GE 24LEDI-C4-11000.4 Quick Start Manual

LED 1100 C4 LIGHTS
LED-24a
FOR INDOOR USE ONLY
IMPORTANT SAFETY INSTRUCTIONS
When using electric products, basic precautions should always be followed including the following:
READANDFOLLOWALLSAFETYINSTRUCTIONS.
a)
b) Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When products
are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If
one is not provided, contact a qualified electrician for proper installation.
c) This seasonal use product is not intended for permanent installation or use.
d) Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat.
e) Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails.
f) Do not let lamps rest on the supply cord or on any wire.
g) Unplug the product when leaving the house, when retiring for the night, or if left unattended.
h) This is an electric product-not a toy! To avoid risk of fire, burns, personal injury and electric shock it
should not be played with or placed where small children can reach it.
i) Do not use this product for other than its intended use.
j) Do not hang ornaments or other objects from cord, wire, or light string.
k) Do not close doors or windows on the product or extension cords as this may damage the wire insulation.
l) Do not cover the product with cloth, paper or any material not part of the product when in use.
m)This product is equipped with push-in type lamps. Do not twist lamps.
n) This product employs overload protection (fuse). A blown fuse indicates an overload or short –circuit situation.
If the fuse blows, unplug the product from the outlet. Also unplug any additional strings or products that may
be attached to the product. Replace the fuse as per the user servicing instructions (follow product marking for
proper fuse rating) and check the product. If the replacement fuse blows, a short-circuit may be present and
the product should be discarded.
o) Read and follow all instructions that are on the product or provided with the product.
SAVE THESE INSTRUCTIONS
p)
USE AND CARE INSTRUCTIONS
a) When the product is placed on a live tree, the tree should be well maintained and fresh. Do not place
on live trees in which the needles are brown or break off easily. Keep the tree holder filled with water.
b) If the product is placed on a tree, the tree should be well secured and stable.
c) Before using or reusing, inspect product carefully. Discard any products that have cut, damaged, or frayed wire
insulation or cords, cracks in the lampholders or enclosures, loose connections, or exposed copper wire.
d) When storing the product, carefully remove the product from wherever it is placed, including tree, branches, or
bushes, to avoid any undue strain or stress on the product conductors, connections, and wires.
e) When not in use, store neatly in a cool, dry location protected from sunlight.
CAUTION:
1.This lighting string is rated 48 Watts (0.4 Amps),do not overload.
2. a) replace lamps only with 3.3 volt, 0.066 watt spare lamps provided with product. b) Risk of fire. This
product does not contain lamp shunts, which allow the product to operate if one lamp burns out. Do
not replace lamps with other than the spare lamps provided with this product.
MODEL NO.
USER SERVICING INSTRUCTIONS
24LED(I)-C4-1100(0.4)
Replace the fuse.
a) Grasp plug and remove from the receptacle or other outlet device. Do not unplug by pulling on cord.
b) Using a flathead screwdriver, open fuse cover.
Slide open the fuse access cover on top of attachment plug towards blades.
c) Remove fuses carefully.
d) Risk of fire. Replace fuse only with 3 Amp, 125 Volt fuse (provided with product).
e) Close fuse cover. Slide closed the fuse access cover on top of attachment plug.
f) Risk of fire. Do not replace attachment plug. Contains a safety device (fuse) that
should not be removed. Discard product if the attachment plug is damaged.
Replace the lamp.
1. Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord.
2. Pull lamp and plastic base straight out of lampholder.
3. Replace lamp with only 3.3 Volt, 0.066 Watt,
LED type lamp(provided with product).
If the new lamp base does not fit in lampholder,
follow the steps below step 3.
a) Remove the base of burned out lamp by straightening lamp leads and gently pull lamp out.
b) Thread leads of new lamp through holes in old base with one lead in each hole.
c) After lamp is fully inserted into base, bend each lead up, like other lamps in the
light set so that the leads will touch the contacts inside the lampholder.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Modifications not approved by the party responsible for compliance could void user's authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
For questions and /or assistance, call customer service at 1-877-398-7337
or visit us on the web at
©2015 Nicolas Holiday Inc., 9F., No. 37, Guangfu North Rd. Taipei, Taiwan 10560 All rights reserved.
www.geholidaylighting.com
FP-15 PRINTED IN CHINA
