GUIDEBOOK
CAMCORDER
GZ-MG610
EK
Dear Customers
Thank you for purchasing this camcorder.
Before use, please read the safety
information and precautions contained
in pages 6 and 7 to ensure safe use of
this product.
EN
ENGLISH

Advertisement

Table of Contents
loading

Related Manuals for JVC GZ-MG610

Summary of Contents for JVC GZ-MG610

  • Page 1 GUIDEBOOK CAMCORDER GZ-MG610 Dear Customers Thank you for purchasing this camcorder. Before use, please read the safety information and precautions contained in pages 6 and 7 to ensure safe use of this product. ENGLISH...
  • Page 2 To AC Outlet (110V to 240V) CAUTION • Be sure to use JVC battery packs. If you use any other battery packs besides JVC battery packs, safety and performance can not be guaranteed. Grip Adjustment Adjust the strap and fasten.
  • Page 3 Date/Time Setting Select the city closest to the area where you use Open the LCD monitor to the camcorder turn on the camcorder Power button LCD monitor Select [ON] if daylight Select [YES] within saving time is effective 10 seconds Slide your finger up and down on the sensor.
  • Page 4 Video recording CAUTION Before recording an important scene, it is recommended to conduct a trial recording. Slide the mode switch to select (video) mode Select recording mode The mode changes when you press the button. The auto recording indicator appears. Start recording Remaining space on the hard disk...
  • Page 5 Playing back Select playback mode The mode changes when you press the button. Select the desired file Index screen Select (Touch OK) Playback screen To perform operations such as forward search or reverse search (Z p. 24)  To view files on TV (Z p. 31) ...
  • Page 6 Safety Precautions IMPORTANT (for owners in the U.K.) Caution on Replaceable lithium battery Connection to the mains supply in the United The battery used in this device may present a fire Kingdom. or chemical burn hazard if mistreated. DO NOT cut off the mains plug from this Do not recharge, disassemble, heat above 100°C equipment.
  • Page 7 If you wish to dispose of this product, please visit Any commercial use without proper permission our web page www.jvc-europe.com to obtain is prohibited. (Even if you record an event such information about the take-back of the product.

  • Page 8: Table Of Contents

    Contents GETTING STARTED EDITING Accessories ..........10 Managing Files ........32 Attaching the Core Filter to the USB Cable ... 11 Capturing a Still Image from a Video .... 32 Deleting Files ..........32 Index ............12 Protecting Files ..........34 Indications on LCD Monitor ....14 Viewing File Information .......
  • Page 9 After the menu is displayed on the LCD recorded data to a DVD or other recording monitor: media for storage. JVC will not be responsible for any lost data. Make a trial recording Before the actual recording of important data,...

  • Page 10: Getting Started

    GETTING STARTED Accessories BN-VF808U AP-V20M AC Adapter Power Cord Battery Pack AV Cable USB Cable CD-ROM Core Filter NOTE Make sure to use the provided cables for connections. Do not use any other cables.

  • Page 11: Attaching The Core Filter To The Usb Cable

    Attaching the Core Filter to the USB Cable The core filter reduces interference caused when connecting to other devices. Connect the end of the cable with the core filter to the camcorder. Release the stopper. 3 cm Wind once. To be connected to the camcorder...

  • Page 12: Index

    Index NOTE • Be careful not to cover 0, 1, and 2 during shooting. • The LCD monitor can rotate 270°.
  • Page 13 Camcorder ! Power Button # DISPLAY Button (Z p. 15) $ Speaker % Zoom Lever (Z p. 22) Speaker Volume Control & SNAPSHOT Button (Z p. 21) ( Touch Sensor ) OK Button * MENU Button + Mode Switch [ , UPLOAD Button (Z p.

  • Page 14: Indications On Lcd Monitor

    Indications on LCD Monitor During both Video and Still Image During Video Recording Only Recording 1 . 1 1 . 2 0 0 9 1 6 : 5 5 ! Mode Indicator # EXPORT Mode Indicator (Z p. 52) ! Selected Recording Mode Indicator $ Counter (Z p.
  • Page 15 During Video Playback During Still Image Playback 1 . 1 1 . 2 0 0 9 1 6 : 5 5 1 . 1 1 . 2 0 0 9 1 6 : 5 5 ! Mode Indicator ! Mode Indicator # Playlist Playback Indicator (Appears when # Quick Review Indicator (Z p.

  • Page 16: Necessary Settings Before Use

    Necessary Settings before Use To detach the battery pack  Charging the Battery Pack Close the LCD monitor to turn off the camcorder. Attach the battery pack, then connect the AC adapter. NOTE • You can also use the camcorder with just the AC adapter.

  • Page 17: Language Setting

    Select [CLOCK SETTING]. Select the city closest to the area you are traveling. Select the city closest to the area where you use the camcorder. To return to the previous screen  Select @. Selected area is highlighted To quit the screen ...

  • Page 18: Other Settings

    Other Settings Grip Adjustment Tripod Mounting Align the camcorder stud hole with the tripod stud, and the mounting socket with the screw, and then rotate the camcorder clockwise to mount it to the tripod. NOTE Do not use a tripod on unsteady or unlevel surfaces.

  • Page 19: Using A Microsd Card

    To remove a microSD card  Using a microSD Card Push the microSD card once. After the card comes out a little, pull it out. The camcorder is programmed to record on the built-in hard disk when it is shipped from NOTE •...

  • Page 20: Recording/Playback

    RECORDING/PLAYBACK Recording Files Video Recording Slide the mode switch to select Press PLAY/REC to select the (video) mode. recording mode. SNAPSHOT Press START/STOP to start recording. Approximate remaining time for recording You can also start/stop recording by selecting [REC] on the LCD monitor. (On-screen recording control) To stop recording To change the video quality...

  • Page 21: Still Image Recording

    Still Image Recording Slide the mode switch to select Press PLAY/REC to select the (still image) mode. recording mode. Press and hold SNAPSHOT halfway. indicator becomes green when the captured image is focused. Press SNAPSHOT fully to take a still image. To view the last recorded image ...

  • Page 22: Zooming

    Recording Files (Continued) Checking the Remaining Battery Zooming Power Preparation: • Select mode. mode: • Select the recording mode. Press INFO twice or INFO and then select Zoom out Zoom in mode: Press INFO. W: Wide angle T: Telephoto You can also zoom out/zoom in by selecting [W] or [T] on the LCD monitor.

  • Page 23: Checking The Remaining Space On The Recording Media

    Checking the Remaining Space on Registering Files to Events the Recording Media If you select an event to register the file to before starting recording, you can find the file Preparation: • easily at playback. Select mode. • Select the recording mode. Preparation: •...

  • Page 24: Playing Back Files

    Playing Back Files Video Playback Press PLAY/REC to select the Slide the mode switch to select playback mode. (video) mode. The index screen appears. Select the desired file. To move to the previous or next page To delete a video ...

  • Page 25: Still Image Playback

    Still Image Playback Slide the mode switch to select Press PLAY/REC to select the playback mode. (still image) mode. The index screen appears. Select the desired file. To move to the previous or next page  Touch [ ] or [ ] for over a second. To delete a still image ...

  • Page 26: File Search Function

    Playing Back Files (Continued) Date Index Screen File Search Function You can search the desired file by the Preparation: recording date. • Select mode. • Select the playback mode. Select Group Index Screen mode, go to step 3. In case of You can search the desired file by the group.

  • Page 27: Playing Back Mpg Files

    Event Screen Playing Back MPG Files You can search the desired file by the event MPG files (demonstration files, etc.) are stored that you registered the file to when recording. in the EXTMOV folder. (Z p. 23) After searching by the event, you can Follow the procedure below to play back the search by the recording date to narrow down MPG files in the EXTMOV folder.

  • Page 28: Manual Recording

    Manual Recording Manual recording mode enables you to set the Manual Setting in Menu focus and screen brightness, etc. manually. In the manual recording mode: Changing to Manual Recording Mode Touch MENU. Preparation: Select [MANUAL SETTING]. • Select mode. • Select the recording mode.
  • Page 29 Menus Settings: [ ] = Factory-preset 1 [OFF]: Deactivates the function. NIGHT: Records with more sensitivity in dim locations by adjusting the shutter speed automatically. TWILIGHT: Makes evening scenes look more natural. SCENE SELECT 6 PORTRAIT: The subject in the foreground is accentuated Adjusts the exposure and by blurring the background.
  • Page 30 Manual Recording (Continued) Menus Settings: [ ] = Factory-preset @ [AUTO]: White balance is adjusted automatically. MANUAL: MWB: Adjusts the white balance manually depending on the light source. 1) Hold a sheet of plain white paper in front of the camcorder so that the white paper fills Adjusts the white balance to the screen.

  • Page 31: Using With Tv

    USING WITH TV Viewing Files on TV This camcorder is designed to be used with Playback Operation high-definition or PAL-type color television signals. It cannot be used with a television of a After the connection with TV is completed different standard. Turn on the camcorder and the TV.

  • Page 32: Editing

    EDITING Managing Files CAUTION Deleting Files Do not remove the recording medium or perform any other operation (such as turning • Protected files cannot be deleted. To delete off the power) while accessing files. Also, them, release the protection first. •...
  • Page 33 Deleting Selected Files Deleting All Files After performing steps 1-2 (Z p. 32) After performing steps 1-2 (Z p. 32) Select [FILE SELECT]. Select [DELETE ALL]. Select the desired file and select Select [YES]. • mark appears on the file. To select other files, repeat this step.

  • Page 34: Protecting Files

    Managing Files (Continued) Protecting Selected Files Protecting Files After performing steps 1-3 Preparation: • Select mode. Select [FILE SELECT]. • Select the playback mode. Touch MENU. Select [EDIT]. Select the desired file and select Select [PROTECT/CANCEL]. • (protection) mark appears on the file.

  • Page 35: Viewing File Information

    Protecting All Files Viewing File Information After performing steps 1-3 (Z p. 34) Preparation: mode: Select [PROTECT ALL]. Pause the playback. Otherwise, select the file on the index screen. mode: Play back the still image. Otherwise, select the file on the index screen. Press INFO.

  • Page 36: Changing The Event Registration

    Managing Files (Continued) Select a new event. Changing the Event Registration To cancel the event registration, select Preparation: [CANCEL]. • Select mode. • Select the playback mode. Touch MENU. Select [EDIT]. Changing the Event of the Selected Files After performing steps 1-3 Select [SET RANGE AND CHANGE].

  • Page 37: Trimming Files

    Select [SET] at the end point. Trimming Files It is recommended to select [SET] after the pause button is pressed. You can select the necessary part of the video and save it as a new video file. Preparation: • Select mode.

  • Page 38: Playlists

    Playlists It is a list that enables you to organize Select the file to add to playlist. recorded videos in order of preference. Preparation: • Select mode. • Select the playback mode. To preview scenes, select the file and Creating Playlists select [CHECK].

  • Page 39: Playing Back Playlists

    Creating Playlists Including Picture Playing Back Playlists Titles You can easily create a playlist including a Touch MENU. picture title. Select [PLAYBACK PLAYLIST]. Press TITLE. Select the playlist. Select the desired picture title. You can check the picture title in full-screen To stop playback ...

  • Page 40: Other Operations Of Playlists

    Playlists (Continued) Other Operations of Playlists You can perform additional editing and delete files in a created playlist. Adding/Deleting Files in Playlist After performing steps 1-2 (Z p. 38) Select [EDIT]. Select the playlist you want to edit. To add or delete files, follow the steps 5 to 8.

  • Page 41: Copying

    You can dub video recorded on this camcorder onto VCR/DVD recorder. NOTE It is recommended to use the JVC DVD burner (CU-VD50/CU-VD3). When using CU-VD20 or Select [COPY] or [MOVE]. CU-VD40, the recording time may take approx. 2 times longer than the time that is described in the instruction manual of DVD burner.

  • Page 42: Using A Dvd Burner

    Copying Files (Continued) Select the direction. Using a DVD Burner & & ([HDD SD] or [SD HDD]) Supported discs: 12cm DVD-R, DVD-RW • Regarding DVD-R discs, only unused DVD-R discs can be used. Regarding DVD-RW discs, used DVD-RW discs can also be used, but they need to be formatted before recording.
  • Page 43 Select [EXECUTE]. Backup All Files • The files are copied on the disc. When Preparation: [COMPLETED] appears, touch OK. • Connect the camcorder to the DVD burner. • When [INSERT NEXT DISC PRESS • Select mode. [STOP] TO EXIT CREATE] appears, change the disc.
  • Page 44 Copying Files (Continued) Select the desired disc number. Selecting Files for Backup Preparation: • Connect the camcorder to the DVD burner. • Select mode. Select [SELECT AND CREATE]. • If you select [ALL], all discs in the list are created. •...
  • Page 45 To play back the created disc using the  Digest Playback camcorder 1) Connect the camcorder to the DVD You can view a few seconds from the burner. beginning of each video (digest) in the created 2) Turn on the camcorder first, then turn on DVD.

  • Page 46: Creating A Dvd Using A Pc

    Copying Files (Continued) Preparation: Creating a DVD using a PC Load the provided CD-ROM into the PC. In Windows Vista, the auto play dialog box You can copy the data from the camcorder and appears. create a DVD using a PC. Click [Easy Installation].
  • Page 47 Making Backup on the PC Click [All volume in camcorder] and click [Next]. Preparation: • Install the software to the PC. • Make sure that enough free space is left in the PC’s HDD. • Close the LCD monitor to turn off the camcorder.
  • Page 48 Copying Files (Continued) Making User Lists to Arrange the Double-click the recording date. Files You can make a user list of a certain subject (such as Travel, Athletic meet) and put the files related to the subject into the user list. Preparation: Make backup on the PC.
  • Page 49 Copying Files to a DVD Input the disc name, select the top menu style and click [Next]. Preparation: Use a recordable DVD disc. (It is recommended to use a DVD-R disc.) Select the user list and click [Create Disc]. Click [Start]. Click [Select files individually] and click [Next].
  • Page 50 Use of this software is authorized according to the terms of the software license. When contacting the nearest JVC office or agency in your country (refer to the JVC Worldwide Service Network at http://www.jvc-victor.co.jp/english/worldmap/index-e.html) about this software, please have the following information ready.

  • Page 51: Dubbing Files To A Vcr/Dvd Recorder

    Open the LCD monitor to turn on the Dubbing Files to a VCR/DVD Recorder camcorder. Preparation: • Set the VCR/DVD recorder to its AUX Create a playlist. • input mode. Turn off all units. Check that the images from the camcorder To connect using the AV connectors ...

  • Page 52: Using With A Portable Media Player

    Using with a Portable Media Player Turning on the Export Mode Changing the Export Setting You can easily transfer videos recorded in You can set the recorded videos to the export export mode to iTunes . All the files with the setting.

  • Page 53: Transferring The Files To Pc

    Transferring the Files to PC Preparation: Install iTunes on a PC. ® http://www.apple.com/itunes/ Connect the camcorder to the PC with the USB cable. Select [EXPORT TO LIBRARY]. All the files with the export setting turned on are transferred to PC. If you cannot export the file to iTunes ®...

  • Page 54: Uploading Files To Websites

    Uploading Files to Websites Turning on the Upload Mode Upload Trimming You can upload the file to video sharing You can select the necessary part of the websites (YouTube ) quickly after recording. video and save it as a new video file ready for uploading.

  • Page 55: Uploading Files

    Select [CAPTURE TRIMMED FILE]. Uploading Files For details on uploading files, refer to the operation guide of MediaBrowser in the CD- ROM. Connect the camcorder to the PC To set the start/end point again, select with the USB cable. [REDEFINE AREA]. Select [UPLOAD].

  • Page 56: Further Information

    FURTHER INFORMATION Changing the Menu Settings Touch MENU. To return to the previous screen  Select @. Select the desired menu. To quit the screen  Select [QUIT]. Select the desired setting. Mode Menus Settings: [ ] = Factory-preset See page 28. (In the manual recording mode only) MANUAL SETTING LIGHT See page 22.
  • Page 57 Mode Menus Settings: [ ] = Factory-preset VIDEO QUALITY [ULTRA FINE] / FINE / NORMAL / ECONOMY Sets the video quality. IMAGE QUALITY [FINE] / STANDARD Sets the image quality. 35X/OPTICAL / [70X/DIGITAL] / 800X/DIGITAL NOTE ZOOM Optical zoom is used up to [35X/OPTICAL]. Digital zoom Sets the maximum zoom ratio.
  • Page 58 Changing the Menu Settings (Continued) Menus Settings: [ ] = Factory-preset Select [DISPLAY SETTINGS], then select sub-menus. DISPLAY SETTINGS [ENGLISH] LANGUAGE See page 17. Sets the display language. CLOCK ADJUST See page 16. Sets the time. DATE STYLE: DATE DISPLAY STYLE month.day.year / year.month.day / [day.month.year] Sets the date and time display TIME:...
  • Page 59 Updates and improves the system NOTE software. Information about obtaining system update will be made available on the JVC’s web site. FACTORY PRESET YES: Performs this function. Returns all the camcorder settings to [NO]: Returns to the menu screen without executing reset.
  • Page 60 Changing the Menu Settings (Continued) Menus Settings: [ ] = Factory-preset Select [CONNECTION SETTINGS], then select sub-menus. CONNECTION SETTINGS DISPLAY ON TV [OFF]: Does not display on TV. Displays camcorder’s on-screen ON: Displays on TV. display on a TV screen. VIDEO OUTPUT Sets the aspect (16:9/4:3) to the 4:3 / [16:9]...
  • Page 61 Menus Settings: [ ] = Factory-preset Select [MEDIA SETTINGS], then select sub-menus. MEDIA SETTINGS REC MEDIA FOR IMAGE [HDD] / SD Sets the recording medium for still images. REC MEDIA FOR VIDEO [HDD] / SD Sets the recording medium for video. [FILE]: Initializes all files in the HDD.

  • Page 62: Troubleshooting

    If the solutions indicated in the malfunctions. chart do not solve the problem, consult your • The camcorder heats up when it is used for a nearest JVC dealer or JVC service center for long time. instructions. • The battery heats up during charging.
  • Page 63 Trouble Action • Recording cannot be Slide the mode switch to select the desired mode ( performed. • If the camcorder temperature increases, REC flashes in the LCD monitor and recording stops automatically to protect the HDD. Turn off the camcorder, wait for a while, and start recording again. •...
  • Page 64 Troubleshooting (Continued) Trouble Action • Sound or video are Sometimes playback is interrupted at the connecting section interrupted. between two scenes. This is not a malfunction. • Select [PLAYBACK MPG FILE] then search the video on the index screen. (Video files that have damaged management information can be Cannot find a recorded played back.) video.
  • Page 65 If a malfunction occurs in the HDD  !   P erform [FORMAT HDD]. (All data is deleted.) #  If this does not solve the problem, contact the JVC customer service for repairs. To reset the camcorder when it does not operate normally ...

  • Page 66: Warning Indications

    Set the clock. If the message still appears after setting the SET DATE/TIME! clock, the battery for the clock has been depleted. Consult your nearest JVC dealer. • Be sure to use JVC battery packs. COMMUNICATING ERROR • CANNOT USE IN Set [REC MEDIA FOR VIDEO] to [HDD].
  • Page 67 Indication Action • VIDEO MANAGEMENT FILE IS Select [OK] to restore. DAMAGED, RECOVERY IS REQUIRED TO RECORD/PLAYBACK, RECOVER? • Use files recorded with the camcorder. (Files recorded with other UNSUPPORTED FILE! device may not be played back.) • Switch off the [PROTECT/CANCEL] function in the MENU. THIS FILE IS PROTECTED •...
  • Page 68 Warning Indications (Continued) Indication Action • DVD-R DISC HAS BEEN ALREADY Replace the disc of the DVD burner with another disc. USED • FINALIZATION FAILED Replace the disc of the DVD burner with another disc. • NO FILES Slide the mode switch to select the desired mode (...

  • Page 69: Cleaning

    Cleaning Before cleaning, turn off the camcorder and remove the battery pack and AC adapter. To clean the camcorder  Wipe the camcorder gently with a soft cloth. If the camcorder is particularly dirty, dip the cloth into diluted mild soap and wring it out well. After wiping with the wet cloth, wipe again with a dry cloth.

  • Page 70: Specifications

    Specifications General AC Adapter   Power supply Power requirement DC 11 V (Using AC adapter) AC 110 V to 240 V , 50 Hz/60 Hz DC 7.2 V (Using battery pack) Output § Power consumption DC 11 V , 1 A Approx.
  • Page 71 h: hour/m: minute Approximate recordable time (for video) Recording medium microSD Card Quality 30 GB 4 GB 8 GB ULTRA FINE 7 h 10 m 57 m 1 h 54 m FINE 10 h 40 m 1 h 25 m 2 h 50 m NORMAL 14 h 10 m...

  • Page 72: Cautions

    Cautions Battery Pack Recording Medium • Be sure to follow the guidelines below The supplied battery pack is Terminals to prevent corruption or damage to your a lithium-ion battery. Before recorded data. using the supplied battery • Do not bend or drop the recording medium, or pack or an optional battery subject it to strong pressure, jolts or vibrations.
  • Page 73 Avoid using the unit of Japan, Limited is: ... in places subject to excessive humidity or dust. JVC Technical Services Europe GmbH ... in places subject to soot or steam such as near Postfach 10 05 04 a cooking stove.
  • Page 74 JVC Software License Agreement 4 LIMITED WARRANTY JVC SOFTWARE LICENSE AGREEMENT JVC warrants that any media in which the IMPORTANT Program is embodied are free from any TO CUSTOMERS: PLEASE MAKE SURE defects in materials and workmanship TO READ THIS CAREFULLY BEFORE...
  • Page 75 CAUTION: Agreement without giving any notice to You. • Operate this equipment according to the In this event, JVC may claim against You for operating procedures described in this any damages caused by Your breach. Should manual. this Agreement be terminated, You must •...

  • Page 76: Terms

    Terms AC Adapter ............16 Manual Recording ..........28 Adjust Brightness ..........29 Menu Settings ...........56 Auto Power Off ..........58 microSD Card ............19 AV Connection ..........31, 51 Monitor Backlight ..........58 Monitor Bright ............58 Backlight Compensation ........28 Moving Files ............41 Battery Pack ..........16, 72 Number of Images ..........71 CD-ROM ............10, 46 Clock Adjust ............16...
