- Page 1 27" LED Monitor Dell SE2722HR Service Service Service Simplified...
-
Page 2: Important Safety Notice
Accordingly, a servicer who uses a service procedure or tool which is not recommended by DELL must first satisfy himself thoroughly that neither his safety nor the safe operation of the equipment will be jeopardized by the service method selected. - Page 3 1. Exploded view diagram with list of items...
-
Page 4: Tools Required
2. Wiring connectivity diagram 3. Tools Required... -
Page 5: Disassembly Procedures
List the type and size of the tools that would typically can be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description: ‐ Screwdriver (Phillip-head, Hexagonal head) ‐ Penknife 3.1Disassembly Procedures Tools: 2 Power screwdrivers (φ=5mm, L=60mm);... - Page 6 Take scraper insert the bezel bottom site Disconnect the cables Tear out all the tapes. Unscrew the 2 Remove the screws on the mainboard mainframe. and power Torque=6±1kgf.cm board Tear out the wires and mylar. remove the screws Mainboard on the board by the Philips-head.
-
Page 7: Assembly Procedures
Unscrew the screws Remove the by the hexagon mainboard screwdriver. and power board panel 3.2 Assembly Procedures: screw the screws on Assemble the mainboard and the boards powerboard Assemble the maylar... - Page 8 stick all the aluminum foil and connect the cable Assemble and screw the two screws on the two mainframe sites of mainframe Assemble screw the six screws the rear by the Philips-head cover Screwdriver...
-
Page 9: Troubleshooting Instructions
Push the stand in Assemble and tighten the the stand screw on the stand ass’y ass’y 4. Trouble shooting instructions...
