Customer Service: 1-866-942-5362 English, French and Spanish
(Telephone is not valid in Mexico, toll-free in U.S. and Canada only)
1.
Please read instructions prior to assembly.
(Please note that there is a recommended
tool not included in this package).
2.
Verify that there are no missing parts.
"Adult assembly required due to the presence of small parts, points, and
IMPORTANT, RETAIN FOR FUTURE REFERENCE:
READ CAREFULLY
Date: 2019-12-27
Whalen Furniture Manufacturing
ITM. / ART. 991070
MODEL# WSZB184872-GW5BMS
Assembly Instructions
Monday - Friday, 8:30 a.m. - 4:30 p.m. PST
E-mail :
parts@whalenfurniture.com
SHELF MAXIMUM CAPACITY: 454 kg / 1000 lb EVENLY DISTRIBUTED.
ENTIRE UNIT MAXIMUM CAPACITY: 2268 kg / 5000 lb EVENLY DISTRIBUTED.
CONCENTRATED LOAD CAPACITY: 732.6 kg / 1615 lb PER SQUARE METER
edges as received."
Rev. 0001-N
3.
Two people are recommended for assembly.
4.
Gently set parts on a flat, smooth surface.
5.
For indoor use only.
(0.45 kg / 1 lb PER SQUARE INCH)
1
Advertisement
Related Manuals for Whalen WSZB184872-GW5BMS
Summary of Contents for Whalen WSZB184872-GW5BMS
- Page 1 ITM. / ART. 991070 MODEL# WSZB184872-GW5BMS Assembly Instructions Customer Service: 1-866-942-5362 English, French and Spanish Monday - Friday, 8:30 a.m. - 4:30 p.m. PST (Telephone is not valid in Mexico, toll-free in U.S. and Canada only) E-mail : parts@whalenfurniture.com Please read instructions prior to assembly.
- Page 2 Failure to follow these guidelines can result in properly damage or personal injuries. Storage Rack is NOT recommended for outdoor use. 1. Do not exceed 454 kg / 1000 lb per shelf. Do not exceed 2268 kg / 5000 lb per unit. 2.
-
Page 3: Parts List
Parts List Please read completely through the instructions and verify that all parts listed are present before beginning assembly PART# PART DESCRIPTION QUANTITY A- Angle Post B-Long Z-beam C-Short Z-beam D- Shelf Deck E- Post Cap F- Post Inserts G- Post Clips Tipping Restraint Hardware Kit Tool Required: Rubber Mallet (NOT INCLUDED) - Page 4 Whalen Storage at 1-866-942-5362 for assistance. If you have any defective parts please do not use, improper installation may result in damage or injury.
- Page 5 Assembly Instructions 3. Now pick up a Short Z-beam (part C) and join into the top two keyholes of the other 2 Angle Posts (part A) to create a Top End Assembly. Drive the rivets to the bottom of the keyhole with a rubber mallet.
- Page 6 6. Proceed to add two additional Long Z-beams (part B) to top two keyholes of the Angle Posts (part A). As shown in detail #6 install the Z-beams in the upright position. Be sure to have the rivets in the keyholes before hitting the beams near the joints to lock the pieces together. 7.
- Page 7 Assembly Instructions 8. Now lay the Shelf Decks (part D) in between the Z-beams. See detail #8A. Insert the Post Caps (part E) on the top of the Angle Posts (part A), as shown in detail #8B Shelf Deck Z-beam OPTION #2 Side by Side 9.
- Page 8 Assembly Instructions 11. Complete the Add-on Unit by adding two Long Z-beams (part B) at the top keyholes of the Angle Posts (part A), as shown in detail #11. Install all Z-beams in the upright position. Hit the beams near the joint with a rubber mallet to lock joints into place. 12.
-
Page 9: Care And Maintenance
NOTE: The tipping restraint hardware included is for wooden stud wall construction. It must be attached to a wall stud. Depending upon your wall construction, different anchor hardware maybe required. Please contact your local hardware store for assistance. Young children can be seriously injured by tipping furniture. You must install the tipping restraint hardware with the unit to prevent the unit from tipping, causing any accidents or damage. -
Page 10: Limited Lifetime Warranty
LIMITED LIFETIME WARRANTY This Whalen product (exclusive of shelves) is warranted to the original purchaser. If there is a failure in this unit due to defects in materials or workmanship, Whalen Storage will repair or replace this item at our discretion without charge. - Page 11 IF YOU ARE REQUIRED TO ORDER PARTS PLEASE USE THE LIST BELOW 991070 / WSZB184872-GW5BMS Heavy-Duty Storage Rack *WSZB184872-GW5BMS-01-AP Angle Post *WSZB184872-GW5BMS-02-LZB Long Z-beam *WSZB184872-GW5BMS-03-SZB Short Z-beam *WSZB184872-GW5BMS-04-SD Shelf Deck *WSZB184872-GW5BMS-05-PC Post Cap *WSZB184872-GW5BMS-06-PI Post Inserts *WSZB184872-GW5BMS-07-PC Post Clips *WSZB184872-GW5BMS-08-CH...
- Page 12 Distributed by: Costco Wholesale Canada Ltd.* Importado por: Costco Wholesale Australia Pty Ltd Costco Wholesale Corporation 415 W. Hunt Club Road Importadora Primex S.A. de C.V. 17-21 Parramatta Road P.O. Box 34535 Ottawa, Ontario Blvd. Magnocentro No. 4 Lidcombe NSW 2141 Seattle, WA 98124-1535 K2E 1C5, Canada San Fernando La Herradura...
