USER MANUAL
AFTER SALES SUPPORT:
WWW.SPTOOLS.COM
IMPORTANT
ALL PERSONS WHO ARE TO USE THIS EQUIPMENT MUST THOROUGHLY READ
AND UNDERSTAND THIS INSTRUCTION MANUAL PRIOR TO OPERATION.
SP61090
SMART CHARGER
8 STAGE 10AMP
MULTI VOLT
RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO
MANUAL FOR FUTURE
NOTE: Proof of purchase must be retained by
the customer as it will be required in the
event of a claim under warranty.
AUSTRALIA: Visit the website's contact page to get in
touch with your local service department.
INTERNATIONAL: Use the county selector to get in touch
with your service department in your country or region.
REFERENCE
Advertisement
Table of Contents
Related Manuals for SP tools SP61090
Summary of Contents for SP tools SP61090
- Page 1 USER MANUAL SP61090 SMART CHARGER 8 STAGE 10AMP MULTI VOLT RETAIN THESE INSTRUCTIONS AND ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE NOTE: Proof of purchase must be retained by the customer as it will be required in the event of a claim under warranty.
-
Page 2: Table Of Contents
CONTENTS Introduction Intended Use Operating Instructions Safety Precautions & Warnings Technical Features Technical Specification Warranty Details... -
Page 3: Introduction
Intended Use The SP61090 - 6,12, 24 Volt Battery Charger is ideal for the home handyman or small workshop, designed to efficiently charge 6, 12 or 24 Volt lead acid automotive, Motorcycle, marine and light industrial type batteries, Including Calcium-Calcium (Cal-Cal), Calcium- Silver (Cal-Ag), Lead Antimony, Absorbed Glass Matt (AGM) and Gel battery types. -
Page 4: Operating Instructions
Operation How to use: 1) Check the battery is suitable for this charger. 2) Select the correct battery voltage by rotating the Voltage selection switch. 3) Connect the charger Positive (Red) Lead to the Positive of the battery. 4) Connect the charger Negative (Black) Lead to the Negative of the battery. 5) Plug the charger into the power socket &... - Page 5 Charging Stages: Stage 1 – “Desulphation” In this initial start-up stage, a high frequency voltage pulse (0.5 sec) is to assist in “waking up” a deeply discharged battery. This method of pulse charging can also help to reduce build-up of sulphate crystals that may have formed on the battery plates during the time it was discharged.
-
Page 6: Safety Precautions & Warnings
Stage 8 – “Maintain” This final stage regulates the fully charged battery. A small pulse charge is applied at 0.5Hz to maintain the battery at its fully charged state and ready to be used at any time. If a load is applied to the battery and the battery voltage drops below 6.2 volts (6 Volt Setting), 12.4 volts (12 Volt Setting) or 24.4 volts (24 Volt Setting), the charger will restart from the absorption stage. -
Page 7: Technical Features
LED display simultaneously showing charging voltage, percentage of battery charge Battery Testing function while charging (faulty batteries cause the Full Battery Bar display to flash). Technical Specifications: Model No: SP61090 Output Current 10 Amp Output Voltage 6Volt / 12Volt / 24Volt... -
Page 8: Warranty Details
To the extent permitted by law and subject to this Limited Warranty, and as part of the terms of the sale of the equipment or part thereof: SP Tools shall not be liable for any form of loss, damage, cost, injury or harm of any kind (whether direct, indirect, special or consequential) howsoever arising from the use or supply of the equipment to the purchaser.
