DAEWOO ELECTRONICS MINI Service Manual page 43

NO PART NAME
14 Power Cord AS
15 HEATER DRY
16 SWITCH THERMOSTAT
HARNESS SUB HEATER
17
DRY
18 UNIT FAN MOTOR AS
19 FUSE TEMPERATURE
20 THERMISTOR DRY
Fuse (M-PCB)
Fuse (M-PCB)
21
Fuse (M-PCB)
Fuse (M-PCB)
X-Capacitor
X-Capacitor
22
X-Capacitor
X-Capacitor
Relay
Relay
Relay
23
Relay
Relay
Relay
24 Transformer
Varistor
25
Varistor
Photo coupler
Photo coupler
26
Photo coupler
Photo coupler
PCB
PCB
PCB
27 PCB
PCB
PCB
PCB
※ MINI 1.0: D-CV701PCNCX, D-CV701MWNCX, D-CV701JCNCX, D-CV701GGNCX, D-CV701GCNCX,
D-CV701AWNCX, D-CV701, CHINA, ODW-JDM883, D-CV701SCNCX, D-CV701TCNCX
D-CV701TCNCX, D-CV701WWNCX, D-CV701PCNCX
※ MINI 2.0: MINI 1.5, CHINA, ODW30-999B, MINI 1.5, CHINA, DWM30-999PG, ODW30-999G
MINI 2.0_COMBO,WASH_영문_SM.indd 42
PART CODE
66112-0000808-00 Mini2 CHINA
66112-0000807-00 Mini2 KOREA
66112-0000809-00 Mini2 CHILE
66112-0000810-00 Mini2 MEXICO
66127-0002200-00 220V INCOLOY800, Ø6.6: 1050W
66148-0006100 115℃/130℃ (On/Off)
UL1015 AWG18 90MM #250 FLAG,
66126-0022602-00
HEATER DRY-THERMOSTAT
66149-0008606 DR7806SSWC/W CCW, 17.5Vdc, 1.6A, 28W Gyeong Nam Nakagawa
66122-0000501 Thermal Fuse : 128℃
361AAAAC00 R40=26.065㏀, R90=4.4278㏀
40504-0002700 250 V, 8 A
- 250 V, 5 A
40504-0002700 250 V, 8 A
- 250 V, 5 A
40C01-0014300 PCX2 335M, 275 V, 0.1 ㎌
40C01-0014300 CMPP, 275 V, 0.1 ㎌
- CMPP, 275 V, 0.68 ㎌
- PCX2 335M, 275 V, 0.68 ㎌
40507-0000300 GT-1A-12D, 250 V, 25 A
40507-0000300 SFK-112DM, 250 V, 20 A
40507-0000300 HF160F, 250 V, 25 A
40507-0000600 SMIH-S-112LM, 250 V, 16 A
40507-0000600 OMIH-SH-112LM, 250 V, 16 A
40507-0000600 GA-1A-12LH, 250 V, 16 A
40512-0017800, Input : DC 310 V, output :
40512-0017800
DC 5 V, 15 V, Class E
40D09-0000700 SVC561-14, 560 V, 50 A
40D09-0002300 SVC681-14, 680 V, 50 A
40101-0025400 EL817C, 5 kV
40101-0025400 PC17K1, 5 kV
40101-0025400 PC-817, 5 kV
40101-0025400 LTV-817B, 5 kV
40302-1093300 KB-3151C, V-0
40302-1093200 KB-6160C, V-0
40302-1112900 KB-5150&, V-0
- CCP-3400, V-0
- CCP-508, V-0
- ETL-XPC-204, V-0
- ETL-CEM1-502, V-0
42
SPEC MAKER
Longwell/
NION Electronics
Haiyan Donghai
Pacific CONTROLS
DongYang Electronics
DongYang Electronics
SST
ORISEL
ORISEL
Littel Fuse
Littel Fuse
Cowell Fashion
SUNGHO
SUNGHO
Cowell Fashion
GOLDEN
SANYOU
HONGFA
SANYOU
TYCO
GOLDEN
TDK
삼화콘덴서
삼화콘덴서
에버라이트
고덴시
SHARP
LITE ON
KING BOARD
KING BOARD
KING BOARD
Chang chun
Chang chun
Eternal
Eternal
REMARK
