Maxcess MAGPOWR Spyder-Plus Instruction Manual page 56

12.0
Starting Parameter Name
Modbus
Register
0x70 Tension Setpoint 100% Calibration
Point
0x72 Manual Setpoint 0% Calibration Point
0x74 Manual Setpoint 100% Calibration Point
0x76 Load Cell Positive Bias
0x77 Load Cell Negative Bias
0x78 Load Cell Gain Reference
0x79 Load Cell Offset
0x7A Applied Tension Binary
0x7B Digital Input Active State
0x7C Security State
0x7D Security Code
0x7E Numeric Display Rate
0x80 Bar Graph Display Rate
0x82 Position Setpoint 0% Calibration Point
0x84 Position Setpoint 100% Calibration
Point
0x86 Dancer 0% Calibration Point
0x88 Dancer 100% Calibration Point
0x8A Tuning Type (Dancer Torque)
0x8B Tuning Type (Dancer Speed)
0x8C Proportional Gain (Dancer)
0x8E Integrator Time (Dancer)
0x90 Initial Screen (Load Cell)
0x91 Initial Screen (Dancer)
0x92 Use Taper?
0x93 System State Status
0x94 Tension On/Off Status
0x95 Tension Setpoint
0x97 Actual Tension
www.maxcessintl.com
COMMUNICATION (OPTIONAL)
Parameter Parameter
Format Type
FLOAT Cal
FLOAT Cal
FLOAT Cal
UINT16 Cal
UINT16 Cal
UINT16 Cal
UINT16 Cal
UINT16 Cal
BYTE Data
BYTE None
UINT16 None
FLOAT Data
FLOAT Data
FLOAT Cal
FLOAT Cal
FLOAT Cal
FLOAT Cal
BYTE Data
BYTE Data
FLOAT Data
FLOAT Data
BYTE Data
BYTE Data
BYTE Data
UINT16 None
UINT16 None
FLOAT None
FLOAT None
MAGPOWR Spyder-Plus
Used with Read /
Control Write
Types
LC, OPT Read / { 0 - 4095 }
Write
LC, OPT Read / { 0 - 4095 }
Write
LC, OPT Read / { 0 - 4095 }
Write
LC, DT, DS Read / { 0 - 511 }
Write
LC, DT, DS Read / { 0 - 511 }
Write
LC, DT, DS Read / { 0 - 511 }
Write
LC, DT, DS Read / { 0 - 4095 }
Write
LC, DT, DS Read / { 0 - 4095 }
Write
LC, DT, DS, Read / 0 = Active Low
OPT Write 1 = Active High
LC, DT, DS, Read 0 = Not Locked
OPT Only 1 = Locked
LC, DT, DS, Write { 0 - 9999 }
OPT Only
LC, DT, DS, Read / { 0.0 - 60.0 } seconds
OPT Write
LC, DT, DS, Read / { 0.0 - 60.0 } seconds
OPT Write
DT, DS Read / { 0 - 4095 }
Write
DT, DS Read / { 0 - 4095 }
Write
DT, DS Read / { 0 - 4095 }
Write
DT, DS Read / { 0 - 4095 }
Write
DT Read / 0 = PD
Write 1 = PID
DS Read / 0 = P
Write 1 = PI
DT, DS Read / { 0.0 - 999.0 }
Write
DT, DS Read / { 0.0 - 60.0 } seconds
Write
LC Read / 0 = Operator Menu
Write 1 = Tension
2 = Output Level
DT, DS Read / 0 = Operator Menu
Write 1 = Position
2 = Output Level
LC, OPT Read / 0 = No
Write 1 = Yes
LC, DT, DS, Read 0 = Hold
OPT Only 1 = Start
2 = Run
3 = Stop
4 = E-Stop
5 = Manual
LC, DT, DS, Read 0 = Tension Off
OPT Only 1 = Tension On
LC Read { 0.0 - 99999.0 } lb.
Only
LC, OPT Read { 0.0 - 99999.0 } lb.
Only
MI 850A320 1 M
Range
