Failure
Code Cause
Text message
F013 Sensor does not detect an echo
during operation
no measured value
available Antenna system dirty or defective
F017 Adjustment not within specifi-
cation
Adjustment span
too small
F025 Values are not continuously rising,
for example illogical value pairs
Error in the lineari-
zation table
F036 Failed or interrupted software up-
date
No operable soft-
ware
F040 Hardware defect
Error in the elec-
tronics
F080 General software error
General software
error
F105 The instrument is still in the
switch-on phase, the measured
Determine meas-
value could not yet be determined
ured value
F113 EMC interference
Communication
error
VEGAPULS 6X • Two-wire 4 ... 20 mA/HART
Failure: Due to a malfunction in the instrument, a fault signal is
output.
This status message is always active. It cannot be deactivated by the
user.
Function check: The instrument is being worked on, the measured
value is temporarily invalid (for example during simulation).
This status message is inactive by default.
Out of specification: The measured value is unreliable because an
instrument specification was exceeded (e.g. electronics temperature).
This status message is inactive by default.
Maintenance required: Due to external influences, the instrument
function is limited. The measurement is affected, but the measured
value is still valid. Plan in maintenance for the instrument because a
failure is expected in the near future (e.g. due to buildup).
This status message is inactive by default.
11 Diagnosis, asset management and service
Rectification
Check or correct installation and/
or parameter settings
Clean or exchange process com-
ponent or antenna
Change adjustment according
to the limit values (difference be-
tween min. and max. ≥ 10 mm)
Check linearization table
Delete table/Create new
Repeat software update
Check electronics version
Exchanging the electronics
Send instrument for repair
Exchanging the electronics
Send instrument for repair
Disconnect operating voltage
briefly
Wait for the end of the switch-on
phase
Duration up to approx. 3 minutes
depending on the version and pa-
rameter settings
Remove EMC influences
DevSpec
State in CMD 48
Byte 5, Bit 0 of
Byte 0 ... 5
Byte 5, Bit 1 of
Byte 0 ... 5
Byte 5, Bit 2 of
Byte 0 ... 5
Byte 5, Bit 3 of
Byte 0 ... 5
Byte 5, Bit 4 of
Byte 0 ... 5
Byte 5, Bit 5 of
Byte 0 ... 5
Byte 5, Bit 6 of
Byte 0 ... 5
Byte 4, Bit 4 of
Byte 0 ... 5
