Operator's Manual
Log Lifter: Accessory for a log splitter that lifts logs onto log
splitter. Fits model 11954 log splitter.
WARNING: HYDRAULIC INJECTION HAZARD. High fluid pressures and temperatures are
developed in hydraulic log splitters. To avoid hydraulic injection, shut off the engine, disconnect the
spark plug, and move all control valve handles back and forth to relieve system pressures before
beginning assembly. If injured by escaping fluid, no matter how small the wound is, see a doctor at
once. A typical injection injury may be a small puncture wound that does not look serious. However,
severe blood poisoning, infection, disability, gangrene, amputation, or death can result if proper
medical treatment is not administered immediately by a doctor who is familiar with injection injuries.
WARNING: HEAVY LIFTING The assembly of this product requires lifting heavy parts. Two or
more people are required during some steps. Serious back injury can occur.
Any Questions, Comments, Problems or Parts Orders
Call NorthStar Product Support 1-800-270-0810
M11953E.1
ITEM NUMBER
SERIAL NUMBER
11953
:
:
Advertisement
Table of Contents
Related Manuals for NorthStar M11953E.1
Summary of Contents for NorthStar M11953E.1
- Page 1 WARNING: HEAVY LIFTING The assembly of this product requires lifting heavy parts. Two or more people are required during some steps. Serious back injury can occur. Any Questions, Comments, Problems or Parts Orders Call NorthStar Product Support 1-800-270-0810...
- Page 2 Hazard Signal Word Definitions...
-
Page 3: Table Of Contents
Table of Contents Rules for Safe Operation ....………………..……4-7 Safety Label Locations ...….........….. 8 Machine Component Identification…......... 9-12 Assembly ………………………………………………… 13-21 Operation Instructions ..........…...22 Towing and Moving the Log Splitter…………………….. 23 Specifications ..............24 Parts Explosion ..............25 Limited Warranty..............27... -
Page 4: Rules For Safe Operation
Rules for Safe Operation Training WARNING: 1. Read the log lift Operator’s Manual the log splitter Operator’s Manual and the engine owner’s manual completely before attempting to use the log lift. Serious injury or death can result if safety instructions are not followed. 2. - Page 5 Rules for Safe Operation Preparation WARNING: 1. CRUSH HAZARD. Moving parts from log lift can crush and cut. Be thoroughly familiar with all controls and with the proper use of the equipment. Know how to stop the log lift and relieve system pressures quickly. 2.
- Page 6 Rules for Safe Operation Operation WARNING: Before using this log lift, review the “Rules for Safe Operation” and read the log splitter operators manual thoroughly. Failure to follow these rules may result in serious injury to the operator or bystanders. CRUSH HAZARD.
- Page 7 Rules for Safe Operation Maintenance and Storage WARNING: 1.) Refer to the engine manual for proper engine maintenance and storage. 2.) Always shut off the engine, disconnect the spark plug, and move all control valve handles back and forth to relieve system pressures before repairing or adjusting the splitter except as recommended by the manufacturer.
-
Page 8: Safety Label Locations
Safety Label Locations CAUTION A.) Read the Operator's Manual. B.) Only one person should operate the log splitter. C.) Split wood in direction of the grain only. D.) Stay in the designated OPERATOR POSITION. E.) Hold bark side of logs when loading. F.) Keep hands away from ram, wedge, and partly split logs. -
Page 9: Machine Component Identification
Machine Component Identification Closely inspect all contents in the shipping carton. If you have missing or damaged components then: Contact Product Support at 1-800-270-0810. - Page 10 Machine Component Identification...
- Page 11 Machine Component Identification...
- Page 12 Machine Component Identification...
-
Page 13: Assembly
Assembly 1.) Before beginning assembly, start engine and extend ram to its full out position. This will make assembly easier. Then, shut off the engine, disconnect the spark plug, and move all control valve handles back and forth to relieve system pressures and allow log splitter to cool before beginning assembly. - Page 14 Assembly 2.) Splitter Control Valve a.) Disconnect return line hose. b.) Remove elbow from splitter control valve (save elbow for later). c.) Remove conversion plug from splitter control valve. (save conversion plug for later) d.) Install tee into splitter control valve. Tighten with wrench. Point tee at 5 o’clock. e.) Install power beyond plug, pipe reducer, and hose with elbow into splitter control valve.
- Page 15 Assembly 3.) Install Lift Control Valve Fittings a.) Install two ½” x JIC6 elbows into bottom ports on lift control valve. Tighten with wrench. Point elbows as shown below. b.) Install two pipe reducers and two ½” elbows into IN and OUT ports on lift control valve. Tighten with wrench.
- Page 16 Assembly 4.) Install Lift Control Valve. a.) Bolt tubes onto the hydraulic tank with three ¼ x ¾” bolts. Tighten with wrench. b.) Bolt lift control valve and valve plate to tubes with three ¼ x 2” bolts. Make sure decal faces up.
- Page 17 Assembly 5.) Connect Hoses to Lift Control Valve a.) Connect hose from tee (hose with straight fittings) to OUT port on lift control valve. Tighten with two wrenches. Make sure hose doesn’t twist. Align tee so hose doesn’t touch beam slide when it is retracted and make sure hose doesn’t touch any sharp steel surfaces.
- Page 18 Assembly 6.) Install backstop onto log cradle with eight 3/8 x 1-1/4” bolts and 3/8” lock nuts. The backstop fits inside the log cradle. Tighten with a wrench.
- Page 19 Assembly 7.) Install Hydraulic Cylinder a.) Bolt right and left cylinder mounts to middle log cradle support with four 3/8 x 1-3/4” bolts and 3/8” lock nuts. Do not tighten completely. b.) Connect hydraulic cylinder to left and right cylinder mounts with 6” clevis pin (make sure ports point downward).
- Page 20 Assembly 8.) Attach Lift Table to Log Splitter (this step requires two or more people) a.) Bolt left mount arm to log cradle. Use four 3/8 x 1-1/4” bolts and lock nuts. Do not tighten completely. b.) Bolt right mount arm to log cradle. Use four 3/8 x 1-1/4” bolts and lock nuts. Do not tighten completely.
- Page 21 Assembly 10.) Double check all fittings to make sure they are tight. A loose fitting can be a safety hazard. Apply “Moving Parts” caution label to log splitter. See safety label location section of this 11.) manual for location. 12.) Run Log Splitter a.) Start engine.
-
Page 22: Operation Instructions
Operation Instructions Operating the log lift 1.) Lower the log lift by pushing the lift control. WARNING CRUSH HAZARD: Moving parts from log splitter can crush and cut. Keep hands and Log lift feet away from log lift. Down a.) Stay in the OPERATOR POSITION while actuating controls. LIFT b.) If a helper is assisting in loading logs to be split, never actuate controls until CONTROL... -
Page 23: Towing And Moving The Log Splitter
Towing and Moving the Log Splitter WARNING RISK OF PERSONAL INJURY AND/OR PROPERTY DAMAGE The log lift table must be locked in the up position and the lift cylinder must be extended completely in the up position before towing or moving the log splitter. Towing or moving the log splitter in with the log lift in any other position is a safety hazard and can cause damage to the log lift and log splitter. -
Page 24: Specifications
The manufacturer reserves the right to make improvements in design and/or changes in specifications at any time without incurring any obligation to install them on units previously sold. Any Questions, Comments, Problems or Parts Orders Call NorthStar Product Support 1-800-270-0810... -
Page 25: Parts Explosion
Parts Explosion – Rev E.1 PART# DESCRIPTION PART# DESCRIPTION 39013 Lift table 50CSC128 Pipe reducer 39122 Left mount arm 39213 Hose w/ elbow 38983 Lift pin 39273 Tube 2501935 Travel pin 788079 Flow reducer 39159 Lynch pin 50125 Hose w/ straight fittings 189900 Roller 39206... - Page 26 This page has intentionally been left blank.
-
Page 27: Limited Warranty
