Terramite T6 Parts Manual

Compact tractor loader backhoe

page of 113

/ 113
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Compact Tractor

Loader Backhoe

IMPORTANT!

READ THIS MANUAL BEFORE OPERATING MACHINE.

Parts

MANUAL

" B a c k e d b y a W o r l d o f E x p e r i e n c e "

600 Goff Mountain Road

P.O. Box 7146, Charleston, WV 25356-7146 U.S.A.

1-800-428-3772

Fax 1-800-776-4845

International 1-304-776-4231

Fax 1-304-776-4845

www.terramite.com

Table of Contents

Need help?

Do you have a question about the T6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Terramite T6

Page 1 “ B a c k e d b y a W o r l d o f E x p e r i e n c e ” 600 Goff Mountain Road P.O. Box 7146, Charleston, WV 25356-7146 U.S.A. 1-800-428-3772 Fax 1-800-776-4845 International 1-304-776-4231 Fax 1-304-776-4845 www.terramite.com...
Page 2 SECTION SEVEN: INDEX View from Right Side Outrigger Assembly ............2.41 Index ......................... 7.1 to 7.4 View of Flip Over Pads .................... 2.42 The Terramite T6 Parts Manual is Subject to Change Without Notice CONTENTS Copyright © 1999 Terramite Corporation...
Page 4 3-15 in 1974, the Model 4 in 1976 and the Model 5 in 1980. The T5B was introduced in 1986, the T5C, premiered in 1990, and the latest compact loader/backhoe, the T6 made its debut in early 1997. Each model represented major as well as minor improvements in the original machine.
Page 5 PURCHASED FROM ___________________________________ CERTIFICATE OF ORIGIN# __________________________________ NAME OF PURCHASER _____________________________________________________________________________________________ ADDRESS _________________________________________________________________________________________________________ PHONE ( ____________ ) ________________________ CERTIFICATE OF ORIGIN# _________________________________________ TYPE OF BUSINESS ________________________________________________________________________________________________ IS THIS YOUR FIRST TERRAMITE? __________ WHAT KIND OF SIMILAR EQUIPMENT DO YOU OWN? ___________________ __________________________________________________________________________________________________________________ __________________________________________________________________________________________________________________ OPTIONS __________________________________________________________________________________________________________ __________________________________________________________________________________________________________________...
Page 6 You may need a hard hat, safety shoes, safety glases, heavy gloves, hearing protection, reflective clothing, wet weather Do not allow the T6 to be operated by anyone who gear and a respirator. Never take chances by wearing loose is intoxicated or on medication that would affect their clothing, watches or rings.
Page 8 Green/Brown - Sewer Always contact your local One-Call system White - Proposed Excavation before starting your digging project. Pink - Temporary Survey Markings One-Call Safety Labels & Placards Available From Hazard Communication Systems, Inc. 800-748-0241 Copyright © 1999 Terramite Corporation...
Page 9 NOTE: This order form is for ease of use when ordering parts identified in this manual. Simply photocopy this page (keep this page for future use) and fill in the parts needed. Fax to Terramite at the number above. We will promptly respond to your request. SOLD TO:...
Page 10 NOTE: This order form is for ease of use when ordering parts identified in this manual. Simply photocopy this page (keep this page for future use) and fill in the parts needed. Fax to Terramite at the number above. We will promptly respond to your request. SOLD TO:...
Page 11 SECTION TWO:...
Page 13 " MP x " FM Swivel 88698 8-6.98 Hose, " x 98" 23106 1-31.T6 Front Curl Cylinder - Loader Bucket 12406 1-24.T6X Loader Arm Assembly 13200 1-32.T5C Pin, 1" x 4 " 13060 1-33.03.60 Cutting Edge (Weld-On) Copyright © 1999 Terramite Corporation...
Page 14 " x 20" 88642 8-6.42 Hose, " x 42" 88675 8-6.75 Hose, " x 75" 20176 0107.6-6 Fitting, 3/8" MP x 3/8" FM Swivel 22176 2107.6-6 Fitting, " x " Swivel 90° 22266 022T.6-6 Fitting, " Tee Copyright © 1999 Terramite Corporation...
Page 15 View from Front of Loader Bucket ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 13306 1-33.T6 60" Loader Bucket 13060 1-33.03.60 Cutting Edge (Weld-On) Copyright © 1999 Terramite Corporation...
Page 16 Fitting, 3/8" MP x 3/8" FM Swivel 88698 8-6.98 Hose, " x 98" 23106 1-31.T6 Front Curl Cylinder - Loader Bucket 13000 1-30.T5C Pin, 1" x 5 ", Front Curl Cylinder 14021 1-402.1 Reflective Tape, Amber Copyright © 1999 Terramite Corporation...
Page 17 Fitting, 3/8" MP x 3/8" FM Swivel 88698 8-6.98 Hose, " x 98" 23106 1-31.T6 Front Curl Cylinder - Loader Bucket 14004 1-400.4 Decal, Stand Clear 88620 8-6.20 Hose, " x 20" 20082 1N6CF Nut, " NC Flange Copyright © 1999 Terramite Corporation...
Page 18 Decal, Terramite Large 12076 12076 2 WD 12077 12077 4 WD 14101 1-400.101 Decal, T6, 2WD 14099 1-400.99 Decal, American Flag 14004 1-400.4 Decal, Stand Clear 22506 1-25.T6 Arm Cylinder - Lift 14100 1-400.100 Decal, Pinch Point Copyright © 1999 Terramite Corporation...
Page 19 Fitting - 1/4" Straight Male to 1/4" Female Swivel 90° 81002 81002 Cylinder, Steering 16066 16066 Bumper 53002 53002 Spindle, w/Drive Motor Housing - Right 53003 53003 Spindle, w/Drive Motor Housing - Left 53043 3-04.3 Tie Rod Ends Copyright © 1999 Terramite Corporation...
Page 20 3-10R.5 Spindle 53043 3-04.3 Tie Rod Ends 53054 3-05.4 Tie Rod 25811 1-58.T6 Power Steering Cylinder after 1-97 25803 1-58.3 Power Steering Rod 51007 1-27.8A Tire Mounted on Rim Assembly 2WD 53091 53091 Thrust Bearing Copyright © 1999 Terramite Corporation...
Page 21 -28 Straight 14203 14203 Decal, Read Operators Manual 14076 1-400.76 Decal, Parking Brake NONE 4 Pt. ROP MF - Weld on Type (FACTORY EQUIPPED) 28500 1N8CL Nut, 1/2" x 13NC Stover B (NOT SHOWN) 2.10 Copyright © 1999 Terramite Corporation...
Page 22 View from Back of Seat ITEM PART NUMBER DESCRIPTION QTY. 11911 Box, Manual, Operator’s Seat 14260 Assembly, Seat, w/Swivel Disc w/Arm, T5D/T6/T9 11045 Set, Arm Rest, T5C/T5D/T6/T7/T9/Sweeper 11903 Belt, Seat, T5C/T5D/T6/T7/T9/Sweeper 14011 Knob, Seat Shaft 2.36 2.11 Copyright © 1999 Terramite Corporation...
Page 23 Tire(s), Front 23 x 10.5 x 12 51273 1-27.3 Tire Valve 50017 50017 Rim, Front - 4WD 50017 50017 Rim, Front - 2WD 51019 51019 Tire Mounted on Rim Assembly 2WD 51019 51019 Tire Mounted on Rim Assembly 4WD 2.12 Copyright © 1999 Terramite Corporation...
Page 24 PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 51173 1-17.3 Tire, Rear HF 31" x 15.5" x 15" 50006 1-18.4 28506 1N8FWR Nut, " NF Lug 50018 1-17.3A Tire and Rim Assembly, Rear - HFT 2.13 Copyright © 1999 Terramite Corporation...
Page 25 Cotter Pin 53150 3-15 53125 3-12.5 Bearing, Outer 53140 3-14 Washer 53136 3-13.6 Hub, 5 on 4 after 6-1-96, kit 53124 3-12.4 Race, Inner 53123 3-12.3 Bearing, Inner 53111 3-11.1 Seal 53116 3-10R.5 Spindle 2.14 Copyright © 1999 Terramite Corporation...
Page 26 Decal, Alarm Must Sound 15542 1-55.42 Hood Latch 14053 1-400.53 Decal, Call Before You Dig 14204 14204 Decal, Controls 13072 13072 Front Wobblestick Handle 14202 14202 Decal, Warning Rollover Hazard 14203 14203 Decal, Read Operators Manual 2.15 Copyright © 1999 Terramite Corporation...
Page 27 Fitting, " F 90° x " F Swivel 20786 2107.8-6 Fitting, " MP x " F. Swivel 20010 Fitting, Nipple " x 3" 84007 1-40A-T6 Valve, Front with Fittings (Assembled - Hoses not included) 2.16 Copyright © 1999 Terramite Corporation...
Page 28 View of Battery from the Left Side of Engine Compartment ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 73230 7-32.3M Cable, Battery Starter (Red) 77022 7-02.2 Battery 15033 7-02.5 Battery Hold Down Bracket 72028 7-30M Cable, Battery Ground (Black) 2.17 Copyright © 1999 Terramite Corporation...
Page 29 71017 7-10.1D.T6 Wiring Harness, Engine 42 Amp. 72013 72013 Wiring Harness, Engine 55 Amp. (After Engine SN 0909008C) 15106 1-51.6 Steering Gear 88658 8-6.58 Hose, " x 58" 88465 8-4.65 Hose, " x 65" 2.18 Copyright © 1999 Terramite Corporation...
Page 30 (Inside Hose Wrap) 88999 8-HOSE.WRAP Hose Wrap 3' (Sold Per Foot) 22011 2-200.11 Filter, Air (Included in 22022) 40047 1-100.23A Engine Assembly, 31.5 hp. Perkins 103.15 22022 P.ZZ7A806 Air Cleaner Base Assembly 38185 Either Decal 2.19 Copyright © 1999 Terramite Corporation...
Page 31 View of Under Side of Air Cleaner ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 22022 P.ZZ7A806 Air Cleaner Base Assembly 22068 22068 Hose, Air Cleaner 2.20 Copyright © 1999 Terramite Corporation...
Page 32 PREVIOUS PART NUMBER DESCRIPTION QTY. 15506 15506 Filter, Fuel " Line 22009 2-200.9 Filter, Oil 22007 D2-200.7C Filter, Fuel 84000 84000 Hose, Fuel " Line 80033 80033 Hose, Fuel " Line 10267 10267 Bracket, Fuel Filter 2.21 Copyright © 1999 Terramite Corporation...
Page 33 View from Left Side of Engine Compartment (After March 31, 1998) ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 43701 43701 Muffler 16137 16137 Bracket, Muffler 2.22 Copyright © 1999 Terramite Corporation...
Page 34 " - 13 x 3" NC Gr 8 28957 1W7F Washer, " USS 16061 16061 Plate, Engine 48001 48001 Rubber Motor Mount 22023 1W12F Washer, " Flat 28500 1N8CL Nut, 1/2" x 13NC Stover B 2.23 Copyright © 1999 Terramite Corporation...
Page 35 13020 13020 Cable, Brake (Short) (SN 980506 and After) 13001 13001 Brake Lever (SN 980506 and After) 64010 6-00.7 Transmission, Tandem Pump 4WD 64011 6-00.8 Transmission, 2WD 66007 6-00.4.7 Pump, Double 2WD & 4WD 2.24 Copyright © 1999 Terramite Corporation...
Page 36 PREVIOUS PART NUMBER DESCRIPTION QTY. 55620 5-62M Brake Band 55606 5-60.6 Brake Cable 55613 5-61.3DA Brake Off Set Link Not Shown - Attaches to Brake Band 64003 4-00.3 Drive Motor Torque 51800 1-80 Drive Motor Flange 2.25 Copyright © 1999 Terramite Corporation...
Page 37 Drive Shaft Coupler - 2 WD 26500 26500 Set Screw Drive Shaft Coupler/13 Tooth Spline for the 4 WD ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 60001 60001 Drive Shaft Coupler - 2 WD 26500 26500 Set Screw 2.26 Copyright © 1999 Terramite Corporation...
Page 38 (Prior to SN 6980507) ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 55004 5-00.4 Rear Axle 51800 1-80 Drive Motor Flange 26288 1B6.28F8 Bolt, " x 1 " NF GR8 57034 57034 Brake Drum 2.27 Copyright © 1999 Terramite Corporation...
Page 39 Chase Nipple " 22057 SCR.NIPPLE.NUT Chase Nipple Nut " 55000 55000 Axle, Rear w/Brakes Installed 55002 55002 Brake Shoe Assembly RH (Not Shown) 55003 55003 Brake Shoe Assembly LH (Not Shown) 55001 55001 Brake Drum 2.28 Copyright © 1999 Terramite Corporation...
Page 40 View from Left Side of Fuel Tank ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 11299 D735 Gauge, Fuel 15005 1-28.4 Cap, Safety Fuel, Diesel Green 2.29 Copyright © 1999 Terramite Corporation...
Page 41 View from Right Side of Hydraulic Tank ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 22206 2-206 Cap, Hydraulic Filler Breather 21283 1-28.3 Gauge, Hydraulic 2.30 Copyright © 1999 Terramite Corporation...
Page 42 View of Deck Lid In Front of Operator Seat View of Deck Lid (Behind Operator Seat) ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 15066 1-57.2 Front Deck Cover 15001 1-57.1 Deck Lid 15067 1-57.3 Rear Deck Lid 2.31 Copyright © 1999 Terramite Corporation...
Page 43 1-62.7 Pillow Block Bearing, 2WD 10140 10140 Spring Centering Bolt , 2WD 13029 13029 Pedal Spring, 2 WD 11610 1-61 Pedal Block, 2WD 11620 1-62 Pedal Shaft, 2WD Close Up of Pedal Spring Installation 2.32 Copyright © 1999 Terramite Corporation...
Page 45 Rod - "-28NF Linkage 64002 64002 Tandem Transmission 22079 22079 Nut, " - 28 NF JAM LH Thread 13030 13030 Ball Joint, " - 28NF LH Thread 70000 D705 Neutral Safety/Back Up Alarm Switch 2.34 Copyright © 1999 Terramite Corporation...
Page 46 PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 22013 22013 Washer " 22044 22044 Bolt, -16NC x 15087 15087 Bracket, Bottom Transmission 16182 16182 Bracket, Top Transmission 23001 23001 Nut, 3/8" - 16NC Lock, 4 WD 2.35 Copyright © 1999 Terramite Corporation...
Page 47 ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 11911 MANUAL.BOX Manual Box 14260 14260 Seat Assembly, Swivel 14046 1-400.46 Decal, "Read Owners Manual..." 11903 1-19.3 Seat Belt Assembly (Both Halves) 11045 11045 Arm Rest 2.36 Copyright © 1999 Terramite Corporation...
Page 48 " F - Bushing 20065 0502.12-8 Fitting, #12 O’Ring x " FPT 21788 3107.8-8 Fitting, " M x " FM Swivel 45 21766 3107.6-6 Fitting, " MP x " MP 45 Degrees 23413 1-34.113 Restrictor w/Spring SHOWN 2.37 Copyright © 1999 Terramite Corporation...
Page 49 (2 Wheel Drive) 88845 8-8.45 Hose, " x 45" (4 Wheel Drive) 80075 80075 Hose, " x 138" 86101 8-6.101 Hose, " x 101" 88420 8-4.20 Hose, " x 20" 88880 8-8.80 Hose, " x 80" 2.38 Copyright © 1999 Terramite Corporation...
Page 50 Wobblestick Pivot Block, Right Rear 13465 1-64RR.T6 Handle, Wobblestick, Right Rear 13965 1-65 Linkage 13443 1-64.3 Connecting Link 13411 1-34.11 Valve Link 13418 1-34.18 Pin, Valve Hose Link Pivot 13410 1-34.10 Aluminum Valve Handle Bracket 2.39 Copyright © 1999 Terramite Corporation...
Page 51 View from Operator Position of Backhoe Valve (Continued) ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY. 13942 1-42R Knob 13464 1-64LR.T6 Handle, Wobblestick, Left Rear 14052 1-400.50A.1 Decal, Plate, Wobblestick Controls 13465 1-64RR.T6 Handle, Wobblestick, Right Rear 13431 1-34.31 Handle, Outrigger 2.40 Copyright © 1999 Terramite Corporation...
Page 52 (SN 6990214 and after) 11047 11047 Outrigger 20082 20082 Nut, " NC Flange 10202 10202 Pin, Linch " Diameter 11595 11595 Rubber Street Pad 17156 17156 Pin, 1" x 5 ", Outrigger to Foot Pad Pull 2.41 Copyright © 1999 Terramite Corporation...
Page 55 Pin, Cotter, ” x ”, Linkage, Valve, All Tractors 25500 Nut, ” - 24 NF Jam 13944 Block, Pivot, Wobblestick, Front, T5C/T5D/T6/T7/T9 13411 Link, “U”, Valve, All Tractors 13995 Bolt, Wobblestick Hinge, Front, All Tractors 2.44 Copyright © 1999 Terramite Corporation...
Page 56 1-52.01 Swing Rod 21428 S4MPG Fitting, Grease, "-28 Straight 11100 1-11.T5C Pin, 1” x 6 " 80126 80126 Hose, " x 52" 15486 1-54.80.T6 Swing Stop 10406 1-04.T6 Pin, 1 " x 8 " 2.45 Copyright © 1999 Terramite Corporation...
Page 57 20025 Fitting - 90° Tee 80045 8-4.15 Hose, " Swing Crossover, 15" 20174 0107.4-4 Fitting, Straight " Swivel 88420 8-4.20 Hose, " Swing to Valve, 20" 88425 8-4.25 Hose, " Swing to Valve, 25" 2.46 Copyright © 1999 Terramite Corporation...
Page 58 Decal, Digging Depth 10' 10707 1-07L.T6 Pin, 1 " x 7 " 14022 1-402.2 Reflector, Red 14004 1-400.4 Decal, Stand Clear 14054 1-400.54 Decal, Crush Hazard 14107 1-400.107 Decal, Radius Terramite 10291 10291 Boom Assembly 2.47 Copyright © 1999 Terramite Corporation...
Page 59 View of Right Side of Rear Bucket & Linkage Assembly & ITEM PART NUMBER DESCRIPTION QTY. 19095 Bucket, 16”, Quick Attach, T6/T9 22053 Bolt, ” x ” NC Gr8 28956 Washer, ” SAE 2.48 Copyright © 1999 Terramite Corporation...
Page 60 ”OD x 3” L 10819 Bushing 1 ID” x 1 ” OD x 1” L 17055 Bushing, 1 ” ID x 1 ” OD x 2” L 18261 Linkage Link, Right, T5C/T5D/T6/T7/T9 18260 Linkage Link, Left, T5C/T5D/T6/T7/T9 2.49 Copyright © 1999 Terramite Corporation...
Page 61 Bucket, 38”, Quick Attach, T6/T9 19002 Ripper, Quick Attach, T6/T9 11129 Outrigger Pad Assembly, Flip Over 19001 Blade, Landscape, Quick Attach, T6/T9 19441 Edge, Cutting, Serrated, 60” w/Bolts, T6/T9 19434 Edge, Cutting, Bolt-On, 60” w/Bolts, T6/T9 2.50 Copyright © 1999 Terramite Corporation...
Page 62 Loader arm listed off ground a few inches. Backhoe dipper fully extended Loader bucket curled back Backhoe Bucket curled all the way back Backhoe boom in full raised position 2.51 Copyright © 1999 Terramite Corporation...
Page 63 15W40 when outside temperature is above 40 degrees F. Use engine oil type API SF.CD 10 weight when outside temperature is below 40 degrees F. Replace filter with Terramite / 2-200.5C filter or NAPA / 1759 filter. It is important to follow these instructions to alleviate any cold weather engine starting problems and any pressure or heat related component failure.
Page 64 (Fig. D). Repeat process on existing injector lines. NOTE: A FTER STEPS IF ENGINE DOES NOT START YOU MUST REPEAT STEPS UNTIL ALL AIR IS REMOVED FROM SYSTEM BEFORE ENGINE WILL START ECN T9805-017 P/N 40126 2.53 Copyright © 1999 Terramite Corporation...
Page 67 T6 Transmission - 2WD PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88614 8-6.14 Discharge Port - Transmission Oil Tank - Upper return (SEE PAGE 3.14) 88820 8-8.20 Exhaust Port - Transmission Torque Motor - 2WD - (SEE PAGE 3.2) 88857 8-8.57...
Page 68 T6 Torque Motor - 2WD PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88820 8-8.20 Torque Motor Transmission - Exhaust Port (SEE PAGE 3.1) 88820 8-8.20 Torque Motor Transmission - Exhaust Port (SEE PAGE 3.1) Copyright © 1999 Terramite Corporation...
Page 69 T6 Transmission - 4WD PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88614 8-6.14 Discharge Port - Transmission Oil Tank - Upper Return (SEE PAGE 3.14) 80889 8-8.9 Exhaust Port - Transmission Cartridge Block - (SEE PAGE 3.6) 88181 8-8.18.1...
Page 70 T6 4WD Front Axle Assembly (From Operators Position) PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88465 8-4.65 Upper Port - Left Motor Cartridge Block - (SEE PAGE 3.6) 88465 8-4.65 Lower Port - Left Motor Cartridge Block - (SEE PAGE 3.6)
Page 71 T6 Torque Motor - 4WD PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88181 8-8.18.1 Torque Motor Cartridge Block - (SEE PAGE 3.6) 88817 88817 Torque Motor Cartridge Block - (SEE PAGE 3.6) Copyright © 1999 Terramite Corporation...
Page 72 T6 4WD Cartridge Block PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88465 8-4.65 Cartridge Block Front Axle Assembly - (SEE PAGE 3.4) 88465 8-4.65 Cartridge Block Front Axle Assembly - (SEE PAGE 3.4) 88817 88817 Cartridge Block Torque Motor - (SEE PAGE 3.5)
Page 73 HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88100 8-8.100 Return - Oil Cooler Drive System Block - (SEE PAGE 3.13) 88831 88831 Intake - Oil Cooler Front Valve Assembly - Return (SEE PAGE 3.10) Copyright © 1999 Terramite Corporation...
Page 74 T6 Steering Column 2WD and 4WD PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88658 8-6.58 "T" Port Steering Column Drive System Block - (SEE PAGE 3.13) 88658 8-6.58 "P" Port Steering Column Transmission - Gear Pump 2WD (SEE PAGE 3.1)
Page 75 T6 Power Steering Cylinder PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88465 8-4.65 Steering Cylinder Steering Column - Port "L" (SEE PAGE 3.8) 88465 8-4.65 Steering Cylinder Steering Column - Port "R" (SEE PAGE 3.8) Copyright © 1999 Terramite Corporation...
Page 76 T6 Loader Valve Assembly PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88831 88831 Return - Front Valve Assembly Oil Cooler (SEE PAGE 3.7) 88880 8-8.80 Intake - Front Valve Assembly Rear Valve Assembly - Pressure Port (SEE PAGE 3.11) 3.10...
Page 77 T6 Backhoe Valve Assembly PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88880 8-8.80 Pressure Port - R. Valve Assembly Front Valve - Intake (SEE PAGE 3.10) 88840 8-8.40 Return Port - R. Valve Assembly Drive System Block - (SEE PAGE 3.13)
Page 78 NUMBER PART NUMBER STARTING POINT ENDING POINT 81028 8-10.28 Filter - Return Line Oil Tank - Lower Dump (SEE PAGE 3.14) 81012 8-10.12 Filter - Intake Line Drive System Block - (SEE PAGE 3.13) 3.12 Copyright © 1999 Terramite Corporation...
Page 79 T6 Drive System Distributor Block PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88100 8-8.100 Port A Oil Cooler - Return Line (SEE PAGE 3.7) 88658 8-6.58 Port B Steering Column - Port "T" (SEE PAGE 3.8) 88840 8-8.40...
Page 80 T6 Hydraulic Oil Tank Assembly PART PREVIOUS HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT 88614 8-6.14 Oil Tank - Upper Return Transmission - Discharge (SEE PAGE 3.3) 81028 8-10.28 Oil Tank - Lower Return Filter Assembly - Return (SEE PAGE 3.12) 88820 8-8.20...
Page 86 Seal Ring (2) Drive Link End Cover Assembly Thrust Washer Wear Plate Special Bolt (7) Thrust Washer Rotor Set Plug Thrust Bearing Rotor O-Ring Bearing Vane (7) Sping Coupling Shaft Stator Valve (Shuttle) 11A Key Copyright © 1999 Terramite Corporation...
Page 87 Shim-Drive Pinion Adjusting 55050 5-05 Baffle-Pinion Bearing 55060 5-06 Shim-Pinion Bearing Adjusting 55070 5-07 Kit-Outer Pinion Bearing 706030X 55080 5-08 Slinger-Pinion Bearing Outer 55090 5-09 Seal-Pinion 35723 55100 5-10 End Yoke Assembly 3-4-5761X Continued On Next Page Copyright © 1999 Terramite Corporation...
Page 88 LIMITED SLIP DIFFERENTIAL (TRAC-LOK) STD. ON SER #9975236 & UP 55390 5-39 Case-Differential 55400 5-40 Gear-Differential 55410 5-41 Shaft-Differential 55420 5-42 Ring-Snap 55430 5-43 Spacer-Differential Gear (Dished) 55440 5-44 Plate-Differential 55450 5-45 Disc-Differential 55460 5-46 Plate-Differential (Selective Thickness) 55470 5-47 Clip-Differential Clutch Retainer Copyright © 1999 Terramite Corporation...
Page 89 2700 ± 400 2000 ± 300 with one that is of same part no. and grade or better. ISO - International Standard Organization *1 newton meter (N . m) is approximately the same as 0.1 mkg. Copyright © 1999 Terramite Corporation...
Page 90 1. Before disassembly, it is suggested that each valve section be marked numerically to avoid incorrect reassembly. 2. Remove three assembly stud nuts from the left end section using a " thin wall socket. 3. Remove valve sections by sliding from assembly studs. Copyright © 1999 Terramite Corporation...
Page 91 21866-001 ..STD 9002-011 ..VITON 9002-108 ..VITON THESE SEALS ARE NOT INTERCHANGEABLE. OLD AND NEW STYLE SECTIONS MAY BE USED IN THE SAME ASSEMBLY PROVIDED THE CORRECT SEALS ARE USED FOR EACH SECTION. Copyright © 1999 Terramite Corporation...
Page 92 Notes: 1. Seal and washer not sold separately. Order Seal Kit. 2. These are matched parts and are not sold separately. Buna-N seals are standard for all Gresen valve assemblies. Optional Viton seals are available. Copyright © 1999 Terramite Corporation...
Page 93 SEAL KIT, (Contains items 2, 3, 4, 5 and 6) PLUG, Lift Check, Steel (Heavy Duty) SEAL, O-Ring WASHER, Back-Up, Outer Not Sold Separately SEAL, O-Ring, Outer WASHER, Back-Up, Inner SEAL, O-Ring POPPET, Lift Check SPRING, Lift Check Copyright © 1999 Terramite Corporation...
Page 95 GASKET, Relief Body O-RING, Adjusting Screw Not Sold Separately O-RING, Valve Seat BODY SCREW, Adjusting NUT, Jam, Adjusting Screw NUT, Acorn Cap GUIDE, Spring WASHER, Spacer (SP) WASHER, Spacer (SPK) POPPET, Check SEAT, Valve 4.11 Copyright © 1999 Terramite Corporation...
Page 97 Pin/w - Clam Bucket Pivot 19358 19358 Clam/W - 4 in 1 19357 19357 Blade/w - 4 in 1 Clam 17137 17137 Pin/w - Clam Cylinder (Barrel End) 13200 13200 Pin, 1" x 4 " Copyright © 1999 Terramite Corporation...
Page 98 " Male Pipe Ends 42" Lg. 80029 80029 Hose/A - " Male Pipe Ends 25" Lg. (Used with Clam Shell 21403 1-40.3 Handle, Loader, Black Bucket Only) View of Dash for Clam Shell 4 in 1 Bucket (Factory Installed Option) Copyright © 1999 Terramite Corporation...
Page 99 PREVIOUS PART NUMBER DESCRIPTION QTY. 80119 80119 Hose, 1/4" Male Pipe Ends 109" Lg. 20146 1-46 Valve, Loader, 3 Spool (Used with Clam Shell Bucket Only) 22784 8MA-4UFS Fitting, "M 90° x "M Swivel SHOWN Copyright © 1999 Terramite Corporation...
Page 100 SECTION SIX...
Page 101 Gegengewicht contrapeso coupler raccord Anschlussstück, conector, enganche Schnellwechsler coupling accouplement Verbindungsstück acoplamiento cover couvercle Deckel cubierta, tapa crankcase carter moteur Kurbelgehäuse cárter crankshaft vilebrequin Kurbelwelle cigüeñal crosshead traverse Kreuzkoph cruceta coupelle Aussenring, Schale taza Copyright © 1999 Terramite Corporation...
Page 102 Rahmen bastidor front avant vorne, Front frente, parte delantera fuel carburant Kraftstoff combustible FFTL triple levée Dreifach-Vollfreihub alto despejo libre fuse fusible Sicherung fusible gasket joint Dichtung junta Copyright © 1999 Terramite Corporation...
Page 103 Planierer nivelador light lumière Leuchte line canalisation Leitung tuberia liner chemise, garniture Laufbuchse camisa lining revêtement, garniture (frein) Auskleidung, Belag revestimiento, forro link baillette, maillon Glied, Gelenkstück eslabón locknut contre-écrou Kontermutter, Siche- tuerca de traba Copyright © 1999 Terramite Corporation...
Page 104 Lager-, Laufring anillo de cojinete cuvette radiator radiateur Kühlernetz radiador rail rail (glissiére) Schiene riel, mástil rear arrière, AR rückwärts, hinten posterior, trasero rectifier redresseur Gleichrichter rectificador regulator régulateur Regler, Reguliervorrichtung regulador relay relais Relais relé Copyright © 1999 Terramite Corporation...
Page 105 Ventilstössel carrete springs ressort Feder resortes sprocket barbotin Antriebsrad rueda dentada standard (Std.) normal Standard estándar starter démarreur Anlasser arranque stationary (Stat.) stationnaire Aussenmast, stationär estacionario, inmóvil stator stator Ständer, Stator estator Copyright © 1999 Terramite Corporation...
Page 106 Kabelbaum mazo de cables wire marker marquer de fil Kabelmarkierung marcador de alambre worm vis sans fin Schnecke tornillo sin fin wrap revêtement, enveloppe Hülle envolver, envoltura yoke chape Gabelgelenk, Joch horquilla Copyright © 1999 Terramite Corporation...
Page 107 SECTION SEVEN...
Page 108 Bucket, 24", Quick Attach ......................2.49 Decal, Stand Clear ..................... 2.6, 2.7, 2.45 Bucket, 24", Regular ........................ 2.50 Decal, T6, 2 Wheel Drive ....................2.7, 2.45 Bucket, 36", Quick Attach ......................2.49 Decal, T6, 4 Wheel Drive ......................2.45 Bucket, 36", Regular ........................ 2.50 Decal, Terramite Large ......................
Page 109 Handle, Loader, Black ........................ 5.2 Handle, Outrigger ........................2.40 Handle, Wobblestick, Left Rear ..................2.39, 2.40 Handle, Wobblestick, Right Rear ..................2.39, 2.40 History of Terramite Backhoes ....................1.1 DESCRIPTION PAGE Hood Latch ..........................2.15 MAB/MAE Torquemotor Exploded Assembly View - Typical ............4.2 Hose Guide ..........................
Page 110 Seat Assembly, Swivel ......................2.36 Pin, Front Axle Picot 5-1/2" Long ....................2.8 Seat Belt Assembly (Both Halves) ................... 2.36 Pin, Front Axle Pivot 1-1/2" x 7-1/4" L ..................2.9 Shaft-Axle Flanged, Rear Axle Assembly ................... 4.4 Copyright © 1999 Terramite Corporation...
Page 111 T6 4WD Front Axle Assembly ....................3.4 View from Right Side of Engine Compartment ................. 2.21 T6 Backhoe Hydraulic Circuit Wobblestick Hose Diagram 2WD ..........3.15 View from Right Side of Hydraulic Tank ................... 2.30 T6 Backhoe Hydraulic Circuit Wobblestick Hose Diagram 4WD ..........3.16 View from Right Side of Linkage Assembly-Non Quick Attach Bucket ........
Page 112 “ B a c k e d b y a Wo r l d o f E x p e r i e n c e ” 600 Goff Mountain Road P.O. Box 7146, Charleston, WV 25356-7146 U.S.A. 1-800-428-3772 Fax 1-800-776-4845 International 1-304-776-4231 Fax 1-304-776-4845 www.terramite.com...
