Parts List; Assembly Drawing - Harbor Freight Tools 43533 Set Up And Operating Instructions Manual

Part Description
1 Left-handed Nut
2 Polishing Wheel
3 Wheel Pushing Ring
4 Washer
5 Bearing
6 Snap Ring
7 Rotor
8 Armature
9 Fan
10 Bearing
11 Sanding Wheel
12 Right Nut
13 Shaft Mounting Nut
14 Wheel Cover
15 Nut
16 Bolt
17 Wheel Cover
1 2
28
29
For technical questions, please call 1-800-444-3353.
SKU 43533

PARTS LIST

Q'ty Part
1 18 Clamp
1 19 Stator
4 20 Clamp
2 21 Wire Cover
1 22 Brush Holder
2 23 Wire Cover
1 24 Brush Screw
1 25 Brush Spring
1 26 Brush
1 27 Motor Housing
1 28 Wheel Cover
1 29 Circuit Board
1 30 Base Holder
1 31 Knob
6 32 Flex Shaft
2 33 Adaptor
1 34 Cord

ASSEMBLy DRAWING

3 4 5 6
26 25 24 23 22
27
30
49
Description
7 8 9
21 20 19
31 32 33
45 44 43
48 47 46
Q'ty Part Description
1 35 Spring
1 36 Plug
2 37 Shaft Connector Nut
2 38 Tool Rest
1 39 Flex Shaft Hose
2 40 Spring
2 41 Chuck Cover
2 42 Bearing
2 43 Washer
1 44 Bearing
1 45 Spindle
1 46 Chuck
1 47 Fixing Nut
1 48 Mounted Stone Bit
1 49 Chuck Cover
1 50 Wrench
1 51 Plastic Safety Lens
10
18
17 16
37
35 36
34
41
42
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
11 12 13
15 14
38 39
40
51
