Mitsubishi Electric CITY MULTI PQRY-P72-336ZLMU-A1 Data Book

Hide thumbs
Table of Contents

Advertisement

Quick Links

AIR CONDITIONING SYSTEMS
MODEL
PQRY-P72-336Z(S)LMU-A1

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric CITY MULTI PQRY-P72-336ZLMU-A1

Summary of Contents for Mitsubishi Electric CITY MULTI PQRY-P72-336ZLMU-A1

  • Page 1 AIR CONDITIONING SYSTEMS MODEL PQRY-P72-336Z(S)LMU-A1...
  • Page 2 GENERAL LINE-UP GENERAL LINE-UP I.GENERAL LINE-UP Water Cooled WR2 Series - 575V 144K 168K 192K Type(BTU/h) 120K Type(BTU/h) PQRY-P72ZLMU-A1 PQRY-P96ZLMU-A1 PQRY-P120ZLMU-A1 PQRY-P144ZSLMU-A1 PQRY-P168ZSLMU-A1 PQRY-P192ZSLMU-A1 Model Name Model Name Type(BTU/h) 216K 240K PQRY-P216ZSLMU-A1 PQRY-P240ZSLMU-A1 Model Name 144K 168K 192K 288K 312K 336K Type(BTU/h) Type(BTU/h)

  • Page 3: Table Of Contents

    CONTENTS WR2-Series-575V PQRY-P-Z(S)LMU-A1 I.WR2-Series-575V 1. SPECIFICATIONS............................ 2 2. EXTERNAL DIMENSIONS ........................16 3. CENTER OF GRAVITY ..........................20 4. ELECTRICAL WIRING DIAGRAMS ......................21 5. SOUND LEVELS ............................22 6. OPERATION TEMPERATURE RANGE....................26 7. CAPACITY TABLES ..........................27 7-1. Correction by temperature ....................... 27 7-2.

  • Page 4: Specifications

    1. SPECIFICATIONS WR2-Series-575V I.WR2-Series-575V 1. SPECIFICATIONS Heat Source Model PQRY-P72ZLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 72,000 (Nominal) 21.1 Power input 3.61 (575) Current input (Rated) BTU/h 69,000 20.2 Power input 3.34 3.12...
  • Page 5 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P96ZLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 96,000 (Nominal) 28.1 Power input 5.21 (575) Current input (Rated) BTU/h 92,000 27.0 Power input 4.82 5.19 (575) Current input Temp.

  • Page 6: Precautions For Indoor Unit And Bc Controller

    1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P120ZLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 120,000 (Nominal) 35.2 Power input 7.51 (575) Current input (Rated) BTU/h 114,000 33.4 Power input 6.95 7.35 (575) Current input Temp.

  • Page 7: Precautions For Outdoor Unit/Heat Source Unit

    1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P144ZLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 144,000 (Nominal) 42.2 Power input 8.78 (575) Current input (Rated) BTU/h 137,000 40.2 Power input 8.07 9.98 (575) Current input 11.1...

  • Page 8: Precautions For Control-Related Items

    1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P168ZLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 168,000 (Nominal) 49.2 Power input 12.05 (575) Current input 13.4 (Rated) BTU/h 161,000 47.2 Power input 11.10 11.88 (575) Current input...
  • Page 9 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P192ZLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 192,000 (Nominal) 56.3 Power input 15.05 (575) Current input 16.7 (Rated) BTU/h 183,000 53.6 Power input 13.87 14.19 (575) Current input...
  • Page 10 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P144ZSLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 144,000 (Nominal) 42.2 Power input 7.11 (575) Current input (Rated) BTU/h 137,000 40.2 Power input 6.53 7.72 (575) Current input Temp.
  • Page 11 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P168ZSLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 168,000 (Nominal) 49.2 Power input 9.33 (575) Current input 10.4 (Rated) BTU/h 161,000 47.2 Power input 8.58 9.22 (575) Current input...
  • Page 12 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P192ZSLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 192,000 (Nominal) 56.3 Power input 11.30 (575) Current input 12.6 (Rated) BTU/h 183,000 53.6 Power input 10.40 10.98 (575) Current input...
  • Page 13 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P216ZSLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 216,000 (Nominal) 63.3 Power input 14.03 (575) Current input 15.6 (Rated) BTU/h 206,000 60.4 Power input 12.93 13.24 (575) Current input...
  • Page 14 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P240ZSLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 240,000 (Nominal) 70.3 Power input 16.89 (575) Current input 18.8 (Rated) BTU/h 228,000 66.8 Power input 15.57 16.15 (575) Current input...
  • Page 15 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P288ZSLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 288,000 (Nominal) 84.4 Power input 20.42 (575) Current input 22.7 (Rated) BTU/h 275,000 80.6 Power input 18.82 21.43 (575) Current input...
  • Page 16 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P312ZSLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 312,000 (Nominal) 91.4 Power input 23.41 (575) Current input 26.1 (Rated) BTU/h 297,000 87.0 Power input 21.59 23.67 (575) Current input...
  • Page 17 1. SPECIFICATIONS WR2-Series-575V Heat Source Model PQRY-P336ZSLMU-A1 Indoor Model Non-Ducted Ducted Power source 3-phase 3-wire 575 V ±10% 60 Hz Cooling capacity *1 BTU/h 336,000 (Nominal) 98.5 Power input 26.84 (575) Current input 29.9 (Rated) BTU/h 320,000 93.8 Power input 24.76 25.85 (575) Current input...

  • Page 18: External Dimensions

    2. EXTERNAL DIMENSIONS WR2-Series-575V 2. EXTERNAL DIMENSIONS PQRY-P72, 96, 120ZLMU-A1 Unit: mm(in) MEES21K047...
  • Page 19 2. EXTERNAL DIMENSIONS WR2-Series-575V PQRY-P144, 168, 192ZLMU-A1 Unit: mm(in) MEES21K047...
  • Page 20 2. EXTERNAL DIMENSIONS WR2-Series-575V PQRY-P144, 168, 192, 216, 240ZSLMU-A1 Unit: mm(in) MEES21K047...
  • Page 21 2. EXTERNAL DIMENSIONS WR2-Series-575V PQRY-P288, 312, 336ZSLMU-A1 Unit: mm(in) MEES21K047...

  • Page 22: Center Of Gravity

    3. CENTER OF GRAVITY WR2-Series-575V 3. CENTER OF GRAVITY PQRY-P72, 96, 120ZLMU-A1 Unit: mm [in.] Model 373 [14-11/16] 228 [9] 428 [16-7/8] PQRY-P72ZLMU-A1 PQRY-P96ZLMU-A1 373 [14-11/16] 228 [9] 428 [16-7/8] PQRY-P120ZLMU-A1 373 [14-11/16] 228 [9] 428 [16-7/8] *1 Mounting Pitch 79.5 [3-3/16] 473 [18-5/8] (*1) 721 [28-7/16] (*1)

  • Page 23: Electrical Wiring Diagrams

    4. ELECTRICAL WIRING DIAGRAMS WR2-Series-575V 4. ELECT RICAL WIR ING DIAGRAMS PQRY-P72, 96, 120, 144, 168, 192ZLMU-A1 MEES21K047...

  • Page 24: Sound Levels

    5. SOUND LEVELS WR2-Series-575V 5. SOUND LEVELS Sound level of PQRY-P120ZLMU-A1 Measurement condition PQRY-P72, 96, 120ZLMU-A1 Stand 60Hz 60Hz 3-1/4ft. NC-70 (1m) NC-60 NC-50 Measurement location NC-40 NC-30 Approximate minimum audible limit on NC-20 continuous noise Octave band central frequency (Hz) dB(A) Standard 60Hz...
  • Page 25 5. SOUND LEVELS WR2-Series-575V Sound level of PQRY-P192ZLMU-A1 Measurement condition PQRY-P144, 168, 192ZLMU-A1 Stand 60Hz 60Hz 3-1/4ft. NC-70 (1m) NC-60 NC-50 NC-40 NC-30 Measurement location Approximate minimum audible limit on NC-20 continuous noise Octave band central frequency (Hz) dB(A) Standard 60Hz 53.5 59.0 54.0 54.0 50.5 47.0 52.0...
  • Page 26 5. SOUND LEVELS WR2-Series-575V Sound level of PQRY-P192ZSLMU-A1 Measurement condition PQRY-P144, 168, 192, 216, 240ZSLMU-A1 Stand 60Hz 60Hz NC-70 3-1/4ft. (1m) NC-60 NC-50 Measurement location NC-40 NC-30 Approximate minimum audible limit on NC-20 continuous noise Octave band central frequency (Hz) dB(A) Standard 60Hz...
  • Page 27 5. SOUND LEVELS WR2-Series-575V Sound level of PQRY-P336ZSLMU-A1 Measurement condition PQRY-P288, 312, 336ZSLMU-A1 Stand 60Hz 60Hz 3-1/4ft. NC-70 (1m) NC-60 NC-50 NC-40 Measurement location NC-30 Approximate minimum audible limit on NC-20 continuous noise Octave band central frequency (Hz) dB(A) Standard 60Hz 51.0 53.0 60.5 49.5 51.5 50.5 53.0...

  • Page 28: Operation Temperature Range

    6. OPERATION TEMPERATURE RANGE WR2-Series-575V 6. OPERATION TEMPERATURE RANGE • Cooling Inlet water temperature • Heating Inlet water temperature Combination of cooling/heating operation (Cooling main or Heating main) Indoor temperature Inlet water temperature Cooling Heating 10 to 45 C (50 to 113 F) 15 to 24 CWB (59 to 75 FWB) 15 to 27 CDB (59 to 81 FDB) * The upper limit of the outlet water temperature is approximately 70°C (158°F) when the circulating-water flow...

  • Page 29: Capacity Tables

    7. CAPACITY TABLES WR2-Series-575V 7-1. Correction by temperature 7. CAPACITY TABLES CITY MULTI could have varied capacity at different designing temperature. Using the nominal cooling/heating capacity value and the ratio below, the capacity can be observed at various temperature. PQRY- P72ZLMU Nominal Rated...
  • Page 30 7. CAPACITY TABLES WR2-Series-575V PQRY- P96ZLMU Nominal Rated 28.1 27.0 Cooling Cooling Capacity BTU/h 96,000 Capacity BTU/h 92,000 (Non-Ducted) 4.82 Input 5.21 Input (Ducted) 5.19 Capacity Capacity Inlet-water temp. Water volume Input Input 1.10 1.05 1.00 0.95 0.90 10.0 15.0 20.0 25.0 30.0...
  • Page 31 7. CAPACITY TABLES WR2-Series-575V PQRY- P120ZLMU Nominal Rated 35.2 33.4 Cooling Cooling Capacity Capacity BTU/h 120,000 BTU/h 114,000 (Non-Ducted) 6.95 Input 7.51 Input (Ducted) 7.35 Capacity Capacity Inlet-water temp. Water volume Input Input 1.10 1.05 1.00 0.95 0.90 10.0 15.0 20.0 25.0 30.0...
  • Page 32 7. CAPACITY TABLES WR2-Series-575V PQRY- P144ZLMU Nominal Rated 42.2 40.2 Cooling Cooling Capacity BTU/h 144,000 Capacity BTU/h 137,000 (Non-Ducted) 8.07 Input 8.78 Input (Ducted) 9.98 Capacity Capacity Inlet-water temp. Water volume Input Input 1.10 1.05 1.00 0.95 0.90 10.0 15.0 20.0 25.0 30.0...
  • Page 33 7. CAPACITY TABLES WR2-Series-575V PQRY- P168ZLMU Nominal Rated 49.2 47.2 Cooling Cooling Capacity BTU/h 168,000 Capacity BTU/h 161,000 (Non-Ducted) 11.10 Input 12.05 Input (Ducted) 11.88 Capacity Capacity Inlet-water temp. Water volume Input Input 1.10 1.05 1.00 0.95 0.90 10.0 15.0 20.0 25.0 30.0...
  • Page 34 7. CAPACITY TABLES WR2-Series-575V PQRY- P192ZLMU Nominal Rated 56.3 53.6 Cooling Cooling Capacity BTU/h 192,000 Capacity BTU/h 183,000 (Non-Ducted) 13.87 Input 15.05 Input (Ducted) 14.19 Capacity Capacity Water volume Inlet-water temp. Input Input 1.10 1.05 1.00 0.95 0.90 10.0 15.0 20.0 25.0 30.0...
  • Page 35 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P144ZSLMU Nominal Rated 42.2 40.2 Cooling Cooling Capacity BTU/h 144,000 Capacity BTU/h 137,000 (Non-Ducted) 6.53 Input 7.11 Input (Ducted) 7.72 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...
  • Page 36 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P168ZSLMU Nominal Rated 49.2 47.2 Cooling Cooling Capacity BTU/h 168,000 Capacity BTU/h 161,000 (Non-Ducted) 8.58 Input 9.33 Input (Ducted) 9.22 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...
  • Page 37 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P192ZSLMU Nominal Rated 56.3 53.6 Cooling Cooling Capacity BTU/h 192,000 Capacity BTU/h 183,000 (Non-Ducted) 10.40 Input 11.30 Input (Ducted) 10.98 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...
  • Page 38 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P216ZSLMU Nominal Rated 63.3 60.4 Cooling Cooling Capacity BTU/h 216,000 Capacity BTU/h 206,000 (Non-Ducted) 12.93 Input 14.03 Input (Ducted) 13.24 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...
  • Page 39 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P240ZSLMU Nominal Rated 70.3 66.8 Cooling Cooling Capacity BTU/h 240,000 Capacity BTU/h 228,000 (Non-Ducted) 15.57 Input 16.89 Input (Ducted) 16.15 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...
  • Page 40 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P288ZSLMU Nominal Rated 84.4 80.6 Cooling Cooling Capacity BTU/h 288,000 Capacity BTU/h 275,000 (Non-Ducted) 18.82 Input 20.42 Input (Ducted) 21.43 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...
  • Page 41 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P312ZSLMU Nominal Rated 91.4 87.0 Cooling Cooling Capacity BTU/h 312,000 Capacity BTU/h 297,000 (Non-Ducted) 21.59 Input 23.41 Input (Ducted) 23.67 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...
  • Page 42 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P336ZSLMU Nominal Rated 98.5 93.8 Cooling Cooling Capacity BTU/h 336,000 Capacity BTU/h 320,000 (Non-Ducted) 24.76 Input 26.84 Input (Ducted) 25.85 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...
  • Page 43 7. CAPACITY TABLES WR2-Series-575V PQRY- P72ZLMU Nominal Rated 21.1 20.2 Cooling Cooling Capacity BTU/h 72,000 Capacity BTU/h 69,000 (Non-Ducted) 3.34 Input 3.61 Input (Ducted) 3.12 Capacity Capacity Inlet-water temp. Water volume Input Input 1.10 1.05 1.00 0.95 0.90 50.0 60.0 70.0 80.0 90.0...
  • Page 44 7. CAPACITY TABLES WR2-Series-575V PQRY- P96ZLMU Nominal Rated 28.1 27.0 Cooling Cooling Capacity BTU/h 96,000 Capacity BTU/h 92,000 (Non-Ducted) 4.82 Input 5.21 Input (Ducted) 5.19 Capacity Capacity Water volume Inlet-water temp. Input Input 1.10 1.05 1.00 0.95 0.90 50.0 60.0 70.0 80.0 90.0...
  • Page 45 7. CAPACITY TABLES WR2-Series-575V PQRY- P120ZLMU Nominal Rated 35.2 33.4 Cooling Cooling Capacity BTU/h 120,000 Capacity BTU/h 114,000 (Non-Ducted) 6.95 Input 7.51 Input (Ducted) 7.35 Capacity Capacity Water volume Inlet-water temp. Input Input 1.10 1.05 1.00 0.95 0.90 50.0 60.0 70.0 80.0 90.0...
  • Page 46 7. CAPACITY TABLES WR2-Series-575V PQRY- P144ZLMU Nominal Rated 42.2 40.2 Cooling Cooling Capacity BTU/h 144,000 Capacity BTU/h 137,000 (Non-Ducted) 8.07 Input 8.78 Input (Ducted) 9.98 Capacity Capacity Water volume Inlet-water temp. Input Input 1.10 1.05 1.00 0.95 0.90 50.0 60.0 70.0 80.0 90.0...
  • Page 47 7. CAPACITY TABLES WR2-Series-575V PQRY- P168ZLMU Nominal Rated 49.2 47.2 Cooling Cooling Capacity Capacity BTU/h 168,000 BTU/h 161,000 (Non-Ducted) 11.10 Input 12.05 Input (Ducted) 11.88 Capacity Capacity Inlet-water temp. Water volume Input Input 1.10 1.05 1.00 0.95 0.90 50.0 60.0 70.0 80.0 90.0...
  • Page 48 7. CAPACITY TABLES WR2-Series-575V PQRY- P192ZLMU Nominal Rated 56.3 53.6 Cooling Cooling Capacity Capacity BTU/h 192,000 BTU/h 183,000 (Non-Ducted) 13.87 Input 15.05 Input (Ducted) 14.19 Capacity Capacity Inlet-water temp. Water volume Input Input 1.10 1.05 1.00 0.95 0.90 50.0 60.0 70.0 80.0 90.0...
  • Page 49 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P144ZSLMU Nominal Rated 42.2 40.2 Cooling Cooling Capacity BTU/h 144,000 Capacity BTU/h 137,000 (Non-Ducted) 6.53 Input 7.11 Input (Ducted) 7.72 Capacity Capacity Water volume* Inlet-water temp. Input Input 1.10 1.05 1.00 0.95...
  • Page 50 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P168ZSLMU Nominal Rated 49.2 47.2 Cooling Cooling Capacity BTU/h 168,000 Capacity BTU/h 161,000 (Non-Ducted) 8.58 Input 9.33 Input (Ducted) 9.22 Capacity Capacity Water volume* Inlet-water temp. Input Input 1.10 1.05 1.00 0.95...
  • Page 51 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P192ZSLMU Nominal Rated 56.3 53.6 Cooling Cooling Capacity BTU/h 192,000 Capacity BTU/h 183,000 (Non-Ducted) 10.40 Input 11.30 Input (Ducted) 10.98 Capacity Capacity Water volume* Inlet-water temp. Input Input 1.10 1.05 1.00 0.95...
  • Page 52 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P216ZSLMU Nominal Rated 63.3 60.4 Cooling Cooling Capacity BTU/h 216,000 Capacity BTU/h 206,000 (Non-Ducted) 12.93 Input 14.03 Input (Ducted) 13.24 Capacity Capacity Water volume* Inlet-water temp. Input Input 1.10 1.05 1.00 0.95...
  • Page 53 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P240ZSLMU Nominal Rated 70.3 66.8 Cooling Cooling Capacity BTU/h 240,000 Capacity BTU/h 228,000 (Non-Ducted) 15.57 Input 16.89 Input (Ducted) 16.15 Capacity Capacity Water volume* Inlet-water temp. Input Input 1.10 1.05 1.00 0.95...
  • Page 54 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P288ZSLMU Nominal Rated 84.4 80.6 Cooling Cooling Capacity BTU/h 288,000 Capacity BTU/h 275,000 (Non-Ducted) 18.82 Input 20.42 Input (Ducted) 21.43 Capacity Capacity Water volume* Inlet-water temp. Input Input 1.10 1.05 1.00 0.95...
  • Page 55 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P312ZSLMU Nominal Rated 91.4 87.0 Cooling Cooling Capacity BTU/h 312,000 Capacity BTU/h 297,000 (Non-Ducted) 21.59 Input 23.41 Input (Ducted) 23.67 Capacity Capacity Water volume* Inlet-water temp. Input Input 1.10 1.05 1.00 0.95...
  • Page 56 7. CAPACITY TABLES WR2-Series-575V *The drawing indicates characteristic per unit. PQRY- P336ZSLMU Nominal Rated 98.5 93.8 Cooling Cooling Capacity BTU/h 336,000 Capacity BTU/h 320,000 (Non-Ducted) 24.76 Input 26.84 Input (Ducted) 25.85 Capacity Capacity Inlet-water temp. Water volume* Input Input 1.10 1.05 1.00 0.95...

  • Page 57: Correction By Total Indoor

    7. CAPACITY TABLES WR2-Series-575V 7-2. Correction by total indoor CITY MULTI system have different capacities and inputs when many combinations of indoor units with different total capacities are connected. Using following tables, the maximum capacity can be found to ensure the system is installed with enough capacity for a particular application.
  • Page 58 7. CAPACITY TABLES WR2-Series-575V P120ZLMU PQRY-P120ZLMU-A1 PQRY- Non-Ducted Ducted BTU/h 120,000 Nominal cooling 35.2 capacity 7.51 Input 114,000 BTU/h Rated cooling 33.4 capacity Input 6.95 7.35 P120ZLMU PQRY- Non-Ducted Ducted BTU/h 135,000 Nominal Heating 39.6 capacity 7.09 Input 129,000 BTU/h Rated Heating 37.8...
  • Page 59 7. CAPACITY TABLES WR2-Series-575V P168ZLMU PQRY-P168Z(S)LMU-A1 PQRY- Ducted Non-Ducted BTU/h 168,000 Nominal cooling 49.2 capacity Input 12.05 161,000 BTU/h Rated cooling 47.2 capacity Input 11.10 11.88 P168ZLMU PQRY- Non-Ducted Ducted BTU/h 188,000 Nominal Heating 55.1 capacity 9.86 Input 179,000 BTU/h Rated Heating 52.5...
  • Page 60 7. CAPACITY TABLES WR2-Series-575V P216ZSLMU PQRY-P216ZSLMU-A1 PQRY- Non-Ducted Ducted 216,000 BTU/h Nominal cooling 63.3 capacity 14.03 Input BTU/h 206,000 Rated cooling 60.4 capacity Input 12.93 13.24 P216ZSLMU PQRY- Non-Ducted Ducted BTU/h 243,000 Nominal Heating 71.2 capacity Input 12.88 232,000 BTU/h Rated Heating 68.0...
  • Page 61 7. CAPACITY TABLES WR2-Series-575V P288ZSLMU PQRY-P288ZSLMU-A1 PQRY- Non-Ducted Ducted BTU/h 288,000 Nominal cooling 84.4 capacity 20.42 Input 275,000 BTU/h Rated cooling 80.6 capacity Input 18.82 21.43 P288ZSLMU PQRY- Non-Ducted Ducted BTU/h 323,000 Nominal Heating 94.7 capacity 17.50 Input 308,000 BTU/h Rated Heating 90.3...
  • Page 62 7. CAPACITY TABLES WR2-Series-575V P336ZSLMU PQRY-P336ZSLMU-A1 PQRY- Non-Ducted Ducted BTU/h 336,000 Nominal cooling 98.5 capacity Input 26.84 320,000 BTU/h Rated cooling 93.8 capacity Input 24.76 25.85 P336ZSLMU PQRY- Ducted Non-Ducted 378,000 BTU/h Nominal Heating 110.8 capacity Input 20.77 361,000 BTU/h Rated Heating 105.8...

  • Page 63: Correction By Refrigerant Piping Length

    7. CAPACITY TABLES WR2-Series-575V 7-3. Correction by refrigerant piping length CITY MULTI system can extend the piping flexibly within its limitation for the actual situation. However, a decrease of cooling/ heating capacity could happen correspondently. Using following correction factor according to the equivalent length of the piping shown at 7-3-1 and 7-3-2, the capacity can be observed.
  • Page 64 7. CAPACITY TABLES WR2-Series-575V PQRY-P288ZSLMU PQRY-P336ZSLMU Total capacity of indoor unit Total capacity of indoor unit 1.00 1.00 0.95 0.95 0.90 0.90 0.85 0.85 0.80 0.80 0.75 0.75 0.70 0.70 0.65 0.65 Piping equivalent length Piping equivalent length PQRY-P312ZSLMU Total capacity of indoor unit 1.00 0.95 0.90...
  • Page 65 7. CAPACITY TABLES WR2-Series-575V 7-3-2. Heating capacity correction PQRY-P72ZLMU PQRY-P216, 240ZSLMU 1.00 1.00 0.90 0.90 0.80 0.80 Piping equivalent length Piping equivalent length PQRY-P96, 120ZLMU PQRY-P288, 312ZSLMU 1.00 1.00 0.90 0.90 0.80 0.80 Piping equivalent length Piping equivalent length PQRY-P144, 168, 192Z(S)LMU PQRY-P336ZSLMU 1.00 1.00...
  • Page 66 7. CAPACITY TABLES WR2-Series-575V 7-3-3. How to obtain the equivalent piping length 1. PQRY-P72ZLMU Equivalent length = (Actual piping length to the farthest indoor unit) + (1.15 x number of bent on the piping) [ft.] Equivalent length = (Actual piping length to the farthest indoor unit) + (0.35 x number of bent on the piping) [m] 2.

  • Page 67: System Design Guide

    8. SYSTEM DESIGN GUIDE WR2-Series-575V 8-1. Designing of water circuit system 8. SYSTEM DESIGN GUIDE 1) Example of basic water circuit The water circuit of the water heat source CITY MULTI connects the heat source unit with the cooling tower/auxiliary heat source/heat storage tank/circulation pump with a single system water piping as shown in the figure below.
  • Page 68 8. SYSTEM DESIGN GUIDE WR2-Series-575V 2) Cooling tower a) Types of cooling tower Types of cooling towers The cooling towers presently used include the open type cooling tower, open type cooling tower + heat exchanger, closed type cooling tower, and air-cooled type cooling Closed type tower.
  • Page 69 8. SYSTEM DESIGN GUIDE WR2-Series-575V 3) Auxiliary heat source and heat storage tank When the heating load is larger than the cooling load, the circulation water temperature lowers in accordance with the heat balance of the system. It should be heated by the auxiliary heat source in order to keep the inlet water tempera- ture within the operating range of the water heat source CITY MULTI.
  • Page 70 8. SYSTEM DESIGN GUIDE WR2-Series-575V When heat storage tank is not used • - 860 × Pw × T QH = × K (kcal) (kcal/day) Total of heating load on weekday including warming up Operating hour of auxiliary heat source Operating hour of heat source water pump 1.05~1.10 Allowance factor (Heat storage tank, piping loss, etc.)
  • Page 71 8. SYSTEM DESIGN GUIDE WR2-Series-575V b) Heat storage tank Heat storage tank can be classified by types into the open type heat storage tank exposed to atmosphere, and the closed type heat storage tank with structure separated from atmosphere. Although the size of the tank and its instal- lation place should be taken into account, the closed type tank should be used by considering corrosion problems.
  • Page 72 8. SYSTEM DESIGN GUIDE WR2-Series-575V 4) Piping system The following items should be kept in your mind in planning / designing water circuits. a) All units should be constituted in a single circuit in principle. b) When plural numbers of the water heat source CITY MULTI unit are installed, the rated circulating water flow rate should be kept by making the piping resistance to each unit almost same value.
  • Page 73 8. SYSTEM DESIGN GUIDE WR2-Series-575V 5) Practical System Examples and Circulation Water Control Since the water heat source CITY MULTI is of water heat source system, versatile systems can be constituted by combining it with various heat sources. The practical system examples are given below. Either cooling or heating operation can be performed if the inlet water temperature of the water heat source CITY MULTI stays within a range of 10~45°C [50~113°F].
  • Page 74 8. SYSTEM DESIGN GUIDE WR2-Series-575V Example-2 Combination of closed type cooling tower and hot water heat storage tank T1 : Proportional type, insertion system thermostat T2 : Proportional type, insertion system thermostat T3 : Proportional type, insertion system thermostat V1 : Proportional type, motor-driven 3-way valve V2 : Proportional type, motor-driven 3-way valve XS : Auxiliary switch (Duplex switch type) SC : Step controller...
  • Page 75 8. SYSTEM DESIGN GUIDE WR2-Series-575V Example-3 Combination of closed type cooling tower and boiler T1 : Proportional type, insertion system thermostat T2 : Proportional type, insertion system thermostat T3 : Proportional type, insertion system thermostat V1 : Proportional type, motor-driven 3-way valve : Selector switch : Relay XS : Auxiliary switch (Duplex switch type)
  • Page 76 8. SYSTEM DESIGN GUIDE WR2-Series-575V Example-4 Combination of closed type cooling tower and heat exchanger (of other heat source) T1 : Proportional type, insertion system thermostat T2 : Proportional type, insertion system thermostat V1 : Proportional type, motor-driven 3-way valve V2 : Proportional type, motor-driven 3-way valve : Selector switch : Relay...
  • Page 77 8. SYSTEM DESIGN GUIDE WR2-Series-575V 6) Pump interlock circuit Heat source • Plural indoor units (8HP:15sets, 16HP:16sets maximum) being connected to equipment a single refrigerant system can be controlled individually. • The transmission line is of a jumper wiring system using non-polar 2 wires. Refrigerant piping BC controller Transmission line...
  • Page 78 8. SYSTEM DESIGN GUIDE WR2-Series-575V Operation ON signal Terminal No. TB8-1, 2 Relay contacts output Rated voltage: 3~: 208/230V Output Rated load: 1 A • When setting No.917 for Dip switch 4 (Dip switch 6-10 is ON) is OFF. Operation The relay closes during compressor operation.
  • Page 79 8. SYSTEM DESIGN GUIDE WR2-Series-575V 7) Water flow rate control The function described here calculates the amount of circulating water required for the heat-exchanger unit based on the operation status of the heat-exchanger, and then outputs signals that adjust the water control valve. Signals requesting to decrease the water control valve opening are output when the heat-source unit is in partial-load operation, which decreases the amount of circulating water supplied to the heat-source unit and helps reduce the power required to operate the circu- lating water pump in the water circuit system.
  • Page 80 8. SYSTEM DESIGN GUIDE WR2-Series-575V b) Circulating water flow rate control signal output 1. Water flow rate control signal output Signal to control the water flow rate control valve is calculated by using the circulating water flow rate required, which is calculated based on the operating status of the unit.
  • Page 81 8. SYSTEM DESIGN GUIDE WR2-Series-575V c) Schematic system diagram including heat-source units, water circuits, power supplies, and signals 208/230 VAC Pump operation ON signal 208/230 VAC Pump operation ON signal Heat-source Heat-source I/O board I/O board : Water pipes unit 1 unit 2 : Power-supply wiring : Signal wiring...
  • Page 82 8. SYSTEM DESIGN GUIDE WR2-Series-575V d) Electrical wiring diagram of heat-source unit Terminal blocks TB8 and TB9 for controlling water flow rate are found on the I/O board. Wiring connections need to be made for each heat-source unit. 63H1 CNDC CN801 CN61 CPU power...
  • Page 83 8. SYSTEM DESIGN GUIDE WR2-Series-575V e) Installation Note the following for installing the circulating water flow rate control system. 1. Make sure that water circuit components necessary to build a circulating water flow rate control system are in place.  See Figure c)-1 and Table c)-1. ...
  • Page 84 8. SYSTEM DESIGN GUIDE WR2-Series-575V Standard Power-save settings for the pump ·DipSW4 (901) = ON ·DipSW4 (901) = OFF ·DipSW4 (917) = OFF ·DipSW4 (917) = ON Remote controller ON Remote controller ON Heat-source unit Heat-source unit Stopped Thermo-ON Stopped Thermo-ON Thermo-OFF Thermo-OFF...

  • Page 85: Water Piping Work

    8. SYSTEM DESIGN GUIDE WR2-Series-575V 8-2. Water piping work Although the water piping for the CITY MULTI WR2 system does not differ from that for ordinary air conditioning systems, pay special attention to the items below in conducting the piping work. 1) Items to be observed on installation work Installation example of heat source unit •...
  • Page 86 8. SYSTEM DESIGN GUIDE WR2-Series-575V In order to keep the water quality within such standards, you are kindly requested to conduct bleeding-off by overflow and periodical water quality tests, and use inhibitors to suppress condensation or corrosion. Since piping may be corroded by some kinds of inhibitor, consult an appropriate water treatment expert for proper water treatment.
  • Page 87 8. SYSTEM DESIGN GUIDE WR2-Series-575V 5) Handling plate heat exchangers for heat-source units <Designing the piping system>  Install a strainer (50 mesh or finer recommended) near the heat-source unit on the inlet side of the hot/cold water pipe and cooling-water pipe (hereafter referred to as water pipes) to prevent an infiltration of foreign materials of solid nature, such as dirt and sand, into the plate heat exchanger.
  • Page 88 8. SYSTEM DESIGN GUIDE WR2-Series-575V <Maintaining plate heat exchangers> Plate heat exchangers must be maintained in a planned and periodical manner to prevent scale formation, which may cause performance loss or decrease water flow rate that result in freeze damage to the plate heat exchanger. ...

  • Page 89: Optional Parts

    9. OPTIONAL PARTS CITY MULTI units can be easily connected by using Joint sets and Reducer sets provided by Mitsubishi Electric. Refer to section "Piping Design" or the Installation Manual that comes with the Joint set or Reducer set for how to install the Joint set or Reducer set.
  • Page 90 9. OPTIONAL PARTS WR2-Series-575V CMY-R201S-G For High pressure For Low pressure For Liquid line ø3/4 ø5/8 ø3/8 ø1 ø1/2 ø3/4 ø3/4 ø1/2 1-11/16 ø1 2-5/16 2-5/8 ø1 ø3/4 ø1/2 (Outside diameter) (Outside diameter) (Outside diameter) ø3/4 ø3/8 ø5/8 15/16 1-5/8 1-3/16 (2 Pcs.) (2 Pcs.)
  • Page 91 9. OPTIONAL PARTS WR2-Series-575V CMY-R204S-G For High pressure For Low pressure For Liquid line ø1 ø3/4 ø5/8 ø1 ø1-1/4 ø3/4 ø3/4 ø1 ø1-1/4 2-5/16 2-5/8 3-9/16 ø1 ø1-1/4 ø3/4 ø3/4 ø5/8 ø1 (Outside diameter) (Outside diameter) (Outside diameter) (Outside diameter) (Outside diameter) (Outside diameter) ø5/8...
  • Page 92 9. OPTIONAL PARTS WR2-Series-575V CMY-R303S-G1 ø1-1/8 ø7/8 (Outside diameter) (Outside diameter) ø7/8 ø3/4 3-3/16 3-3/16 (2 Pcs.) (2 Pcs.) ø3/4 ø1/2 ø3/4 (Outside diameter) (Outside diameter) (Outside diameter) ø1/2 ø3/8 ø5/8 3-3/16 3-3/16 3-3/16 (2 Pcs.) ø1-1/2 ø1-3/8 (Outside diameter) (Outside diameter) ø1-3/8 ø1-1/8...

  • Page 93: Outdoor Twinning Kit

    9. OPTIONAL PARTS WR2-Series-575V 9-2. OUTDOOR TWINNING KIT The following optional Outdoor Twinning Kit is needed to use to combine multiple refrigerant pipes. Refer to section "Piping Design" for the details of selecting a proper twinning kit. CMY-Q100CBK2 <Elbow pipe(Accessory)> <Accessory>...

  • Page 94: Joint Kit "Cmy-R160-J1" For Bc Controller

    9. OPTIONAL PARTS WR2-Series-575V 9-3. JOINT KIT "CMY-R160-J1" FOR BC CONTROLLER Joint kit "CMY-R160-J1" for BC controller is used to combine 2 ports of the BC controller at a PURY/PQRY system so as to enable down-stream Indoor capacity above P54 as shown in Fig. 1. The Joint kit include following items: Instruction Joint pipe(Small)

  • Page 95: Electrical Work

    10. ELECTRICAL WORK WR2-Series-575V 10-1. General cautions 10. EL ECTRICAL WORK Follow ordinance of your governmental organization for technical standard related to electrical equipment, wiring regulations, and guidance of each electric power company. Wiring for control (hereinafter referred to as transmission cable ) shall be (50mm[1-5/8in] or more) apart from power source wiring so that it is not influenced by electric noise from power source wiring.

  • Page 96: 10-2.Power Supply For Heat Source Unit

    10. ELECTRICAL WORK WR2-Series-575V 10-2. Power supply for Heat source unit 10-2-1. Electrical characteristics of Heat source unit at cooling mode Symbols: MCA: Minimum Circuit Ampacity SC: Starting Current, RLA: Rated Load Amps PQRY-P-Z(S)LMU Heat source unit Compressor Model Unit Combination Volts Voltage range MCA(A)

  • Page 97: 10-3.Power Cable Specifications

    Be sure to use the appropriate type of overcurrent protection switch. Note that generated overcurrent may include some amount of direct current. The breakers for current leakage should support Inverter circuit. (e.g. Mitsubishi Electric's NV-C series or equivalent). If no earth leakage breaker is installed, it ...

  • Page 98: 10-4.Power Supply Examples

    10. ELECTRICAL WORK WR2-Series-575V 10-4. Power supply examples The local standards and/or regulations is applicable at a higher priority. 10-4-2. PQRY-P144, 168, 192, 216, 240, 288, 312, 336ZSLMU <In the case a system controller is connected.> Note: 1 The transmission cable is not-polarity double-wire. Central control 2 Symbol means a screw terminal for wiring.
  • Page 99 10. ELECTRICAL WORK WR2-Series-575V The local standards and/or regulations is applicable at a higher priority. 10-4-2. PQRY-P144, 168, 192, 216, 240, 288, 312, 336ZSLMU <In the case a system controller is connected.> Note: 1 The transmission cable is not-polarity double-wire. Central control 2 Symbol means a screw terminal for wiring.

  • Page 100: M-Net Control

    11. M-NET CONTROL WR2-Series-575V 11-1. Transmission cable length limitation 11. M-NET CONTROL 11-1-1. Using MA Remote controller MA remote controller refers to Simple MA remote controller and wireless remote controller. Long transmission cable causes voltage down, therefore, the length limitation should be obeyed to secure proper transmission. Max.

  • Page 101: 11-2.Transmission Cable Specifications

    11. M-NET CONTROL WR2-Series-575V 11-2. Transmission cable specifications Transmission cables ME Remote controller cables MA Remote controller cables Shielding wire (2-core) Sheathed 2-core cable (unshielded) Type of cable CVVS, CPEVS or MVVS Cable size [AWG22 16] *1 More than 1.25 [AWG16] 0.3 1.25 [AWG22 16]...

  • Page 102: 11-3.System Configuration Restrictions

    11. M-NET CONTROL WR2-Series-575V 11-3. System configuration restrictions 11-3-1. Common restrictions for the CITY MULTI system For each Outdoor/Heat source unit, the maximum connectable quantity of Indoor unit is specified at its Specifications table. A) 1 Group of Indoor units can have 1-16 Indoor units; B) Maximum 2 remote controllers for 1 group;...
  • Page 103 11. M-NET CONTROL WR2-Series-575V Table 2 The equivalent power supply The equivalent Category Model power supply Transmission Booster PAC-SF46EPA-G 25 *1 Power supply unit PAC-SC51KUA Expansion controller PAC-YG50ECA BM ADAPTER BAC-HD150 AE-200A/AE-50A 0.75 System controller EW-50A LM-AP TB3 and TB7 total TB7 only TB3 only Outdoor unit other than the following...
  • Page 104 11. M-NET CONTROL WR2-Series-575V 11-3-3. Ensuring proper power supply to System controller The power to System controller (excluding AE-200A, AE-50A, EW-50A, BAC-HD150, LM-AP) is supplied via M-NET transmission line. M-NET transmission line at TB7 side is called Centralized control transmission line while one at TB3 side is called Indoor-Outdoor/Heat source transmission line.
  • Page 105 11. M-NET CONTROL WR2-Series-575V 11-3-4. Power supply to LM-AP 1-phase 208-230VAC power supply is needed. The power supply unit PAC-SC51KUA is not necessary when connecting only the LM-AP. Yet, make sure to change the power supply changeover connector CN41 to CN40 on the LM-AP. 11-3-5.

  • Page 106: 11-4.Address Setting

    11. M-NET CONTROL WR2-Series-575V 11-4. Address setting 11-4-1. Switch operation In order to constitute CITY MULTI in a complete system, switch Rotary switch operation for setting the unit address No. and connection No. is Branch Unit address No. setting required. No.
  • Page 107 11. M-NET CONTROL WR2-Series-575V 11-4-2. Rule of setting address Note Unit Address setting Example Use the most recent address within the same group of indoor units. Make the indoor units address connected to the BC controller (Sub) larger than the indoor units address connected to the BC controller (Main).
  • Page 108 11. M-NET CONTROL WR2-Series-575V 11-4-3. System examples Factory setting Original switch setting of the heat sources, indoors, controllers, LM-AP, and BM ADAPTER at shipment is as follows. • Heat source unit : Address: 00, CN41: ON (Jumper), DipSW5-1: OFF • Indoor unit : Address: 00 •...
  • Page 109 11. M-NET CONTROL WR2-Series-575V 11-4-3-2. MA remote controller, Single-refrigerant-system, System Controller <Two heat source units> <One heat source unit> PQRY PQRY CN40 CN41 CN40 CN41 CN40 CN41 DipSW5-1 DipSW5-1 DipSW5-1 Group 1 Group 2 Group 3 Group 4 Indoor unit BC controller TB15 TB15...
  • Page 110 11. M-NET CONTROL WR2-Series-575V 11-4-3-3. MA remote controller, Multi-refrigerant-system, System Controller at TB7/TB3 side, Booster for long M-NET wiring PQRY PQRY PQRY CN40 CN41 CN40 CN41 CN40 CN41 CN40 CN41 CN40 CN41 DipSW5-1 DipSW5-1 DipSW5-1 DipSW5-1 DipSW5-1 Group1 Group 2 Group 21 Indoor unit BC controller...
  • Page 111 11. M-NET CONTROL WR2-Series-575V 11-4-3-4. ME remote controller, Single-refrigerant-system, No system controller <Two heat source units> <One heat source unit> PQRY PQRY CN40 CN41 CN40 CN41 CN40 CN41 DipSW5-1 DipSW5-1 DipSW5-1 Group 1 Group 2 Group 3 Group 4 BC controller Indoor unit TB02 ME R/C...
  • Page 112 11. M-NET CONTROL WR2-Series-575V 11-4-3-6. ME remote controller, Multi-refrigerant-system, System Controller at TB7 side, Lossnay, Booster for long M-NET wiring PQRY PQRY PQRY CN40 CN41 CN40 CN41 CN40 CN41 CN40 CN41 CN40 CN41 DipSW5-1 DipSW5-1 DipSW5-1 DipSW5-1 DipSW5-1 Group 1 Group 2 Group 21 BC controller...
  • Page 113 11. M-NET CONTROL WR2-Series-575V 11-4-3-8. ME remote controller, Multi-refrigerant-system, No Power supply unit PQRY PQRY CN40 CN41 CN40 CN41 CN40 CN41 DipSW5-1 DipSW5-1 DipSW5-1 Group 1 Group 2 BC controller TB02 ME R/C ME R/C Group 4 Group 3 BC controller TB02 ME R/C ME R/C...
  • Page 114 11. M-NET CONTROL WR2-Series-575V 11-4-3-10. AE-200A + AE-50A, EW-50A AE-200A can control max. 200 indoor units/via AE-50A. <Two heat source units> <Two heat source units> <One heat source unit> AE-200A PQRY PQRY PQRY CN21 CN40 CN41 CN40 CN41 CN40 CN41 CN40 CN41 CN40...
  • Page 115 11. M-NET CONTROL WR2-Series-575V 11-4-3-11. LM-AP LM-AP can transmit max. 50 indoor units; If system controller (SC) is used, DipSW1-2 at LM-AP and DipSW5-1 at Heat source unit should set to "ON". Change Jumper from CN41 to CN40 to activate power supply to LM-AP itself for those LM-AP connected without system controller (SC).
  • Page 116 11. M-NET CONTROL WR2-Series-575V ® 11-4-3-12. BACnet EW-50A (AE-200A) can control up to 50 units/groups (including Lossnay). *To use the BACnet ® function on EW-50A (AE-200A), BACnet ® license registration is required. EW-50A(01) <Two outdoor units> <One outdoor unit> CN40 CN41 LAN2 CN40...

  • Page 117: Piping Design

    12. PIPING DESIGN WR2-Series-575V 12. PIPING DESIGN Section 12-2. Explains the piping design including piping length limitation and piping size selection rule. MEES21K047...

  • Page 118: 12-1.R410A Piping Material

    12. PIPING DESIGN WR2-Series-575V 12-1. R410A Piping material The maximum operation pressure of R410A air conditioner is 4.15 MPa [601 psi]. The refrigerant piping should ensure the safety under the maximum operation pressure. You shall follow the local industrial standard. Procedures for installing the branched pipes Refer to the instructions that came with the branched pipe kit (separately sold) for details.

  • Page 119: 12-2.Piping Design

    12. PIPING DESIGN WR2-Series-575V 12-2. Piping Design 12-2-1. IF 16 ports or less are in use, i.e., if only one BC controller is in use with no sub BC controller. "BC controller," "BC controller (Main)," and "BC controller (Sub)" that appear in this section refer to the J1-type, JA1/KA1 type, and KB1 type. When mixing GA1/HA1/GB1/HB1 type and JA1/KA1/KB1 type, specifications and restrictions is according to GA1/HA1/GB1/HB1type.
  • Page 120 12. PIPING DESIGN WR2-Series-575V 12-2-2. IF more than 16 ports are in use, or if there is more than one BC controller in use for one Heat source unit Note1. No Header usable on PQRY system. Note2. Indoor unit sized P72-P96 should be connected to BC controller via Y shape joint CMY-R160-J1. Note3.
  • Page 121 12. PIPING DESIGN WR2-Series-575V Piping length and height between IU and BC controller Height difference between Main BC controller Height difference between Main BC controller and farthest indoor unit (ft) and farthest indoor unit (ft) Fig. 2 Fig. 3 Fig. 3 *9.
  • Page 122 12. PIPING DESIGN WR2-Series-575V 12-2-3. IF more than 16 ports are in use, or if there is more than one BC controller in use for two Heat source units Note1. No Header usable on PQRY system. Joint CMY-R160-J1 Liquid side Note2.
  • Page 123 12. PIPING DESIGN WR2-Series-575V Piping length and height between IU and BC controller Height difference between Main BC controller Height difference between Main BC controller and farthest indoor unit (ft) and farthest indoor unit (ft) Fig. 2 Fig. 3 Fig. 3 *9.
  • Page 124 12. PIPING DESIGN WR2-Series-575V 12-2-4. Total piping length restrictions (m) [PQRY-P144, 168, 192ZLMU-A1] [PQRY-P72, 96, 120ZLMU-A1] [PQRY-P144, 168, 192, 216, 240, 288, 312, 336ZSLMU-A1] 1000 1000 90 100 110 90 100 110 Distance between heat source unit and BC controller (m) Distance between heat source unit and BC controller (m) Total piping length restrictions (ft.) [PQRY-P144, 168, 192ZLMU-A1]...

  • Page 125: 12-3.Refrigerant Charging Calculation

    12. PIPING DESIGN WR2-Series-575V 12-3. Refrigerant charging calculation Sample connection (with 5 BC controllers and 8 indoor units) (PQRY-P288ZSLMU-A1) 5 : P48 Heat source Twinning kit (High/Low press.) CMY-Q100CBK2: Heat source unit P144 to P240 CMY-Q200CBK: Heat source unit P288 to P336 Pipe (LP Gas) The Low press.
  • Page 126 12. PIPING DESIGN WR2-Series-575V * When connecting the CMB-P**-NU-G1, CMB-P**-NU-GA1, CMB-P**-NU-HA1, CMB-P**-NU-GB1, or CMB-P**-NU-HB1 to a given system, add the amount of refrigerant as indicated in the table below. BC controller Amount (kg/unit) G1/GA1-type HA1-type GB1/HB1-type • When the piping length from the outdoor unit to the farthest indoor unit is longer than 30.5 m (100 ft) Amount of High-pressure pipe High-pressure pipe...
  • Page 127 12. PIPING DESIGN WR2-Series-575V * When connecting the CMB-P**-NU-G1, CMB-P**-NU-GA1, CMB-P**-NU-HA1, CMB-P**-NU-GB1, or CMB-P**-NU-HB1 to a given system, add the amount of refrigerant as indicated in the table below. BC controller Amount (oz/unit) G1/GA1-type HA1-type GB1/HB1-type • When the piping length from the outdoor unit to the farthest indoor unit is longer than 30.5 m (100 ft) Amount of High-pressure pipe High-pressure pipe...
  • Page 128 12. PIPING DESIGN WR2-Series-575V Amount of factory charged refrigerant Heat source unit Charged amount Model 5.0 kg P120 P144 P168 6.0 kg P192 Sample calculation Indoor ø28.58 [1-1/8"] 40 m [131ft.] ø6.35 [1/4"] 10 m [32ft.] Heat source unit: P288 ø9.52 [3/8"] 10 m [32ft.] ø9.52 [3/8"]...

  • Page 129: 12-4.Compatibility

    12. PIPING DESIGN WR2-Series-575V 12-4. Compatibility Outdoor/Heat source unit BC controller Compatibility PQRY-P-Z(S)LMU S/W Ver. 6.42 or later J1 type Compatible PQRY-P-Z(S)LMU G1 type Compatible PQRY-P-Z(S)LMU G type Compatible BC controller Outdoor/Heat source unit Compatibility Main JA1/KA1 type GB1/HB1 type GB1/HB1 type Compatible JA1/KA1 type KB1 type...

  • Page 130: Installation

    13. INSTALLATION WR2-Series-575V 13-1. General requirements for installation 13. INSTALLATION 1. If possible, locate the unit to reduce the direct thermal radiation to the unit. 2. Consider the amount of noise the unit produces when choosing an installation location. Valves and refrigerant flow on the outdoor/heat source unit may generate noise. 3.

  • Page 131: 13-3.Piping Direction

    13. INSTALLATION WR2-Series-575V 13-3. Piping direction 1. Insulation installation With City Multi WY/ WR2 Series piping, as long as the temperature range of the inlet water is kept to average temperatures year-round (30°C[86°F] in the summer, 20°C[68°F] in the winter), there is no need to insulate or otherwise protect indoor piping from exposure.
  • Page 132 WR2-Series-575V MEES21K047...
  • Page 133 CONTENTS Installation information Installation information I.Installation information 1. Installation information ..........................2 1-1. General precautions ........................2 1-2. Precautions for Indoor unit and BC controller .................. 4 1-3. Precautions for outdoor unit/heat source unit .................. 5 1-4. Precautions for control-related items ....................6 MEES20K084...

  • Page 134: Installation Information

    1. Installation information Installation information I.Installation information 1. In stallation information * Refer to the enclosed Installation Manual for details on installation. Arrange to have an expert install the system correctly. 1-1. General precautions 1-1-1. Usage The air-conditioning system described in this DATA BOOK is designed for human comfort. This product is not designed to assist in the preservation of food, provide conditions to maintain plants or animals, or stabilize environments for the preservation of precision equipment or art objects.
  • Page 135 Ensure that there is enough space around each unit. 1-1-7. Optional accessories Only use accessories recommended by Mitsubishi Electric. Consult your local distributor or a qualified technician when installing them. Improper installation by an unqualified person may result in water leakage, power leakage, system breakdown, or fire.
  • Page 136 1. Installation information Installation information 1-2. Precautions for Indoor unit and BC controller 1-2-1. Operating environment The refrigerant (R410A) used in the air conditioner is non-toxic and nonflammable. However, if the refrigerant leaks, the oxygen level may drop to harmful levels. If the air conditioner is installed in a small room, measures must be taken to prevent the refrigerant concentration from exceeding the safety limit even if the refrigerant leaks.
  • Page 137 1. Installation information Installation information 1-3. Precautions for outdoor unit/heat source unit 1-3-1. Installation environment The outdoor unit with the salt-resistant specification is recommended for use in an area in which it will be exposed to salt air. Even when the unit with the salt-resistant specification is used, it is not completely protected against corrosion. Be sure to follow the directions or precautions described in the Instruction Book and Installation Manual for installation and maintenance.
  • Page 138 1. Installation information Installation information 1-4. Precautions for control-related items 1-4-1. Product specification To introduce the MELANS system, a consultation with us is required in advance. Especially to introduce the electricity charge-apportioning function or energy save function, further detailed consultation is required. Consult your local distributor for details.
  • Page 139 CAUTION FOR REFRIGERANT LEAKAGE I.CAUTION FOR REFRIGERANT LEAKAGE 1. Caution for refrigerant leakage ........................Ub-1-2 1-1. Refrigerant property ..........................Ub-1-2 1-2. Confirm the Critical concentration and take countermeasure ..............Ub-1-2 Ub-1- 1 MEES16K100...
  • Page 140 Note 1. Countermeasure 3 should be done in a proper way in which the fresh air supply shall be on whenever the leakage happens. Note 2. In principle, MITSUBISHI ELECTRIC requires proper piping design, installation and air-tight testing after installation to avoid leakage happening.
  • Page 141 - Doing so may cause the unit or pipes to burst, or result in explosion or fire during use, repair, or at the time of disposal of the unit. - It may also be in violation of applicable laws. - MITSUBISHI ELECTRIC CORPORATION cannot be held responsible for malfunctions or accidents resulting from the use of the wrong type of refrigerant.

This manual is also suitable for:

City multi pqry-p72-336zslmu-a1City multi pqry-p72zlmu-a1City multi pqry-p96zlmu-a1City multi pqry-p120zlmu-a1City multi pqry-p144zslmu-a1City multi pqry-p168zslmu-a1 ... Show all

Table of Contents
