Fromm P300 Operation Manual

Electrical plastic strapping tool
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATION MANUAL
ELECTRICAL PLASTIC
STRAPPING TOOL
MODEL P300
CE Declaration of conformity
We declare that the machine P300
is in conformity with the following standard or
standardised documents:
FROMM Holding AG
Hinterbergstrasse 26
For Parts & Service 1-877-862-6699
98/37/EEC
73/23/EEC
89/336/EEC
CH - 6330 Cham
28.10 2002
R.Fromm
Director

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P300 and is the answer not in the manual?

Questions and answers

Related Manuals for Fromm P300

Summary of Contents for Fromm P300

  • Page 1 OPERATION MANUAL ELECTRICAL PLASTIC STRAPPING TOOL MODEL P300 CE Declaration of conformity We declare that the machine P300 is in conformity with the following standard or standardised documents: 98/37/EEC 73/23/EEC 89/336/EEC FROMM Holding AG Hinterbergstrasse 26 CH - 6330 Cham 28.10 2002...
  • Page 2 INDEX PAGE GENERAL SAFETY RULES SAFETY RULES FOR STRAPPING TOOLS WARRANTY CONDITIONS AND LIABILITY APPROPRIATE USE TECHNICAL DATA Description of the tool ........6 Sound information .

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/ or serious injury. The term "power tool" in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. SAVE THESE INSTRUCTIONS.

  • Page 4: Safety Rules For Strapping Tools

    1.4 Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.

  • Page 5: Strap Breakage Hazard

    WARRANTY CONDITIONS AND LIABILITY FROMM Holding AG warrants all its strapping tools and machine heads during a period of 24 months from the date of installation at the end-user's sight by the distributor, however, not later than 30 months from the date of shipment to the distributor of FROMM Holding AG.

  • Page 6: Appropriate Use

    Description of the tool The tool model P300 has been designed to strap packages with plastic strapping. The plastic strapping is fed around the package manually or in combination with a strap feeder. The straps are inserted in the tool, automatically tensioned, sealed by friction welding and separated.

  • Page 7: Chart Of Types

    CHART OF TYPES The item-No. is built up in form (nn.nnnn) and is marked on label (for instance 43.9944). • The first two digits of the item-No. define the electrical data and specifications of the tool. • The last two digits of the Item No. describe the strap width, the strap thickness and the strap quality as per the following chart.

  • Page 8: Installation

    INSTALLATION Tool must be connected to the line using the original plug / cord only. Supply voltage and frequency must be identical with the indications on the label. For the tools with item-No. 43.11.. / 43.18.. / 43.94.. / 43.95.. / 43.96..a helix cable with plug (item- No. N5.

  • Page 9: Wearing Plate

    Wearing plate As an option, tool can be equipped with a wearing plate complete (item-No. P30.1411) to protect base from excessive wear on abrasive package surfaces (like bricks, concrete blocks etc.). Remove screw N1.1305 and pin N2.2110 from body and attach wearing plate with the 3 screws N1.2210 and the pin N2.2138.

  • Page 10: Operation

    OPERATION Always wear safety glasses with side shields which conform to ANSI Standard Z87.1. Feeding the strap around the package The strapping is fed around the package in the direction as shown in the illustration. Important! Use only plastic strap which is recommended by your local sales representative (name and address on the rear page of the operation manual).

  • Page 11: Removing The Tool

    Tensioning Press down the switching lever and then release it again after the desired strap tension has been reached. The tensioning operation can be interrupted and restarted at any time. The desired tension of the strap can be preselected on the rotary knob. Turning it in a clockwise direction increases the tension (+) and in a counter-clockwise direction lowers it (-).

  • Page 12: Seal - Control

    (see name and address on the rear page of this manual). Use original packing. The electric plastic strapping tool P300 is a high performance tool. We strongly recommend you to have it serviced by an authorized service shop after 12 months at the latest if used one shift per day. If used two or more shifts per day the tool has to be serviced after a shorter period of time.
  • Page 14 SPARE PARTS LIST NO.P30099039309001 MODEL P300-0003/43.99XX DATE 14/10/93 ITEM-NO. in GR DESCRIPTION 43.991X 43.992X 43.993X 43.994X 43.995X 43.996X 43.997X 43.998X 43.99X4 43.99X5 43.99X6 43.99X7 FELD N1.1305 SCREW M4 X 8 N1.1903 SLOTTED CHEESE HD SCREW M5X60 N1.1904 SLOTTED CHEESE HD SCREW M5X20 N1.1905...
  • Page 15 SPARE PARTS LIST NO.P30099039309001 MODEL P300-0003/43.99XX DATE 14/10/93 ITEM-NO. in GR DESCRIPTION 43.991X 43.992X 43.993X 43.994X 43.995X 43.996X 43.997X 43.998X 43.99X4 43.99X5 43.99X6 43.99X7 FELD N2.5175 PRESSURE SPRING 1.6 X 10 X 45 N2.5176 PRESSURE SPRING 0.6X5.5X31 N2.5177 PRESSURE SPRING 0.55X5.55X15 N2.5178...
  • Page 16 SPARE PARTS LIST NO.P30099039309001 MODEL P300-0003/43.99XX DATE 14/10/93 ITEM-NO. in GR DESCRIPTION 43.991X 43.992X 43.993X 43.994X 43.995X 43.996X 43.997X 43.998X 43.99X4 43.99X5 43.99X6 43.99X7 FELD N5.3407 P30.0131 PROTECTION TUBE N5.3608 P30.0131 PIPE CLAMP N6.3207 PLUG N6.6217 O-RING 15 X 2 N7.1105...
  • Page 17 SPARE PARTS LIST NO.P30099039309001 MODEL P300-0003/43.99XX DATE 14/10/93 ITEM-NO. in GR DESCRIPTION 43.991X 43.992X 43.993X 43.994X 43.995X 43.996X 43.997X 43.998X 43.99X4 43.99X5 43.99X6 43.99X7 FELD P30.1139 BOLT P30.1140 ROLL P30.1141 STRAP GUIDE P30.1142 STRAP GUIDE P30.1143 STRAP GUIDE P30.1144 STRAP GUIDE P30.1145...
  • Page 18 SPARE PARTS LIST NO.P30099039309001 MODEL P300-0003/43.99XX DATE 14/10/93 ITEM-NO. in GR DESCRIPTION 43.991X 43.992X 43.993X 43.994X 43.995X 43.996X 43.997X 43.998X 43.99X4 43.99X5 43.99X6 43.99X7 FELD P30.1185 GRIPPING JAW P30.1186 GRIPPING JAW P30.1187 TENSIONING GRIPPER P30.1188 TENSIONING GRIPPER P30.1189 P30.1190 BOLT P30.1191...
  • Page 19 SPARE PARTS LIST NO.P30099039309001 MODEL P300-0003/43.99XX DATE 14/10/93 ITEM-NO. in GR DESCRIPTION 43.991X 43.992X 43.993X 43.994X 43.995X 43.996X 43.997X 43.998X 43.99X4 43.99X5 43.99X6 43.99X7 FELD P30.1229 P30.0131 COVER P30.1233 P30.0131 LABEL P30.1235 P30.0131 ROTOR 110 - 115 V P30.1236 P30.0131 FIELD 110 - 115 V P30.1237...
