4-7-3 Firmware Update

Firmware can be updated through USB storage.
F/W Update
Ver. 1.00
Explanation
Printer firmware update available using the USB storage directly
without any communication.
File path
F:\ FW_DOWNLOAD
File name
"XT5-4xNR_Vxx.xx_STD_mmddyy.fls" in F:\ FW_ DOWNLOAD folder.
( 203dpi : x is 0 / 300dpi : x is 3 / 600dpi : x is 6)
• Download process explanation
- Check firmware file(*.fls) is in FW_ DOWNLOAD folder
of USB storage.
(If there is no folder, please create FW_download folder and
save the firmware file (* .fls) to it.)
- Connect USB storage to the printer.
- Select "F/W Update" from the "Files" menu.
- Select the firmware download menu.
- If the message "F/W Downloading" is displayed, the firmware
download has started normally.
- When the firmware download is completed successfully,
the message "Printer Restart" is displayed and the rebooting
process is automatically performed.
