- Page 1 Systembaugruppe D992 System board D992 Technisches Handbuch Technical Manual...
- Page 2 IT-Service Shops • unter Angabe der Bestellnummer dieses Ihren zuständigen Vertriebspartner • Handbuches. Ihre Verkaufsstelle Siemens AG Die Adressen der IT-Service-Shops Redaktion OEC BS2 OS ID4 finden Sie im Garantieheft. Otto-Hahn-Ring 6 Aktuelle Informationen zu unseren D-81730 München Produkten, Tips, Updates usw.
- Page 3 D-81730 München Your training needs? The Siemens Training Centers offer you a wide range of training courses in information technology and on IT products and other subjects - onsite near to your workplace or offsite at one of our training centers.
- Page 4 Este manual ha sido impreso sobre papel reciclado. Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Siemens AG D-81730 München Bestell-Nr./Order No.: A26361-D992-Z121-1-7419 A26361-D992-Z121-1-7419...
- Page 5 Deutsch English Systembaugruppe D992 System board D992 Technisches Handbuch Technical Manual Ausgabe Juli 1998 July 1998 edition...
- Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright ã Siemens AG 1998. Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
-
Page 7: Table Of Contents
Contents Introduction ........................1 Notational conventions ....................1 Important notes ........................2 Features..........................3 Ports and connectors: D992 dual ................4 Ports and connectors: D992 mono................5 Possible screen resolution...................6 Interrupt table ......................7 Settings on the system board....................8 Recovering System BIOS - switch 1................9 Write protection for System BIOS - switch 3 .............9... -
Page 9: Introduction
Introduction Introduction This description applies for the system board D992 with PCI bus (Peripheral Component Interconnect). System board D992 is available in two variants: as a monoprocessor system (D992- Mono) and as a dual-processor system (D992-Dual). This manual applies for both variants. -
Page 10: Important Notes
The equipment and tools you use must be free of static charges. • Pull out the power plug before inserting or pulling out boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. 2 - English A26361-D992-Z121-2-7419... -
Page 11: Features
Mono processor system (D992 mono) or Dual processor system (D992 dual: second processor optional) • Processor: Pentium II, 233 (only D992 mono), 266, 300 and 333 MHz with 66 MHz bus frequency, with integrated 16 Kbyte first-level cache and 512 Kbyte second- level cache •... -
Page 12: Ports And Connectors: D992 Dual
Features Ports and connectors: D992 dual 1 = Power supply 5V and ± 12V 11 = Temperature sensor for processor 2 = Voltage converter for processor 1 3 = Temperature sensor for processor 12 = SCSI indicator 13 = Ultra wide SCSI drives... -
Page 13: Ports And Connectors: D992 Mono
Features Ports and connectors: D992 mono " & " & 1 = Power supply 5V and ± 12V 10 = SCSI indicator 2 = Temperature sensor for processor 11 = Ultra wide SCSI drives 3 = Voltage converter for processor... -
Page 14: Possible Screen Resolution
65536 800x600 65536 1024x768 48,4 1024x768 1024x768 68,7 256 * 1024x768 87 interlaced 1024x768 256 * 1280x1024 87 interlaced no 16 color mode The horizontal rate values may have a tolerance range of ± 0.3 kHz. 6 - English A26361-D992-Z121-2-7419... -
Page 15: Interrupt Table
Note that an interrupt cannot be used by two ISA boards or onboard controllers at the same time. The screen controller of the system board does not require interrupt IRQ9. If you are using a different screen controller, it may need interrupt IRQ9. English - 7 A26361-D992-Z121-2-7419... -
Page 16: Settings On The System Board
Switch 2 = must be set to drive Switch 3 = Write-protection for system Switch 5, 6, 7, 8 = clock speed BIOS The switch settings apply both to the dual-processor system and to the monoprocessor system. 8 - English A26361-D992-Z121-2-7419... -
Page 17: Recovering System Bios - Switch 1
Clock speed - switch 5, 6, 7 and 8 The switch may only be set as specified in the table below for the particular processors used. processor switch 5 switch 6 switch 7 switch 8 233 MHz 266 MHz 300 MHz 333 MHz English - 9 A26361-D992-Z121-2-7419... -
Page 18: Extensions: D992 Dual
Extensions: D992 dual Extensions: D992 dual 1 2 3 4 1 = Main memory bank 3 8 = Voltage converter for processor 2 2 = Main memory bank 2 9 = Lithium battery 3 = Main memory bank 1 10 = Flash BIOS... -
Page 19: Extensions: D992 Mono
Extensions: D992 mono Extensions: D992 mono " & 1 = Main memory bank 3 8 = Lithium battery 2 = Main memory bank 2 9 = Flash BIOS 3 = Main memory bank 1 10 = ISA slots - from below: 1 and 2... -
Page 20: Upgrading Main Memory
Pull the memory module out of its location. Ê Replacing the Pentium II System board D992 dual The system board can be upgraded with a second Pentium II processor in slot 2. You can replace the Pentium II processor in slot 1. - Page 21 Extensions: D992 mono Removing the Pentium II If the Pentium II has a temperature sensor, pull out the associated cable. Ê Press the clamps (2) on either side of the Pentium II inwards and pull the Pentium II Ê up and out.
-
Page 22: Upgrading The Video Memory
Extensions: D992 mono Upgrading the video memory If your system board is supplied with a video memory configuration of 1 Mbyte, you may enlarge the video memory up to 2 Mbytes. Information on which DRAM components you can use is available from your sales office or the customer service. -
Page 23: Replacing The Lithium Battery
Extensions: D992 mono Replacing the lithium battery Incorrect replacement of the lithium battery may lead to a risk of explosion. The lithium battery must be replaced with an identical battery or a battery type recommended by the manufacturer (CR2032). Do not throw lithium batteries into the trashcan. It must be disposed of in accordance with local regulations concerning special waste. -
Page 24: Settings In Scsi Setup
How you install internal devices in the system unit and connect them to the power supply is described in the Operating Manual or Technical Manual for your Server in the chapter "System unit" (paragraph "Installing a disk drive"). Further information is provided in the descriptions of your SCSI devices. 16 - English A26361-D992-Z121-2-7419... -
Page 25: Scsi Setup
Start your PC and press key combination , when the following message Ê [Ctrl] [Ctrl] [Ctrl] [Ctrl] appears: Press <Ctrl> <A> for SCSI Select (TM) Utility! The first menu of the onfigure/View Host Adapter Settings SCSI Disk Utilities SCSI setup is displayed. English - 17 A26361-D992-Z121-2-7419... -
Page 26: Terminating The Scsi Setup
( Ê onfigure/View Host Adapter [ESC] [ESC] [ESC] [ESC] Settings Press the key in the first menu and then follow the instructions on the screen to Ê [ESC] [ESC] [ESC] [ESC] terminate the SCSI Setup 18 - English A26361-D992-Z121-2-7419... -
Page 27: Default Settings In The Scsi Setup
Enabled BIOS Support for Int 13 Extensions** Enabled Support for Ultra SCSI Speed Disabled The setting is valid only if Multiple LUN Support enabled ** The setting is valid only if SCSI controller BIOS is Enabled English - 19 A26361-D992-Z121-2-7419... -
Page 28: Scsi Bus Interface Definitions
(ID). The SCSI ID selected here must correspond to the ID configured on the boot device. 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 The ultra-wide SCSI controller boots from the drive with the displayed SCSI ID (default entry: 20 - English A26361-D992-Z121-2-7419... -
Page 29: Scsi Device Configuration
SCSI bus at speeds ranging up to 40 Mbyte/s at synchronous data transfer. If you have entered in the Enabled Support for Ultra SCSI Speed menu item, the transfer rate of 40 Mbyte/s is entered automatically. English - 21 A26361-D992-Z121-2-7419... -
Page 30: Advanced Configuration Options
Advanced Configuration Options RESET SCSI Bus at IC The SCSI bus is reset if you activate this menu item. The SCSI bus will be reset (default entry). Enabled The SCSI bus will not be reset. Disabled 22 - English A26361-D992-Z121-2-7419... - Page 31 Drives up to 1 Gbyte can be used under MS-DOS 5.0. Disabled Back up the data on your large capacity drive before enabling the option. After enabling this option, the drive must be re-partitioned and high-level formatted with the DOS programs. FDISK FORMAT English - 23 A26361-D992-Z121-2-7419...
- Page 32 This option determines whether the SCSI controller BIOS supports the fast transfer rate 40 Mbyte/s at 16-bit data transfer. 40 Mbyte/s transfer rate is supported. Enabled The function is disabled (default entry). Disabled Change the default setting if you have connected ultra-wide SCSI devices to the SCSI controller. 24 - English A26361-D992-Z121-2-7419...
-
Page 33: Scsi Disk Utilities
Are the SCSI devices and the onboard SCSI controller correctly terminated? • Is the SCSI controller activated in the system BIOS ( BIOS Setup • Is parity checking either enabled or disabled on all SCSI devices on the SCSI bus? English - 25 A26361-D992-Z121-2-7419... -
Page 34: Scsi Bios Messages
A timeout has occurred. Check the SCSI bus termination. Remove the SCSI cable from the ultra-wide SCSI controller and restart the system. If system startup is successful, check the SCSI cable. One of the SCSI devices may be defective. Check the SCSI devices. 26 - English A26361-D992-Z121-2-7419...
