Voith BTG Mutek PCD-06 Operation Manual

Particle charge detector

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Operation Manual

Mütek

PCD-06 (Light / Standard / Premium)

Particle Charge Detector

Table of Contents

Need help?

Do you have a question about the BTG Mutek PCD-06 and is the answer not in the manual?

Questions and answers

Summary of Contents for Voith BTG Mutek PCD-06

Page 1 Operation Manual Mütek PCD-06 (Light / Standard / Premium) Particle Charge Detector...
Page 2 Copyright© 2021 BTG Instruments AB The contents of this document are subject to revision without notice due to continued progress in methodology, design, and manufacturing. BTG shall have no liability for any error or damages of any kind resulting from the use of this document. All rights reserved.
Page 3: Table Of Contents
List of contents List of contents Chapter Paragraph Title Page Basic safety Manufacturer’s liability ..... . 7 instructions Intended applications of the PCD-06 ... 8 Non-legitimate use .
Page 4 List of contents Chapter Paragraph Title Page Start-up procedure ......27 4.6.1 PCD-06 Standard and Premium....27 4.6.2 Connect PCD-06 Light .
Page 5 List of contents Chapter Paragraph Title Page VII. Maintenance Cleaning ....... . . 49 7.1.1 Cleaning the instrument .
Page 7: Manufacturer's Liability
I. Basic safety instructions Basic safety instructions 1.1 Manufacturer’s liability Instructions in the operation manual Warranty and liability All users of the Mütek™ PCD-06 have to observe This instrument was built and tested in accordance with this operation manual and to strictly adhere to the EU Guidelines 2014/30/EC and 2014/35/EC.
Page 8: Intended Applications Of The Pcd-06
I. Basic safety instructions 1.2 Intended applications of the PCD-06 Regarding defects covered by the guarantee, BTG Inst- ruments AB shall not be liable for any dam-ages excee- The Mütek™ PCD-06 shall be used exclusively for the ding the cost price. purposes defined in this operation manual and in the The guarantee shall only extend to parts found defec- technical description and shall only be operated in con-...
Page 9: General Safety Directions
I. Basic safety instructions 1.5 General safety directions 1.8 Symbols For all installation, operation, maintenance and repair The following symbols and notices are used in this ope- work performed on the Mütek™ PCD-06 Particle ration manual to designate hazards or to provide special Charge Detector, it is essential that the directions given information: below be followed:...
Page 10: Packaging & Transport
I. Basic safety instructions 1.9 Packaging & transport The Mütek™ PCD-06 Particle Charge Detector is a compact and sturdy unit for which a plastic transporta- tion box is available to enable measurements on site. Information It is recommended to ordering the plastic transportation box to avoid transport damage.
Page 11: Theoretical Background
II. Product description Product description 2.1 Theoretical background Whether a suspension of particles or a true solution of Streaming potential large molecules, most materials dispersed in water If a liquid is forced along a particle surface under pres- carry an electric charge. sure, it will shear off the counter-ions of the diffuse layer In such an aqueous system charges at solid/ liquid or and an electric field is built up.
Page 12 II. Product description 2.1.1 Measurement Charged colloids and particles of a size > 1nm can attract oppositely charged ions from the surrounding water. Separating these so called counterions from the particle creates a measurable potential difference. If such ion separation is achieved through a liquid flow, the potential is called streaming potential with the unit After a sample has been filled into the Mütek™...
Page 13: Calculation Of Charges
II. Product description 2.1.2 Calculation of charges Polyelectrolyte titration included in the calculation to obtain the so-called speci- fic charge density. For quantitative charge measurements of the sample, a polyelectrolyte titration has to be conducted which uses the streaming potential to identify the point of zero Calculation of the specific charge density charge (0 mV).
Page 14: Determination Of The Isoelectric Point
II. Product description 2.1.3 Determination of the isoelectric point 2.1.4 Titrations curves Acid/ base titration Information Apart from charge measurements, the Mütek™ PCD-06 The Mütek™ PCD-06 Standard or Premium conti- lends itself to identifying the isoelectric point (IEP) of nuously generates a titration curve while performing a dispersions.
Page 15: Solid Particles
II. Product description 2.2 Applications 2.1.4.2 Solid particles A titration curve for an aqueous suspension of particles Papermaking is shown in Fig. 2-4. Improved machine running by controlling anionic Here the titration curve is nearly linear, because all solid trash particles contribute toward the creation of a streaming Improved retention control potential.
Page 16: Designation Of The Pcd-06
II. Product description 2.3 Designation of the PCD-06 Hint Check if a legible type plate (below) is provided on the rear panel of the device. Please replace if il-legible or missing. 2.3.1 Type plate PCD-06 The following type plate is provided on the rear panel of the instrument: BTG Instruments AB Industrigatan 1-3...
Page 17: Technical Data
II. Product description 2.4 Technical data Dimensions Mütek PCD-06: 224 mm x 233mm x 335 mm (w x d x h) 5.1 kg Weight Mütek PCD-06 Light: 6.0 kg Mütek PCD-06 Standard: 6.4 kg Mütek PCD-06 Premium: Power supply External power supply Input: 100-240 V AC;...
Page 18 II. Product description 2.5 CE Declaration When using the units in combinations other than those The system operator is responsible for CE directive tested for, BTG can not guarantee CE directive conformity. Conformity must be verified by inspec- conformity. tion. The units in combination with customer-installed exter- nal devices may conform with EMC and safety require- ments when properly installed and CE-marked...
Page 19: Scope Of Delivery
II. Product description 2.6 Scope of delivery 2.6.1 Mütek™ PCD-06 Standard delivery Item PCD-06 Measuring cell Displacement piston External power supply Power cable Piston brush Cationic titrant bottle, 0.001N, 250 ml Anionic titrant bottle, 0.001N, 250 ml Beaker with screen Optional Item Precision pipette, 2-10 ml...
Page 21: Description Of Pcd-06
III. System layout and functions III. System layout and functions The Mütek™ PCD-06 Particle Charge Detector is available as Light, Standard, or Premium. 3.1 Description of PCD-06 Fig. 3-1 Front view PCD-06 PCD-06 Light has no pump installed Designations PCD-06 Standard has one pump installed Display PCD-06 Premium has two pump installed Displacement piston...
Page 22 III. System layout and functions Fig. 3-2 Rear panel PCD-06 Designations DC Input Power ON/ OFF switch Ethernet pH Input USB B interface mV Output USB A interface pH Output Operation Manual Mütek PCD-06 © BTG 2021...
Page 23: Measuring Cell
III. System layout and functions 3.1.1 Measuring cell 3.1.2 pH set (optional) Standard delivery of the Mütek™ PCD-06 includes a The Mütek™ PCD-06 Smart identifies not only the precision measuring cell and a displacement piston. Fit- charge level but also the pH of a sample. ted in the measuring cell are two platinum electrodes for In combination with a Travel Titrator module or an exter- identifying the streaming potential.
Page 25: Safety Rules
IV. Installation IV. Installation This chapter covers the installation of the Mütek™ The Mütek™ PCD-06 is equipped with an external PCD-06 Particle Charge Detector and the necessary power pack which connects to all power voltages within preparations. In the course of installation, all required the range indicated on it.
Page 26: Sample Specification
IV. Installation 4.4.3 Sample specification General Particle sizes Basically, nearly every aqueous sample - including ori- Solid particle sizes in a sample should not exceed 500 ginal concentrations - can be measured. The measura- µm. The minimum detectable limit value is 1 nm. bility of a sample may be verified by the Mütek™...
Page 27: Solutions
IV. Installation 4.5 Solutions Conductivity The conductivity of a sample decisively impacts the streaming potential: the higher the conductivity, the 4.5.1 Titrants lower the electrical resistance in the sample will be and Titrants must always carry the opposite charge of the the more the streaming potential will decrease without, sample.
Page 28: Acids/Bases
IV. Installation 4.5.2 Acids/bases Use diluted acids as titrants for anionic samples, and diluted bases for cationic samples. Hydrochloric acid, sulphuric acid and sodium hydroxide solution have proven useful in this context and are nor- mally applied in concentrations of 0.1 - 0.01 mol/l. 4.5.3 Cleaning solution Warning...
Page 29: Start-Up Procedure
IV. Installation 4.6 Start-up procedure The PCD-06 is available in three variants: 4.6.2 Connect PCD-06 Light • PCD-06 Light with no titration pump installed The Mütek™ PCD-06 can be operated with an external • PCD-06 Standard with one titration pump installed automatic titrator.
Page 30: Replace A Titrant
IV. Installation 4.6.3 Replace a Titrant 4.6.4 Rinse the System Hint Rinse the dosing tubes in order to assure that they are bubble-free, before starting the measurement. Procedure Turn on the Mütek™ PCD-06. Insert the measuring cell. Press the rinse button. The system will be rinsed with 2 ml.
Page 31: Measuring
V. Measuring Measuring Information The Mütek™ PCD-06 measures the streaming potential of an aqueous sample. To detect its charge level a titra- tion is performed until reaching a streaming potential of 0 mV. Titration may be performed manually or better with help of an automatic titrator.
Page 33: Sample Preparation
V. Measuring 5.4 Sample preparation For stock systems including both colloidally dissolved material and solid particles, different ways of sample preparation will give different data on the charge condi- tions prevailing in a sample (see 4.4.3 "Sample specifi- cation", page 24). Generally speaking, results are only directly com-para- ble if the samples are prepared in an identical manner.
Page 34: Back Titration
V. Measuring 5.4.4 Back titration Calculation of charge density q: This method of sample preparation suggests itself in the (V2 - V1) * c following cases: Due to their structure, the samples cannot be trans- V2 - V1: The difference between the charges of ferred to the cell directly which would enable quanti- the fresh cationic titrant and the reacted tative determination of the charge level of larger...
Page 35: Fill Sample Into The Measuring Cell
V. Measuring 5.5 Fill sample into the measuring cell Preparation • If applicable, install pH electrode in the measuring Information cell (see Fig. 5-4 "Insert pH electrode", page 34). Since both electrodes inside the measuring cell must be covered with liquid, the sample volume should be Hint at least 10 ml.
Page 36: Measuring With The Mütek™ Pcd-06 Light
V. Measuring 5.6 Measuring with the Mütek™ PCD-06 Light 5.6.1.1 Start measurement Information • Assemble the Mütek PCD-06 Light according to The display is equipped with a screen saver which auto- chapter 4.6 "Start-up procedure", page 27. matically appears after 20 min. To deactivate the screen •...
Page 37: Start Titration
V. Measuring • To start the potential measurement in mV, press the 5.6.2 Automatic titration with external titrator button "START". Optionally the Mütek PCD-06 can be combined with This will cause the displacement piston to oscil- an automatic titrator. late and the streaming potential to be displayed in mV Information •...
Page 38: Start Measurement
V. Measuring 5.7 Measuring with the Mütek™ PCD-06 Standard or Premium. This will cause the displacement piston to oscil- Information late and the streaming potential to be displayed The display is equipped with a screen saver which auto- in mV. matically appears after 20 min.
Page 39: Result Handling Mütek™ Pcd-06
V. Measuring 5.7.2 Result handling Mütek™ PCD-06 5.7.3 Result transfer to a USB stick All measurement results will be stored in the internal For result transfer to a USB stick, plug in a USB stick in memory. During measurement the diagram screen will the front USB slot of the instrument: show the measurement progress: Open the menu “Results”...
Page 40: Transfer Parameter To A Usb Stick
V. Measuring 5.8 Methods 5.7.3.1 Transfer Parameter to a USB stick For Parameter transfer to a USB stick, plug in a USB Adjusting titration methods stick in the front USB slot of the instrument. The PCD-06 features two factory set, non-editable methods: one for endpoint titrations (EP) and one for iso-electric point titrations (IEP).
Page 41: Setting Of Standard Methods
V. Measuring 5.8.1 Setting of standard methods Method 900: Termination 0 mV Pump Automatic Type Meas. Mode fixed Increment Addition Dynamic dE (set) 8 mV dV (min) 0,01 ml dV (max) 0,1 ml Method 901: Termination 7,00 pH Pump Automatic Type Meas.
Page 42: General Method Settings
V. Measuring 5.8.2 General Method Settings Termination value Adjust the value (mV or pH) you want the titration to end. Hint The typical termination value of an EP titration is 0 mV. However, there is no sharp cut at 0 mV, instead the sig- nal will cross the zero line and show the opposite sign.
Page 43: Volume
V. Measuring 5.8.3 Volume Dynamic: Selecting this mode, the dosage will be set under dyna- Here you can program, how much titrant is to be mic control. Parameters for controlling the dosage are injected per dosing step. ΔE, Vmin and Vmax. ΔE is the mV signal change bet- Fixed: ween two dosage steps, and Vmin Vmax specify, how The pump will deliver the same amount of titrant in...
Page 44: Time
V. Measuring 5.8.4 Time Example: ΔE (Stability) is 1 mV, Δt (Stability) is 1 s, tmin is 5 s and Here you can program the time interval between two tmax is 15 s. Means that the PCD continuously checks titrant dosing steps. for the defined stability criterion: the signal must not Fixed: swing more than 1 mV within 1 s.
Page 45: Settings
V. Measuring 5.9 Settings 5.9.2 Titrant Settings Select the titrant for those settings to be changed, press 5.9.1 About device on the three dots to open the submenu. The following parameters can be adjusted: Titrant name Opens a keyboard to enter any name Batch number Opens a keyboard to enter a...
Page 46: Ph Calibration (Optional)
V. Measuring 5.9.3 pH Calibration (optional) This will open the following screen: Information If the Mütek™ PCD-06 is connected to an external titra- tor system, the pH electrode has to be simultaneously calibrated on the titrator and Mütek™ PCD-06. For calibration, use two commercial buffer solutions, one of them with pH 7.0 and the other with pH 4.01 or pH 9.21.
Page 47: Date And Time
V. Measuring 5.9.4 Date and Time 5.9.5 Calibration Adjust date and time in this menu: Information With the following settings the instruments calibration will be changed, this has a direct influence to the mea- surement results. This setting should be changed only from a skilled user.
Page 48 V. Measuring Analog output: In case the PCD-06 is connect to an external titrator the output signal can be adjusted to this titrator. 1. Display the potential value in the titrator (for that refer to the titrator manual). 2. Press the "Calibrate" button for Analog out in the PCD-06 screen 3.
Page 49: Diagnostics And
VI. Diagnostics and troubleshooting VI. Diagnostics and troubleshooting 6.1 Safety instruction 6.2 Personnel requirements If errors occur that are not listed in the table below, dis- Troubleshooting may only be performed by qualified connect the Mütek™ PCD-06 and tag it as "defective". and skilled personnel.
Page 50: Basic Faults
VI. Diagnostics and troubleshooting 6.3.2 Basic faults The following basic faults may be experienced with the Mütek™ PCD-06 also when used in combination with an exter- nal titrator: Problem Cause Solution Heavy fluctuations of strea- Excessive conductivity of the • Dilute sample.
Page 51: Cleaning
VII. Maintenance VII. Maintenance 7.1 Cleaning 7.2 Maintenance 7.1.1 Cleaning the instrument 7.2.1 Personnel requirements Use a soft and lint-free cloth to wipe the outer surfaces Maintenance shall exclusively be carried out by quali- of the instrument. Take care not to scratch the touch- fied and skilled personnel.
Page 52 VII. Maintenance • Press "Accept" to return to "NEW TEST" without • Select 5 or 10 ml any changes Information • Press "Adjust" to set a new factor for the cationic titrant. If you select 5 ml fill 5 ml de-ionized water into the measuring cell.
Page 53: Checking The Streaming Potential
VII. Maintenance 7.3 Proper handling of the pH electrode 7.2.4 Checking the streaming potential If a freshly cleaned measuring cell is filled with 10 ml of The pH electrode must not fall dry. Therefore always put anionic titrant 0.001 N repeatedly in succession, the on the protection cap, when not using the electrode.
Page 54: Yearly Lab Check™ Inspection
VII. Maintenance 7.4 Yearly LAB Check™ inspection To guarantee reliable measurement from the start, every Mütek™ laboratory instrument undergoes thoro- ugh testing before leaving the factory. BTG’s maintenance program LAB Check™ keeps your laboratory device in perfect working order year after year.
Page 55: Safety Instructions
VIII. Shutting down the system, storage and disposal VIII. Shutting down the system, storage and disposal 8.1 Safety instructions 8.4 Storage Please adhere to the applicable safety rules when shut- Store the Mütek™ PCD-06 in a suitably protected place. ting down the system. Do not keep outdoors.
Page 57: Spare Parts List
IX. Parts list IX. Parts list 9.1 Spare parts list Item Description Part No. HA2004839 Measuring cell for Mütek PCD-06 PA2005535 Displacement piston for Mütek PCD-06 External power supply P00X50359 Piston brush for cleaning the measuring cells, d = 20 mm P00X10158 Beaker with screen P00X18977...
Page 58: Consumables
IX. Parts list 9.3 Consumables Item Description Remarks Part No. Cationic titrant bottle 0.001 N, 250 ml Ready-to-use titrant for HB2000369 Mütek PCD-06 Cationic titrant bottle 0.001 N, 4x250 ml Ready-to-use titrant for HB2000370 Mütek PCD-06 Cationic titrant 0.001 N, 1000 ml Ready-to-use titrant for H00X10217 Mütek...
Page 60 BTG Instruments AB P.O. Box 602 SE-661 29 Säffle Sweden Phone: +46 533 426 00 www.btg.com...
