- Page 2 Thank you for choosing MIKROE! We present you the ultimate multimedia solution for embedded development. Elegant on the surface, yet extremely powerful on the inside, we have designed it to inspire outstanding achievements. And now, it’s all yours. Enjoy premium.
-
Page 3: Table Of Contents
Ta b l e o f c o n t e n t s Introduction 4.2 External flash storage 1.Key microcontroller features 5. Connectivity 1.1 MCU programming/debugging 5.1 RF 1.2 MCU reset 5.2 USB 2. Power supply unit 5.3 mikroBUS shuttle connectors ™... - Page 4 Pick your own look Identical in the back, choices up front. mikromedia 4 for PIC Capacitive FPI with bezel mikromedia 4 for PIC Capacitive FPI with frame...
-
Page 5: Introduction
4 for PIC CAPACITIVE FPI is a compact development The usability of mikromedia 4 FPI does not end with its ability to accelerate the prototyping and application development stages: it board designed as a complete solution for the rapid development is designed as the complete solution which can be implemented of multimedia and GUI-centric applications. -
Page 6: Key Microcontroller Features
∫ Operating frequency up to 64 MHz ∫ High-Precision PLL for USB For the complete list of MCU features, please refer to the PIC18F97J94 datasheet. mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... - Page 7 4 for PIC CAPACITIVE FPI U S E R M A N U A L...
-
Page 8: Mcu Programming/Debugging
It is used to generate a LOW logic level on the microcontroller reset pin. Figure 3: Front and back partial view mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... - Page 9 4 for PIC CAPACITIVE FPI U S E R M A N U A L...
-
Page 10: Power Supply Unit
USB power source is used in combination with the battery. Figure 4: Power supply unit view mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... -
Page 11: Detailed Description
The transition between available power sources is designed to provide ∫ 3V3: 3.3V from the main power supply rail uninterrupted operation of the development board. mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... -
Page 12: Psu Connectors
(typically PC), USB power bank, or USB wall adapter. When powered over the USB connector, the available power will depend on the source capabilities. Figure 5: Power supply connectors view mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... - Page 13 4 for PIC CAPACITIVE FPI U S E R M A N U A L...
- Page 14 Using low-quality USB hubs, and too long or low-quality USB cables, may cause a significant USB voltage drop, which can obstruct the battery charging process. mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L...
-
Page 15: Power Redundancy & Ups
Li-Po/Li-Ion battery, mikromedia 4 FPI can be powered ON. This can fails or becomes disconnected. The power supply redundancy also allows be done by a small switch at the edge of the board, labeled as SW1 (2). -
Page 16: Capacitive Display
Human Machine Interfaces (HMIs). It also includes some building various GUI-centric Human Machine Interface (HMI) advanced features such as the embedded video engine, applications. enhanced sketch processing, built-in synthesizer, and more. mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... - Page 17 Figure 10: Display and FT813 view...
- Page 18 Figure 11: MicroSD card slot and Flash memory view mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L...
-
Page 19: Data Storage
4. Data storage The mikromedia 4 FPI development board is equipped with two types of storage memory: with a microSD card slot and a Flash memory module. 4.1 microSD card slot 4.2 External flash storage The microSD card slot allows storing large amounts of data externally, mikromedia 4 FPI is equipped with the SST26VF064B Flash memory (2). -
Page 20: Connectivity
GFSK modulation, allowing data rates in the range from 250 kbps, up to 2 Mbps. The GFSK modulation is the most efficient RF signal modulation mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... -
Page 21: Usb
USB connectors (symmetrical design, higher current rating, compact size, etc). mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... -
Page 22: Mikrobus ™ Shuttle Connectors
∫ An arbitrary length of flat cables may be used (depending on the particular use cases) ∫ Connectivity can be additionally expanded, by cascading these connectors using Shuttle click mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... - Page 23 For additional information about the mikroBUS , please visit the official ™ web page at www.mikroe.com/mikrobus Figure 13: mikromedia 4 FPI connected to mikroBUS Shuttle view mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L...
-
Page 24: Sound-Related Peripherals
4 for PIC CAPACITIVE FPI U S E R M A N U A L mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... -
Page 25: Audio Codec
3.5mm four-pole headphones jack (3), allowing to connect a headset with a microphone. mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... -
Page 26: Sensors And Other Peripherals
6-axis e-compass solution. The I2C slave address can be changed by using two SMD jumpers grouped under the ADDR SEL label (2). Figure 15: mikromedia 4 FPI back view mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... -
Page 27: Real-Time Clock (Rtc)
CR1216, CR1220, CR1225 button cell battery types, allowing it to include a real time clock within the applications. mikromedia 4 for PIC CAPACITIVE FPI U S E R M A N U A L... - Page 28 RAPID DEVELOPMENT OF MULTIMEDIA AND GUI-CENTRIC APPLICATIONS...
-
Page 30: What's Next
What’s Next? You have now completed the journey through each and every feature of mikromedia 4 for PIC CAPACITIVE FPI development board. You got to know its modules and organization. Now you are ready to start using your new board. We are suggesting several steps which are probably the best way to begin. - Page 31 D I S C L A I M E R All the products owned by MikroElektronika are protected by copyright law and international copyright treaty. Therefore, this manual is to be treated as any other copyright material. No part of this manual, including product and software described herein, must be reproduced, stored in a retrieval system, translated or transmitted in any form or by any means, without the prior written permission of MikroElektronika.
- Page 32 If you want to learn more about our products, please visit our website at www.mikroe.com If you are experiencing some problems with any of our products or just need additional information, please place your ticket at www.mikroe.com/support Time-saving embedded tools If you have any questions, comments or business proposals, do not hesitate to contact us at office@mikroe.com...
