WORKSHOP MANUAL
TRACTOR
L3130,L3430,L3830,
L4630,L5030
KiSC issued 02, 2007 A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L3130 and is the answer not in the manual?

Questions and answers

david
April 4, 2025

where are the safety switches

User image 67efdec17e1e5
0
1 comments:
Mr. Anderson
April 4, 2025

The safety switches on a Kubota L3130 are located at the following positions:

1. Shuttle Shift Lever
2. Clutch Pedal
3. PTO Clutch Control Lever
4. HST Pedal – connected via a linkage through the transmission to the left side of the tractor, where an electro-mechanical switch is activated.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Kubota L3130

Summary of Contents for Kubota L3130

  • Page 1 WORKSHOP MANUAL TRACTOR L3130,L3430,L3830, L4630,L5030 KiSC issued 02, 2007 A...
  • Page 2 TO THE READER This Workshop Manual has been prepared to provide servicing personnel with information on the mechanism, service and maintenance of KUBOTA Tractor L3130, L3430, L3830, L4630 and L5030. It is divided into two parts, “Mechanism” and “Servicing” for each section.
  • Page 3 SAFETY INSTRUCTIONS L3130 · L3430 · L3830 · L4630 · L5030, WSM SAFETY INSTRUCTIONS SAFETY FIRST This symbol, the industry’s “Safety Alert Symbol”, is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully.
  • Page 4 SAFETY INSTRUCTIONS L3130 · L3430 · L3830 · L4630 · L5030, WSM SAFETY STARTING • Do not start the engine by shorting across starter terminals or bypassing the safety start switch. • Do not alter or remove any part of machine safety system.
  • Page 5 SAFETY INSTRUCTIONS L3130 · L3430 · L3830 · L4630 · L5030, WSM VENTILATE WORK AREA • If the engine must be running to do some work, make sure the area is well ventilated. Never run the engine in a closed area. The exhaust gas contains poisonous carbon monoxide.
  • Page 6 SAFETY INSTRUCTIONS L3130 · L3430 · L3830 · L4630 · L5030, WSM SAFETY DECALS The following safety decals are installed on the machine. If a decal becomes damaged, illegible or is not on the machine, replace it. The decal part number is listed in the parts list.
  • Page 7 SAFETY INSTRUCTIONS L3130 · L3430 · L3830 · L4630 · L5030, WSM KiSC issued 02, 2007 A Find manuals at https://best-manuals.com...
  • Page 8 SAFETY INSTRUCTIONS L3130 · L3430 · L3830 · L4630 · L5030, WSM KiSC issued 02, 2007 A Find manuals at https://best-manuals.com...
  • Page 9 SAFETY INSTRUCTIONS L3130 · L3430 · L3830 · L4630 · L5030, WSM KiSC issued 02, 2007 A Find manuals at https://best-manuals.com...
  • Page 10 SPECIFICATIONS L3130 · L3430 · L3830 · L4630 · L5030, WSM SPECIFICATIONS ROPS Type L3130 L3430 Model Manual Transmission Model D1503-MA-E-GST-EU D1703-MA-E-GST-EU Type Indirect injection vertical, water-cooled, 4-cycle diesel Number of cylinders Total displacement 1.499 L (91.5 cu.in.) 1.647 L (100.5 cu.in.) 83 ×...
  • Page 11 L3130 · L3430 · L3830 · L4630 · L5030, WSM SPECIFICATIONS ROPS Type L3830 L4630 Model Manual Transmission Model D1803-MA-E-GST-EU V2203-MA-E-GST-EU Type Indirect injection vertical, water-cooled, 4-cycle diesel Number of cylinders Total displacement 1.826 L (111.4 cu.in.) 2.197 L (134.1 cu.in.) 87 ×...
  • Page 12 L3130 · L3430 · L3830 · L4630 · L5030, WSM SPECIFICATIONS CABIN Type L3830 L4630 Model Manual Transmission Model D1803-MA-E-GST-EU V2203-MA-E-GST-EU Type Indirect injection vertical, water-cooled, 4-cycle diesel Number of cylinders Total displacement 1.826 L (111.4 cu.in.) 2.197 L (134.1 cu.in.) 87 ×...
  • Page 13 L3130 · L3430 · L3830 · L4630 · L5030, WSM SPECIFICATIONS CABIN Type L5030 Model Manual Transmission Model V2403-MA-E-GST-EU Type Indirect injection vertical, water-cooled, 4-cycle diesel Number of cylinders Total displacement 2.434 L (148.5 cu.in.) 87 × 102.4 mm (3.4 × 4.0 in.)
  • Page 14 L3130 · L3430 · L3830 · L4630 · L5030, WSM TRAVELLING SPEEDS TRAVELLING SPEEDS [Manual Transmission Type] Model L3130 L3830 - L4630 Tire size (Rear) 12.4-24 13.6-24 Shuttle shift Range gear shift Main gear shift km/h (mph) km/h (mph) lever...
  • Page 15 L3130 · L3430 · L3830 · L4630 · L5030, WSM TRAVELLING SPEEDS [With Creep Speed Model] Model L3130 L3830 - L4630 L5030 Creep gear shift lever High High High Tire size (Rear) 12.4-24 13.6-24 13.6-28 Range Shuttle Main gear km/h...
  • Page 16 L3130 · L3430 · L3830 · L4630 · L5030, WSM TRAVELLING SPEEDS [GST Type (with creep speed model)] Model L4630 L5030 Creep gear shift lever High High Tire size (Rear) 13.6-24 13.6-28 Shuttle shift Main gear shift km/h (mph) km/h (mph)
  • Page 17 L3130 · L3430 · L3830 · L4630 · L5030, WSM DIMENSIONS DIMENSIONS [L3130, L3430, L3830] KiSC issued 02, 2007 A...
  • Page 18 L3130 · L3430 · L3830 · L4630 · L5030, WSM DIMENSIONS [L4630, L5030] KiSC issued 02, 2007 A...
  • Page 19 GENERAL KiSC issued 02, 2007 A...
  • Page 20 GENERAL CONTENTS 1. TRACTOR IDENTIFICATION ................. G-1 2. GENERAL PRECAUTIONS ................G-2 3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING .. G-3 [1] WIRING ..................... G-3 [2] BATTERY....................G-5 [3] FUSE......................G-5 [4] CONNECTOR .................... G-5 [5] HANDLING OF CIRCUIT TESTER............G-6 4.
  • Page 21 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL 1. TRACTOR IDENTIFICATION When contacting your local KUBOTA distributor, always specify engine serial number, tractor serial number and hour meter reading. (1) Tractor Identification Plate (4) Engine Serial Number...
  • Page 22 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL 2. GENERAL PRECAUTIONS • During disassembly, carefully arrange removed parts in a clean area to prevent confusion later. Screws, bolts and nuts should be installed in their original position to prevent reassembly errors.
  • Page 23 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL 3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING To ensure safety and prevent damage to the machine and surrounding equipment, heed the following precautions in handling electrical parts and wiring.
  • Page 24 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL • Securely clamp, being careful not to damage wiring. (1) Clamp (3) Clamp • Wind Clamp Spirally (4) Welding Dent (2) Wire Harness W10114580 • Clamp wiring so that there is no twist, unnecessary sag, or excessive tension, except for movable part, where sag be required.
  • Page 25 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL [2] BATTERY • Take care not to confuse positive and negative terminal posts. • When removing battery cables, disconnect negative cable first. When installing battery cables, check for polarity and connect positive cable first.
  • Page 26 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL • Use sandpaper to remove rust from terminals. • Repair deformed terminal. Make certain there is no terminal being exposed or displaced. (1) Exposed Terminal (3) Sandpaper (2) Deformed Terminal...
  • Page 27 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL 4. LUBRICANTS, FUEL AND COOLANT Capacity Place Lubricants, fuel and coolant L3130 L3430 L3830 40 L No. 2-D diesel fuel Fuel tank 10.6 U.S.gals No. 1-D diesel fuel if temperature is below −10 °C (14 °F)
  • Page 28 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL Capacity Place Lubricants, fuel and coolant L4630 L5030 40 L 43 L No. 2-D diesel fuel Fuel tank 10.6 U.S.gals 11.4 U.S.gals No. 1-D diesel fuel if temperature is below −10 °C (14 °F)
  • Page 29 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL NOTE Engine Oil • Oil used in the engine should have an American Petroleum Institute (API) service classification and Proper SAE Engine OIl according to the ambient temperatures as shown above.
  • Page 30 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL 5. TIGHTENING TORQUES Screws, bolts and nuts whose tightening torques are not specified in this Workshop Manual should be tightened according to tables below. [1] GENERAL USE SCREWS, BOLTS AND NUTS...
  • Page 31 • The items listed above (@ marked) are registered as emission related critical parts by KUBOTA in the U.S.EPA nonroad emission regulation. As the engine owner, you are responsible for the performance of the required maintenance on the engine according to the above instruction.
  • Page 32 • The items listed above (@ marked) are registered as emission related critical parts by KUBOTA in the U.S.EPA nonroad emission regulation. As the engine owner, you are responsible for the performance of the required maintenance on the engine according to the above instruction.
  • Page 33 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL (Only the Check Points Different from Those for Tractors with CABIN) Period Indication on hour meter Reference Important page Item Clogging of air conditioner Clean Daily – condenser screen...
  • Page 34 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL 7. CHECK AND MAINTENANCE CAUTION • Be sure to check and service the tractor on a flat place with engine shut off, the parking brake on and chock the wheels.
  • Page 35 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL [2] CHECK POINTS OF INITIAL 50 HOURS Changing Engine Oil CAUTION • Before changing oil, be sure to stop the engine. • Allow engine to cool down sufficiently, oil can be hot and can burn.
  • Page 36 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL Replacing Hydraulic Oil Filter / Replacing Transmission Oil Filter [HST Type] CAUTION • Be sure to stop the engine before changing the oil filter cartridge. • Allow engine to cool down sufficiently, oil can be hot and can burn.
  • Page 37 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL Changing Transmission Fluid CAUTION • Be sure to stop the engine checking and changing the transmission fluid. • Allow engine to cool down sufficiently, oil can be hot and can burn.
  • Page 38 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL Changing Front Axle Case Oil CAUTION • Be sure to stop the engine before changing the front axle case oil. • Allow engine to cool down sufficiently, oil can be hot and can burn.
  • Page 39 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL [3] CHECK POINTS OF EVERY 50 HOURS Greasing 1. Apply a grease to the following position as figures. NOTE • Apply a small amount of multipurpose grease to the following points every 50 hours.
  • Page 40 L3130 · L3430 · L3830 · L4630 · L5030, WSM G GENERAL Oiling CAUTION • Be sure to stop the engine and remove the key before oiling. (1) Hand Throttle Cable (2) Foot Throttle Cable (GST/Manual Transmission Type) W1072984 Checking Engine Start System...
  • Page 41 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
