SUPA PEG
A U S T R A L I A
SUPA-WING AWNING (STANDARD)
Awning Setup/ Fold Away Instructions
Thank you for your purchase of the Australian made and designed SUPA-WING AWNING
Please follow these few simple step by step instructions to make setting up your
SUPA-WING AWNING (STANDARD) simple to use and to improve the life span of the
**PLEASE NOTE** For winds over 5 knots a second person maybe required to assist for the
• Mounting Bracket Set (2 Brackets) – Refer to installation guide
• 10 x 225mm Galv Tent Pegs
• 2 x Quick Release straps
• Peg Bag
• 5 x SWA005 – Upright poles (Additional for larger awnings)
• 1 x SWA007 & 1 x SWA008 (Spreader Rails) (Additional for larger awnings)
• Pole Bag
(STANDARD).
product
following steps, if the tie down straps are not used **
Contents
Advertisement
Table of Contents
Related Manuals for SUPA PEG SUPA-WING AWNING STANDARD
Summary of Contents for SUPA PEG SUPA-WING AWNING STANDARD
- Page 1 SUPA PEG A U S T R A L I A SUPA-WING AWNING (STANDARD) Awning Setup/ Fold Away Instructions Thank you for your purchase of the Australian made and designed SUPA-WING AWNING (STANDARD). Please follow these few simple step by step instructions to make setting up your SUPA-WING AWNING (STANDARD) simple to use and to improve the life span of the product **PLEASE NOTE** For winds over 5 knots a second person maybe required to assist for the following steps, if the tie down straps are not used ** Contents • Mounting Bracket Set (2 Brackets) – Refer to installation guide • 10 x 225mm Galv Tent Pegs • 2 x Quick Release straps • Peg Bag • 5 x SWA005 – Upright poles (Additional for larger awnings) • 1 x SWA007 & 1 x SWA008 (Spreader Rails) (Additional for larger awnings) • Pole Bag...
- Page 2 SUPA PEG A U S T R A L I A SUPA-WING AWNING (STANDARD) : Setup 1. Park at the proposed site you wish to setup, make sure you have enough clearance on the side and rear of the vehicle for the awning to fold out and expand 2. The Site should be level or close to it. If on a slight slope, face the awning down the slope as to prevent any wind getting under the awning causing it to lift 3. Remove the supplied pole kit from the vehicle, pull out all poles, ropes, pegs and hammer 4. Extend out all the aluminium bent spigot twist lock poles to similar heights 5. Roughly place all the aluminium poles around the vehicle to a position where they can be easily reached while setting up 6. Tie the short strap to the drivers side front roof rack and bring to the back of the vehicle (or the rope can be pegged down at the rear of the vehicle)
- Page 3 SUPA PEG A U S T R A L I A 7. Peg down the long strap at the front of the vehicle on the passenger side to where roughly the awning will extend to (an alternative option is to attach the Strap to your front bull bar if one is available) **PLEASE NOTE** For winds over 5 knots a second person maybe required to assist for the following steps, if the tie down straps are not used ** 8. Unzip the vinyl bag and fold the bag over the awning 9. Undo all Velcro straps holding the canvas and aluminium arms (remembering to support the arms once unstrapped) 10. Roll the canvas out, holding the outside arm, slowly fold the awning around to 270º (*** second person will need to hold the middle arm to prevent the awning from lifting in windy conditions) 11. Once the SUPA-WING STANDARD is folded out, insert an aluminium bent spigot pole into the arm on the rear of the vehicle, making sure to fold back the canvas to insert the spigot through the plastic end insert on the arm, then fold the canvas over and feed the spigot through the eyelet on the canvas 12. Put the strap (the one attached to the roof rack) over the spigot on the rear of the awning and tie off loosely 13.
- Page 4 SUPA PEG A U S T R A L I A 14. Attach the pegged down strap to the front awning pole and loosely tighten 15. Now go along and insert the rest of the aluminium bent spigot poles into the rest of the arms as per the first two poles 16. Once all the poles are in place, adjust the height and square up the awning. If being left unattended or it is raining, lower the pole height to allow for water run off. 17. Tighten up both tie down straps a. (2.5m, 3m or 3.5m versions only) Connect the bird beak spreader pole to the 1...
- Page 5 SUPA PEG A U S T R A L I A SUPA-WING STANDARD Wall Installation **Please Note: two people are required to pack away in winds over 5 knots** 1. Attach the spreader rail between the 2 poles where you want your wall to be located by simply pushing the opening at each end of the spreader on to the spigot between the base of the spigot and the nylon end. This can be done after the awning has been erected 2. Clip the wall to the spreader rail from the outside. 3. Once the wall is clipped on, roll it down for privacy or extra shade...
- Page 6 SUPA PEG A U S T R A L I A SUPA-WING AWNING (STANDARD) : Packing Away **PLEASE NOTE** For winds over 5 knots a second person maybe required to assist for the following steps, if the tie down straps are not used ** 1. In reverse sequence repeat steps 19 through to 14 as per setup 2. Fold back the front arm into the aluminium extrusion, making sure to fold the canvas over the arm to allow it to fold away smoothly 3. Undo the rear rope and take out the poles fold the wing together, making sure to pull the arms toward the front to square up the rear bracket as to fit neatly in the bag 4. Tie off the awning arms with the front Velcro strap 5. Flatten out the canvas and square off 6. Roll up the canvas as tightly as possible and tie off with the remaining Velcro straps, undo the front Velcro strap and retie it to include the canvas and awning arms 7. Fold over the vinyl bag and zip it up, pack away poles, pegs ropes and hammer in the canvas pole bag And you’re done! Don’t forget to clean up your site of any rubbish or debris to help keep this country beautiful. If the awning is packed up damp. Be sure to put up again and soon as there is dry weather to dry the canvas out. Any abuse or neglect of awning can result in voiding the Warranty.
