210.100-IOM (JUL 2018)
Page 50
Name of Installing Contractor ______________________________ Unit Tag # _________________________________________
Qualified Technician's Name: ______________________________ Unit Model # ______________________________________
Frick Sales Order # _______________________________________ Unit Serial # _______________________________________
Job Name _______________________________________________
Job Site Location ________________________________________
Job Site Contact and Phone # _____________________________
GENERAL UNIT INSPECTION
Identify and perform appropriate "lockout/tag out" and safety rules. For details on points below, see appropriate section of
Installation, Operation, Maintenance manual provided with each air handler. For VFD equipped air handlers, refer to the VFD
forms for additional start-up requirements.
Unit inspected for damage interior and exterior.
Unit installed on flat and level surface.
within roof slope limitations where applicable.
Package Installed According to 090.400-SB (Proper Installation
of Electronic Equipment)
All shipping splits sealed and secured properly.
Unit installed with proper clearances.
Visually inspect roof curb for tight seal around unit.
All shipping bolts and other material have been removed. (Fan,
VIFB, Energy Recovery Wheel, Damper)
All shipped loose parts installed.
Controls installation complete.
Remote Panel is mounted and wired.
Unit control panel is accessible. (Catwalk, ladder, etc.)
All field wiring complete and inspected.
All wiring and tubing connections made at shipping splits.
All field piping connections complete.
Fan Inspection
Verify that bearings and locking collars have properly tightened
setscrews, bolts and nuts.
Sheaves properly aligned and tight on shaft.
Belt tension adjusted properly per drive package label on fan.
Verified fan alignment with unit discharge. Adjust with isolation.
Burners
Gas Supply is provided up to unit.
Gas supply pressure is correct.
PRV installed, if required?
I have reviewed, understand, and acknowledge the terms and conditions of Johnson Controls start-up policies detailed
in this document. The information that is provided in the prestart-up checklist is accurate.
Authorized Signature
Please FAX to Johnson Controls - Frick Service: 717-762-8624
ACUAIR
HYGIENIC AIR UNITS
®
INSTALLATION - OPERATION - MAINTENANCE
ACUAIR AIR HANDLER PRESTART-UP CHECKLIST
PRESTART-UP (For Site Records)
Outdoor unit mounted
Condensate drain properly trapped.
Air hoods installed properly.
Terminal screws and wiring connections
in control, electric and Air Modulator panels.
Verify that all ductwork is complete and available for full airflow.
Clean air filters installed properly and secured.
Damper linkage is tight and in correct "power off" position.
Pipe chase floor sealed at penetrations.
Pneumatic tubing for room pressure sensors is in place.
Filter gauge is installed in supply ductwork and set to zero
Verify all plastic spacers have been removed between door and
door frame.
Verify Energy Recovery Wheel turns freely and wheel segments
are fully engaged.
Installer has cleaned out interior.
Correct line voltage is supplied at disconnect.
Fan wheel properly aligned, tight on shaft and freely moving.
Verified fan base isolators and thrust restraints for proper
adjustment. NOTE: Do not remove functional bolts from
seismic isolators.
Fan bearings properly lubricated.
Flue is installed, if needed.
Gas line is purged.
Authorized Firm
secure
Phone #
