- Page 1 Evolution MAX THE SUPERIOR STICK VACUUM...
- Page 2 Features Battery indicator HEPA 13 exhaust filter Battery Suction power control LED display On/off button HEPA cyclone filter Dust bin Dust sensor Dust release button Rod release button Floor head release button Combination power head...
-
Page 3: What's In The Box
What’s in the box Hard floor Combination Mini Crevice tool power head power head motorised brush Extension hose Elbow connector 2-in-1 brush Long dusting brush Charger adaptor 2 Batteries charging dock(not shown) -
Page 4: Specifications
INTRODUCTION Congratulations on the purchase of your new Wertheim Evolution MAX Stick Vacuum. There are many useful features built into your Stick Vacuum. We recommend that you carefully read this instruction manual to take the best advantage of these features. -
Page 5: Before You Begin
BEFORE YOU BEGIN This cleaner must be operated in accordance with these instructions and used only for domestic household cleaning to remove dry dirt and dust from household carpets, flooring, walls and fabrics. This cleaner is not fit to be used as an industrial cleaner and will void the manufacturer’s warranty if used inappropriately. -
Page 6: Precautionary Measures
PRECAUTIONARY MEASURES: Do not operate the vacuum cleaner too close to heaters, radiators or other hot surfaces. Before inserting the plug into the wall, make sure your hands are dry. Before turning on the vacuum cleaner, safely remove any large objects from the floor or cleaning surface in order to prevent damage to the filter. -
Page 7: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT! Always switch off the vacuum cleaner before cleaning, when not in use or attempting any maintenance task. The charger must only be connected to an AC power supply at the voltage shown on the rating label. This vacuum cleaner should only be used for its intended purpose as described in this instruction manual. - Page 8 11. Do not use the vacuum cleaner 19. Never clean the vacuum to pick up flammable items or cleaner or any of the electrical combustible liquids (i.e. gasoline, parts, especially the electrical hot ashes, cigarettes, matches, connections with water or liquid explosive materials or anything cleaners.
- Page 9 Battery use and care Never attempt to open the The vacuum cleaner is only to be used with the charger provided battery for any reason. If the with the vacuum cleaner. plastic housing of the battery casing breaks or cracks, Only charge the battery inside immediately discontinue use the cleaner or the charging...
- Page 10 ASSEMBLY Important! Always remove the power plug from the power supply before assembly. Insert the charger stand rod into the charger base. Ensure that the rod is inserted securely into the charger base. Place the charging dock onto the top of the charger stand rod.
- Page 11 Insert the rod into the air inlet of the cleaner. You will hear an audible “click” sound when it is securely in place. Installing and removing the battery Insert the battery into the cleaner until it clicks into place. To remove the battery, press both battery release buttons and gently remove.
- Page 12 INSTRUCTIONS FOR USE On/off button Press the on/off button to turn the cleaner on or off. Once turned on, the vacuum cleaner will enter continuous mode and will run without the button being held down. Auto mode Press the ‘auto’ button to enter auto mode. While in auto mode, the cleaner will automatically adjust the suction power to match the amount of dust detected.
- Page 13 Caution! Do not try to open the battery and repair it yourself. Warning! The charger has been specially designed to charge the Wertheim Evolution MAX Stick Vacuum. Do not use any other charger.
-
Page 14: Led Display
LED DISPLAY Dust sensor indicator Power change indicator Auto mode indicator Motor blockage indicator Roller brush blockage indicator... -
Page 15: Tools And Accessories
TOOLS & ACCESSORIES Important! Ensure that the cleaner is switched off before fitting or removing accessories. Hard floor power head Ideal for thoroughly cleaning hard floors. Combination power head Ideal for daily cleaning on multi surfaces, especially carpets. Mini motorised brush Ideal for picking up pet hair from furniture and upholstery. - Page 16 Extension hose Ideal for flexible cleaning in hard to reach places. Elbow connector Ideal for cleaning at unconventional angles. Crevice tool Ideal for cleaning in crevices, corners and hard to reach places. Long dusting brush Ideal for dusting hard to reach places. 2-in-1 brush Ideal for gentle dusting without scratching surfaces.
-
Page 17: Maintenance
MAINTENANCE Important! Always remove the battery from the cleaner before performing any maintenance. Emptying the dust bin Disconnect the rod from the cleaner. Hold the cleaner over a rubbish bin and press the dust release button to open and empty the dust bin. - Page 18 Cleaning the HEPA cyclone filter Pull the filter unit from the cleaner. Following the arrow, twist the cyclone filter and remove it. Place the filter unit back into the cleaner, lining up the clips on each side with the grooves inside the cleaner.
- Page 19 Cleaning hard floor power head Disconnect the power head from the rod. To release the brush roller from the power head, use a flat head screwdriver (not supplied) to turn the screw and unlock the cover. Lift the small cover to access the brush roller. Lift out the brush roller from the power head.
- Page 20 Cleaning mini turbo brush. Disconnect the mini turbo brush from the cleaner. To release the roller brush from the mini turbo brush, use a flat head screwdriver or coin (not supplied) and turn the coin to unlock the cover. Lift the small cover to access the roller brush. Lift the roller brush from the motorised brush.
-
Page 21: Troubleshooting
TROUBLESHOOTING Servicing should be performed by an authorised service agent or qualified technician. Contact Wertheim Customer Service for your nearest authorised service agent on 1800 815 270 (AUS), 0800 282 288 (NZ). FAULT CAUSE SOLUTION Cleaner doesn’t - Flat battery... -
Page 22: Spare Parts
TROUBLESHOOTING Roller brush jammed The roller Turn off the cleaner and indicator is on during brush is remove the battery, then operation. jammed. follow the maintenance procedures in this manual to clean the roller brush. Air blockage indicator The suction is Turn off the cleaner and is on during operation. - Page 23 If Electrical Home-Aids Pty Ltd decide to repair or replace the cleaner, it will do so at its own cost. Your Wertheim cleaner, in the case of domestic Electrical Home-Aids Pty Ltd is unable to accept use, has a two year parts and labour warranty...
- Page 24 Electrical Home-Aids Pty. Limited ABN: 62 007 539 577 Brandon Office Park, Building 3, First Floor, 530-540 Springvale Road, Glen Waverley, Victoria, 3150 wertheimcleaning.com.au wertheim.co.nz enquiries@wertheim.net.au V2 08/2021...
