Light Unit Functions
This Control Unit can be connected to Light Units and Spotlights with 24V DC inputs. Connect 24V DC Light Units to the 24V LIGHT connectors and
Spotlights to HLV LIGHT connectors. The functions vary with the Light Units that are connected. Check the following table before using the Light Units.
24V DC Light Units
Item
Applicable illuminators
Lighting method
Lighting
Continuous mode
mode
ON/OFF mode
Strobe mode
Control
Manual control
mode
External control
Rated capacity
Lighting delay time
Channel selection
Light Unit connection detection
Power startup time
Light Units with 24V DC input voltage
PWM control or lighting time control
46W max.
Depends on the power consumption of the Light Units.
Depends on which Light Units are connected/disconnected.
Detected when connected for the first time.
0.5 s
Spotlights: HLV2 series, HLV series*
*not including HLV-27 series/HLV-14-R/
HLV-14-GR/HLV-14-BL/HLV-14-SW
Variable current control
Per connector: 3.9 W max. (700mA max.)
Depends on the light intensity of the Light Unit.
Only connected Light Units can be selected.
Detected at any time.
4 4
Output Connectors (HLV LIGHT)
SMP-03V-BC×4
* Rated capacity per connector: 3.9 W max.
(700mA max.)
Output Connectors (24V LIGHT)
SMP-03V-BC×4
Total for all connectors×8
* Total rated capacity: 46 W max.
Spotlights
Reference
---
3 s
page
10
10
5, 6
5, 6
5, 6
5
6, 7
10
8
5
5
10
