Page 17
Repeated use of the memory card will eventually reduce the memory card’s performance. Should this be the case, you will need to purchase a new memory card. Wear and tear on the memory card is not covered by the Samsung warranty. The memory card is an electronic precision device.
Important notes Be sure to observe the following precautions! This unit contains precision electronic components. Do not use or store this unit in the following locations. - Areas exposed to severe changes in temperature and humidity. - Areas exposed to dust and dirt. - Areas exposed to direct sunlight or the inside of a vehicle in hot weather.
Page 76
Important notes If the camera is exposed to an electronic interference, it will turn itself off to protect the memory card. Camera Maintenance - Use a soft brush (available from photo stores) to gently clean the lens and LCD assemblies. If this does not work, lens-cleaning paper with lens cleaning fluid can be used.
Warning indicator There are several warnings that may appear on the LCD display Warning indicator Causes Remedy - Memory card error - Turn off the camera power and turn it on again CARD ERROR ! - Insert the memory card again - Format the memory card (p.67) - There is insufficient - Insert a new memory card...
Before contacting a service center Please check the following Symptom Causes Remedy - There is low battery - Insert fresh batteries capacity - An AC Power Adapter is - Connect an AC Power Adapter The camera not connected doesn t switch on - Batteries are inserted - Insert the batteries according to the incorrectly with the...
Page 79
Before contacting a service center Symptom Causes Remedy - If the subject is closer than 0.8m, - A picture was taken select macro shot mode within 0.8 m from the subject without setting an The images are appropriate macro mode unclear - Take a picture within the flash range - Taking a picture beyond...
Page 80
Before contacting a service center Symptom Causes Remedy Colour of image is different to - White balance setting is - Select appropriate White balance the original incorrect scene Images are too - Exposure is excessive - Reset exposure compensation bright - Check the connection cables - The external monitor has not been connected...
Specifications Type 1/2.7" CCD Image Effective Pixel Approx. 3.2 Mega-pixel Sensor Total Pixel Approx. 3.3 Mega-pixel SHD Lens f = 5.8 ~ 17.4mm Focal Length (35mm film equivalent : 38 ~ 114mm) Lens F No. F2.8 ~ F4.8 Still Image mode : 1.0X ~ 4.0X Digital Zoom Play mode : 1.0X ~ 8.0X (depends on image size) Optical Viewfinder...
Page 82
1024 : S.FINE 64, FINE 106, NORMAL 139 Capacity (32MB) 640 : S.FINE 129, FINE 201, NORMAL 227 * These figures are measured under Samsung’s standard conditions and may vary depending on shooting conditions and camera settings. Single image, Thumbnails, Slide show, Movie Clip...
Starting PC Mode Downloading stored images You can download the still images stored on the camera to your PC's hard disk and print them or use a photo editing software to edit them. 1. Connect the camera to your PC with the USB cable. 2.
Page 93
Starting PC Mode 6. Press the right mouse button and a pop-up menu will open. Click [Paste]. 7. An image file is transferred from the camera to your PC. - By using [Digimax Viewer], you can see the stored images in the memory directly on the PC monitor and you can copy or move the image files.
Using PhotoImpression With PhotoImpression, you can edit or store still images that you downloaded from the camera. This software is only available in Windows version. To start the program, click [Start Programs ArcSoft PhotoImpression PhotoImpression]. The following screen will appear. [ Help Button ] [ Command Button ] [ Tool Bar ]...
Page 102
"Driver" tab, and click [Update Driver] or [Reinstall Driver]. If a message appears asking you to specify the location where the appropriate driver for the device is, specify the "D:\Digimax430 370\Samsung Digimax.KENOX Installation" folder (where D: is the drive letter of the CD-ROM where the driver CD is inserted).
Page 103
Click the [OK] button. Most problems will be solved with those remedies. If the movie clip doesn't play back continuously, install the JPEGCODE provided with the camera again. For more information, visit the samsung website(www.samsungcamera.com) and see the FAQ page.
