9.2.35 — Air Compressor: 60"-85", 100-400 HP
ITEM PART NO. DESCRIPTION
REQ.
1 003-00585 BASE, COMPRESSOR
1
2 1 538-00125 AIR & OIL TANK ASSEMBLY
3 1 813-00124 FAN BUSHING
1 035-00322 COUPLING GUARD
4
5 1 819-00136 PUMP, HALF W/ KEY WAY
6 1 015-00048 CLAMP, AIR OIL TANK
7 1 505-00108 PUMP, AIR ASSEMBLY
8 2 008-01869 BRACKET, COMPRESSOR
9 1 845-00043 NUT, FLARED
10 1 857-00129 NIPPLE
11 1 845-00202 ELBOW , FLARED, ODC x NPT.
1 651-00261 HEAT EXCHANGER, LUBE OIL FOR COMP.
12
13 1 813-00146 FAN
14 1 841-00060 KEY
1 952-00144 WASHER, FLAT
15
16 1 841-00354 SCREW-SELF-TAPPING
1
17
858-00088 PIPE PLUG
18 1 845-00043 NUT, ODC
19 1 507-03442 TUBING ASSY TANK TO FIN TUBING
1 923-00079 FILTER AIR
20
21 1 861-00345 HOSE, FLEXIBLE, W/FITTINGS
VALVE, SWING CHECK
22 1 940-03656
1 277-00172 ORIFICE
23
24 1 861-00347 ADAPTER, MPT x MALE THD.
25 1 868-00136
CAPSCREW, HEX HD.
1 507-05637
26 TUBING ASSMEBLY TO COMPRESSOR
27 1 859-00025
TEE
NOTES:
1. ASSEMBLE THE MOTOR & AIR COMPRESSOR TO THE BASE WITH THE
USE OF 31 SHIMS. ADJUST THE CENTERLINES OF THE AIR
COMPRESSOR TO WITHIN .009 IN NOTE DETAIL B FOR COUPLING
ASSEMBLY, SECURE MOTOR & COMPRESSOR TIGHTLY TO THE BASE.
2. SLIDE THE FAN ONTO THE SHAFT UNTIL IT IS BOTTOMED. TIGHTEN
THE SETSCREW AGAINST THE KEY FIRST, THEN TIGHTEN THE SETSCREW
AGAINST THE SHAFT.
3. BOLT THE TANK TO THE BASE.
4. FIT THE PIPING AS SHOWN.
5. CUT TUBE 26 TO SUIT, INSTALL NUT 18 & FLARE @ ASS'Y.
6. FAN SHOULD BE ASSEMBLIED SUCH THAT THE SIDES OF BLADES
13 MARKED BLOWER IS TOWARD THE HUB 3 .
5 37
1/16" MIN.
3/32" MAX.
7/8" MIN.
15/16" MAX.
DETAIL "C"
35
46
34
12
36
42
25
9-48
ITEM
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
53 VIEW "B-B"
16 15
42
44
17
26
23
10
33
29 49
23
47
32
11
28
9
18
30
26
AIR
FLOW
21
53
SEE VIEW "B-B"
54
PART NO. DESCRIPTION
REQ.
1 857-00166 NIPPLE
1 859-00081 ELBOW
ELBOW, REDUCING
1 847-01628
12 927-00017 SHIM, HORSESHOE
1 157-01217 FITTING ASSY, PIPE FILTER FOR COMPRESSOR.
1 919-00194 CAP
1 845-00073 UNION, ODC
1 845-00426 UNION, ELBOW, ODC
PIN-CYLINDER
4 056-00277
1 819-00056 INSERT
1 847-00468 BUSHING
LOCKWASHER
10 952-00093
8 868-00056 CAPSCREW, HEX. HD.
1 868-00450 CAPSCREW, HEX. HD.
2 952-00117 LOCKWASHER
2 015-00147 CLAMP, COMPRESSOR
1 008-01874 BRACKET-HEAT EXCHANGER
ELBOW, MALE ODC X NPT.
1 845-00263
1 072-00048 SCREEN, FINNED TUBING
FILTER BASKET OIL TO COMPRESSOR
1 171-00114
1 868-00158 CAPSCREW, HEX. HD.
GAS COCK, TEE HANDLE
1 825-00104
2 857-00163 NIPPLE
2 857-00167 NIPPLE
1 857-00151 NIPPLE
1 859-00106 STREET ELBOW
BUSHING
1 847-00152
22
52
54
20
29 50
39 VIEW "A-A"
39
5
4
6 48
41
7
37
2
1" NPT COMPRESSED
24 38
AIR OUTLET
SEE VIEW "A-A"
SEE AIR COMPRESSOR PIPING SHEET
50
FOR MOTOR SELECTION
20
39
22
45
19
40 8
52
