Samsung WMG100 Manual

English / Français / Deutsch / Nederlands
Wireless Multimedia Gateway
WMG100
MOBILE ENHANCEMENT
This product uses a non-harmonised frequency and is intended for
use in the following countries: France
Printed in Korea
World Wide Web Code No.:GH68-XXXXXA
www.samsungmobile.com EU A. 07/2008 Rev. 1.0
Connect the gateway to your DMC (Digital
Media Controller)
Connect the gateway to your device using the Wi-Fi technology.
1.
Turn on the Wi-Fi feature of your device.
2.
When your device finds the WMG100 Ad hoc network,
connect to it.
For further details, see the device user manual.
Connect to a DMS (Digital Media server)
and play multimedia file
1.
Open the media controller program on your device.
2.
Select a DMS and multimedia file you want to view on the
connected TV screen. you can play multimedia file.
If you choose the WMG100 as media renderer in DMC, you
can initialize paring. After you initialize paring, press the multi-
function button to complete paring.
For further details, see the device user manual.
English
Safety and usage information
Comply with the following precautions to avoid dangerous or illegal situations
and ensure peak performance of your product.
Keep your product and all accessories out of the reach of small children or
•
animals. Small parts may cause choking or serious injury if swallowed.
Use only Samsung-approved accessories. Using incompatible accessories
•
may damage your product or cause injury.
Avoid exposing your product to very cold or very hot temperatures
•
(below -10° C/14° F or above 40° C/104° F).
Do not allow your product to get wet—liquids can cause serious damage.
•
Do not handle your product with wet hands. Water damage to your product
can void your manufacturer's warranty.
Allowing unqualified personnel to service your product may result in
•
damage to your product and will void your warranty.
Avoid using or storing your product in dusty, dirty areas to prevent damage
•
to moving parts.
Your product is a complex electronic product —protect it from impacts and
•
rough handling to avoid serious damage.
Due to the DRM (Digital Rights Management) system, some
files may not play.
Warranty and parts replacement
Samsung warrants this product as free of defects in material, design and
workmanship for the period of one year from the original date of purchase.
(Depending on your country, the length of warranty may vary.)
If during the period of warranty this product proves defective under normal
use and service you should return the product to the retailer from whom it
was originally purchased or qualified service center. The liability of Samsung
and its appointed maintenance company is limited to the cost of repair and/or
replacement of the unit under warranty.
The warranty is limited to the original purchaser
•
A copy of your receipt or other proof of purchase is required for a proper
•
warranty service
The warranty is void if the serial number, date code label or product label is
•
removed, or if the product has been subject to physical abuse, improper
installation modification, or repair by unauthorised third parties
Specifically exempt from any warranty are limited-life consumable
•
components such as batteries and other accessories
Use this user manual to connect your Wireless Multimedia
Gateway to your TV and device. After connections, you can
play multimedia files on a DMS (Digital Media Server) and view
them on your TV screen.
Unpack
Gateway Travel adapter HDMI cable
• • •
Layout
Indicator light
Multi-fuction
button
Digital TV jack
Analogue TV jack
Adapter jack
Samsung will not assume any responsibility for any loss or damage incurred
•
in shipping. All repair work on Samsung products by unauthorised third
parties voids any warranty
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that it
should not be disposed with other household wastes at the end of
its working life.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types
of wastes and recycle it responsibly to promote the sustainable
reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for details
of where and how they can take this item for environmentally safe
recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product should not be
mixed with other commercial wastes for disposal.
Turn the gateway on
1.
Plug the small end of the travel adapter into the gateway
and plug the large end of the travel adapter into a power
outlet.
2.
Press and hold until the indicator light becomes solid
blue to turn the dongle on.
To turn the gateway off, press and hold again.
Connect the gateway to your TV
Connect the gateway to your TV with one of the supplied
cables. For a digital TV, use an HDMI cable. With the HDMI
cable, you can connect the gateway to a monitor or projector.
For a analogue TV, use a TV-out cable.
Digital TV
Analogue TV
Declaration of Conformity (R&TTE)
Samsung Electronics
We,
declare under our sole responsibility that the product
WMG100
to which this declaration relates, is in conformity with the following standards and/or other normative
documents.
SAFETY EN
EMC EN
EN
RADIO EN
We hereby declare that [all essential radio test suites have been carried out and that] the above
named product is in conformity to all the essential requirements of Directive 1999/5/EC.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire, GU46 6GG, UK*
Yong-Sang Park / S. Manager
2008.
(place and date of issue) (name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone number of Samsung Service Centre,
see the warranty card or contact the retailer where you purchased your phone.
