OWNER'S MANUAL.
BMW M5 SEDAN.
Online Edition for Part no. 01405A37B39 - VI/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M5 Sedan and is the answer not in the manual?

Questions and answers

Related Manuals for BMW M5 Sedan

Summary of Contents for BMW M5 Sedan

  • Page 1 LINK: CONTENT & A-Z The Ultimate Driving Machine® OWNER'S MANUAL. BMW M5 SEDAN. Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 2 Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 3 The more familiar you are with your vehicle, the better control you will have on the road. We therefore strongly suggest: Read this Owner's Manual before starting off in your new BMW. Also use the Integrated Owner's Manual in your vehicle. It contains important notes on ve‐...

  • Page 4: Table Of Contents

    On the road ........................CONTROLS Dashboard ........................Sensors of the vehicle ....................Operating state of the vehicle ..................iDrive ..........................BMW Remote Software Upgrade ................General settings ......................Personal settings ......................Connections ........................Opening and closing ..................... Seats, mirrors and steering wheel ................
  • Page 5 © 2021 Bayerische Motoren Werke Aktiengesellschaft Munich, Germany Reprinting, including excerpts, only with the written consent of BMW AG, Munich. US English ID7 VI/21, - Printed on environmentally friendly paper, bleached without chlorine, suitable for recycling. Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 6: Notes Information

    Internet Validity of the Owner's Manual Vehicle information and general information on BMW, for instance, on technology, are available Production of the vehicle on the Internet: www.bmwusa.com. At the time of production at the plant, the printed Owner's Manual is the most current resource.
  • Page 7 ››...‹‹ Responses generated by the voice Owner's Manuals. activation system. Your BMW service center is happy to answer any Action steps questions that you may have about the features and options applicable to your vehicle. Action steps to be carried out are presented as a numbered list.
  • Page 8 The manufacturer of the vehicle recommends of the printed Owner's Manual for the vehicle. that you entrust corresponding procedures to a BMW center. If you choose to use another serv‐ After a software update in the ice facility, BMW recommends use of a facility that performs work, e.g., maintenance and repair,...
  • Page 9 State of California to Specifications for maintenance measures: cause cancer and birth defects or other repro‐ ▷ BMW Maintenance system. ductive harm. To minimize exposure, avoid ▷ Maintenance Booklet, available online and ac‐ breathing exhaust, do not idle the engine ex‐...
  • Page 10 Information NOTES Refer to section on engine oil change regarding nical information. Information about the vehicle recommended service intervals for oil changes. condition, component usage, maintenance rec‐ ommendations, events or faults can be stored temporarily or permanently. Data memory This information generally documents the state of a component, a module, a system, or the sur‐...
  • Page 11 Information NOTES qualified service center or repair shop performs The sound and picture from the mobile device repair or servicing work. can be played back and displayed through the multimedia system. Certain information is trans‐ Data entry and data transmission ferred to the mobile device at the same time.
  • Page 12 Information NOTES Any collection, processing, and use of personal This data can help provide a better understand‐ data above and beyond that needed to provide ing of the circumstances in which crashes and the services must always be based on a legal injuries occur.
  • Page 13 Na‐ tional Highway Traffic Safety Administration NHTSA, in addition to notifying BMW of North America, LLC, P.O. Box 1227, Westwood, New Jersey 07675-1227, Telephone 1-800-831-1117.

  • Page 14: Owner's Manual Media

    Owner's Manual media NOTES Owner's Manual media Vehicle features and Manual for the vehicle will contain the latest in‐ formation. options Printed Owner's Manual This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are Concept not necessarily available in your vehicle, e.g., due The printed Owner's Manual describes all stand‐...
  • Page 15 Owner's Manual media NOTES Scrolling through the Owner's Manual Turn the Controller, until the next or previous contents are displayed. Context help General information The Integrated Owner's Manual can be ac‐ cessed from any menu. Depending on the se‐ lected function, either the associated description or the main menu of the Integrated Owner's Manual will be displayed.

  • Page 16: Quick Reference Entering

    Entering QUICK REFERENCE Entering Opening and closing Buttons for the central locking system Buttons on the vehicle key Overview 1 Unlocking Buttons for the central locking system. 2 Locking 3 Opening the trunk lid Locking 4 Panic mode, pathway lighting Press the button with the front doors closed.
  • Page 17 Entering QUICK REFERENCE Comfort Access Opening and closing the trunk lid with no-touch activation Principle Principle The vehicle can be accessed without operating The trunk lid can be opened and closed with no- the vehicle key. touch activation using the vehicle key you are Carrying the vehicle key with you, e.g., in your carrying.
  • Page 18 Entering QUICK REFERENCE Driver's door Depending on the setting, the doors may also be unlocked. Without automatic tailgate operation: closing Close the trunk lid manually. With automatic tailgate operation: closing Press the button on the inside of the 1 Exterior mirrors trunk lid.
  • Page 19 Entering QUICK REFERENCE Buttons on the Controller Button Function Go to the main menu. Go to the Media/Radio menu. Go to the Communication menu. Go to navigation map. Go to destination input menu for navi‐ gation. Go to the previous display. Go to the Options menu.

  • Page 20: Set-Up And Use

    Set-up and use QUICK REFERENCE Set-up and use Seats, mirrors and steering Adjusting the head restraint wheel Adjusting the height: electrical head restraints Electrically adjustable seats Press switch up or down. 1 Thigh support 2 Forward/backward, height, seat tilt Adjusting the distance: sport seat 3 Upper backrest 4 Backrest width 5 Lumbar support...
  • Page 21 Set-up and use QUICK REFERENCE For equipment specification with M Carbon ▷ Seat position. bucket seat: ▷ Exterior mirror position. The distance to the back of the head is adjusted ▷ Steering wheel position. via the backrest tilt. ▷ Height of the Head-up Display. Adjusting the exterior mirrors Storing Set the desired position.
  • Page 22 Set-up and use QUICK REFERENCE Connecting the mobile phone via Button Function Bluetooth Programmable memory but‐ "COM" tons. "Mobile devices" Tilt the Controller to the right. "New device" "Phone calls and audio" Changeover of waveband/satel‐ lite radio. The vehicle's Bluetooth name is displayed on the Control Display.
  • Page 23 Set-up and use QUICK REFERENCE Enter the numbers. on the display of the mobile device, and con‐ firm that the two match. Select the icon. The connection is estab‐ lished via the mobile phone to which this "Use Apple CarPlay" function has been assigned.

  • Page 24: On The Road

    On the road QUICK REFERENCE On the road Driving Releasing With drive-ready state switched on: Drive readiness Press the switch while stepping on the brake pedal or selector lever position P is set. Turning on drive readiness The LED and indicator light turn off. The parking brake is released.
  • Page 25 On the road QUICK REFERENCE sure on the brake pedal until you are ready to The engaged gear is displayed in the instrument start. cluster, e.g., 1. In selector lever position R, the selector lever locks. Engaging selector lever position P Engage selector lever position R only when the Engage selector lever position P only when the vehicle is stationary.
  • Page 26 On the road QUICK REFERENCE High beams, headlight flasher Window wiper system Turn on window wiper system Press the lever forward or pull it backward. ▷ High beams on, arrow 1. Press the lever up until the desired position is The high beams light up when the low beams reached.
  • Page 27 On the road QUICK REFERENCE Climate control Activate/deactivate rain sensor Automatic climate control Button Function Temperature. Activate: press the lever up once from its 0 posi‐ tion, arrow 1. Air conditioning. Deactivate: press the lever back into the 0 posi‐ tion.
  • Page 28 Cleaning the wheels The friction during hard braking may produce brake dust and make the rims dirty. Brake dust can be removed by cleaning the rims. BMW rec‐ ommends using vehicle care and cleaning prod‐ ucts from BMW. Turn the fuel cap counterclockwise.
  • Page 29 The BMW Assist Concierge service offers infor‐ mation on events, filling stations or hotels, and provides phone numbers and addresses. Many hotels can be booked directly by the BMW Con‐ cierge service. The Concierge service is part of the optional BMW Assist Response Center.

  • Page 30: Dashboard

    Dashboard CONTROLS Dashboard Vehicle features and not necessarily available in your vehicle, e.g., due to the selected options or country versions. This options also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country-spe‐ the applicable laws and regulations must be ob‐...
  • Page 31 Dashboard CONTROLS Parking lights  173 Manual Speed Limiter  221 Automatic headlight control  172 Depending on the equipment: Adaptive light functions  174 Cruise control on/off  223 Automatic High Beam Assis‐ tant  175 beams  173 Depending on the equipment: Active Cruise Control on/off  225 Instrument lighting  177 With steering and traffic jam assis‐ tant  235: Right roadside parking light  173...
  • Page 32 Dashboard CONTROLS Selection lists  166 Wipers  141 Volume, see Owner's Manual for Rain sensor  141 Navigation, Entertainment and Communication  6 Cleaning the windshield  142 Voice activation system  50 Turning drive readiness state on/ Changing the station/track, see off  134 Owner's Manual for Navigation, En‐ tertainment, Communication  6 Auto Start/Stop function  134 Telephone, see Owner's Manual for Navigation, Entertainment and...
  • Page 33 Dashboard CONTROLS In the vicinity of the center console 1 Control Display  46 Panorama View  263 Ventilation  276 Hazard warning system  360 Parking assistance systems  244 Intelligent Safety  183 Sound control  151 4 Glove compartment  296 DSC Dynamic Stability Con‐ trol  217 5 Radio/multimedia, see Owner's Manual for Navigation, Entertainment, and Communica‐ SETUP  212 tion  6 6 Automatic climate...
  • Page 34 Dashboard CONTROLS In the vicinity of the headliner Emergency Call, SOS  362 Reading lights  177 Operating the electric glass sun‐ Interior lights  177 roof  110 Indicator light, front passenger air‐ bag  182 Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 35: Sensors Of The Vehicle

    Sensors of the vehicle CONTROLS Sensors of the vehicle Vehicle features and Cameras options Front camera This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due to the selected options or country versions.
  • Page 36 Sensors of the vehicle CONTROLS Top view cameras ▷ Camera behind the windshield: if the camera has overheated and been temporarily switched off due to excessively high temper‐ atures. ▷ Camera behind the windshield: during cali‐ bration of the camera immediately after vehi‐ cle delivery.
  • Page 37 Sensors of the vehicle CONTROLS Ultrasound sensors Radar sensors, side, rear Ultrasound sensors in the front/ rear bumpers The ultrasound sensors of the Park Distance Control PDC are lo‐ cated in the bumpers. The radar sensors are located in the bumper. Ultrasonic sensors, side System limits of the radar sensors...
  • Page 38 Sensors of the vehicle CONTROLS ▷ Under certain weather conditions, e.g., high relative atmospheric humidity, wet conditions, snowfall, cold, extreme heat, or strong wind. ▷ With tow bars and trailer couplings of other vehicles. ▷ With thin or wedge-shaped objects. ▷...

  • Page 39: Operating State Of The Vehicle

    Operating state of the vehicle CONTROLS Operating state of the vehicle Vehicle features and Safety information options Warning This chapter describes all standard, country-spe‐ An unsecured vehicle can begin to move and cific and optional features offered with the series. possibly roll away.
  • Page 40 Operating state of the vehicle CONTROLS Display in the instrument cluster ▷ After several minutes, if no operation takes place on the vehicle. OFF is displayed in the instru‐ ▷ If the charge state of the vehicle battery is ment cluster. The drivetrain is low.
  • Page 41 Operating state of the vehicle CONTROLS Display in the instrument cluster ▷ Set the parking brake. ▷ On uphill grades or on a downhill slope, The activated drive readiness is indicated in the turn the front wheels in the direction of the instrument cluster, depending on the equipment, curb.

  • Page 42: Idrive

    Via the Controller. All functions of the entertainment system, ▷ Via the touchscreen. e.g., radio stations or connection with external ▷ Via the BMW Intelligent Personal Assistant. devices. ▷ Depending on the equipment: with the ges‐ ture control. Communication Phone and message functions, e-mail and Safety information calendar, and also the connection and manage‐...
  • Page 43 Management of apps, access to apps and ve‐ hicle functions. Additional apps and vehicle func‐ Several menu items are preceded by a check‐ tions can be purchased from the BMW Store. box. The checkbox indicates whether the func‐ tion is activated or deactivated. Selecting the Widgets menu item activates or deactivates the function.
  • Page 44 iDrive CONTROLS Icon Meaning Icon Meaning Roaming is active. Stop. Locating is active. Data protection. SMS text message received. Destination guidance active. Message received. Passengers on board. Reminder. Do not disturb. Sending not possible. Programmable memory buttons Entertainment symbols General information The iDrive functions can be stored on the pro‐...
  • Page 45 iDrive CONTROLS Executing a function Control Display Press the button. Safety information The function will work immediately. This means, for instance that the number is dialed when a NOTICE phone number is selected. Objects in the area in the front of the Control Display can shift and damage the Control Dis‐...
  • Page 46 iDrive CONTROLS Controller Buttons on the Controller Button Function General information The buttons can be used to open the menus di‐ Go to the main menu. rectly. The Controller can be used to select menu items and enter the settings. Go to the Media/Radio menu.
  • Page 47 iDrive CONTROLS Selecting a menu Adjusting contents Depending on the equipment, the contents of Selecting menu items menus "MEDIA", "COM" and "NAV" can be ad‐ justed, for instance to remove the entries of Turn the Controller until the desired menu functions that are not used from the menu.
  • Page 48 iDrive CONTROLS Deleting Entering special characters Icon Function Input Operation Press the Controller: delete letter or Delete a charac‐ Swipe to the left on the number. ter. touchpad. Hold the Controller down: delete all let‐ Enter a blank Swipe to the right in the ters or numbers.
  • Page 49 iDrive CONTROLS Opening the main menu ▷ To show the display bar, pull down the dis‐ play bar at the top edge of the screen. Tap on the icon. ▷ To hide the display bar, pull up the display bar at the top edge of the screen.
  • Page 50 The microphone on the driver's side is active. ▷ BMW Intelligent Personal Assistant is availa‐ ▷ Say the wake word ›Hello BMW‹ or a personal ble depending on the national-market ver‐ wake word. sion. The microphones on the driver's or front pas‐...
  • Page 51 General information tivation word from connected third-party provid‐ ers can be used. Speaking the wake word ›Hello BMW‹ or the per‐ sonal wake word will start the system. "CAR" "Settings" Preset wake word "General settings"...
  • Page 52 iDrive CONTROLS Function examples The voice control system and the feedback it provides does not replace the printed or Integrated Owner's Manual. The speech recog‐ Vehicle status and vehicle information nition and quality of the feedback may vary. ▷ ›Is my tire pressure still OK?‹ ›How can the passenger airbag be deactivated‹...
  • Page 53 iDrive CONTROLS "Response length" The device must be connected via Apple Car‐ Play or Android Auto. Select the desired setting. Speaking during voice output Press and hold the button on the steering wheel for approx. 3 seconds. It is possible to answer during inquiries of the The voice activation of the smartphone is ac‐...
  • Page 54 ▷ Execute gestures clearly. ▷ The gestures can also be executed from the BMW Gesture Control front-passenger side. Principle Several iDrive functions can be operated by hand motion using BMW Gesture Control. Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 55 iDrive CONTROLS Possible gestures Gesture Operation Function Move index finger forward and backward in the di‐ Accept call. rection of the screen. Select a highlighted entry in a list during voice control. Confirm pop-up. Move hand across the width of the Control Display Reject call.
  • Page 56 iDrive CONTROLS Gesture Operation Function Move fist with thumb extended to right left back Forward Skip function. and forth. The next title is played. Stretch out five fingers, form a fist and stretch five Individually assignable gesture. fingers out again. Assigning gesture individually ▷...

  • Page 57: Bmw Remote Software Upgrade

    Standby must be turned on to search for a soft‐ or quality improvements available. ware upgrade. General information Automatic search BMW recommends performing the Remote The vehicle regularly searches for updates in the Software Upgrade as soon as it becomes availa‐ background. ble.
  • Page 58 Display in the vehicle: Via BMW app "CAR" If an upgrade is available, information about the "Settings" new software version is displayed in the BMW "General settings" app. "Remote Software Upgrade" The data for the upgrade can then be down‐...

  • Page 59: Validity Of The Owner's Manual

    Remove connected devices from the OBD socket. In the event of a malfunction, follow the instruc‐ tions on the control display or in the BMW app. Starting installation If the malfunction cannot be remedied, contact a The upgrade can be installed when all prerequi‐...

  • Page 60: After A Software Update In The Vehicle

    BMW Remote Software Upgrade CONTROLS After a software update in the vehicle After a vehicle software update, such as via Re‐ mote Software Upgrade, the Integrated Owner's Manual for the vehicle will contain the latest in‐ formation. Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 61: General Settings

    General settings CONTROLS General settings Vehicle features and Setting the time format options "CAR" "Settings" This chapter describes all standard, country-spe‐ "General settings" cific and optional features offered with the series. "Date and time" It also describes features and functions that are "Time format:"...
  • Page 62 General settings CONTROLS Setting the date format data to analyze the attention of the driver. This system supports various vehicle assistance sys‐ "CAR" tems, e.g.: "Settings" ▷ Fatigue alert. "General settings" ▷ Steering and traffic jam assistant with Ex‐ "Date and time" tended Traffic Jam Assistant.

  • Page 63: General Information

    General settings CONTROLS Speed warning Activating/deactivating pop-ups Principle For some functions, pop-ups are displayed auto‐ The speed warning can be used to set a speed matically on the Control Display. Some of these limit. A warning will be issued when this speed pop-ups can be activated or deactivated.
  • Page 64 Communication messages, for example e- mails, SMS text messages or reminders. General information ▷ Messages, for instance from the BMW app. The BMW Intelligent Personal Assistants allows ▷ Messages from the manufacturer of the vehi‐ the configuration of the range of messages that cle, for instance technical information or im‐...
  • Page 65 General settings CONTROLS "Notification display" Select the desired setting. Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 66: Personal Settings

    Phone book. The vehicle offers different services, whose use ▷ Online data, for instance Favorites, cookies. requires a data transfer to BMW or a service pro‐ ▷ Office data, for instance voice memos. vider. The data transmission can be deactivated ▷...
  • Page 67 If the set-up assistant was opened in the in the driver's profile can be synchronized with guest profile: create driver profile. the personal BMW ConnectedDrive account. It is ▷ Pairing mobile devices with the vehicle. thereby possible to use these settings in other ▷...
  • Page 68 In the following cases the guest profile is auto‐ Scanning the displayed QR code will accept matically active: the access data for the ConnectedDrive ac‐ count from the BMW app. ▷ A driver profile has not been created yet. ▷...
  • Page 69 ConnectedDrive account. This means that it is possible to use the "CAR" personal settings in other BMW vehicles with "Driver profiles" ConnectedDrive access as well, if this function is Tilt the Controller to the right.
  • Page 70 "Avatar" Select the desired profile picture. ConnectedDrive countries: The profile image is transferred from the Con‐ nectedDrive customer portal or the BMW app. Deleting the driver profile "CAR" "Driver profiles" Tilt the Controller to the right.

  • Page 71: Connections

    Connections CONTROLS Connections Vehicle features and not necessarily available in your vehicle, e.g., due to the selected options or country versions. This options also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country-spe‐ the applicable laws and regulations must be ob‐...
  • Page 72 Connections CONTROLS Function Connection type Symbol in the device list Apple CarPlay: Bluetooth and WLAN. Using apps via iDrive and via voice op‐ eration. Android Auto: Bluetooth and WLAN. Using apps via iDrive and via voice op‐ eration. Displaying the vehicle identification The following connection types require one-time pairing with the vehicle: number and software part number...
  • Page 73 Bluetooth audio. phones via Bluetooth®. WLAN in the vehicle, Wi-Fi hotspot. ▷ "Apps" Apps. With the installed BMW app, apps from the smartphone can be displayed in the Screen Mirroring. vehicle. Apple CarPlay. ▷ "Wi-Fi®"...
  • Page 74 Compatible device with Bluetooth interface. pected. Compatible devices, refer to page 72. In this case, the following explanations can help: ▷ The vehicle key or BMW display key is in the Why could the mobile phone not be paired or vehicle. connected? ▷...
  • Page 75 Connections CONTROLS WLAN connection ▷ Transmission of the telephone book entries is not yet complete. ▷ It is possible that only the telephone book en‐ General information tries of the mobile phone or the SIM card are For certain applications, such as apps, the data transmitted.
  • Page 76 Connections CONTROLS Connecting a device to the Tilt the Controller to the right. Internet via the Wi-Fi hotspot "Settings" "Internet connection" Using the Internet for the first time via the Wi- Fi hotspot requires registration and possibly a Select the desired setting. data volume purchase from a service provider.
  • Page 77 Connections CONTROLS Apple CarPlay© Operation preparation For more information, refer to the Integrated Owner's Manual or the Owner's Manual for Navi‐ gation, Entertainment, Communication. Principle Frequently Asked Questions CarPlay allows certain functions of a compatible Apple iPhone to be used via Siri voice control All requirements are met and all required steps and iDrive.
  • Page 78 Connections CONTROLS Frequently Asked Questions Android smartphone with Android 11, regard‐ less of the manufacturer. All requirements are met and all required steps ▷ Compatible devices, refer to page 72. were completed in the specified order. Despite that, the mobile device does not function as ex‐ ▷...
  • Page 79 Connections CONTROLS ▷ Do not use force when plugging the connec‐ Additional information: tor into the USB port. USB port, refer to page 291. ▷ Use a flexible adapter cable. ▷ Protect the USB device against mechanical damage. ▷ Due to the large number of USB devices available on the market, it cannot be guaran‐...

  • Page 80: Opening And Closing

    There is a risk of injury. Take the cle key and the BMW display key. vehicle key with you so that the vehicle can be Each vehicle key contains a replaceable battery.
  • Page 81 Opening and closing CONTROLS ▷ Pressing the Start/Stop button. ▷ If only the driver's door and the fuel filler flap or all access to the vehicle will be unlocked ▷ Releasing the parking brake. when the button is pressed for the first time. ▷...
  • Page 82 Opening and closing CONTROLS Locking With Comfort Access: convenient closing General information Safety information The behavior of the vehicle during locking using the vehicle key depends on the following set‐ tings: Warning ▷ If the locking of the vehicle is confirmed with With convenient closing, body parts can be a light signal or a sound signal.
  • Page 83 Opening and closing CONTROLS Trunk lid Replacing the battery General information NOTICE To avoid locking the vehicle key in the vehicle, Improper batteries in the vehicle key can dam‐ do not place the vehicle key in the cargo area. age the vehicle key. There is a risk of damage Depending on the vehicle equipment and coun‐...
  • Page 84 Opening and closing CONTROLS Have old batteries disposed of by a deal‐ ▷ Fault of radio transmission by a charging er’s service center or another qualified process of mobile devices, for instance service center or repair shop or take charging of a mobile phone. them to a collection point.
  • Page 85 CONTROLS Safety information ▷ The options provided by the Remote Serv‐ ices of the BMW app include the ability to lock and unlock a vehicle. Warning This requires an active BMW Connected‐ People or animals in the vehicle can lock the Drive contract and the BMW app must be in‐...
  • Page 86 Opening and closing CONTROLS Overview Display General information The display is divided into the upper status line, the information area, and the lower status line. Upper status line The upper status line displays the following infor‐ mation: ▷ Vehicle secured/vehicle unsecured. 1 Opening the trunk lid ▷...
  • Page 87 Opening and closing CONTROLS Hiding the display on the display manually: press Main menu Information/Function the button on the left side of the display key. "Mobility info" Range with available fuel. To show the display: "Preconditioning With parked-car heating: Press the button on the left side of the dis‐ setting"...
  • Page 88 Malfunction Charging General information A Check Control message is displayed. Via USB BMW display key detection by the vehicle may Connect the display key via the micro-USB malfunction under the following circumstances: charging interface to a USB port. ▷ The battery of the display key is discharged.
  • Page 89 Opening and closing CONTROLS Key Card Turning on drive readiness via emergency detection of the BMW display key Principle The Key Card allows the vehicle to be unlocked and locked, as well as started. General information The Key Card is available with Comfort Access.

  • Page 90: In The Vehicle

    Key Card. A vehicle key must be located in the vehicle to deactivate the Key Card. When BMW Digital Key is activated for the vehi‐ cle, a digital key can be used instead of the vehi‐ cle key.

  • Page 91: Principle

    Opening and closing CONTROLS If the Key Card is not detected, slightly change BMW Digital Key can be used with a compatible the position of the Key Card and repeat the pro‐ smartphone or other compatible mobile termi‐ cedure. nals, such as a Smartwatch.
  • Page 92 The proof of authorization can be started via the control key or another method may be used for BMW app or via the activation code in the corre‐ sponding smartphone function, for instance the Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 93 CONTROLS authentication. Follow the corresponding instruc‐ The digital remote control key must be enabled tions on the smartphone or the Control Display. again to be able to use BMW Digital Key again. "CAR" Deleting a shared key "Settings" "Doors/ vehicle access"...
  • Page 94 Opening and closing CONTROLS Safety information Ensure that the display is facing up. Close the cover of the smartphone tray. Press the Start/Stop button to start the en‐ Warning gine. For some country versions, unlocking from the inside is only possible with special knowledge. Sale of the smartphone Persons who spend a lengthy time in the vehi‐...
  • Page 95 Opening and closing CONTROLS Locking/unlocking via the door Alarm system lock The activated alarm system is triggered when the door is opened, if the vehicle has been un‐ Pull and hold the door handle outward with locked via the door lock. one hand.
  • Page 96 ▷ The interior lights are switched on, unless ▷ Unlocking and locking the vehicle using the they were manually switched off. BMW Digital Key. ▷ Folded in exterior mirrors are folded out. ▷ Opening trunk lid. If the exterior mirrors were folded in via the ▷...
  • Page 97 Opening and closing CONTROLS Convenient closing ▷ With anti-theft protection: Anti-theft protec‐ tion is switched off. Safety information ▷ With alarm system: The alarm system will be switched off. Warning Locking With convenient closing, body parts can be jammed. There is a risk of injury. Make sure General information that the area of movement of the doors is clear The behavior of the vehicle during locking via the...
  • Page 98 Opening and closing CONTROLS Safety information General information To avoid locking the vehicle key in the vehicle, do not place the vehicle key in the cargo area. Warning Selector lever position P must be engaged for Body parts can be jammed when operating the touchless opening of the trunk lid.
  • Page 99 Opening and closing CONTROLS Settings Moving your foot again will stop the closing mo‐ tion, and moving it one more time after that will Contactless opening and closing of the tailgate re-open the trunk lid. can be switched on or off. "CAR"...
  • Page 100 Opening and closing CONTROLS Malfunction front passenger is engaged in the safety belt buckle during locking: Vehicle key detection by the vehicle may mal‐ ▷ The vehicle will be locked but not secured function under the following circumstances: against theft. ▷...
  • Page 101 Opening and closing CONTROLS Safety information When unlocking with the vehicle key, the doors may also be unlocked. Warning Open from inside Body parts can be jammed when operating the Press the button in the storage compart‐ trunk lid. There is a risk of injury. Make sure that ment of the driver's door.
  • Page 102 Opening and closing CONTROLS With automatic tailgate ▷ By pressing the button on the vehicle key. Pressing again continues the opening mo‐ operation: opening and closing tion. ▷ By pressing or pulling the button in the driv‐ Opening er's door. Pressing again continues the open‐ ing motion.
  • Page 103 Opening and closing CONTROLS Valet parking mode Malfunction In the event of an electrical malfunction, operate the unlocked trunk lid manually with a slow and Principle smooth motion. In the valet parking mode, the Control Display is disabled. The operation via iDrive is no longer Trunk emergency unlocking possible.
  • Page 104 Opening and closing CONTROLS Via the vehicle settings The trunk lid will be locked and disconnected from the central locking system. "CAR" "Activate now" "Settings" This PIN can be used once to deactivate the "General settings" valet parking mode for the active guest pro‐ "Valet parking mode"...
  • Page 105 Opening and closing CONTROLS Guest profile "Doors/ vehicle access" Deactivate or activate the desired confirma‐ In the guest profile, the valet parking mode can tion signals: only be deactivated if the valet parking mode was activated in the guest profile. ▷...
  • Page 106 Opening and closing CONTROLS Trunk lid Establishing idle state after opening the front doors Trunk lid and doors "CAR" You can set up if only the trunk lid will be un‐ "Settings" locked or if the doors will also be unlocked when "Doors/ vehicle access"...
  • Page 107 Opening and closing CONTROLS Opening the doors with the alarm not correctly closed. Correctly closed access points are secured. system switched on When the still open access points are closed, The alarm system is triggered when a door is the interior motion sensor and tilt alarm sen‐ opened if the door was unlocked using the sor will be switched on.
  • Page 108 Drive readiness is switched on. When a window is often opened in the same po‐ The vehicle key must be in the car's interior. sition, this task can be performed by the BMW Intelligent Personal Assistant. For instance when Opening the same parking garage is frequently used.
  • Page 109 Opening and closing CONTROLS Closing The window closes with limited jam protec‐ tion. If the closing force exceeds a specific ▷ Pull the switch to the resistance threshold, closing is interrupted. point. The window closes while the switch is being Pull the switch past the resistance held.
  • Page 110 Opening and closing CONTROLS Roller sunblinds, rear side Overview windows Safety information Warning With closed roller sunblinds and open windows, the roller sunblinds may be strained while driv‐ ing due to the wind. The roller sunblinds may be damaged and vehicle occupants may be Button for the roller sunblind.
  • Page 111 Opening and closing CONTROLS Overview Opening/closing the glass sunroof and sun protection separately ▷ Slide switch back to the resist‐ ance point and hold. Holding down the switch opens the sun protection. If the sun protection is already fully open, the glass sunroof opens.
  • Page 112 Opening and closing CONTROLS Pressing the switch again Close all doors. stops the motion. Push the switch forward past the resistance ▷ Briefly press out the switch twice in succes‐ point and hold. sion toward the front past the resistance The glass sunroof closes with limited jam point.
  • Page 113 Opening and closing CONTROLS Make sure that the closing path is clear. Initializing the system Press the switch up and hold it until the initialization is complete: Initialization begins within 15 seconds. ▷ If the glass sunroof is closed, it opens then closes again.

  • Page 114: Seats, Mirrors And Steering Wheel

    Seats, mirrors and steering wheel CONTROLS Seats, mirrors and steering wheel Vehicle features and Seats options Safety information This chapter describes all standard, country-spe‐ cific and optional features offered with the series. Warning It also describes features and functions that are Seat setting while driving can lead to unex‐...
  • Page 115 Seats, mirrors and steering wheel CONTROLS Longitudinal direction The current seat position can be stored using the memory function. Overview Press switch forward or backward. Height 1 Thigh support 2 Forward/backward, height, seat tilt 3 Upper backrest 4 Backrest width 5 Lumbar support 6 Backrest tilt, head restraint For equipment specification with M Carbon...
  • Page 116 Seats, mirrors and steering wheel CONTROLS Backrest tilt Lumbar support Principle The curvature of the seat backrest can be ad‐ justed in a way that it supports the lumbar region of the spine. The lower back and the spine are supported for upright sitting position.
  • Page 117 Seats, mirrors and steering wheel CONTROLS Upper backrest All belt fastening points are designed to achieve the best possible protective effect of the safety belts with proper use of the safety belts and cor‐ Principle rect seat setting. Notes on sitting safely, refer to The upper backrest supports the back in the page 114.
  • Page 118 Seats, mirrors and steering wheel CONTROLS Buckling the safety belt Warning Guide the safety belt slowly over shoulder The protective effect of safety gear, including and hip to put it on. safety belts, may not be fully functional or fail in Insert the tongue plate into the safety belt the following situations: buckle.
  • Page 119 Seats, mirrors and steering wheel CONTROLS reminder can also be activated if objects are Pull the latch plate at the end of the belt out placed on the front passenger seat. of the fixture on the rear shelf. Insert the lower buckle tongue in the belt Safety belt reminder for rear lock, arrow 1.
  • Page 120 Seats, mirrors and steering wheel CONTROLS Front head restraints ▷ Only use accessories that have been de‐ termined to be safe for attachment to a head restraint. General information ▷ Do not use any accessories, for instance The current head restraint position can be stored pillows, while driving.
  • Page 121 Seats, mirrors and steering wheel CONTROLS The head restraint is automatically repositioned ▷ Do not use seat or head restraint covers. when the upper backrest is adjusted. ▷ Do not hang objects, for instance clothes M5 CS: hangers, directly on the head restraint. The distance to the back of the head is adjusted ▷...
  • Page 122 Seats, mirrors and steering wheel CONTROLS ▷ To lower: press the button, arrow 1, and push The mirror setting is stored for the driver profile the head restraint down. currently in use. When a driver profile is selected, the stored position is called up automatically. ▷...
  • Page 123 Seats, mirrors and steering wheel CONTROLS Malfunction Activating In case of an electrical malfunction, adjust the slide the switch to the driver's side mirror by pressing the edges of the mirror glass. mirror position. Folding in and out Engage selector lever position R. Deactivating NOTICE Slide the switch to the front passenger's side...
  • Page 124 Seats, mirrors and steering wheel CONTROLS Steering wheel Steering wheel heating Overview Safety information Warning Steering wheel adjustments while driving can lead to unexpected steering wheel movements. Vehicle control could be lost. There is a risk of accident. Adjust the steering wheel while the vehicle is stationary only.
  • Page 125 Seats, mirrors and steering wheel CONTROLS Safety information The procedure stops when a switch for setting the seat is pressed or one of the memory but‐ tons is pressed again. Warning The adjustment of the seat position on the driv‐ Using the memory function while driving can er's side is interrupted after a short time while lead to unexpected seat or steering wheel...
  • Page 126 Seats, mirrors and steering wheel CONTROLS Turning on Rear Press the button once for each intensity level. The maximum intensity level is reached when three LEDs are lit. Turning off Press and hold the button until the LEDs turn off. Seat heating Adjusting the massage program "CAR"...
  • Page 127 Seats, mirrors and steering wheel CONTROLS Overview has been switched on. A new alignment is car‐ ried out after the settings have been changed. Depending on the equipment package, the fol‐ lowing functions can be automatically activated: ▷ Seat heating. ▷...

  • Page 128: Transporting Children Safely

    Transporting children safely CONTROLS Transporting children safely Vehicle features and Warning options A heated vehicle may result in death to per‐ sons, especially children, or animals. There is a This chapter describes all standard, country-spe‐ risk of injury or danger to life. Do not leave per‐ cific and optional features offered with the series.
  • Page 129 Transporting children safely CONTROLS Installing child restraint Safety information systems Warning The safety belt cannot be fastened correctly on General information children shorter than 5 ft, 150 cm without suita‐ Pay attention to the specifications and the oper‐ ble additional child restraint systems. The pro‐ ating and safety information of the child restraint tective effect of safety gear, including safety system manufacturer when selecting, installing,...
  • Page 130 Transporting children safely CONTROLS On the front passenger seat Child seat security Deactivating airbags Warning Active front passenger airbags can injure a child in a child restraint system when the airbags are activated. There is a risk of injury. Make sure that the front passenger airbags are deacti‐...
  • Page 131 Transporting children safely CONTROLS Mounts for the lower LATCH Position anchors Icon Meaning General information The corresponding icon shows the mounts for the lower The lower anchors may be used to attach the LATCH anchors. CRS to the vehicle seat up to a combined child and CRS weight of 65 lbs/30 kg when the child is Seats equipped with lower restrained by the internal harnesses.
  • Page 132 Transporting children safely CONTROLS Assembly of LATCH child Attachment points restraint fixing systems Icon Meaning Install child restraint system, see manufactur‐ er's information. The respective icon shows the attachment point for the upper Ensure that both LATCH anchors are prop‐ retaining strap.
  • Page 133 Transporting children safely CONTROLS Doors 3 Head restraint 4 Rear shelf 5 Attachment point 6 Hook for upper retaining strap Attaching the upper retaining strap to the attachment point Open the attachment point cover. Raise the head restraint. Push the locking lever on the rear doors up. Guide the upper retaining strap between the supports or along both sides of the head re‐...

  • Page 134: Driving

    Driving CONTROLS Driving Vehicle features and Auto Start/Stop function options Principle This chapter describes all standard, country-spe‐ The Auto Start/Stop function helps save fuel. cific and optional features offered with the series. The system switches off the engine during a It also describes features and functions that are stop, for instance in traffic jam or at traffic lights.
  • Page 135 Driving CONTROLS When all functional preconditions are fulfilled, the ▷ Where there is a risk of window condensation engine switches off. when the automatic climate control is switched on. Air conditioning system when the ▷ Engine or other parts not at operating tem‐ engine is switched off perature.
  • Page 136 Driving CONTROLS System limits Activating/deactivating the system manually Even if driving off was not intended, the deacti‐ vated engine starts up automatically in the fol‐ Principle lowing situations: ▷ In case of excessive warming of the interior The engine is not automatically switched off. when air conditioning is turned on.
  • Page 137 Driving CONTROLS Automatic deactivation Warning General information Unattended children or animals in the vehicle can cause the vehicle to move and endanger In certain situations, the Auto Start/Stop function themselves and traffic, for instance due to the is deactivated automatically for safety reasons, following actions: for instance if no driver is detected.
  • Page 138 Driving CONTROLS While driving Automatic Hold General information Principle To use as emergency brake while driving. Automatic Hold assists the driver by automati‐ cally setting and releasing the brake, such as Pull the switch and hold it. The vehicle when moving in stop-and-go traffic. brakes hard while the switch is being pulled.
  • Page 139 Driving CONTROLS Establishing operational readiness of Automatic Hold Warning Unattended children or animals in the vehicle Turn on drive readiness. can cause the vehicle to move and endanger themselves and traffic, for instance due to the Press the button. following actions: The LED lights up.
  • Page 140 Driving CONTROLS Blinking The LED goes out. The indicator light goes out. Automatic Hold is switched off. If the vehicle is being held by Automatic Hold, press additionally on the brake pedal, when switching off. Malfunction Press the lever past the resistance point. If the parking brake fails or in case of a fault, se‐...
  • Page 141 Driving CONTROLS The high beams light up when the low beams Press the lever up until the desired position is are switched on. reached. ▷ High beams off/headlight flasher, arrow 2. ▷ Resting position of the wipers, position 0. ▷ Rain sensor, position 1.
  • Page 142 Driving CONTROLS Safety information Upward: high rain sensor sensitivity. Downward: low rain sensor sensitivity. NOTICE Windshield washer system If the rain sensor is activated, the wipers can accidentally start moving in vehicle washes. Safety information There is a risk of damage to property, among other potential damage.
  • Page 143 Driving CONTROLS Fold-away position of the wipers Folding out the wipers Turn on standby state. Principle Press and hold the wiper lever down, until the In the fold-out position, the wipers can be folded wipers stop in a close to vertical position. out from the windshield, which is important, for instance, when changing the wiper blades or for folding away under frosty conditions.
  • Page 144 Driving CONTROLS ▷ Various driving programs: Drive mode or se‐ Icon Function quential mode. Drive mode or sequential mode. ▷ Low Speed Assistant. Parking. ▷ Various Drivelogic programs. ▷ Launch Control. Selector lever positions ▷ Upshifting display, Shift lights. D is Drive mode Safety information Selector lever position for driving.
  • Page 145 Driving CONTROLS Engaging a selector lever Engaging selector lever position P position General information To prevent the vehicle from creeping after you select a gear position, maintain pressure on the brake pedal until you are ready to start. The engaged selector lever position is displayed in the instrument cluster and on the selector lever.
  • Page 146 Driving CONTROLS Sequential mode D/S Selector lever position P is engaged automati‐ cally after approximately 35 minutes. Principle If there is a malfunction, you may not be able to change the selector lever position. In sequential mode, it is possible to shift gears Electronically unlock the transmission lock, if manually using the selector lever or the shift pad‐...
  • Page 147 Driving CONTROLS Gear change Switching via the shift paddles Principle Manual gear-shifting is possible via the shift pad‐ dles or the selector lever in sequential mode. The shift paddles on the steering wheel allow you to shift gears quickly while keeping both hands on the steering wheel.
  • Page 148 Driving CONTROLS Low Speed Assistant After each switch between Sequential mode and Drive mode, the last program selected is an ac‐ tive. Principle If the drive-ready state is switched on after the The Low Speed Assistant gives assistance at vehicle has been in the idle state and is in Drive very low speeds.
  • Page 149 Driving CONTROLS "Transmission" A Check Control message is displayed. Select the desired program Release Start/Stop button and selector lever. ▷ "D1" to "D3": Drive mode. Release brake, as soon as the starter stops. ▷ "S1" to "S3": sequential mode. Maneuver the vehicle from the hazardous area and secure it against rolling away.
  • Page 150 Driving CONTROLS Press and hold down the accelerator pedal Program Response behavior beyond the resistance point at the full throttle "EFFICIENT" Efficient, comfortable. Minimal position, kickdown. consumption. A destination flag is displayed in the instru‐ Ideal, for instance in city traffic ment cluster.
  • Page 151 Driving CONTROLS Selecting a program To activate the desired configuration with the se‐ lected settings, press the corresponding button on the steering wheel: Using the button ▷ ▷ Display in the instrument cluster When the display of the widget in the in‐ strument cluster for M SETUP is acti‐...

  • Page 152: Displays

    Displays CONTROLS Displays Vehicle features and Selection lists  166 options Widgets  154 Trip odometer, see Trip data  167 This chapter describes all standard, country-spe‐ M Steptronic Sport transmission: gear display cific and optional features offered with the series. with Drivelogic  163 It also describes features and functions that are 6 Engine oil temperature  162 not necessarily available in your vehicle, e.g., due...
  • Page 153 Displays CONTROLS Display ▷ "ROAD": all displays of the assist systems and Intelligent Safety are active in the stand‐ ard view of the instrument cluster for comfort oriented driving. ▷ "SPORT": in the M View, the displays of the assist systems and Intelligent Safety are re‐ duced to a minimum.
  • Page 154 Displays CONTROLS Safety information and the Lane Change Assistant indicate a lane change to the next lane. At the same time, the lane change to the next lane is shown with ani‐ Warning mation in the Assisted Driving View. The system cannot serve as a substitute for the System limits driver’s personal judgment in assessing visibility and traffic situation.
  • Page 155 Displays CONTROLS Selecting Current consumption The current consumption displays the current consumption of fuel. Check whether you are cur‐ rently driving in an efficient and environmentally- friendly manner. Energy recovery During energy recovery, the kinetic energy of the vehicle is converted into electric energy in coast‐ ing overrun mode.
  • Page 156 Displays CONTROLS Hiding Check Control messages Text messages Text messages in combination with an icon in the instrument cluster explain a Check Control message and the meaning of the indicator/warn‐ ing lights. Supplementary text messages Additional information, such as the reason for a fault or the required action, can be called up via Check Control.
  • Page 157 Displays CONTROLS Red lights Approach control warning with light braking function Safety belt reminder The indicator light is illuminated: pre‐ warning. Brake and increase distance. Indicator light flashes or is illuminated: safety belt on the driver or passenger Indicator light flashes and an acoustic side is not buckled.
  • Page 158 Displays CONTROLS Active Cruise Control with Stop&Go is stabilized. Reduce speed and modify your driv‐ ing style to the driving circumstances. function The indicator light lights up: DSC has malfunc‐ Indicator light flashes and an acoustic tioned. signal sounds: braking and evading. Have the system immediately checked by a deal‐...
  • Page 159 Displays CONTROLS Green lights of the interference, the system automatically becomes active again. Safety belt reminder for rear seats ▷ In the case of tires with special approval: the tire pressure monitor was unable to complete The safety belt is buckled on the corre‐ the reset.
  • Page 160 Displays CONTROLS High beams are switched on and off automati‐ a cruise control system: Speed Limit Assistant is cally depending on the traffic situation. active and detected speed limits can be applied manually for the displayed system. Additional information: Automatic High Beam Assistant, refer to Indicator light illuminates: the detected page 175.
  • Page 161 Displays CONTROLS Blue lights Additional information: Assisted Driving Plus, refer to page 239. High beams M xDrive: rear-wheel drive activated High beams are switched on. Additional information: The M xDrive 2WD program is activated. High beams, refer to page 140. The driving forces are distributed via the rear axle.
  • Page 162 Displays CONTROLS Tachometer dle or in the lower half of the temperature display. ▷ Hot engine: the pointer is at the high end of General information the temperature range. In addition, a Check A yellow prewarning field and a red prewarning Control message is displayed.
  • Page 163 Displays CONTROLS Adjusting the unit General information Depending on the country version, it may be The estimated range available with the remaining possible to set the unit for the digital tachometer. fuel is permanently displayed in the instrument cluster. "CAR" With a low remaining range, a Check Control "Settings"...
  • Page 164 Displays CONTROLS Gear shift indicator Some information on service notifications can also be shown on the BMW display key. Principle Display The gear shift indicator recommends the most Detailed information on service efficient gear for the current driving situation. notifications...
  • Page 165 Displays CONTROLS With the navigation system, the system takes "Driver Assistance" into account the information stored in the naviga‐ If necessary, "Driving" tion data and also displays speed limits present "Speed Limit Assistance" on routes without signs. "Speed limits" Without a navigation system, the system is sub‐ "Show current limit"...

  • Page 166: On The Control Display

    Displays CONTROLS Selection lists a speed limit is exceeded may depend on the Speed Limit Assistant settings. ▷ "Excess speed display": the speed limit Concept that is detected by the Speed Limit Info is Lists can be displayed and, if necessary, used for displayed with a marking in the speedom‐...

  • Page 167: Car

    Displays CONTROLS ▷ Total time for shut off engine through the Button Function Auto Start/Stop function. Change the entertainment ▷ Consumption history in form of a chart. source. Pressing the button again will Displays close the currently displayed "CAR" list. "Driving information"...
  • Page 168 Displays CONTROLS ▷ "Start of trip ( )": the values are automati‐ been reset, the following interval is automatically cally reset approx. four hours after the ve‐ set: "Individual ( )". hicle has come to a standstill. ▷ "Refueling ( )": the values are automati‐ Sport displays cally reset after refueling with a larger quantity of fuel.
  • Page 169 Displays CONTROLS Going to the vehicle status Overview "CAR" "Vehicle status" Information at a glance Symbols Description "Flat Tire Monitor": status of the run-flat tires, refer to page 337. "Tire Pressure Monitor": status Turning on/off of the Tire Pressure Monitor, re‐ fer to page 332.
  • Page 170 Displays CONTROLS Configuring the M MODE programs Turn the Controller until the desired height is reached. Depending on the selected View mode, various Press the Controller. settings can be selected. The height of the Head-up Display can also be "CAR" stored using the memory function.
  • Page 171 Displays CONTROLS Shift lights Shift lights in the Head-up Display Principle The Shift lights in the instrument cluster indicate the maximum shift point at which the best possi‐ ble acceleration can be achieved. General information If the Head-up Display is switched on, the Shift lights will be displayed in the Head-up Display.

  • Page 172: Lights

    Lights CONTROLS Lights Vehicle features and Icon Function options Low beams. This chapter describes all standard, country-spe‐ Instrument lighting. cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due Right roadside parking light.
  • Page 173 Lights CONTROLS Parking lights, low beams Welcome lights and roadside parking lights Principle General information The exterior lighting is switched on automatically when approaching or unlocking the vehicle. Position of switch: If the driver's door is opened when the drive- General information ready state is switched off, the exterior lighting is Depending on the equipment, the exterior light‐...
  • Page 174 Lights CONTROLS Setting the duration General information "CAR" The adaptive light functions may consist of one system or multiple systems, depending on the "Settings" equipment version: "Exterior lighting" ▷ Adaptive Light Control. "Pathway lighting" ▷ Cornering light. Select the desired setting. "OK"...
  • Page 175 Lights CONTROLS Adaptive headlight range Press the button on the turn signal lever. control The indicator light in the instrument clus‐ ter is illuminated when the low beams are switched on. The adaptive headlight range control feature bal‐ ances out acceleration and braking processes as The headlights are automatically switched be‐...
  • Page 176 Lights CONTROLS Safety information wagons; when driving close to train or ship traffic; or at animal crossings. ▷ In tight curves, on hilltops or in depressions, Warning in crossing traffic or half-obscured oncoming If adjustments have been made or the sensitiv‐ traffic on highways.
  • Page 177 Lights CONTROLS Instrument lighting To switch off permanently: press the button and hold for approx. 3 seconds. The interior lights in the rear of the vehicle can Functional requirement be switched on and off independently. The but‐ The parking lights or low beams must be ton is located in the rear headliner.
  • Page 178 Lights CONTROLS Turning speaker lighting on/off "Color" Select the desired setting. The speaker lighting is switched on when the ve‐ hicle is unlocked, and switched off when the ve‐ Setting the brightness hicle is locked. "CAR" Setting the brightness "Settings" "CAR"...

  • Page 179: Safety

    Safety CONTROLS Safety Vehicle features and not necessarily available in your vehicle, e.g., due to the selected options or country versions. This options also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country-spe‐ the applicable laws and regulations must be ob‐...
  • Page 180 Adjust seat and steering wheel so that hands Vehicle modifications for a person with disabili‐ can be crossed over the steering wheel. Se‐ ties may affect the air bag system; contact BMW lect the settings so that the shoulder rests Customer Relations for further information.
  • Page 181 Safety CONTROLS Strength of the driver's and front Warnings and information on the airbags are also found on the sun visors. passenger airbag Operational readiness of the General information airbag system The power that triggers the driver's/front passen‐ ger airbags depends on the position of the driv‐ Safety information er's/front passenger seat.
  • Page 182 Safety CONTROLS Automatic deactivation of ▷ Do not attach covers, cushions, ball mats or other items to the front passenger seat un‐ the front passenger airbags less they are specifically determined to be safe for use on the front passenger seat. Principle ▷...
  • Page 183 Safety CONTROLS straint system has been detected and the front style to traffic conditions. Watch traffic closely passenger airbags are not activated. and actively intervene where appropriate. Intelligent Safety Warning Due to system limits, individual functions can Principle malfunction during tow-starting/towing with the Intelligent Safety systems activated.
  • Page 184 Safety CONTROLS Press the button. above approx. 3 mph/5 km/h. The timing of warn‐ ings may vary with the current driving situation. The menu for the Intelligent Safety sys‐ tem is displayed. When the vehicle is driven so that it is intention‐ ally approaching another vehicle, the Forward If all Intelligent Safety systems were switched off, Collision Warning and brake intervention are de‐...
  • Page 185 Safety CONTROLS Overview Press the button repeatedly. The following settings are switched be‐ Button in the vehicle tween: "ALL ON": all Intelligent Safety systems are switched on. Basic settings are activated for the subfunctions. "INDIVIDUAL": the Intelligent Safety systems are switched on according to the individual settings.
  • Page 186 Safety CONTROLS Warning with braking function Brake intervention The warning prompts the driver to intervene. If a Display warning is active, the maximum braking force is used when the brake is applied. The brake pedal A warning symbol appears in the instrument must be applied sufficiently quickly and force‐...
  • Page 187 Safety CONTROLS Detection range ▷ In tight curves. ▷ If the driving stability control systems are lim‐ ited or deactivated, for instance DSC OFF. ▷ Up to 10 seconds after the start of the engine via the Start/Stop button. Warning sensitivity The more sensitive the warning settings are, for example the warning time, the more warnings are displayed.
  • Page 188 Safety CONTROLS Warning with evasion support Warning Display in the instrument cluster Indicators and warnings cannot serve as a sub‐ stitute for the driver’s personal judgment. Due If a collision with a detected vehicle or a detected to its limits, the system may not issue warnings person is imminent, a warning symbol appears or reactions, or these may be issued late or in a on the instrument cluster and in the Head-up...
  • Page 189 Safety CONTROLS of damage to property. Actively intervene as ▷ In tight curves. warranted. Refer to the information in this Own‐ ▷ If the driving stability control systems are lim‐ er’s Manual regarding the scope of the sys‐ ited or deactivated, for instance DSC OFF. tem’s operation and limitations.
  • Page 190 Safety CONTROLS Safety information Intelligent Safety Warning Sensors The system cannot serve as a substitute for the The system is controlled by the following sen‐ driver’s personal judgment in assessing visibility sors: and traffic situation. There is a risk of accident. ▷...
  • Page 191 Safety CONTROLS Manual switching off Icon Meaning Press and hold this button. Danger of collision with vehicle cross‐ All Intelligent Safety systems are ing from the right. switched off. Danger of collision with vehicle cross‐ Button Status ing from the left. Button lights up green: all Intelligent Danger of collision with vehicle for Safety systems are switched on.
  • Page 192 Safety CONTROLS Brake intervention Detection range The warning prompts the driver to intervene. The system may also assist in braking if there is a risk of collision. The vehicle can be decelerated to a standstill. The brake intervention can be interrupted by stepping on the accelerator pedal or by actively moving the steering wheel.
  • Page 193 Safety CONTROLS cess of premature or unjustified warnings and re‐ style to traffic conditions. Watch traffic closely actions. and actively intervene where appropriate. Pedestrian Warning with Warning City Collision Mitigation Due to system limits, individual functions can malfunction during tow-starting/towing with the Intelligent Safety systems activated.
  • Page 194 Safety CONTROLS Detection range Press the button repeatedly. The following settings are switched be‐ tween: "ALL ON": all Intelligent Safety systems are switched on. Basic settings are activated for the subfunctions. "INDIVIDUAL": the Intelligent Safety systems are switched on according to the individual settings. Some Intelligent Safety systems cannot be indi‐...
  • Page 195 Safety CONTROLS to activate the Brake Assistant function, the ▷ Partially covered pedestrians. brakes must be applied sufficiently quickly and ▷ Pedestrians that are not detected as such be‐ forcefully. cause of the viewing angle or contour. If there is a risk of collision, the system may also ▷...
  • Page 196 Safety CONTROLS with a brief active steering intervention in addi‐ Intelligent Safety tion to vibrating. The system thus helps keep the vehicle in the lane. Sensors Safety information The system is controlled by the following sen‐ sors: ▷ Cameras behind the windshield. Warning Additional information: The system cannot serve as a substitute for the...
  • Page 197 Safety CONTROLS Some Intelligent Safety systems cannot be indi‐ "Vibration intensity" vidually switched off. Select the desired setting. The setting is applied to all Intelligent Safety sys‐ Manual switching off tems. Press and hold this button. Switch steering intervention on/off All Intelligent Safety systems are The steering intervention can be switched on switched off.
  • Page 198 Safety CONTROLS keep the vehicle in the lane. The steering inter‐ er’s Manual regarding the scope of the sys‐ vention can be noticed on the steering wheel tem’s operation and limitations. and can be manually overridden at any time. Dur‐ ing an active steering intervention, the display in System limits of the sensors the instrument cluster will blink.
  • Page 199 Safety CONTROLS General information traffic closely and actively intervene where ap‐ propriate. Warning Indicators and warnings cannot serve as a sub‐ stitute for the driver’s personal judgment. Due to its limits, the system may not issue warnings or reactions, or these may be issued late or in a manner that is not consistent with their normal use.
  • Page 200 Safety CONTROLS Switching on manually Setting the warning time "CAR" Press the button. "Settings" The menu for the Intelligent Safety sys‐ tem is displayed. "Driver Assistance" If all Intelligent Safety systems were switched off, "Safety and Warnings" all systems are now switched on. "Active Blind Spot Detection"...
  • Page 201 Safety CONTROLS Warning function System limits Light in the exterior mirror Safety information Warning The system is designed to operate in certain conditions and circumstances. Due to condi‐ tions or other factors, the system may not re‐ spond. There may be a risk of accident or risk of damage to property.
  • Page 202 Safety CONTROLS ▷ In the event of missing, worn, poorly visible, The minimum speed is country-specific and is merging, diverging, or multiple lane markings displayed in the menu for the intelligent Safety such as in construction areas. systems. ▷ With lane boundaries that are covered in The front camera determines the lane marking snow, ice, dirt or water.
  • Page 203 Safety CONTROLS Overview a setting is changed on the menu, all settings of the menu are activated. Button in the vehicle Press the button repeatedly. The following settings are switched be‐ tween: "ALL ON": all Intelligent Safety systems are switched on. Basic settings are activated for the subfunctions.
  • Page 204 Safety CONTROLS Warning function ▷ Cameras, refer to page 35. ▷ Radar sensors, refer to page 36. Light in the exterior mirror Functional limitations The system may be limited in the following situa‐ tions: ▷ When a vehicle is approaching at a speed much faster than your own.
  • Page 205 Safety CONTROLS General information Overview Sensors The system is controlled by the following sen‐ sors: ▷ Radar sensors, side, rear. Additional information: Sensors of the vehicle, refer to page 35. Switching on/off Radar sensors monitor the area behind the vehi‐ The system is automatically active when the ve‐...
  • Page 206 Safety CONTROLS General information ▷ With lane change function: releasing the switch may trigger an automatic lane change. The emergency stop function is not triggered ▷ The system will take control of the vehicle for automatically. The emergency stop function can a maximum of 2 minutes.
  • Page 207 Other drivers of the vehicle must be informed Principle about the system. In addition, information about the system is required when handing off the ve‐ The BMW Drive Recorder stores brief video re‐ hicle. cordings of the vehicle surroundings, e.g., to document surrounding traffic.
  • Page 208 Drive Recorder ing brake is engaged or if the selector lever is in selector lever position P. The BMW Drive Recorder must be activated be‐ fore the first use of the recording function. "Apps" "Apps"...
  • Page 209 Safety CONTROLS Safety information "Settings" "Camera selection" Select desired camera. Warning In case of an accident, the system switches au‐ The system cannot serve as a substitute for the tomatically to "All" cameras. driver’s personal judgment. Due to the system limits, critical situation could not be detected If driver assistance systems are active, their cam‐...
  • Page 210 Safety CONTROLS General information in time. There is a risk of accident. Make sure that the driver is rested and alert. Adjust driving PostCrash can reduce the risk of another colli‐ style to traffic conditions. sion and subsequent consequences. At standstill Function After coming to a halt, the brake is released auto‐...
  • Page 211 Safety CONTROLS During the display, various settings can be se‐ lected. After a break, another recommendation to take a break cannot be displayed until after approxi‐ mately 45 minutes. System limits The function may be limited in the following sit‐ uations and may issue an incorrect warning or no warning at all: ▷...

  • Page 212: Driving Stability Control Systems

    Driving stability control systems CONTROLS Driving stability control systems Vehicle features and Adaptive brake assistant options In combination with Active Cruise Control ACC, this system ensures that the brakes respond This chapter describes all standard, country-spe‐ even more rapidly when braking in critical situa‐ cific and optional features offered with the series.
  • Page 213 Driving stability control systems CONTROLS Safety information Overview Buttons on the steering wheel Warning Depending on the setting, the DSC may only Button Function be available to a limited extent or may not be available when the M1 or M2 button is acti‐ vated.
  • Page 214 Driving stability control systems CONTROLS Using the button Display in the instrument cluster A reduced number of systems and functions can Icon Description be adjusted directly. Symbol lights up: corresponding Press the button. configuration is activated. Turn the Controller to select the desired set‐ ting.
  • Page 215 Driving stability control systems CONTROLS ▷ Speed Limit Assistant. Warning ▷ Speed Limit Info with preview. Indicators and warnings cannot serve as a sub‐ ▷ Steering and traffic jam assistant. stitute for the driver’s personal judgment. Due ▷ Traffic Jam Assistant. to its limits, the system may not issue warnings ▷...
  • Page 216 Driving stability control systems CONTROLS Overview Program Display "ROAD" Standard View. Button in the vehicle "SPORT" M View: individually set widg‐ ets are displayed. Depending on M View: individually set widg‐ the equipment: ets are displayed. "TRACK" Additional lettering "TRACK" in the instrument display.
  • Page 217 Driving stability control systems CONTROLS Display in the instrument cluster Warning When the display of the widget in the in‐ When driving with a roof load, for instance with strument cluster for M SETUP is acti‐ roof-mounted luggage rack, the vehicle's cen‐ vated, the selected program is displayed.
  • Page 218 Driving stability control systems CONTROLS M xDrive, refer to page 219. ▷ When freeing vehicle from deep snow or driv‐ ing off from loose ground. Activating DSC ▷ With an increased need for dynamics or lon‐ gitudinal acceleration, for instance when driv‐ Press the button.
  • Page 219 Driving stability control systems CONTROLS M xDrive Via iDrive It is possible to configure M Dynamic Mode MDM for buttons M1 or M2. Principle "CAR" M xDrive is the all-wheel-drive system of the ve‐ "M menu" hicle. M xDrive and DSC Dynamic Stability Con‐ trol work together to optimize the traction and "Configure M1"...
  • Page 220 Driving stability control systems CONTROLS Display in the instrument cluster ▷ When the drive-ready state is switched on: "4WD". Icon Description ▷ When MDM is activated: "4WD SPORT". ▷ When DSC is activated: "4WD". The indicator light is illuminated ▷ With activated M Drift Analyzer: "2WD"...

  • Page 221: Driver Assistance Systems

    Driver assistance systems CONTROLS Driver assistance systems Vehicle features and Operation options Turning on Press the button on the steering wheel. This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are The current speed is accepted as the speed not necessarily available in your vehicle, e.g., due limit.
  • Page 222 Driver assistance systems CONTROLS Changing the speed limit Warning when the speed limit is exceeded Visual warning If the speed limit is exceeded: the indica‐ tor light in the instrument cluster flashes while the vehicle speed is greater than the set speed limit. Acoustic warning Press the rocker switch up or down repeatedly ▷...
  • Page 223 Driver assistance systems CONTROLS Cruise control Warning The set speed can be incorrectly adjusted or Principle called up by mistake. There is a risk of accident. With the Cruise Control, a set speed can be ad‐ Adjust the set speed to the traffic conditions. justed using the buttons on the steering wheel.
  • Page 224 Driver assistance systems CONTROLS DSC Dynamic Stability Control is switched on, if The stored speed is displayed on the speedom‐ necessary. eter. DSC Dynamic Stability Control is switched on, if Turning off necessary. Depending on the equipment version, The speed can also be stored by pressing a but‐ press the relevant button on the steer‐...
  • Page 225 Driver assistance systems CONTROLS Continuing cruise control The icon is displayed when the set speed is reached. An interrupted cruise control can be continued by calling up the stored speed. Make sure that the difference between current Active Cruise Control with speed and stored speed is not too large before Stop&Go function ACC calling up the stored speed.
  • Page 226 Driver assistance systems CONTROLS Overview closely and actively intervene where appropri‐ ate. Buttons on the steering wheel Warning Button Function An unsecured vehicle can begin to move and With steering and traffic jam assistant: possibly roll away. There is a risk of accident. Cruise control on/off.
  • Page 227 Driver assistance systems CONTROLS ▷ Cameras behind the windshield. Icon Function ▷ Front radar sensor. Cruise control with distance control. Additional information: Sensors of the vehicle, refer to page 35. Depending on the equipment version, Application range cruise control with distance control and steering and traffic jam assistant.
  • Page 228 Driver assistance systems CONTROLS Interrupting manually Setting the speed When active, press the button on the steering Maintaining and storing the speed wheel: With steering and traffic jam assistant. Without steering and traffic jam assis‐ tant. If interrupting the system while stationary, press on the brake pedal at the same time.
  • Page 229 Driver assistance systems CONTROLS ▷ Each time the rocker switch is tapped to the according to the traffic situation or the ambient resistance point, the set speed increases or conditions, for instance poor visibility. decreases by 1 mph/1 km/h. "CAR" ▷...
  • Page 230 Driver assistance systems CONTROLS Changing between cruise control Display in the speedometer with/without distance control Depending on the equipment, a mark in the speedometer displays the status of the system. Safety information ▷ Green marking: system is ac‐ tive, the marking indicates the desired speed.
  • Page 231 Driver assistance systems CONTROLS Detected vehicle Icon Description Symbol flashes gray: Icon Description The conditions are not adequate Green icon: for the system to work. A vehicle has been detected The system was deactivated but ahead of you. applies the brakes until you ac‐ tively resume control by press‐...
  • Page 232 Driver assistance systems CONTROLS Displays in the Head-up Display Two-wheeled vehicles for instance might not be detected. Set speed Deceleration Some system information can also be displayed in the Head-up Display. The system does not decelerate in the following situations: The icon is displayed when the set speed is reached.
  • Page 233 Driver assistance systems CONTROLS Cornering Weather The following restrictions can occur under unfav‐ orable weather or light conditions: ▷ Poorer vehicle detection. ▷ Short-term interruptions for vehicles that are already recognized. Drive attentively, and react to the current traffic situation. If necessary, intervene actively, for in‐ stance by braking, steering or evading.
  • Page 234 Driver assistance systems CONTROLS closely and actively intervene where appropri‐ ▷ "Show current limit": current speed limits ate. are displayed without being applied in the instrument cluster. ▷ "Off": depending on the national-market version, Speed Limit Info and Speed Limit Warning Assistant will be turned off.
  • Page 235 Driver assistance systems CONTROLS General information For instance, the speed will be reduced in the following situations, if necessary: Depending on the speed, the system orients it‐ ▷ Before making turns. self according to the lane markings or vehicles in front.
  • Page 236 Driver assistance systems CONTROLS Functional requirements Icon Function ▷ Speed below 130 mph/210 km/h. Cruise control with distance control. ▷ Sufficient lane width. ▷ Above approx. 43 mph, 70 km/h: lane mark‐ Depending on the equipment version, ing on both sides is detected. cruise control with distance control and ▷...
  • Page 237 Driver assistance systems CONTROLS Interrupting automatically Icon Description The system interrupts the supporting steering Yellow steering wheel symbol movements automatically, for example in the fol‐ and a signal sounds, if applica‐ lowing situations: ble: ▷ At a speed above 130 mph/210 km/h. System interruption is imminent.
  • Page 238 Driver assistance systems CONTROLS Displays on the steering wheel Icon Description Yellow steering wheel symbol and a signal sounds, if applica‐ ble: System interruption is imminent. Depending on equipment, steer‐ ing wheel symbol flashes red, signal sounds: System is switching off. The two LED lights above the buttons illuminate Green steering wheel icon and analogously to the displays in the instrument...
  • Page 239 Driver assistance systems CONTROLS Extended Traffic Jam warranted. Refer to the information in this Own‐ er’s Manual regarding the scope of the sys‐ Assistant tem’s operation and limitations. Principle System limits of the sensors Extended Traffic Jam Assistant supports the Additional information: driver with vehicle control in traffic jam situations.
  • Page 240 Driver assistance systems CONTROLS Displays in the instrument ▷ The function is only available on certain street types, e.g. freeways. cluster ▷ Driving on a road without pedestrians or cy‐ clists. Icon Description ▷ Sufficient lane width. Indicator light green: system is ▷...
  • Page 241 Driver assistance systems CONTROLS System limits Safety information General information Warning The limits of the Steering and Lane Control As‐ The system cannot serve as a substitute for the sistant system apply. driver’s personal judgment in assessing the Additional information: traffic situation.
  • Page 242 Driver assistance systems CONTROLS Changing lanes Displays in the instrument cluster Ensure that the traffic situation permits changing lanes. Icon Description Press the turn signal lever in the required di‐ rection to the pressure point for signaling Green steering wheel symbol. briefly.
  • Page 243 Driver assistance systems CONTROLS Depending on the Icon Description equipment version: lane Green steering wheel symbol. change with active Gray line for lane marking on the appropriate side. guidance Green arrow symbol for lane- changing. Principle The system carries out a lane The system assists the driver when lane change.
  • Page 244 Driver assistance systems CONTROLS Turn on adaptation to the course ▷ Adaptation to the course of the route is acti‐ vated. of the route ▷ The function must be available in the country "CAR" in which the vehicle is driven. "Settings"...
  • Page 245 Driver assistance systems CONTROLS ▷ Panorama View, refer to page 263. Warning ▷ Remote 3D View, refer to page 265. Due to high speeds when PDC Park Distance ▷ Cross traffic warning, refer to page 266. Control is activated, the warning can be de‐ layed due to physical circumstances.
  • Page 246 Driver assistance systems CONTROLS Warning ▷ If selector lever position R is engaged when the engine is running. Signal tones ▷ Depending on the equipment version: while approaching detected obstacles at a speed slower than approx. 2.5 mph/4 km/h. The ac‐ General information tivation distance depends on the situation in An intermittent tone indicates when the vehicle...
  • Page 247 Driver assistance systems CONTROLS Visual warning of damage to property. Actively intervene as warranted. Refer to the information in this Own‐ er’s Manual regarding the scope of the sys‐ tem’s operation and limitations. System limits of the sensors Additional information: ▷...
  • Page 248 Driver assistance systems CONTROLS Depending on equipment Additionally, the safety information for the PDC Park Distance Control and the Automatic Parking version: emergency brake Assistant apply. function, Active PDC Additional information: ▷ PDC Park Distance Control, refer to page 245. Principle ▷...
  • Page 249 Driver assistance systems CONTROLS General information ▷ Color markings: warning against detected ob‐ stacles. The system uses the ultrasonic sensors of the ▷ Gray markings, hatched area: no obstacles Park Distance Control PDC and the Parking As‐ were detected. sistant. ▷...
  • Page 250 Driver assistance systems CONTROLS Depending on the vehicle and vehicle surroundings closely and actively intervene where appropriate. equipment: switching on/off manually Overview Press the park assistance button. Depending on the vehicle ▷ On: the LED lights up. equipment: button in the vehicle ▷...
  • Page 251 Driver assistance systems CONTROLS More than one assistance function can be active Parking using lanes and turning circle lines at the same time. Position the vehicle so that the red turning circle line leads to within the limits of the Parking aid lines parking space.
  • Page 252 Driver assistance systems CONTROLS System limits ▷ When parking parallel to the road, parallel parking. System limits of the sensors ▷ When parking in reverse perpendicular to the road, perpendicular parking. The system ori‐ Additional information: ents itself with the middle of the parking ▷...
  • Page 253 Driver assistance systems CONTROLS Functional requirements NOTICE For the measurement od parking The system can steer the vehicle over or onto spaces curbs. There is a risk of damage to property, among other potential damage. Watch traffic ▷ Maximum speed while driving forward approx. closely and actively intervene where appropri‐...
  • Page 254 Driver assistance systems CONTROLS Switching on with reverse gear ▷ Parking assistant is activated and parking space search is active. Shift into reverse. ▷ Control Display shows suitable parking The current status of the parking space spaces at the edge of the road next to the ve‐ search is indicated on the Control Display.
  • Page 255 Driver assistance systems CONTROLS Parking using the Automatic ▷ When the driver grasps the steering wheel or takes over steering. Parking Assistant ▷ Possibly on snow-covered or slippery road. Parking ▷ When there are obstacles that are hard to overcome, such as curbs. Switching on and activating the parking assis‐...
  • Page 256 Driver assistance systems CONTROLS Turning off ▷ With ditches or edges, for instance an edge of a port. The system can be switched off manually: ▷ Parking spaces that are not suitable may be Press the park assistance button. detected or suitable parking spaces may not be detected at all.
  • Page 257 Driver assistance systems CONTROLS Safety information Take your hands off the steering wheel and carefully drive off with the accelerator pedal and the brake. Warning When driving in reverse, pay attention to the The system cannot serve as a substitute for the vehicle's surroundings, and if you encounter driver’s personal judgment in assessing the an obstacle, stop immediately and take over...
  • Page 258 Driver assistance systems CONTROLS ▷ After driving a stored distance with major Depending on the view, the vehicle's surround‐ steering-wheel angles, the function of the ings or a part of it is depicted. system will be limited for the return trip. Additionally, assistance functions are shown in ▷...
  • Page 259 Driver assistance systems CONTROLS Sensors Display on the Control Display The system is controlled by the following sen‐ Overview sors: ▷ Front camera. ▷ Top view cameras. ▷ Rearview camera. Additional information: Sensors of the vehicle, refer to page 35. Turning on/off Turning on automatically 1 Toolbar, left...
  • Page 260 Driver assistance systems CONTROLS Automatic camera perspective ▷ "Parking aid lines". ▷ "Obstacle mark.". The automatic camera perspective shows a steering-dependent view in the respective driv‐ ▷ "Settings": apply settings, for instance to ing direction. use the activation points for Panorama View. This perspective adapts to the respective driving Rearview camera situation.
  • Page 261 Driver assistance systems CONTROLS Car wash view Turning circle lines show the course of the small‐ est possible turning radius on a level road. Only one turning circle line is displayed after the steering wheel is turned past a certain angle. Parking using lanes and turning circle lines Position the vehicle so that the red turning circle line leads to within the limits of the...
  • Page 262 Driver assistance systems CONTROLS Setting brightness and contrast The system does not detect whether an obstacle moves later on. For this reason, at standstill, the Brightness and contrast can be adjusted with markings are not shown anymore in the display Surround View or Panorama View switched on.
  • Page 263 Driver assistance systems CONTROLS Additional information: Depending on the equipment version, the func‐ tion can only be used when driving forward. PDC Park Distance Control, refer to page 245. Additional information: Malfunction Surround View, refer to page 258. A camera malfunction is displayed on the Control Safety information Display.
  • Page 264 Driver assistance systems CONTROLS Display on the Control Display Using activation points The use of activation points can be switched on Press the button when the engine is run‐ and off. ning. Depending on the driving direction, the image of Press the button.
  • Page 265 Switching on/off individually Plus: Remote 3D View Pre-adjustment "CAR" Principle "Settings" The BMW app and the pictures of the Surround "General settings" View cameras in combination with the corre‐ "Data privacy" sponding equipment enable the display of the "Select services individually"...
  • Page 266 Driver assistance systems CONTROLS Cross traffic warning Overview Button in the vehicle Principle At blind driveway exits or when driving out of per‐ pendicular parking spaces, road users approach‐ ing from the side are detected sooner by the cross traffic warning than is possible from the driver's seat.
  • Page 267 Driver assistance systems CONTROLS Display in the PDC Park Distance "Cross Traffic Warning" Control view "Cross traffic warning" Turning on automatically If the system was activated on the Control Dis‐ play, it is automatically switched on as soon as PDC Park Distance Control or Panorama View is active and a gear is engaged.
  • Page 268 Driver assistance systems CONTROLS System limits System limits of the sensors Additional information: ▷ Radar sensors, refer to page 36. Functional limitations The system may be limited in the following situa‐ tions: ▷ In tight curves. ▷ When crossing objects move at a very slow or a very fast speed.

  • Page 269: Driving Comfort

    Driving comfort CONTROLS Driving comfort Vehicle features and Selecting a program options Using the button This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due to the selected options or country versions.
  • Page 270 Driving comfort CONTROLS Additional information: Widgets in the instrument cluster, refer to page 154. Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 271: Climate Control

    Climate control CONTROLS Climate control Vehicle features and Automatic climate control options Overview This chapter describes all standard, country-spe‐ Buttons in the vehicle cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due to the selected options or country versions.
  • Page 272 Climate control CONTROLS Turning off Button Function When equipped with automatic climate control Defrost function. with enhanced features: Complete system: Rear window defroster. ▷ Button on the driver's side: Press and hold the left side of the Active seat ventilation, refer to button until the integrated automatic page 126.
  • Page 273 Climate control CONTROLS Adjust temperature of the Functional requirement ventilation The function is available with outside tempera‐ tures above approx. 32 ℉/0 ℃ and with the "CAR" drive-ready state switched on. "Settings" "Climate control" Switching maximum cooling on/off "Heating/ventilation" Press the button. "Temperature adjustment"...
  • Page 274 Climate control CONTROLS Controlling the intensity of the air Air recirculation mode flow Principle With the AUTO program switched on, the inten‐ sity can be adjusted. This changes the automatic You may react to unpleasant odors or pollutants control for the air mass. in the immediate environment by temporarily suspending the supply of outside air.
  • Page 275 Climate control CONTROLS Manual air distribution The program is switched off automatically if the settings on the front passenger side or in the rear are changed. Principle The air distribution for climate control can be ad‐ Defrost function justed manually. Principle Adjusting the air distribution Ice and condensation are quickly removed from...
  • Page 276 Climate control CONTROLS Microfilter/activated-charcoal Front ventilation filter The microfilter removes dust and pollen from the incoming air. The activated-charcoal filter also removes gas‐ eous pollutants from the outside air that enters the vehicle. Have this combined filter changed during vehicle maintenance.
  • Page 277 Climate control CONTROLS Ventilation in the rear, on the Climate control functions side Button Function Temperature. Maximum cooling. AUTO program. ▷ Lever for changing the air flow direction, ar‐ row 1. Air flow, manual. ▷ Thumbwheel for variable opening and closing Intensity Auto program.
  • Page 278 Climate control CONTROLS Switching off using the button AUTO program Press and hold the left side of the but‐ Principle ton. The air flow, air distribution and the temperature are controlled automatically. Temperature Switching the AUTO program on/off Principle Press the button. The automatic climate control cools or heats to The LED of the button is illuminated the configured temperature and then keeps the...
  • Page 279 Climate control CONTROLS Manual air distribution ▷ Make sure that the vehicle's date and time are set correctly. Principle ▷ Open the air vents to allow air to flow out. The air distribution for climate control can be ad‐ Switching on/off directly justed manually.
  • Page 280 Turning on riod of time for the climate control. Switch on the display of the BMW display Setting the departure time key. "Preconditioning setting" Via iDrive...
  • Page 281 Activate the desired departure time. sufficient ventilation, e.g. in enclosed garages. Via BMW display key Switch on the display of the BMW display Warning key. When stationary climate control is in operation, "Preconditioning setting"...
  • Page 282 Climate control CONTROLS Switching on via BMW display key Via iDrive: Switch on the display of the BMW display "CAR" key. "Settings" "Preconditioning setting" "Climate control" Tap on the icon. "Preconditioning/ventilation" "Activate now" "Remote Engine Start" "Start" "Starting engine for clim. control"...
  • Page 283 The system will be available BMW display key again as soon as the drive-ready state is acti‐ Switch on the display of the BMW display vated and deactivated again. key. Observe the information about the intended use "Preconditioning setting"...
  • Page 284 The system is automatically BMW recommends the use of genuine BMW switched on with the pre-ventilation if fragrancing fragrance cartridges. was switched on at the completion of the last The genuine BMW fragrance cartridges are not trip.
  • Page 285 Climate control CONTROLS "Level" Remove the cover of the new fragrance car‐ tridge. Hold the cover on the top to slide it Select the desired setting. from the fragrance cartridge. Display The illustrations on the Control Display show the actual filling level of the fragrance cartridges. "CAR"...
  • Page 286 Climate control CONTROLS Insert the fragrance cartridge without pres‐ Fragrance cartridge, arrow 2: second fra‐ sure into the cartridge holder. The cartridge grance indicated on the Control Display. snaps lightly into place. Pull desired fragrance cartridge from the Push the cartridge holder up, until it engages. holder.

  • Page 287: Interior Equipment

    Interior equipment CONTROLS Interior equipment Vehicle features and Safety information options Warning This chapter describes all standard, country-spe‐ The operation of remote-controlled systems cific and optional features offered with the series. with the integrated universal remote control, It also describes features and functions that are such as the garage door, may result in injury, not necessarily available in your vehicle, e.g., due for example, body parts becoming jammed in a...
  • Page 288 Interior equipment CONTROLS Control elements on the interior Canada: if programming with the hand-held transmitter was interrupted, hold down the in‐ mirror terior mirror button and repeatedly press and release the hand-held transmitter button for 2 seconds. 6. ▷ The LED lights up green: programming completed.
  • Page 289 Interior equipment CONTROLS Synchronizing the universal remote control with Release the button. the system: ▷ The LED flashes fast: the hand-held transmitter was detected but program‐ Park the vehicle within range of the remote- ming is not complete. controlled system. Press the button on the interior mirror for Program the relevant button on the interior 2 seconds and release.
  • Page 290 Interior equipment CONTROLS Deleting stored functions Do not damage the socket by using non-com‐ patible connectors. All stored functions will be deleted. The func‐ tions cannot be deleted individually. Safety information Press and hold the two outer buttons on the in‐ terior mirror simultaneously for approximately 10 seconds until the LED on the interior mirror Warning...
  • Page 291 Interior equipment CONTROLS Front center console In the cargo area Push the cover forward until it engages. A socket is located on the right side in the cargo area. Unfold the cover. USB port General information Follow the information regarding the connection of mobile devices to the USB port in the section on USB connections.
  • Page 292 Qi capability and of other mo‐ bile devices, which support the Qi standard. ▷ Charging the BMW Display key. General information A USB port is located in the center console. When inserting the mobile phone, make sure...
  • Page 293 Interior equipment CONTROLS NOTE This device has been tested for human exposure limits and found compliant at a minimum dis‐ tance of 2 in/5 cm during operation. Therefore, a distance of 4 in/10 cm must be maintained in every direction when operating the device.
  • Page 294 Interior equipment CONTROLS LED displays LTE-Compensator - Information and User Manual Color Meaning Your car is equipped with a wireless charging tray (WCA) to charge your mobile phone and Blue The mobile phone is charging. connect it to the mobile network. To ensure the The blue LED stays illuminated once best possible connection a signal booster (LTE- the inserted mobile phone with Qi ca‐...
  • Page 295 BMW dealer. You must not remove the booster from the car nor use it with any other than the preinstalled coupling device or antenna.

  • Page 296: Storage Compartments

    Storage compartments CONTROLS Storage compartments Vehicle features and Front passenger side glove options compartment This chapter describes all standard, country-spe‐ Safety information cific and optional features offered with the series. It also describes features and functions that are Warning not necessarily available in your vehicle, e.g., due to the selected options or country versions.
  • Page 297 Storage compartments CONTROLS Safety information integrated key, for instance when the vehicle is parked by valet parking. Additional information: Warning Integrated key, refer to page 94. Breakable objects, such as glass bottles or glasses, can break in the event of an accident Driver's side glove or a braking or evasive maneuver.
  • Page 298 Storage compartments CONTROLS Center armrest, front Opening the cup holder General information A storage compartment is located in the center armrest between the seats. Opening the storage compartment Push the cover forward until it engages. Press the button. Closing the storage Two cup holders are located in the center con‐...
  • Page 299 Storage compartments CONTROLS Closing the cup holder weight, shatterproof, and sealable containers. Do not transport hot beverages. Fold in the cup holder fully, until it engages. Clothes hooks NOTICE With an open cup holder, the center armrest General information cannot be folded back up. There is a risk of damage to property, among other potential The clothes hooks are located in the grab han‐...

  • Page 300: Cargo Area

    Cargo area CONTROLS Cargo area Vehicle features and Warning options Improperly stowed objects can shift and be thrown into the car's interior, for instance in the This chapter describes all standard, country-spe‐ event of an accident or during braking and eva‐ cific and optional features offered with the series.
  • Page 301 Cargo area CONTROLS cargo and luggage load capacity calculated in seat is not occupied, secure each of the outer Step 4. safety belts in the opposite buckle. If your vehicle will be towing a trailer, load ▷ Fold down the rear seat backrests completely from your trailer will be transferred to your ve‐...
  • Page 302 Cargo area CONTROLS Storage compartment on Safety information the left side Warning Improper use of the multifunction hooks can General information lead to a risk of objects flying about during A storage compartment is located on the left braking and evasive maneuvers, for example. side in the cargo area.
  • Page 303 Cargo area CONTROLS Safety information Folding down the rear seat backrest from the cargo area Unlock the belt lock of the center safety belt Warning in the rear using the latch plate of another Danger of jamming with folding down the back‐ safety belt.
  • Page 304 Cargo area CONTROLS Folding back the backrest Return the rear seat backrest to the upright seat position and engage it. Release the belt tongue from the fixture on the rear shelf. Insert the belt tongue in the belt lock of the center safety belt.
  • Page 305 Cargo area CONTROLS Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 306: Driving Tips

    BMW M5 Technology DRIVING TIPS BMW M5 Technology Vehicle features and Compound brake options General information This chapter describes all standard, country-spe‐ The high-performance brake system has perfo‐ cific and optional features offered with the series. rated compound brake discs.
  • Page 307 The combination of M xDrive, active M dif‐ ferential, and an Adaptive M chassis in this vehi‐ cle ensures a high degree of driving dynamics that is typical of BMW M. Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 308: Things To Remember When Driving

    Things to remember when driving DRIVING TIPS Things to remember when driving Vehicle features and Engine, transmission, and axle drive options Up to 1,200 miles/2,000 km This chapter describes all standard, country-spe‐ Drive at varying engine and road speeds, but do cific and optional features offered with the series.
  • Page 309 Things to remember when driving DRIVING TIPS Following part replacement Warning Observe the break-in procedures again, if com‐ If combustible materials, such as leaves or ponents mentioned above are replaced. grass, come in contact with hot parts of the ex‐ haust gas system, these materials can ignite.
  • Page 310 Things to remember when driving DRIVING TIPS ▷ Drive through water only if it is not deeper enter into the driver's floor area. Use floor mats than maximum 9.8 inches/25 cm. that are suitable for the vehicle and can be safely attached to the floor.
  • Page 311 Things to remember when driving DRIVING TIPS M Driver's Package: driving in Warning the higher speed range In idle state or with the engine switched off, safety functions, for instance engine braking ef‐ Warning fect, braking assistance and steering assis‐ Damage to vehicle components can negatively tance, may not be available.
  • Page 312 Things to remember when driving DRIVING TIPS Driving on racetracks Warning The vehicle is not designed for use in M Sport or motor sport type competition. There is a risk of accident. Do not use the vehicle for M Sport or motor sport type competitions.

  • Page 313: Saving Fuel

    Saving fuel DRIVING TIPS Saving fuel Vehicle features and Close the windows and glass sunroof options Driving with the glass sunroof and windows open results in increased drag and raises fuel con‐ This chapter describes all standard, country-spe‐ sumption. cific and optional features offered with the series. It also describes features and functions that are Tires not necessarily available in your vehicle, e.g., due...
  • Page 314 Switch off these functions if they are not needed. Have maintenance carried out Have the vehicle maintained regularly to achieve optimal vehicle efficiency and service life. BMW Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 315 Saving fuel DRIVING TIPS Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 316: Mobility

    Refueling MOBILITY Refueling Vehicle features and Safety information options NOTICE This chapter describes all standard, country-spe‐ With a driving distance of less than cific and optional features offered with the series. 30 miles/50 km the engine may no longer have It also describes features and functions that are sufficient fuel.
  • Page 317 Refueling MOBILITY Turn the fuel cap counterclockwise. Have fuel filler flap unlocked by a dealer’s service center or another qualified service center or re‐ pair shop. Place the fuel cap in the bracket attached to the fuel filler flap. Closing Warning The retaining strap of the fuel cap can be jam‐...

  • Page 318: Wheels And Tires

    Wheels and tires MOBILITY Wheels and tires Vehicle features and Tire pressure specifications options In the tire inflation pressure table The tire inflation pressure table, refer to This chapter describes all standard, country-spe‐ page 318, contains all tire inflation pressure cific and optional features offered with the series.
  • Page 319 Wheels and tires MOBILITY Checking using tire inflation The corrected tire inflation pressures are applied automatically. Make sure that the correct tire set‐ pressure specifications in the tire tings have been made. inflation pressure table With tires that cannot be found in the tire pres‐ Determine the intended tire inflation pressure sure values on the Control Display, reset the Tire levels for the mounted tires.
  • Page 320 Wheels and tires MOBILITY Tire inflation pressures at max. Tire size Pressure specifica‐ speeds above 100 mph/160 km/h tions in bar/PSI Rear: 285/40 R 19 2.3 / 33 107 V M+S XL Warning In order to drive at maximum speeds in excess F: 275/40 ZR 19 2.4 / 35 of 100 mph/160 km/h, please observe, and, if...
  • Page 321 Wheels and tires MOBILITY M5 CS Tire size Pressure specifica‐ tions in bar/PSI Tire size Pressure specifications F: 275/35 ZR 20 2.4 / 35 in bar/PSI 102Y XL Specifications in R: 285/35 ZR 20 2.5 / 36 bar/PSI with cold 104Y XL tires With M Driver’s Package:...
  • Page 322 Wheels and tires MOBILITY Locate the maximum tire load on the tire sidewall Designation Manufacture date and the Gross Axle Weight Rating – GAWR – on DOT … 1921 19th week 2021 the certification label on the driver door B-pillar. Divide the tire load by 1.1.
  • Page 323 Wheels and tires MOBILITY Minimum tread depth does not include acceleration, cornering, hydro‐ planing, or peak traction characteristics. Temperature The temperature grades are A, the highest, B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 324 Wheels and tires MOBILITY Approved wheels and tires ▷ Driving over curbs. ▷ Road damage. General information ▷ Tire pressure too low. The following properties are recommended and ▷ Vehicle overloading. approved by the manufacturer of the vehicle for ▷ Incorrect tire storage.
  • Page 325 Wheels and tires MOBILITY Retreaded tires Warning Incorrect wheel/tire combinations will impair the Warning vehicle's handling characteristics and a variety Retreaded tires can have different tire casing of system functions, such as the Antilock Brak‐ structures. With advanced age the service life ing System (ABS) or Dynamic Stability Control.
  • Page 326 Wheels and tires MOBILITY Storing tires ▷ From a dealer’s service center or another qualified service center or repair shop. Tire pressure ▷ www.pirelli.com Do not exceed the maximum tire inflation pres‐ Safety information sure indicated on the tire sidewall. Storage Warning ▷...
  • Page 327 Wheels and tires MOBILITY Intensive use After correcting the tire inflation pressure, carry out a reset of the Tire Pressure Monitor TPM. After an extended period of intensive driving on a racetrack and driving over curbs or leaving the roadway, the sport tires can become damaged. Tire repair set Inspect the sport tires for damage, foreign ob‐...
  • Page 328 Wheels and tires MOBILITY Overview 3 Tire pressure display 4 Reduce tire inflation pressure button Storage 5 On/off switch 6 Compressor 7 Connector/cable for socket 8 Connection hose Safety measures ▷ Park the vehicle as far away as possible from passing traffic and on solid ground.
  • Page 329 Wheels and tires MOBILITY Screw the filler hose of the sealant bottle onto the tire valve of the nonworking wheel. NOTICE The compressor can overheat during extended operation. There is a risk of damage to prop‐ erty, among other potential damage. Do not run the compressor for more than 10 minutes.
  • Page 330 Wheels and tires MOBILITY Checking and adjusting the tire Insert the connector into the power socket in the vehicle interior. inflation pressure Checking Switch off the compressor. Read the tire pressure on the tire pressure display. To continue the trip, a tire inflation pressure of at least 2 bar must be reached.
  • Page 331 Wheels and tires MOBILITY Adjustment Reset the Tire Pressure Monitor again. Replace the faulty tire and the sealant bottle of Stop at a suitable location. the tire repair set promptly. Screw the connection hose of the compres‐ Additional information: sor directly onto the tire valve stem. ▷...
  • Page 332 Wheels and tires MOBILITY When operating the system, also note the infor‐ mation found in the Tire inflation pressure chap‐ Use only in pairs on the rear wheels, equipped ter. with the tires of the following size: Additional information: ▷ 265/40 R 19.
  • Page 333 Wheels and tires MOBILITY Tire settings Status display General information Current status The tire sizes of the mounted tires can be gath‐ The system status can be displayed on the Con‐ ered from the tire inflation pressure details on the trol Display, e.g., whether or not the system is ac‐...
  • Page 334 Wheels and tires MOBILITY One to four yellow wheels Messages: for tires without special approval A flat tire or major tire pressure loss has occurred in the indicated tires. General information Gray wheels A low tire inflation pressure may cause the DSC It may not be possible to identify tire pressure Dynamic Stability Control to be switched on.
  • Page 335 Wheels and tires MOBILITY Safety information Icon Possible cause There is a tire pressure loss. Warning A damaged regular tire with low or missing tire inflation pressure impacts handling, such as Measure steering and braking response. There is a risk Reduce the vehicle speed.
  • Page 336 Wheels and tires MOBILITY In addition, an icon with a Check Control mes‐ Actions in the event of a flat tire, refer to sage appears on the Control Display. page 336. Icon Possible cause Actions in the event of a flat tire There is a tire pressure loss.
  • Page 337 Wheels and tires MOBILITY for example a flat tire may be indicated although ingly, when the low tire pressure telltale illumi‐ the tire inflation pressures are correct. nates, you should stop and check your tires as soon as possible, and inflate them to the proper Malfunction pressure.
  • Page 338 Wheels and tires MOBILITY General information tire. Initialization is started by confirming the tire inflation pressures. The system detects tire pressure loss on the ba‐ Do not initialize the system when driving with tire sis of rotation speed differences between the in‐ chains.
  • Page 339 Wheels and tires MOBILITY Changing wheels/tires Icon Possible cause There is a flat tire or a major tire pres‐ General information sure loss. When a flat tire kit is used, an immediate wheel change when there is a tire pressure loss in the Measure event of a flat tire is not always necessary.
  • Page 340 Wheels and tires MOBILITY Securing the vehicle against an emergency or spare wheel in the event of a breakdown. rolling General information Warning The vehicle manufacturer recommends to addi‐ On soft, uneven or slippery ground, for example tionally secure the vehicle against rolling away snow, ice, tiles, etc., the vehicle jack can slip when changing a wheel.
  • Page 341 Wheels and tires MOBILITY Lug bolt lock Preparing the vehicle ▷ Park the vehicle on solid and non-slip ground Principle at a safe distance from traffic. The wheel lug bolts have a special coding. The ▷ Turn on the hazard warning system. lug bolts can only be released with the adapter ▷...
  • Page 342 Wheels and tires MOBILITY Jacking up the vehicle Extend the vehicle jack by turning the vehicle jack crank or lever clockwise. Warning Hands and fingers can be jammed when using the vehicle jack. There is a risk of injury. Com‐ ply with the described hand position and do not change this position while using the vehicle jack.
  • Page 343 Wheels and tires MOBILITY Mounting a wheel Mount one emergency wheel only, as required. Unscrew the lug bolts. Remove the wheel. Put the new wheel or emergency wheel on and screw in at least two lug bolts in a cross‐ wise pattern until hand-tight.

  • Page 344: Engine Compartment

    Engine compartment MOBILITY Engine compartment Vehicle features and not necessarily available in your vehicle, e.g., due to the selected options or country versions. This options also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country-spe‐ the applicable laws and regulations must be ob‐...
  • Page 345 Engine compartment MOBILITY Hood Warning Body parts can be jammed when opening and Safety information closing the hood. There is a risk of injury. Make sure that the area of movement of hood is clear during opening and closing. Warning Improperly executed work in the engine com‐...
  • Page 346 Engine compartment MOBILITY Closing the hood Energetically close the hood from approx. 20 in/50 cm. The hood must engage on both sides. Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 347: Operating Materials

    Operating materials MOBILITY Operating materials Vehicle features and Safety information options CAUTION This chapter describes all standard, country-spe‐ The use of poor-quality fuels may result in cific and optional features offered with the series. harmful engine deposits or damage. Addition‐ It also describes features and functions that are ally, problems relating to drivability, starting and stalling, especially under certain environmental...
  • Page 348 Control Display depending on the engine oil level. Recommended gas quality Safety information BMW recommends AKI 93. Refuel with this gasoline to achieve the rated performance and consumption values. NOTICE An engine oil level that is too low causes en‐...
  • Page 349 Operating materials MOBILITY Electronic oil measurement Detailed measurement Principle General information The engine oil level is checked when the vehicle The electronic oil measurement has two measur‐ is stationary and displayed via a scale. ing principles: If the engine oil level is outside its permissible ▷...
  • Page 350 Operating materials MOBILITY Take care not to add too much engine oil. Opening, refer to page 345. Open the lid counterclockwise. Safety information Warning Operating materials, for instance oils, greases, coolants, fuels, can contain harmful ingredients. There is a risk of injury or danger to life. Follow the instructions on the containers.
  • Page 351 Operating materials MOBILITY Oil specification BMW Longlife-01 FE. Alternative engine oil types If an engine oil suitable for continuous use is not available, up to 1 US quart/liter of an engine oil with the following oil rating can be added:...
  • Page 352 Operating materials MOBILITY Coolant level Turn the lid of the coolant reservoir slightly counterclockwise to allow any excess pres‐ sure to dissipate, then open it. General information Open the coolant reservoir lid. Depending on the motorization, there are up to two coolant reservoirs in the engine compart‐...
  • Page 353 Follow the usage instructions on the washer fluid container. Use of BMW’s Windshield Washer Concentrate or the equivalent is recommended. Warning Washer fluid can ignite and catch fire on con‐...

  • Page 354: Maintenance

    Therefore, hand the service advisor the vehicle key with which the vehicle was driven most re‐ BMW maintenance system cently. Storage periods The maintenance system provides service notifi‐ cations and thereby provides support in main‐...
  • Page 355 Maintenance MOBILITY Socket for OBD Onboard Emissions Diagnosis ▷ The warning light lights up: Emissions are deteriorating. Have the vehicle checked as soon as possible. General information ▷ The warning light flashes under certain cir‐ Devices connected to the OBD socket trigger cumstances: the alarm system when the vehicle is locked.

  • Page 356: Replacing Components

    Replacing components MOBILITY Replacing components Vehicle features and switch on the wiper without a wiper blade in‐ stalled. options This chapter describes all standard, country-spe‐ NOTICE cific and optional features offered with the series. Folded-away wipers can be jammed when the It also describes features and functions that are hood is opened.
  • Page 357 Replacing components MOBILITY Headlight glass Insert the new wiper blade and press it on un‐ til it you hear it snap into the holder. The inside of the headlight glass can fog up in Fold down the wipers. cool or humid weather. When driving with the lights switched on, the condensation evaporates after a short time.
  • Page 358 Replacing components MOBILITY Register the battery to the NOTICE vehicle Battery chargers that charge the vehicle battery The manufacturer of the vehicle recommends via sockets or cigarette lighters in the vehicle that you have a service center or another quali‐ may overload or damage the 12 V electrical fied service center or repair shop register the ve‐...
  • Page 359 MOBILITY Safety information Information on the fuse layout, as well as the po‐ sitions of any other fuse boxes, is available on the Internet: www.bmw.com/fusecard. Warning Additional fuse boxes Incorrect and repaired fuses can overload elec‐ trical lines and components. There is a risk of Additional fuse boxes are located in the vehicle.

  • Page 360: Breakdown Assistance

    BMW Roadside Assistance Principle Contact the BMW Group Roadside Assistance if assistance is needed in the event of a break‐ down. Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 361 Control Display. If the vehicle is equipped with Teleservices, sup‐ When BMW Accident Assistance is activated, port is offered through Teleservice Diagnosis. data on the vehicle's condition is sent to BMW. "APPS" Functional requirements "Installed apps"...
  • Page 362 Breakdown Assistance MOBILITY Overview The Check Control message for BMW Accident Assistance can also be called up from the stored Check Control messages for a certain length of time. Additional information: Check Control, refer to page 155. Starting manually BMW Accident Assistance can also be con‐...
  • Page 363 DANGER Even if you are unable to respond, the BMW Contact with live components can lead to an Response Center can take further steps to electric shock. There is a risk of injury or danger help you under certain circumstances.
  • Page 364 Breakdown Assistance MOBILITY Tow-starting and towing Connecting the cables Before you begin, switch off all unnecessary electronic systems/components, such as the Safety information radio, on the assisting and receiving vehicles. Open the cover of the starting aid terminal. Warning Attach one terminal clamp of the positive Due to system limits, individual functions can jumper cable to the positive battery terminal, malfunction during tow-starting/towing with the...
  • Page 365 Breakdown Assistance MOBILITY Additional information: NOTICE Rolling or pushing the vehicle, refer to page 145. If the tow bar or tow rope is attached incor‐ Tow truck rectly, damage to other vehicle parts can occur. There is a risk of damage to property, among other potential damage.
  • Page 366 Breakdown Assistance MOBILITY Tow fitting Safety information General information NOTICE If the tow fitting is not used as intended, there may be damage to the vehicle or to the tow fit‐ ting. There is a risk of damage to property, among other potential damage.

  • Page 367: Vehicle Care

    Vehicle Care MOBILITY Vehicle Care Vehicle features and Distances and temperature ▷ Maximum temperature: 140 ℉/60 ℃. options ▷ Minimum distance from sensors, cameras, seals: 12 inches/30 cm. This chapter describes all standard, country-spe‐ cific and optional features offered with the series. ▷...
  • Page 368 Vehicle care products state off in car washes. General information General information BMW recommends using vehicle care and In a car wash, the vehicle must be able to roll cleaning products from BMW. Suitable vehicle freely. care products are available from a dealer’s serv‐...
  • Page 369 Vehicle Care MOBILITY Matte paintwork Caring for special components Only use cleaning and care products suitable for Light-alloy wheels vehicles with matte paintwork. When cleaning the vehicle, use only neutral rim Leather care cleaners having a pH value from 5 to 9. Do not use abrasive cleaning agents or steam cleaners Remove dust from the leather regularly, using a above 140 ℉/60 ℃.
  • Page 370 Vehicle Care MOBILITY Kenaf enter into the driver's floor area. Use floor mats that are suitable for the vehicle and can be Only treat parts made of Kenaf fibers using suita‐ safely attached to the floor. Do not use loose ble care products.
  • Page 371 Vehicle Care MOBILITY Taking the vehicle out of service When the vehicle is shut down for longer than three months, special measures must be taken. Further information is available from a dealer's service center or another qualified service center or repair shop. Online Edition for Part no.

  • Page 372: Reference

    The dimensions can vary depending on the The height of the vehicle can also differ, e.g. due model version, equipment version or country- to tires and vehicle load. specific measurement procedure. BMW M5 / M5 CS Width with mirrors in/mm 83.7/2,126 Width without mirrors in/mm 74.9/1,903...
  • Page 373 Approved front axle weight lbs/kg 2,571/1,166 Approved rear axle weight lbs/kg 2,579/1,170 Capacities BMW M5 / M5 CS Fuel tank, approx. US gal/liters 20.1/76.0 Observe further information on fuel quality, refer to page 347. Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 374: Appendix

    The following chapters were updated in the printed version of the Owner's Manual after the editorial deadline for the Integrated Owner's Manual in the vehicle had closed: ▷ Opening and closing: BMW Digital Key: gen‐ eral. Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 375 Appendix REFERENCE Online Edition for Part no. 01405A37B39 - VI/21...

  • Page 376: Everything From A To Z

    Everything from A to Z REFERENCE Everything from A to Z Index Air quality Alarm system Alarm, unintentional 3D View, see Surround View All-season tires, see Winter tires All-wheel drive, see M xDrive Ambient air package Ambient light ABS Antilock Braking System Android Auto, connection to the vehicle Acceleration Assistant, see Launch Control Android Auto preparation, connection to the ve‐...
  • Page 377 Camera, rearview camera, without Surround Entertainment, Communication View BMW Accident Assistance Camera, see Surround View BMW Assist, see Owner's Manual for Navigation, Cameras, see Sensors of the vehicle Entertainment and Communication CANCEL button, Active Cruise Control BMW Digital Key CANCEL button, cruise control...
  • Page 378 Car wash, automatic Climate control rules Catalytic converter, see Hot exhaust gas sys‐ Closing with the Key Card Closing with the smartphone, see BMW Digital CBS Condition Based Service Cell phone, see Owner's Manual for Navigation, Clothes hooks Entertainment and Communication...
  • Page 379 Cornering light Diagnosis connection Corrosion on brake discs Differential lock Cosmetic mirror Digital Key Cross traffic warning Digital Key, see BMW Digital Key Cruise control Dimensions Cruise control, active with Stop&Go func‐ Dimmable exterior mirrors tion Dimmable interior mirror Cruise control, see Active Cruise Control...
  • Page 380 Driver assistance, driving, see Intelligent Emergency braking, see PostCrash - iBrake Safety Emergency call Driver assistance, parking, see Parking assis‐ Emergency service, see BMW Accident Assis‐ tance systems tance Driver assistance, see Intelligent Safety Emergency service, see BMW Roadside Assis‐...
  • Page 381 Everything from A to Z REFERENCE Entertainment, selection list in the instrument Floor carpet, care cluster Floor mats, care Entry comparison Fold-away position, wiper Equipment, interior Foot brake Error indicators, see Check Control Forward collision mitigation, see Intelligent ESP Electronic Stability Program, see DSC Safety Evasion Assistant For Your Own Safety...
  • Page 382 General driving notes Hills General settings Hill start assistant, see Drive-off assistant Gesture Control Holder for beverages, front Gestures, see BMW Gesture Control Holder for beverages, rear Glare shield, see Sun visor HomeLink, see Integrated Universal Remote Glass sunroof, electric Control...
  • Page 383 Loading Keyless Go, see Comfort Access Loading the cargo area, see Stowing cargo Key, mechanical Local time, see Time Key, see BMW display key Locking, automatic Key, see Vehicle key Locking, see Opening and Closing Kickdown, M Steptronic Sport transmission...
  • Page 384 Maintenance, see Service notifications Mobile phone, see Owner's Manual for Naviga‐ Maintenance system, BMW tion, Entertainment and Communication Make-up mirror Mobile Service, see BMW Accident Assis‐ Malfunction, BMW display key tance Malfunction, vehicle key Mobile Service, see BMW Roadside Assis‐...
  • Page 385 Everything from A to Z REFERENCE Neck restraints, rear, see Head restraints Owner's Manual via voice operation, BMW Intelli‐ rear gent Personal Assistant Net, cargo area Neutral cleaner, see Light-alloy wheels, care Notifications No-touch opening and closing of the trunk lid...
  • Page 386 Remote 3D View Remote control for audio, see Owner's Hand‐ Safe braking book for Navigation, Entertainment, Communi‐ Safe Share function, see BMW Digital Key cation Safety belt reminder for driver's seat and front Remote control, see Vehicle key passenger seat Remote control, universal Online Edition for Part no.
  • Page 387 Slide/tilt glass roof, see Glass sunroof Sequential mode Slipperiness, see Outside temperature Service and warranty Slippery road, see Outside temperature Service Center, see BMW Accident Assis‐ Smallest turning circle, vehicle tance Smartphone, connecting Service Center, see BMW Roadside Assis‐ Smartphone Integration, Android Auto prepara‐...
  • Page 388 Status control display, tires Technical changes, see For Your Own Safety Status information, iDrive Technical data Status of Owner's Manual Technology, BMW M Status, vehicle Telephone, see Owner's Manual for Navigation, Steering and Lane Control Assistant Entertainment and Communication Steering Assistant, see Steering and Lane Con‐...
  • Page 389 Everything from A to Z REFERENCE Temperature display electric motor, see Sport TPM Flat Tire Monitor displays Traffic bulletins, see Owner's Handbook for Navi‐ Temperature display, see outside tempera‐ gation, Entertainment, Communication ture Traffic Jam Assistant, see Assisted Driving Temperature, engine oil Plus Theft alarm system, see Alarm system Traffic jam assistant, see Steering and Lane...
  • Page 390 Voice command response Upholstery material care Voice control Upper backrest, front Voice control, gesture control Upper retaining strap, top tether Voice control, see BMW Intelligent Personal As‐ USB connection sistant USB port, position in vehicle Voice control system Used battery, disposing of...
  • Page 391 Everything from A to Z REFERENCE WiFi connection, see WLAN connection Wi-Fi hotspot Window, defrosting Windows, powered Windshield, defrosting Windshield washer fluid, see Washer fluid Windshield washer nozzles Windshield wiper, see Wiper system Winter storage, see Long-term vehicle stor‐ Winter tires Winter tires, tread Wiper blades, replacing Wiper fluid, see Washer fluid...
  • Page 392 *BL5A37B3900E* 01405A37B39 ue Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 395 California Proposition 65 Warning For vehicles sold in California: Online Edition for Part no. 01405A37B39 - VI/21...
  • Page 396 The Ultimate Driving Machine® BMW DRIVER'S GUIDE APP. Your customized information about the vehicle in an app. Optimized for smartphones & tablets. Can be used offline. *BL5A37B3900E* 01405A37B39 ue Online Edition for Part no. 01405A37B39 - VI/21...

Table of Contents
