrigeration Circuit Schematic - Standard Operation

    Figure 3.11 Refrigeration Circuit Schematic - Standard Operation Discharge Liquid Saturated Suction Vapor Mixture Vapor 1) Compressor 13) Economizer Expansion Valve (EXV) 2) Discharge Service Valve 14) Economizer Expansion Valve (EXV) Sensing Bulb 3) Discharge Pressure Transducer (DPT) 15) Economizer Connection 4) Condenser 16) Electronic Expansion Valve (EEV) 5) Receiver...

  • Page 38: Figure 3.12 Refrigeration Circuit Schematic - Economized Operation

    Figure 3.12 Refrigeration Circuit Schematic - Economized Operation Discharge Liquid Saturated Suction Vapor Mixture Vapor 1) Compressor 13) Economizer Expansion Valve (EXV) 2) Discharge Service Valve 14) Economizer Expansion Valve (EXV) Sensing Bulb 3) Discharge Pressure Transducer (DPT) 15) Economizer Connection 4) Condenser 16) Electronic Expansion Valve (EEV) 5) Receiver...

  • Page 39: Figure 3.13 Refrigeration Circuit Schematic - Water-Cooled Condenser (Tube In Shell)

    Figure 3.13 Refrigeration Circuit Schematic - Water-Cooled Condenser (Tube In Shell) Discharge Liquid Saturated Suction Vapor Mixture Vapor 1) Compressor 14) Economizer Solenoid Valve (ESV) 2) Discharge Service Valve 15) Economizer Expansion Valve (EXV) 3) Discharge Pressure Transducer (DPT) 16) Economizer Expansion Valve (EXV) Sensing Bulb 4) Condenser 17) Economizer 5) Rupture Disk...

  • Page 40: Figure 3.14 Refrigeration Circuit Schematic - Water-Cooled Condenser (Brazed Plate)

    Figure 3.14 Refrigeration Circuit Schematic - Water-Cooled Condenser (Brazed Plate) Discharge Liquid Saturated Suction Vapor Mixture Vapor 1) Compressor 15) Economizer Solenoid Valve (ESV) 2) Discharge Service Valve 16) Economizer Expansion Valve (EXV) 3) Discharge Pressure Transducer 17) Economizer Expansion Valve (EXV) Sensing Bulb 4) Condenser 18) Economizer 5) Water-Cooled Condenser...

  • Page 41: Microprocessor

    Read the Controller Service section (see Section 7.27), including all caution statements, before performing any service on the controller. Figure 4.1 Controller EN12830 CONTROLLER With CARRIER REV 5147 YYWW: 1035 12-00579-00 Micro-Link3 S/N: 0491162 DataCORDER 59980 T B C1...

  • Page 42: Table 4-1 Display Module Leds

    The display module consists of two 5-digit displays and seven indicator lights. The indicator lights are described in Table 4–1. The keypad consists of eleven push button switches that act as the user’s interface with the controller. The switch functions are described in Table 4–2.

  • Page 43: 4.2 Controller Software

    4.2 Controller Software The controller software is a custom designed program that is subdivided into configuration software and operational software. The controller software performs the following functions: • Control supply or return air temperature to required limits, provide modulated refrigeration operation, economized operation, unloaded operation, electric heat control, and defrost.

  • Page 44: Operational Software (Cd Function Codes)

    Table 4–3 Controller Configuration Variables (Continued) Config Title Default Option CnF50 Enhanced Bulb Mode Interface CnF51 Timed Defrost Disable CnF52 Oil Return Algorithm CnF53 Water Cool Oil Return Logic CnF55 TXV Boost Relay CnF56 TXV Boost Circuit CnF57 PWM Compressor Control DUV, DUV module, ACDC coil CnF59 Electronic Evaporator Expansion Valve...

  • Page 45: Table 4-4 Controller Function Codes

    Table 4–4 Controller Function Codes Code Description If a function is not applicable or the related option not purchased for the unit, the display will read “-----” Display Only Functions - Cd01 through Cd26 are display only functions. Cd01 Capacity Modulation (%) Cd01 displays the DUV percent closed.
  • Page 46 Table 4–4 Controller Function Codes Code Description Cd16 Compressor Motor Hour Meter / Unit Run Time Hour Meter Cd16 displays the compressor motor hours. The user can view unit run time by pressing the ENTER key while in Cd16. Total hours are recorded in increments of 10 hours (i.e., 3000 hours is displayed as 300). The Compressor Motor Hour Meter display can be reset to 0 by pressing and holding the ENTER key for 5 seconds.
  • Page 47 Table 4–4 Controller Function Codes Code Description Cd27 Defrost Interval (Hours or Automatic) Cd27 controls the Defrost Timer Interval, which is the desired period of time between defrost cycles. The user-selected intervals are 3, 6, 9, 12, 24 Hours, Off, AUTO, PuLS, AUTO2, or AUTO3. Factory default is “AUTO”.
  • Page 48 Table 4–4 Controller Function Codes Code Description Cd31 Stagger Start Offset Time (Seconds) Cd31 displays the stagger start offset time, which is the amount of time that the unit will delay at start-up. This allows multiple units to stagger their control initiation when all units are powered up together. The eight possible offset values are: 0 (Factory Default), 3, 6, 9, 12, 15, 18 or 21 seconds.
  • Page 49 Table 4–4 Controller Function Codes Code Description Cd36 Evaporator Fan Speed Cd36 is for setting the desired evaporator fan speed for use during the Dehumidification Bulb Mode option. This code is enabled only if Dehumidification Mode (Cd33) is On and Bulb Mode (Cd35) has been set to “bulb.”...
  • Page 50 Table 4–4 Controller Function Codes Code Description Cd43 XtendFRESH Mode Cd43 controls the XtendFRESH controlled atmosphere option. If a unit does not have the XtendFRESH option, dashes “-----” will be displayed. Cd43 contains four selectable modes of operation: • FrESh - All XtendFRESH operations are enabled and setpoints for CO and O can be edited.
  • Page 51 Table 4–4 Controller Function Codes Code Description Configurable Functions - Cd45 through Cd48 are user-selectable functions. The operator can change the value of these functions to meet the operational needs of the container. Cd45 Vent Position Sensor (VPS) Position Cd45 displays positional values for the Vent Position Sensor (VPS). Values are to 240 for UPPER, 0 to 225 for LOWER.
  • Page 52 Table 4–4 Controller Function Codes Code Description Cd48 Dehumidification / Bulb Cargo Mode Parameter Selection Initially Cd48 will display current Dehumidification Mode: bUlb (bulb cargo mode), dEhUM (normal dehumidification), or OFF. Pressing ENTER key will take the interface down into a hierarchy of parameter selection menus (mode, setpoint, evaporator speed, DTT setting).
  • Page 53 Table 4–4 Controller Function Codes Code Description Cd50 QUEST Enable / Disable Cd50 enables or disables QUEST Mode, which is a power saving option that reduces energy requirements. Cd50 applies to either QUEST or QUEST II, depending on which option was chosen for the particular unit.
  • Page 54 Table 4–4 Controller Function Codes Code Description Cd51 Automatic Cold Treatment (ACT) Mode Parameter Selection Cd51 controls the Automated Cold Treatment (ACT) Mode option, which is a method to simplify the task of completing cold treatment by automating the process of changing the setpoints. Cold treatment is an effective post-harvest method to control Mediterranean and certain other tropical fruit flies.
  • Page 55 Table 4–4 Controller Function Codes Code Description Cd53 Automatic Setpoint Change (ASC) Mode Parameter Selection Cd53 controls the Automated Setpoint Change (ASC) Mode option, which allows up to 6 setpoint changes to be pre-programmed over defined periods. If the unit is not configured for ASC, then this will not be allowed and Cd53 will display dashes “-----”. Cd53 initially displays the countdown timer in days and hours remaining in the right display, regardless of whether it is enabled.
  • Page 56 Table 4–4 Controller Function Codes Code Description Cd58 Water Pressure Switch / Condenser Fan Switch State or Override Logic State Cd58 displays “CLOSE” if the WPS or CFS switch contacts are closed or if these options are not installed. “OPEn” is displayed when the WPS or CFS switch contacts are open. When the WPS/CFS Override Logic is “TRUE”, the right display will flash on all units.
  • Page 57 Table 4–4 Controller Function Codes Code Description Cd63 FuelWise Cd63 controls FuelWise Mode, which is an option that saves energy while operating in the perishable setpoint range. When operating in the frozen setpoint range, Frozen Economy Mode complements FuelWise. Note: FuelWise was previously referred to as Enhanced Economy Mode. If the unit is not configured for FuelWise, then this will not be allowed and Cd63 will display dashes “-----”.
  • Page 58 Table 4–4 Controller Function Codes Code Description Cd70 Temperature Setpoint Lock Cd70 enables or disables the Temperature Setpoint Lock feature. When set to “On”, this will prevent setpoint change from the keypad. The default setting is “OFF”. An event will be recorded in the DataCorder each time an action is taken at Cd70.

  • Page 59: 4.3 Modes Of Operation

    4.3 Modes of Operation General operation sequences for cooling, heating and defrost are described in the following paragraphs. Operational software responds to various inputs. These inputs come from the temperature sensors and pressure transducers, the temperature setpoint, the settings of the configuration variables and the function code assignments.

  • Page 60: Perishable Heating

    4.3.7 Perishable Heating When it is necessary to raise the control temperature, the system will enter Perishable Heating mode. If the temperature drops to 0.5°C (0.9°F) below setpoint, the unit will transition to Perishable Heating mode, and the heaters will be energized. The unit will transition back to Perishable Idle mode when the temperature rises to 0.2°C (0.4°F) below the setpoint, and the heaters will de-energize.

  • Page 61: Perishable Dehumidification - Bulb Mode

    will continue to cycle heating to maintain relative humidity below the selected setpoint. If dehumidification is terminated by a condition other than the humidity sensor, e.g., an out-of-range or compressor shutdown condition, the heat relay is de-energized immediately. Two timers are activated during dehumidification to prevent rapid cycling and consequent contactor wear: 1.

  • Page 62: Perishable Mode Cooling - Sequence Of Operation

    4.3.11 Perishable Mode Cooling - Sequence of Operation NOTE In Standard Perishable mode, the evaporator motors run in high speed. In Economy Fan mode, the fan speed is varied. a. When supply air temperature is above setpoint and decreasing, the unit will cool with the condenser fan motor (CF), compressor motor (CH), and evaporator fan motors (EF) energized, and the white COOL light illuminated (see Figure...

  • Page 63: Perishable Mode Heating - Sequence Of Operation

    4.3.12 Perishable Mode Heating - Sequence of Operation a. If the supply air temperature decreases 0.5°C (0.9°F) below setpoint, the system enters the heating mode (see Figure 4.3). The controller closes contacts TH (see Figure 4.5) to allow power flow through the heat termination thermostat (HTT) to energize the heaters (HR).

  • Page 64: Frozen Idle Mode

    4.3.16 Frozen Idle Mode When temperature drops to setpoint minus 0.2°C (0.4°F) and the compressor has run for at least five minutes, the unit will transition to the Frozen Idle mode. The compressor is turned off and the evaporator fans continue to run to circulate air throughout the container.

  • Page 65: Defrost

    c. When the return air temperature decreases to 0.2°C (0.4°F) below setpoint, contacts TC, TS and TN are opened to de-energize the compressor, economizer solenoid valve and condenser fan motor. The white COOL light is also de-energized. The EEV will close. d.

  • Page 66: Defrost Operation

    4.3.21 Defrost Operation Initiation of defrost is dependent on the state of the Defrost Temperature Sensor (DTS). When the DTS senses a temperature less than 10°C (50°F), the defrost options become active and the timer is engaged for the initiation of the defrost cycle.

  • Page 67: Defrost Related Settings

    Figure 4.8 Defrost ENERGIZED DE-ENERGIZED 24 VOLT POWER IP-CM IP-EM1 IP-EM2 The EEV and DUV are independently operated by the microprocessor. Complete schematics and legends are located in Section 9. Defrost will terminate when the DTS reading rises above one of two model number configurable options selection, either an upper setting of 25.6°C (78°F) which is default or lower setting of 18°C (64°F).

  • Page 68: Protection Modes Of Operation

    4.3.23 Protection Modes of Operation Evaporator Fan Operation Opening of an evaporator fan internal protector will shut down the unit. Failure Action Function code Cd29 may be operator set to select the action the controller will take upon a system failure. The Table 4–4.

  • Page 69: 4.4 Controller Alarms

    • During QUEST pulldown, supply air temperature is lowered somewhat relative to the nominal setpoint. Evaporator fans are forced to operate at high speed. Steady-state QUEST mode control maintains the same lowered supply air temperature that was used during QUEST pulldown. The compressor cycles on and off according to return air high and low limits. Depending on the fan mode of operation selected, the evaporator fans may be programmed to run at low speed some or all of the time according to the control logic.

  • Page 70: Table 4-5 Alarm Indications And Descriptions

    Table 4–5 Alarm Indications and Descriptions AL03 Loss of Superheat Control Cause: Superheat has remained below 1.66°C (3°F) degrees for five minutes continuously while compressor running. Compressor drawing more than 2.0 amps, compressor pressure ratio is greater than 1.8, and Electronic Expansion Valve (EEV) is at 0% open.
  • Page 71 Table 4–5 Alarm Indications and Descriptions AL08 High Compressor Pressure Ratio Cause: Controller detects discharge pressure to suction pressure ratio is too high. The controller will attempt to correct the situation by restarting the compressor. Component Discharge Pressure Transducer (DPT) Troubleshooting Confirm accurate DPT pressure readings.
  • Page 72 Table 4–5 Alarm Indications and Descriptions Troubleshooting Check unit wiring. Confirm pressure readings during start-up; suction pressure should decrease and discharge pressure should increase. Corrective Action Correct wiring. Component Current Sensor Troubleshooting Check the right-most digit in display at code Cd41. If display is 3 or 4, check compressor / sensor wiring.
  • Page 73 Table 4–5 Alarm Indications and Descriptions Component Monitor Unit Troubleshooting Alarm is display only; the alarm may clear itself during operation. Corrective Action If alarm remains active or is repetitive, replace compressor at next available opportunity. AL18 Discharge Pressure High Cause: Discharge pressure is over the maximum for 10 minutes within the last hour.
  • Page 74 Table 4–5 Alarm Indications and Descriptions Troubleshooting Check compressor operation. Corrective Action If the alarm persists, it may indicate a failing compressor, replace the compressor. See Compressor Service Section 7.9. AL20 Control Contactor Fuse (F3) Cause: Control power fuse (F3A or F3B) is open. Component Check F3A fuse.
  • Page 75 Table 4–5 Alarm Indications and Descriptions AL23 Loss of Phase B Cause: Controller fails to detect current draw. Component Incoming Power Troubleshooting Check incoming power source. Corrective Action Correct power source as required. AL24 Compressor IP Cause: Compressor internal protector (IP) is open. Component Compressor Troubleshooting Shut down unit disconnect power and check resistance of compressor windings at contactor T1-T2, T2-T3.
  • Page 76 Table 4–5 Alarm Indications and Descriptions Corrective Action Resetting the unit may correct problem, monitor the unit. Component Suction Pressure Transducer (SPT) Troubleshooting Confirm accurate SPT pressure readings. See Manifold Gauge Set Section 7.2. Corrective Action Replace SPT if defective. Component Discharge Pressure Transducer (DPT) Troubleshooting Confirm accurate DPT pressure readings.
  • Page 77 Table 4–5 Alarm Indications and Descriptions AL50 Air Vent Position Sensor (VPS) Cause: Vent Position Sensor (VPS) Sensor out of range. Component Vent Position Sensor (VPS) Troubleshooting Make sure VPS is secure. Corrective Action Manually tighten panel. Troubleshooting If the alarm persists, replace the VPS or the assembly. Corrective Action Replace VPS.
  • Page 78 Table 4–5 Alarm Indications and Descriptions AL56 Primary Return Sensor (RTS) Cause: Invalid Return Temperature Sensor (RTS) reading. Component Return Temperature Sensor (RTS) Troubleshooting Perform pre-trip P5. Corrective Action If P5 passes, no further action is required. If P5 fails, replace the defective sensor as determined by P5. See Temperature Sensor Service Section 7.29.
  • Page 79 Table 4–5 Alarm Indications and Descriptions Corrective Action Replace heater(s) if defective. See Evaporator Heater Removal and Replacement Section 7.16. Component Contactor Troubleshooting Check voltage at heater contactor on the heater side. Corrective Action If no voltage present, replace heater contactor if defective. AL62 O2 Out of Range Cause: This is a notification alarm and does not pose a risk to fresh produce.
  • Page 80 Table 4–5 Alarm Indications and Descriptions AL65 Discharge Pressure Transducer (DPT) Cause: Compressor Discharge Pressure Transducer (DPT) is out of range. Component Compressor Discharge Pressure Transducer (DPT) Troubleshooting Confirm accurate DPT pressure readings. See Manifold Gauge Set Section 7.2. Corrective Action Replace DPT if defective. AL66 Suction Pressure Transducer (SPT), Evaporator Pressure Transducer (EPT) Cause: Suction Pressure Transducer (SPT) out of range.
  • Page 81 Table 4–5 Alarm Indications and Descriptions Troubleshooting Perform pre-trip P5. Corrective Action If P5 passes, no further action is required. Corrective Action If P5 fails, replace the defective sensor as determined by P5. See Temperature Sensor Service Section 7.29. AL72 Control Temp Out of Range Cause: After the unit goes in-range for 30 minutes then out of range for a continuous 120 minutes.

  • Page 82: 4.5 Pre-Trip Diagnostics

    4.5 Pre-Trip Diagnostics Pre-Trip Diagnostics is an independent controller function that suspends normal refrigeration controller activities and provides preprogrammed test routines. The test routine can be run in Auto Mode, which automatically performs a pre programmed sequence of tests, or Manual Mode, which allows the operator to select and run any of the individual tests.
  • Page 83 Table 4–6 Controller Pre-Trip Test Codes (Continued) P1-1 Heaters Turned Off Heater is then turned off. After 10 seconds, the current draw is measured. The change in current draw is then recorded. Test passes if change in current draw test is in the range specified. Condenser Fan Current Draw: For P2 tests, the condenser fan is turned on, then off.
  • Page 84 Table 4–6 Controller Pre-Trip Test Codes (Continued) P4-1 High Speed Evaporator Fan Motors Off High speed evaporator fans are on and current draw is measured. High speed evaporator fans are then turned off and after 10 seconds the current draw is measured again. The change in current draw is then recorded.
  • Page 85 Table 4–6 Controller Pre-Trip Test Codes (Continued) P5-9 Primary vs. Secondary Evaporator Pressure Transducer Test This is a Pass / Fail test of the primary Evaporator Pressure Transducer and secondary Evaporator Pressure Transducer. Test passes if secondary Evaporator pressure is within +/- 1.5 psi of the primary Evaporator pressure. P5-10 Humidity Sensor Controller Configuration Verification Test This is a Pass / Fail / Skip test of the humidity sensor configuration.
  • Page 86 Table 4–6 Controller Pre-Trip Test Codes (Continued) Tests P6-6 through P6-10 are conducted by changing status of each valve and comparing suction pressure change and/or compressor current change with predetermined values. Tests will cause compressor and condenser fans to cycle on and off as needed to generate the pressure required for individual pre-trip sub tests. The compressor will start in order to build discharge pressure, followed by compressor pump down sequence.
  • Page 87 Table 4–6 Controller Pre-Trip Test Codes (Continued) Perishable Mode Tests: In order for P8 tests to execute, Pre-trip tests P7-0 and P7-1 must have passed or have been skipped. P8-0 Perishable Mode Test If the control temperature is below 15.6°C, the setpoint is changed to 15.6°C, and a 180 Minute timer is started.

  • Page 88: 4.6 Datacorder

    4.6.1 DataCORDER Description Carrier Transicold “DataCORDER” software is integrated into the controller and serves to eliminate the temperature recorder and paper chart. DataCORDER functions may be accessed by keypad selections and viewed on the display module. The unit is also fitted with interrogation connections which may be used with the Carrier Transicold DataReader to download data.

  • Page 89: Datacorder Configuration Software

    • Battery Low (battery pack) • Data Retrieval • Defrost Start and End • Dehumidification Start and End • Power Loss (with and without battery pack) • Power Up (with and without battery pack) • Remote Probe Temperatures in the Container (USDA Cold treatment and Cargo probe recording) •...

  • Page 90: Table 4-8 Sensor Configuration

    Changing the configuration to generic and selecting which data points to record may be done using the Carrier Transicold Data Retrieval Program. A list of the data points available for recording follows.

  • Page 91: Datacorder Operational Software

    16. Discharge Pressure Transducer (DPT) 17. Suction Pressure Transducer (SPT) 18. Vent Position Sensor (VPS) Logging Interval (dCF03) The user may select four different time intervals between data recordings. Data is logged at exact intervals in accordance with the real time clock. The clock is factory set at Greenwich Mean Time (GMT). Thermistor Format (dCF04) The user may configure the format in which the thermistor readings are recorded.

  • Page 92: Table 4-9 Datacorder Function Code Assignments

    Table 4–9 DataCORDER Function Code Assignments Code Description Recorder Supply Temperature Current reading of the Supply Recorder Sensor (SRS). Recorder Return Temperature Current reading of the Return Recorder Sensor (RRS). dC3-5 USDA 1,2,3 Temperatures Current readings of the three USDA probes. dC6-13 Network Data Points 1-8 Current values of the network data points (as configured).

  • Page 93: Datacorder Power Up

    4.6.4 DataCORDER Power Up The DataCORDER may be powered up in any one of four ways: 1. Normal AC power: The DataCORDER is powered up when the unit is turned on via the Stop-Start switch. 2. Controller DC battery pack power: If a battery pack is installed, the DataCORDER will power up for communication when an interrogation cable is plugged into an interrogation receptacle.

  • Page 94: Table 4-10 Datacorder Alarm Indications

    Table 4–10 DataCORDER Alarm Indications Code Description dAL70 Recorder Supply Temperature Out of Range The supply recorder sensor reading is outside of the range of -50°C to 70°C (-58°F to +158°F), or the probe check logic has determined there is a fault with this sensor. NOTE: The P5 pre-trip test must be run to inactivate the alarm.

  • Page 95: Pre-Trip Data Recording

    4.6.6 Pre-Trip Data Recording Section 4.5) and the results of each test included The DataCORDER will record the initiation of a pre-trip test (see in pre-trip. The data is time-stamped and may be extracted via the Data Retrieval program. See Table 4–11 for a description of the data stored in the DataCORDER for each corresponding pre-trip test.

  • Page 96: Datacorder Communications

    Table 4–11 DataCORDER Pre-Trip Result Records (Continued) Test Title Data P6-7 Digital Unloader Valve Test Pass / Fail / Skip P6-9 Liquid Injection Valve Test (If equipped) Pass / Fail / Skip P6-10 Electronic Expansion Valve Test Pass / Fail / Skip P7-0 High Pressure Switch Closed Pass / Fail / Skip Result, AMBS, DPT or CPT (if equipped)

  • Page 97: Usda Cold Treatment

    T107, T108, and T109 of the USDA Treatment Manual. In response to the demand to replace fumigation with this environmentally sound process, Carrier has integrated Cold Treatment capability into its microprocessor system. These units have the ability to maintain supply air temperature within one quarter degree Celsius of set point and record minute changes in product temperature within the DataCORDER memory, thus meeting USDA criteria.

  • Page 98: Figure 4.10 Datacorder Probe Calibration Screen

    2. Calibrate the three USDA probes by ice bathing the probes and performing the calibration function (see Figure 4.10) with the DataLINE. Refer to the Ice Bath Preparation procedure. This calibration procedure generates the probe offsets which are stored in the controller and applied to the USDA sensors for use in generating sensor type reports.

  • Page 99: Iso Trip Header

    Figure 4.11 DataCorder Probe Calibration Screen e. Using the System Tools screen (see Figure 4.12) in the DataLine software perform a “Trip Start.” Figure 4.12 DataCorder Systems Tool Screen 4.6.9 ISO Trip Header DataLINE provides the user with an interface to view/ modify current settings of the ISO trip header through the ISO Trip Header screen.

  • Page 101: Operation

    SECTION 5 OPERATION 5.1 Inspection WARNING Beware of unannounced starting of the evaporator and condenser fans. The unit may cycle the fans and compress or unexpectedly as control requirements dictate. 1. Check inside the unit for the following conditions: • Check channels or “T”...

  • Page 102: 5.3 Adjust Fresh Air Makeup Vent

    PROCEDURE: 1. Make sure the Start-Stop switch (ST), located on the control panel, is in “0” position (Off). 2. Make sure circuit breaker CB-1, located in the control box, and CB-2, located on the transformer, are both in “0” position (Off). 3.

  • Page 103: Lower Fresh Air Makeup Vent

    Figure 5.2 Upper Fresh Air Make Up Flow Chart FLOW FLOW (CMH) 60HZ (CMH) 50HZ TBAR TBAR 1 1/2” 1 1/2” TBAR TBAR 2 5/8” 2 5/8” TBAR 3” TBAR 3” PERCENT OPEN PERCENT OPEN 5.3.2 Lower Fresh Air Makeup Vent a.

  • Page 104: Vent Position Sensor

    5.3.3 Vent Position Sensor The vent position sensor (VPS) allows the user to determine the position of the fresh air vent via Cd45. This function code is accessible via the Code Select key. The vent position will display for 30 seconds whenever motion corresponding to 5 CMH (3 CFM) or greater is detected.

  • Page 105: 5.5 Connect Remote Monitoring Receptacle

    5.5 Connect Remote Monitoring Receptacle Figure 3.10). If remote monitoring is required, connect the remote monitor plug at the unit receptacle (see When the remote monitor plug is connected to the remote monitoring receptacle, the following remote circuits are energized: •...

  • Page 106: 5.8 Pre-Trip Diagnosis

    5.8 Pre-Trip Diagnosis CAUTION Pre-trip inspection should not be performed with critical temperature cargoes in the container. CAUTION When PRE-TRIP key is pressed, economy, dehumidification and bulb mode will be deactivated. At the completion of pre-trip activity, economy, dehumidification and bulb mode must be reac- tivated.

  • Page 107: Displaying Pre-Trip Test Results

    CAUTION When a Pre-trip Auto 2 test runs to completion without being interrupted, the unit will terminate Pre-trip and display “Auto 2” “end.” The unit will suspend operation until the user depresses the ENTER key! 3. When an automatic test fails, it will be repeated once. A repeated test failure will cause “FAIL” to be shown on the right display, with the corresponding test number to the left.

  • Page 108: 5.10 Optional Operating Modes

    In Frozen Mode, only the controlling probes are considered. Disagreement of the controlling probes can trigger a defrost probe check, which will occur when the difference between the sensors is greater than 2.0°C (3.6°F). Normally, the controlling probes are the return probes but if both return probes are invalidated, the supply probes are used for control purposes.

  • Page 109: Tripwise

    TripWise TripWise is a new premium option available for PrimeLINE and PrimeLINE with Edge units. TripWise is software logic that runs during every voyage as often as possible to indicate whether a standard Pre-trip Inspection (PTI) is needed and skip unless necessary. The tests run in the background and are similar to those completed as part of the standard PTI selection.

  • Page 110: Figure 5.4 Tripwise Status In Datacorder

    If “-----” is displayed, the TripWise function option is not active on the unit. To add this option to the unit, the equipment owner would need to contact their Regional Carrier Sales Manager. 4. Use the Arrow keys to toggle between “ON” and “OFF” and then press the ENTER key to select the desired option.

  • Page 111: Xtendfresh

    In DataLINE version 3.2, perform an all data download by selecting from the drop down menu “TripWise Summary” and then select a date in “User Logged Events” as shown in the Figure below. This will generate the status / results in a DataLINE TripWise Summary Report Figure 5.5 Generating TripWise Summary Report 5.10.3...

  • Page 112: Automatic Cold Treatment Mode

    5.10.4 Automatic Cold Treatment Mode Automated Cold Treatment (ACT) Mode is a method to simplify the task of completing cold treatment by automating the process of changing the setpoints. ACT is set up through function code Cd51. Refer to Table 4–4 for detail description of Cd51 menu selections and display values.

  • Page 113: Automatic Setpoint Change Mode

    5.10.5 Automatic Setpoint Change Mode Automatic Setpoint Change (ASC) Mode allows up to 6 setpoint changes to be pre-programmed over defined periods of time using function code Cd53. Refer to Table 4–4 for detail description of Cd53 menu selections and display values.

  • Page 114: Quest Mode

    5.10.6 Quest Mode QUEST Mode, controlled with function code Cd50, is a power saving option that reduces energy requirements. QUEST Mode can apply to either QUEST or QUEST II option depending on which option was chosen for the Table 4–4 particular unit.

  • Page 115: Figure 6.1 Unit Troubleshooting Sequence

    SECTION 6 TROUBLESHOOTING Figure 6.1 Unit Troubleshooting Sequence Start Troubleshooting Check Power Refer to Connect Power Procedure Unit does Section 5.2 Supply self test? Refer to Connect Power Procedure Check Power Evaporator Section 5.2 Supply fans start? Correct Install Latest Refer to Controller Software Section software Software...
  • Page 116 Condition Possible Cause Remedy / Reference Unit will not Start or Starts then Stops External power source OFF Turn on Start-Stop switch (ST) OFF or defective Check No power to unit Circuit breaker tripped or OFF Check Section 5.2.2 Autotransformer not connected Circuit breaker OFF or defective Check Control transformer defective...
  • Page 117 Condition Possible Cause Remedy / Reference Unit Runs but has Insufficient Cooling Section 6.7 Abnormal pressures Section 6.16 Abnormal temperatures Abnormal currents Section 6.17 Controller malfunction Section 6.9 Evaporator fan or motor defective Section 7.17 Refrigeration system Compressor service valves or liquid line shutoff valve Open valves completely partially closed Frost on coil...
  • Page 118 Condition Possible Cause Remedy / Reference Manual defrost switch defective Replace Will not initiate defrost Keypad is defective Replace manually Defrost temperature sensor open Replace Initiates but relay (DR) drops Low line voltage Section 3.3 Heater contactor or coil defective Replace Initiates but does not defrost Heater(s) burned out...

  • Page 119: Microprocessor Malfunction

    Condition Possible Cause Remedy / Reference Microprocessor Malfunction Incorrect software and/or controller configuration Check Section 7.29 Defective sensor Will not control Defective wiring Check Low refrigerant charge Section 7.3 6.10 No Evaporator Air Flow or Restricted Air Flow Section 6.6 Frost on coil Evaporator coil blocked Section 7.15...

  • Page 120: 6.13 Autotransformer Malfunction

    Condition Possible Cause Remedy / Reference Failed suction pressure transducer (SPT) Replace Liquid slugging in evaporator pressure transducer (EPT) compressor Failed EEV Replace 6.13 Autotransformer Malfunction Circuit breaker (CB-1 or CB-2) tripped Check Section 7.26 Autotransformer defective Unit will not start Power source not turned ON Check 460 VAC power plug is not inserted into the receptacle...

  • Page 121: Service

    Charge only with refrigerants R-134a or R-513A as specified for the unit model number: Refrigerant must conform to AHRI Standard 700 specification. NOTE Annual maintenance procedures for PrimeLINE units 69NT40-561 can be found in the 62-10327 Annual Maintenance Manual, located in the Literature section of the Container Refrigeration website.

  • Page 122: Evacuating The Manifold Gauge Set

    7.2) is required for service of the models covered A manifold gauge / hose set with self-sealing hoses (see within this manual. The manifold gauge/hose set is available from Carrier Transicold. (P/N 07-00294-00, which includes items 1 through 6, Figure 7.2.)

  • Page 123: Connecting The Manifold Gauge Set

    For example, the valve stem is first fully backseated when connecting a manifold gauge to measure pressure. Then, the valve is opened 1/4 to 1/2 turn to measure the pressure. Figure 7.3 Service Valve Valve (Frontseated) Valve (Backseated) 1) Access Valve 4) Compressor or Filter Drier Inlet Connection 2) Step Cap...

  • Page 124: Automatic Pump Down

    CAUTION The scroll compressor achieves low suction pressure very quickly. Do not use the compressor to evacuate the system below 0 psig. Never operate the compressor with the suction or discharge service valves closed (frontseated). Internal damage will result from operating the compressor in a deep vacuum.

  • Page 125: Evacuation And Dehydration

    2. Essential tools to properly evacuate and dehydrate any system include a vacuum pump (8m3/hr = 5 cfm volume displacement) and an electronic vacuum gauge. The pump is available from Carrier Transicold, P/N 07-00176-11. The micron gauge is P/N 07-00414-00.

  • Page 126: Evacuate And Dehydrate - Partial System

    NOTE To prevent the area between the Economizer Solenoid Valve (ESV) and the compressor from being isolated during evacuation, it is necessary to open the ESV using a magnet tool (Carrier Transicold P/ N 07-00512-00). 3. Remove the ESV coil from the valve body. Place the magnet tool over the valve stem. An audible click will be heard when the ESV opens.

  • Page 127: Adding Refrigerant To System - Full Charge

    R-1234yf and R-134a. Charging or topping off as a vapor will result in an incorrect mixture of blend in the system. 6. Upon completion, change the refrigerant label (Carrier P/N 76-50235-00) on the front of the unit indicating the change in refrigerant.

  • Page 128: Compressor

    CAUTION The PrimeLINE unit has a hermetically sealed compressor that should not be opened and/or repaired. Doing so can cause a loss in performance and premature system failure due to the precision machinery and assembly required within the compressor. To repair the unit, remove the faulty compressor and replace with an approved Carrier compressor.

  • Page 129: Figure 7.5 Compressor Kit

    10. Remove (slide out) the old compressor from the unit. 11. Inspect compressor base plate for wear. Replace, if necessary. 12. Wire tie the compressor base plate to the compressor, and slide the new compressor into the unit. See Figure 7.5.

  • Page 130: 7.10 High Pressure Switch

    20. Open the compressor terminal cover and connect the compressor power cable following the steps below: a. Liberally coat the orange gasket surfaces with the Krytox lubricant. b. Install the orange gasket part onto the compressor fusite with the grooved or threaded side out. Ensure that the gasket is seated onto the fusite base.

  • Page 131: Replacing High Pressure Switch

    7.10.2 Replacing High Pressure Switch 1. Remove the refrigerant charge. 2. Disconnect wiring from defective switch. The high pressure switch is located on the discharge connection or line and is removed by turning counterclockwise. 3. Install a new high pressure switch after verifying switch settings. 4.

  • Page 132: Condenser Coil Preparation

    12. Remove the cushion clamps securing the liquid line to the top and bottom receiver brackets, retain all clamps and securing hardware. 13. Place a support under the condenser coil before releasing the coil from the frame. 14. Remove the lower mounting bracket bolts from the inside of the coil. 15.

  • Page 133: Figure 7.7 Condenser Fan Position

    18. Remove the condenser fan, and place it on the shaft facing the correct direction. Adjust the fan to the Figure 7.7. correct position, 37mm (1.5”) from the fan shroud, see Figure 7.7 Condenser Fan Position 37mm (1.5”) Shroud 19. Use Loctite “H” on the fan set screws, and tighten. 20.
  • Page 134 Tools Required: • Screw driver set • Standard hand tools • Needle nose pliers (long nose) • 35 degree bent long nose pliers • Duckbill pliers • Tube brush (soft bristle) • Emery cloth • Disposable gloves • Utility knife •...
  • Page 135 3. Using a utility knife, carefully section off the area around the leak (approximately 0.5 inches) 4. Using needle nose pliers, carefully remove the fins from the damaged area above and below the tube needing repair. The fins to be removed should be approximately 1/2” of fin material from each side of the repair location. 5.
  • Page 136 12. Prepare the required amount of epoxy resin per instructions on the package and place on the cardboard and replace the cap onto the epoxy container after use. NOTE When the temperature is below 10°C (50°F), warm up the affected area prior to the repair using a heat gun.
  • Page 137 17. Lightly “crimp” the aluminum wrapper with needle nose pliers. 18. Allow an additional one to two hours for epoxy to cure before leak checking the system. NOTE Keep the unit under vacuum until the epoxy is fully cured. 19. Repeat the original leak check of the system in step 4 to verify that the leak has been plugged. 20.
  • Page 138 12. Remove the condenser fan, and connect the fan motor wiring to the fan motor. 13. Place the condenser fan on the shaft facing the correct direction. Adjust the fan to the correct position, Figure 7.7. 37mm (1.5”) from the fan shroud, see 14.

  • Page 139: Figure 7.8 Water-Cooled Condenser Cleaning - Forced Circulation

    2. To remove slime or mud, use Aluminum Cleaner® 164. Mix 170 grams (6 ounces) per 3.785 liters (1 U.S. gallon) of water. Mix cleaner in one half the volume of water, while stirring, and then add remaining water. Warm this solution and circulate through the tubes until all slime and mud has been removed. 3.

  • Page 140: Figure 7.9 Water-Cooled Condenser Cleaning - Gravity Circulation

    7. The time required for de-scaling will vary, depending upon the extent of the deposits. One way to determine when de-scaling has been completed is to titrate the solution periodically, using titrating equipment provided free by the Oakite technical service representative. As scale is being dissolved, titrate readings will indicate that the Oakite No.

  • Page 141: Figure 7.10 Heater Arrangement

    Section 7.6. 2. Evacuate the low side in accordance with 3. After unit is in operation, inspect for moisture in the system and check charge. 7.15 Evaporator Coil The evaporator section, including the evaporator coil, should be cleaned regularly. The preferred cleaning fluid is fresh water or steam.
  • Page 142 7.16.1 Megger Testing the Heaters WARNING Always turn OFF the unit circuit breakers, disconnect the main power supply, and perform Lock Out / Tag Out before working on moving parts. All of the checks performed during this procedure should be carried out using a 500v Meg-ohm tester. 1.
  • Page 143 WARNING Always turn OFF the unit circuit breakers, disconnect the main power supply, and perform Lock Out / Tag Out before working on moving parts. a. With the heater pair identified, remove the upper back panel inside the container. b. Identify the center point connection for the heater pair (black wiring from heaters) either against the unit back wall or in the wiring loom.

  • Page 144: Figure 7.11 Evaporator Fan Assembly

    3. Remove the four 1/4-20 x 3/4 long bolts that are located under the fan that support the motor and stator housing. Remove the motor and plastic spacer. 7.17.3 Assemble the Evaporator Fan Assembly 1. Assemble the motor and plastic spacer onto the stator. NOTE When removing the black nylon evaporator fan blade, care must be taken to assure that the blade is not damaged.

  • Page 145: Figure 7.12 Access Panel Torque Pattern

    HD) for the unit. This will assist in helping to remove the corrosive fumigation chemicals and dislodging of the corrosive elements. This cleaner is available from the Carrier Transicold Performance Parts Group (PPG) and can be ordered through any of the PPG locations; Part Number NU4371-88.

  • Page 146: Figure 7.13 Electronic Expansion Valve (Eev)

    7.18.2 Cleaning Procedure 1. Remove the upper evaporator access panel inside of the unit. 2. Spray the surface with water before applying the cleaning solution. This helps the cleaner work better. 3. Liberally apply the prepared cleaner solution (5 parts water and 1 part cleaner). 4.
  • Page 147 7.19.2 Installing an EEV 1. Install the valve and a new strainer with the cone of the strainer / screen pointing into the liquid line at the inlet to the valve. 2. During installation, make sure the EEV coil is snapped down fully, and the coil retention tab is properly seated in one of the valve body dimples.
  • Page 148 9. Remove the cap and insert the humidity sensor into the bottle through the bottle opening and pull the connector back through the drilled hole in the cap. Then, secure the cap and seal the wire going through the cap. NOTE Make sure that the sensor is not at all in contact with the salt water.

  • Page 149: Figure 7.14 Coil View Of Economizer Solenoid Valve (Esv)

    7.21 Economizer Solenoid Valve (ESV) Figure 7.14 Coil View of Economizer Solenoid Valve (ESV) 1) Slotted Screw 4) Bottom Coil (large) O-ring 2) Top Coil (small) O-ring 5) Brass Spacer 3) Solenoid Coil, Enclosing Tube and Body - - - - - 7.21.1 Removing a Solenoid Valve Coil WARNING...

  • Page 150: Figure 7.15 Economizer Expansion Valve

    7.22 Economizer Expansion Valve (EXV) Figure 7.15) is an automatic device that maintains constant superheat of The economizer expansion valve (See the refrigerant gas leaving at the point of bulb attachment, regardless of suction pressure. Unless the valve is defective, it seldom requires maintenance other than periodic inspection to ensure that the thermal bulb is tightly secured to the suction line and wrapped with insulating compound.

  • Page 151: Figure 7.16 Adapter And O-Ring

    To confirm what caused the test to fail, perform the following additional test. 1. Connect the manifold gauge set to discharge service valve (DSV) and suction service valve (SSV). 2. Front seat the SSV and pump down the compressor. 3. Front seat the DSV valve to isolate the compressor. 4.

  • Page 152: Figure 7.17 View Of Digital Unloader Valve (Duv) Assembly

    3. Loosen the bolt on top of the DUV and remove the coil assembly. NOTE There is a small spacer tube between the top of the valve and the 12 VDC coil that needs to be reinstalled into the solenoid valve coil. When removing the coil, it may fall out when lifted from the valve body.

  • Page 153: Table 7-1 Valve Override Control Displays

    The Override Timer (tIM) selection is also provided to enter a time period of up to five minutes, during which the override(s) are active. If the timer is active, valve override selections will take place immediately. If the timer is not active, changes will not take place for a few seconds after the timer is started.

  • Page 154: Figure 7.18 Autotransformer

    1. Obtain a grounding wrist strap (Carrier Transicold P/N 07-00304-00) and a static dissipation mat (Carrier Transicold P/N 07-00277-00). The wrist strap, when properly grounded, will dissipate any potential static buildup on the body.

  • Page 155: Figure 7.19 Controller

    7.27.2 Controller Troubleshooting Figure 7.19) are provided on the controller for troubleshooting electrical circuits (see A group of test points (TP, see Table 7–2. schematic diagram sections). A description of the test points is provided in Table 7–2 Test Point Descriptions Test Point Description Not used in this application.
  • Page 156 3. Disconnect the battery wires from the “KA” plug positions 14, 13, 11. 4. Using Driver Bit, Carrier Transicold part number 07-00418-00, remove the four screws securing the display module to the control box. Disconnect the ribbon cable and set the display module aside.
  • Page 157 11. Turn unit power on (“I”) at the Start-Stop switch (ST). 7.28.2 Loading Operational Software PrimeLINE units must be loaded with software version 53XX. See the label in the control box door for factory installed software version. 1. Turn unit power off (“0”) at the Start-Stop switch (ST).
  • Page 158 NOTE For PCMCIA sRAM cards, the display will show "SEt UP" when unit turns on. 6. Use the Arrow keys until the display shows “LOAd 53XX” and press the ENTER key. 7. The display will alternate between the messages “PrESS EntR” and “rEV 53XX”. Press ENTER. 8.
  • Page 159 7.28.4 Setting the Date and Time 1. Turn unit power off (“0”) at the Start-Stop switch (ST). 2. Inspect the pins on the controller’s programming slot for damage. 3. Insert the programming device (with proper software loaded) into the slot. See Figure 7.19.
  • Page 160 11. When the last value is entered, press ENTER to enter the information to the controller. The display will return to “SEt Id”. 12. Turn unit power off (“0”) at the Start-Stop switch (ST). 13. Remove the programming device from the controller. 14.
  • Page 161 3. Place the Start-Stop switch (ST) to “0” to turn the unit Off. Disconnect the power supply. 4. See Section 7.27 to remove the controller to gain access to the sensor plugs. 5. Using the plug connector marked “EC” that is connected to the back of the controller, locate the sensor wires (RRS, RTS, SRS, STS, AMBS, DTS, or CPDS as required).

  • Page 162: Table 7-3 Sensor Resistance - Ambs, Dts, Ets, Rrs, Rts, Srs, Sts

    Table 7–3 Sensor Resistance - AMBS, DTS, ETS, RRS, RTS, SRS, STS °C °F OHMS °C °F OHMS 336,500 42.8 24,173 -38.2 314,773 44.6 23,017 -36.4 294,600 46.4 21,922 -34.6 275,836 48.2 20,886 -32.8 258,336 19,900 242,850 51.8 18,975 -29.2 228,382 53.6 18,093...

  • Page 163: Table 7-4 Sensor Resistance - Primeline Cpds

    Table 7–4 Sensor Resistance - PrimeLINE CPDS °C °F OHMS °C °F OHMS 2,889,600 64.4 117,656 -36.4 2,532,872 68.0 107,439 -32.8 2,225,078 71.6 98,194 -29.2 1,957,446 75.2 89,916 -25.6 1,724,386 86,113 -22.0 1,522,200 78.8 82,310 -18.4 1,345,074 82.4 75,473 -14.8 1,190,945 83.0...

  • Page 164: Figure 7.20 Supply Sensors - Cover Assembly And Sensors

    WARNING When performing the Return Air Sensor calibration, disconnect both evaporator motors. Before proceeding with the calibration procedure, ensure that controller software version is 5368 or higher and DataLINE version 3.1 or higher is installed onto the download device. Only the latest DataLINE and controller software will allow users to carry out Good Distribution Practice (GDP) calibration.

  • Page 165: Figure 7.21 Removing Front Access Panels

    Figure 7.21 Removing Front Access Panels 2. On the right side, disconnect the fan motor wiring, loosen the fastener and remove (slide) the evaporator motor from the unit (see Figure 7.22). Figure 7.22 Removing Evaporator Motor 3. Loosen the fastener on the sensor bracket (see Figure 7.23).

  • Page 166: Figure 7.24 Return Sensors - Cutting Wire Ties

    Figure 7.24) that are securing the sensors to the harness and remove sensor. 4. Cut all the wire ties (see Figure 7.24 Return Sensors - Cutting Wire Ties GDP Calibration, Perform Calibration: 1. Connect the interrogator cable to the interrogator port. Then, power on the unit. WARNING Before powering on the unit, it is important to ensure that all dismantling work is done and tools are away and service personnel are not working on the unit at the time of power on.

  • Page 167: Figure 7.26 Dataline - Calibrate Sensors Button

    3. On the Probe Calibration screen, click on the Calibrate Supply sensors or Calibrate Return sensors button Figure 7.26). (see Figure 7.26 DataLINE - Calibrate Sensors Button Figure 7.27). In the appropriate fields, enter the 4. A Location of Service pop-up window will appear (see Service Center Name and Service Center Location where the calibration is being performed.

  • Page 168: Figure 7.28 Ice Bath

    Figure 7.28). For Return Sensors, place the ice bath on 6. Place the ice bath in a location near sensors (see an elevated platform (ladder) of appropriate height. Figure 7.28 Ice Bath 7. Once temperature stability is ensured, submerge the sensors in the ice water slurry. Make certain that the sensors do not contact the container sides or bottom, or each other.

  • Page 169: Figure 7.30 Dataline - Calibration Results

    10. Once the calibration has completed, a pop-up will appear with the message Calibrate Complete. Click OK to Figure 7.30). acknowledge and the results will then be displayed on the screen in the Results column (see Calibration will fail if the stability cannot be achieved or the sensor offset is greater than 0.3°C (0.5°F). The validity of a sensor can be checked by hand warming the sensors to see if there are changes in the readings on the DataLINE screen.

  • Page 170: Figure 7.31 Sensor Types

    Figure 7.31 Sensor Types 40 mm (1 1/2 in) 2 or 3 wires as required 6.3 mm (1/4 in) 40 mm (1 1/2 in) 2 or 3 wires as required 6.3 mm (1/4 in) 5. Strip back insulation on all wiring 6.3 mm (1/4 inch). 6.

  • Page 171: Figure 7.33 Sts/Srs Positioning

    14. Reinstall sensor. See following sections: • Section 7.29.5 for STS and SRS Reinstallation Section 7.29.6 • for RRS and RTS Reinstallation • Section 7.29.7 for DTS Reinstallation • Section 7.29.8 for ETS1 and ETS2 Reinstallation NOTE The P5 Pre-Trip test must be run to deactivate probe alarms (see Section 5.8).

  • Page 172: Figure 7.35 Ets1/Ets2 Positioning

    7.29.7 Defrost Temperature Sensor (DTS) Reinstallation To properly reinstall a Defrost Temperature Sensor (DTS), insulating material must be placed completely over the sensor to ensure the coil metal temperature is sensed. 7.29.8 Evaporator Temperature Sensor (ETS1/ETS2) Reinstallation The Evaporator Temperature Sensors (ETS1/ETS2) are located in a tube holder under insulation (see Figure 7.35).
  • Page 173 6. Place a bead of the silicone sealer supplied with the replacement sensor around the sensor sealing ring. Insert sensor into the well with the leads parallel to the suction fitting. 7. Reconnect the sensor (see Figure 7.32) and run pre-trip P5. 7.30 Vent Position Sensor (VPS) The vent position sensor (VPS) determines fresh air vent position in near real-time via function code Cd45.

  • Page 174: Figure 7.37 Communications Interface Installation

    Units that have been factory provisioned for installation of a Communication Interface Module (CIM) have the required wiring installed. If the unit is not factory provisioned, a provision wiring kit (Carrier Transicold part number 76-00685-00) must be installed. Installation instructions are packaged with the kit.

  • Page 175: Table 7-5 R-134A Refrigerant Pressure Temperature Chart

    Table 7–5 R-134a Refrigerant Pressure Temperature Chart Note: Underline figures are inches of mercury vacuum °F °C PSIG °C °F -40.0 14.8 -40.0 -0.49 -38.9 13.9 -38.2 -0.46 -37.8 13.0 -36.4 -0.43 -36.7 12.0 -34.6 -0.40 -35.6 10.9 -32.8 -0.37 -34.4 -31.0 -0.34...
  • Page 176 Table 7–5 R-134a Refrigerant Pressure Temperature Chart Note: Underline figures are inches of mercury vacuum °F °C PSIG °C °F 37.0 33.8 2.04 39.0 35.6 2.15 41.1 37.4 2.26 43.2 39.2 2.38 10.0 45.4 41.0 2.50 11.1 47.7 42.8 2.62 12.2 50.0 44.6...
  • Page 177 Table 7–5 R-134a Refrigerant Pressure Temperature Chart Note: Underline figures are inches of mercury vacuum °F °C PSIG °C °F 52.2 187.4 109.4 10.01 53.3 193.0 111.2 10.30 54.4 198.7 113.0 10.60 55.6 204.6 114.8 10.90 56.7 210.6 116.6 11.21 57.8 216.7 118.4...

  • Page 178: Table 7-6 R-513A Refrigerant Pressure Temperature Chart

    Table 7–6 R-513A Refrigerant Pressure Temperature Chart Note: Underline figures are inches of mercury vacuum °F °C PSIG °C °F -40.0 -40.0 -0.32 -38.9 -38.2 -0.28 -37.8 -36.4 -0.25 -36.7 -34.6 -0.21 -35.6 -32.8 -0.17 -34.4 -31.0 -0.13 -33.3 -29.2 -0.09 -32.2 -27.4...
  • Page 179 Table 7–6 R-513A Refrigerant Pressure Temperature Chart Note: Underline figures are inches of mercury vacuum °F °C PSIG °C °F 47.0 33.8 2.65 49.3 35.6 2.78 51.6 37.4 2.91 54.0 39.2 3.04 10.0 56.5 41.0 3.18 11.1 59.0 42.8 3.32 12.2 61.6 44.6...
  • Page 180 Table 7–6 R-513A Refrigerant Pressure Temperature Chart Note: Underline figures are inches of mercury vacuum °F °C PSIG °C °F 52.2 210.5 109.4 11.40 53.3 216.5 111.2 11.72 54.4 222.7 113.0 12.04 55.6 228.9 114.8 12.36 56.7 235.2 116.6 12.70 57.8 241.7 118.4...

  • Page 181: Table 7-7 Recommended Bolt Torque Values (Dry, Non-Lubricated For 18-8 Stainless Steel)

    Table 7–7 Recommended Bolt Torque Values (Dry, Non-Lubricated for 18-8 Stainless Steel) Bolt Diameter Threads In-Lb Ft-Lb Free Spinning 5/16 14.9 27.1 7/16 58.3 9/16 77.3 1104 124.7 1488 168.1 Non Free Spinning (Locknuts etc.) 82.5 5/16 145.2 12.1 16.4 22.0 29.8 7/16...

  • Page 183: Figure 8.1 Legend - Standard Unit Configuration

    SECTION 8 ELECTRICAL WIRING SCHEMATIC AND DIAGRAMS Figure 8.1 LEGEND - Standard Unit Configuration 8–1 T-362...

  • Page 184: Figure 8.2 Schematic Diagram

    ELECTRICAL WIRING SCHEMATIC AND DIAGRAMS Figure 8.2 Schematic Diagram T-362 8–2...

  • Page 185: Figure 8.3 Unit Wiring Diagram (Sheet 1 Of 2)

    ELECTRICAL WIRING SCHEMATIC AND DIAGRAMS Figure 8.3 Unit Wiring Diagram (Sheet 1 of 2) 8–3 T-362...

  • Page 186: Figure 8.4 Unit Wiring Diagram (Sheet 2 Of 2)

    ELECTRICAL WIRING SCHEMATIC AND DIAGRAMS Figure 8.4 Unit Wiring Diagram (Sheet 2 of 2) T-362 8–4...

  • Page 187: Figure 8.5 Legend - Unit With Auto Transformer

    ELECTRICAL WIRING SCHEMATIC AND DIAGRAMS Figure 8.5 Legend - Unit With Auto Transformer 8–5 T-362...

  • Page 188: Figure 8.6 Schematic Diagram - Unit With Auto Transformer

    ELECTRICAL WIRING SCHEMATIC AND DIAGRAMS Figure 8.6 Schematic Diagram - Unit With Auto Transformer T-362 8–6...

  • Page 189: Figure 8.7 Unit Wiring Diagram - Unit With Auto Transformer (Sheet 1 Of 2)

    ELECTRICAL WIRING SCHEMATIC AND DIAGRAMS Figure 8.7 Unit Wiring Diagram - Unit With Auto Transformer (Sheet 1 of 2) 8–7 T-362...

  • Page 190: Figure 8.8 Unit Wiring Diagram - Unit With Auto Transformer (Sheet 2 Of 2)

    ELECTRICAL WIRING SCHEMATIC AND DIAGRAMS Figure 8.8 Unit Wiring Diagram - Unit With Auto Transformer (Sheet 2 of 2) T-362 8–8...
  • Page 191 We, manufacturer: Carrier Transicold Pte Ltd 251 Jalan Ahmad Ibrahim Singapore 629146 Declare, under our sole responsibility, that the PrimeLINE Container Unit: Model: 69NT40-561 is in conformity with the provisions of the following European Directives: • Machinery Directive 2006/42/EC following Annex VIII •...
  • Page 192 China RoHS per SJ/T 11364-2014 产品中有害物质的名称及含量 有害物质 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 部件名称 (Pb) (Hg) (Cd) (Cr (VI)) (PBB) (PBDE) 金属板部件 塑料部件 盘管组件 加热部件 马达，压缩机与风扇组件 温度控制微处理器系统 断路器与接触器 变压器 传感器 通讯组件 阀组件 电缆线/电源 电池 标签与绝缘材料 玻璃部件 本表格依据 SJ/T 11364 的规定编制。 O：表示该有害物质在该部件所有均质材料中的含量均在...
  • Page 193 INDEX Numerics Ambient Temperature Sensor (AMBS) Location 3–1 Automatic Cold Treatment (ACT) Mode 4–14 230 Volt Cable 2–3 Automatic Cold Treatment (ACT) Mode Operation 5–12 460 Volt Cable 2–3 Automatic Setpoint Change (ASC) Mode 4–15 Automatic Setpoint Change (ASC) Mode Operation 5–13 Access Panels Location 3–1 Autotransformer 2–2 Adjust Fresh Air Makeup Vent 5–2...
  • Page 194 Cd44 4–10 Container Unit Operation 5–1 Cd45 4–11 Container Unit Service 7–1 Cd46 4–11 Control Box 2–1 Cd47 4–11 Control Box Component Location 3–10 Cd48 4–12 Control Box Section 3–10 Cd49 4–12 Control Panel Location 3–1 Cd50 4–13 Controller 2–3 7–34 Cd51 4–14 Controller Alarms Description 4–29...
  • Page 195 Evaporator Coil Location 3–7 Evaporator Coil Replacement 7–21 Keypad 4–1 Evaporator Coil Service 7–21 Keypad Location 3–1 Evaporator Fan #1 Location 3–7 Evaporator Fan #2 Location 3–7 Labels 2–3 Evaporator Fan and Motor Assembly Service 7–23 Logging Interval (dCF03) 4–51 Evaporator Fan Operation 2–2 Lower Air 2–3 Evaporator Heaters Megger Testing 7–22...
  • Page 196 Suction Pressure Transducer (SPT) Location 3–2 Pre-Trip Test Codes 4–42 Suction Service Valve Location 3–2 PrimeLINE 2–1 Supply Recorder Sensor (SRS) Location 3–2 PrimeLINE models 2–1 Supply Temperature Sensor (STS) Location 3–2 Probe Diagnostics 5–7 Protection Modes of Operation 4–28 Pump Down 7–3 Temperature Control Microprocessor System 4–1...
  • Page 197 6–2 Troubleshooting, Unit Operates Long 6–2 Troubleshooting, Unit Runs but Insufficient Cooling 6–3 Troubleshooting, Unit Will Not Defrost Properly 6–3 Troubleshooting, Unit Will Not Heat 6–3 Troubleshooting, Unit Will Not Start 6–2 Troubleshooting, Unit Will Not Stop Heating 6–3 Troubleshooting, Water Cooled Condenser 6–6 Unit Display Location 3–1 Unit Identification Information 2–1 Unit Nameplate Location 3–1...
  • Page 198 Carrier Transicold Division, Carrier Corporation P.O. Box 4805 Syracuse, NY 13221 USA https://www.carrier.com/container-refrigeration...

This manual is also suitable for:

Primeline one69nt40-561-20069nt40-561-50069nt40-565-20069nt40-565-500

Table of Contents

Save PDF
